Design and Specifications subject to change without notice.
This unit cannot be connected to a digital preamplifier or an equalizer.
XR-CA430X
FM/AM Cassette Car Stereo
Note
Tape track 4-track 2-channel stereo
ow and flutter 0.08 % ( RMS)
Frequency response 30 18,000 Hz
Signal-to-noise ratio Cassette type
TYPE II, IV 61 dB
TYPE I 58 dB
General
Cassette Player Section
FM
Tuning range 87.5 107.9 MHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz
Usable sensitivity 11 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 65 dB (stereo), 68 dB (mono)
Harmonic distortion at 1 kHz 0.7 % (stereo), 0.5 % (mono)
Separation 33 dB at 1 kHz
Frequency response 30 15,000 Hz
AM
Tuning range 530 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
Outputs Speaker outputs
Speaker impedance 4 8 ohms
Maximum power output 50 × 4 (at 4 ohms)
Outputs Audio outputs (1)
Power antenna relay control terminal
Power amplifier control terminal
Inputs BUS control input terminal
BUS audio input terminal
Antenna input terminal
Tone controls Bass ±10 dB at 20 Hz
Treble ±10 dB at 20 kHz
Power requirements 12 V DC car battery (negative ground)
Dimensions Approx. 178 × 50 × 178mm
(7 1/8 × 2 × 7 1/8 in.) (w/h/d)
Mounting dimensions Approx. 182 × 53 × 161mm
(7 1/4 × 2 1/8 × 6 3/8 in.) (w/h/d)
Mass Approx. 1.2 kg (2 lb 10 oz)
Supplied accessories Parts for installation and connections (1 set)
Front panel case (1)
Power Amplifier Section
2002 SONY MOBILE
PRODUCT GUIDE
Audio Power Specifications
Tuner Section
CD/MD Control
Detachable Faceplate
Xplod® Power: 50 x 4
MBP (My Best Position)
Full Logic cassette mechanism
9-track AMS, Repeat, Blank Skip,
ATA activation
18FM + 12AM memory presets
Active Display w/Demo Mode
13-segment LCD
Indicates step-up
CD TEXT®
XM Ready
Rear Preout
D-Bass
SSIR-EX Tuner
Quartz clock
Best tuning memory
-
PO ER OUTPUT AND TOTAL HARMONIC DISTORTION
23 watts per channel minimum continuous average power into 4 ohms, 4 channels
driven from 20 Hz to 20 kHz with no more than 5 % total harmonic distortion.
Plug shown with wires facing viewer.
Pin Number ire Color Description
1 hite Left front +
2 Green Left rear +
3 Purple Right rear +
4 Gray Right front +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 hite/black Left front -
10 Green/black Left rear -
11 Purple/black Right rear -
12 Gray/black Right front -
13 Sky blue ATT
14
15
16 Yellow Battery
Harness Plug Configuration
16
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
