CD Clock Radio
Operating Instructions
ICF-CD833
Owner's Record
The model number and serial number are located at the bottom.
Record the serial number in the space provided below. Refer to these
numbers whenever you call upon your Sony dealer regarding this product.
Model No. ICF-CD833 Serial No.
Sony Corporation © 1995 Printed in Malaysia

To prevent fire or shock
hazard, do not expose the
unit to rain or moisture.
AISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK}.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the
$ user to the presence of uninsulated
“dangerous voltage” within the
product's enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
INFORMATION
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver. '
- Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
Before You Begin
Thank you for choosing the Sony CD clock radio!
The CD clock radio will give you many hours of
reliable service and listening pleasure.
Before operating the CD clock radio, please read
these instructions thoroughly and retain them for
future reference.
Features
e You can wake up to CD, radio and buzzer
with the snooze function.
You can wake up to any track on CD.
The digital tuner with 5 random memory
presets.
+ A powerful bass is produced with the MEGA
BASS sound system.
* Sleep timer function turns off the CD and
radio 90, 60, 30, or 15 minutes later.
Dual alarm
One bit over sampling and digital filter—
Signal process frequency of 1 bit the reference
frequency means CD playback with less
distortion.
Dual D/A (digital /analogue) conversion
system—High-fidelity CD playback with less
phase shift is accomplished by the dual
converter which works for the left and right
channels independently.
Three-inch disc can be played without an
adaptor.

ge
‘TRANSISTOR
RADIO
LIMITED WARRANTY
