VAIO®QuickStart
PCV-J100

2
Contents
Welcome.......................................................3
Features .......................................................................3
Unpacking Your Computer .........................................4
Computer and Supplied Accessories ...................................4
Manuals................................................................................4
Recovery CDs ......................................................................5
Other ....................................................................................5
Setting Up Your Computer .........................................6
Using the Wheel Mouse.....................................................11
Registering Your Computer .....................12
Using the Standby Function ......................................13
Standby Mode Indicators ...................................................14
Shutting Down Your Computer ................................15
Using the Power Button on the Keyboard .........................15
About the Power Switch ....................................................15
About the Software on Your Computer...16

Features
3
Welcome
Congratulations on your purchase of the Sony VAIO®computer! Your new, high-
performance multimedia computer combines state-of-the-art computer
functionality with the latest audio/video and information technology convergence
features.
Features
 i.LINK®(IEEE1394) — two built-in i.LINK ports provide you with rear
digital connection capability. The i.LINK name and logo identify a high-
speed communication interface (IEEE1394) with which you can easily
connect digital camcorders.
 Digital Media Park™—this suite of Sony original applications includes
PictureGear,™Smart Capture, DVgate,™and Media Bar.™Using the
i.LINK connector, you can capture, view, and share both still and video
images, then catalog everything for fast and easy storage and retrieval.
 Exceptional performance —your computer includes an Intel®processor
and a high-speed V.90-compatible data/fax modem.*
 CD-RW drive —this drive is the ideal solution for making backups and
archiving data, with the ability to store up to 650 MB†of removable,
rewritable storage on a single rewritable CD. Save your movies to CD-R or
CD-RW media and share videos and images with family and friends.
 VA I O S m a r t ™Keyboard —this PS/2®keyboard has programmable
shortcut buttons for launching your favorite programs or accessing the
Internet.
 Sony audio and video quality —take advantage of today’s advanced
multimedia applications, games, and entertainment software with Sony’s
high-fidelity audio system (Yamaha®AC-XG), high-powered 3D graphics
(Direct AGP), and “Sony-Tuned”MPEG digital video playback.
 Microsoft®Windows®98 Second Edition operating system —your
system includes the consumer operating system from Microsoft.
* Actual upload and download speeds may vary due to line conditions, ISP support, and gov-
ernment regulations.
†530 MB after formatting with Direct CD.™

VAIO PCV-J100 QuickStart
4
 Preinstalled software titles —all the software on your computer is
preinstalled, configured, and ready for you to use right out of the box.
 Communications —access popular online services, browse the Internet,
send faxes, and more.
Unpacking Your Computer
Computer and Supplied Accessories
Manuals
 VAIO QuickStart — information on unpacking and setting up your
computer, last-minute supplementary information and software information.
 VAIO User Guide — features and specifications of your computer. It also
includes information on the applications included with your system and how
to contact software vendors, and solve common problems.
 Microsoft®Windows®98 Second Edition Getting Started —explains how
to use the basic features of the Windows®operating system.
PCV-J100 computer and accessories
Power cable
Phone cable
Display (sold separately)
Keyboard
Mouse
System unit
Speakers

Unpacking Your Computer
5
Recovery CDs
 System Recovery CD(s) —allows you to restore the software titles that
shipped with your computer if they become corrupted or are erased
accidentally. It can be used only to restore the hard disk of the Sony
computer you purchased.
 Application Recovery CD(s) —allows you to reinstall individual
applications or device drivers if they are corrupted or accidentally erased.
Other
 Setting up your VAIO Computer (poster)
 Packet containing special product offers

VAIO PCV-J100 QuickStart
6
Setting Up Your Computer
This section illustrates how to set up and install your computer and peripherals.
Connecting a Display:
1Plug the display cable into the MONITOR connector.
2If necessary, plug the display cord into the rear of the display.
PCV-J100 connecting a display
 Install your equipment so that you can easily reach the outlet in the event of an
emergency.

Setting Up Your Computer
7
Connecting the Speakers:
1Plug the cable attached to the right speaker into the R OUT connector on the
back of the left speaker.
2Plug one end of the speaker cable into the INPUT connector on the back of
the left speaker. Plug the other end into the HEADPHONES connector.
3Plug the power cord into the DC IN connector on the back of the left speaker
and plug the other end into a grounded AC wall outlet or power strip.
PCV-J100 connecting speakers

VAIO PCV-J100 QuickStart
8
Connecting the keyboard and mouse:
1Plug the keyboard cable into the PS/2®KEYBOARD connector on the back
of the computer.
2Plug the mouse cable into the MOUSE connector.
PCV-J100 connecting the keyboard and mouse

Setting Up Your Computer
9
Connecting the phone line and power cords:
1Unplug your phone from the wall jack, and plug it into the TELEPHONE
jack on the computer.
2Plug the phone cable that came with your computer into the LINE jack on
the computer, and then plug the other end of the cable into the wall jack.
3Plug the power cord into the back of the computer.
4Plug both the display and power cords into a grounded AC wall outlet or a
power strip.
PCV-J100 connecting the phone line and power cords

VAIO PCV-J100 QuickStart
10
Turning on your VAIO Computer:
1Press the power switch on the display to turn on the power.
2Press the power switch on the computer to turn on the power.
Turning on your PCV-J100 computer
 You may sign up for Internet access with a Sony preferred Internet service provider.

Setting Up Your Computer
11
Using the Wheel Mouse
For information on the Wheel Mouse, see MouseWare Help:
1From the Start menu, select Programs > MouseWare.
2Click MouseWare Help.
The MouseWare Help program will launch.
To set up the mouse for left-handed use:
1Click My Computer on your desktop.
2Click Control Panel, and then Click Mouse.
The Mouse Properties dialog box appears.
3In the Quick Setup tab, click Device Setup.
4In the Device Setup Wizard dialog box, click Next.
5Select the radio button next to “Left side of the keyboard.”
6Click Next three times, and then click Finish.
7Click Apply.

VAIO PCV-J100 QuickStart
12
Registering Your Computer
Take advantage of Sony’s commitment to quality customer support and receive
these benefits by registering your computer:
 Sony Customer Support —Talk to a Support Representative to
troubleshoot problems you may be having with your computer.
 Limited warranty —Protect your investment. See Warranty Card for more
details.
If you did not already register when you first turned on your computer, follow
these steps to use the computer online registration service.
1Make sure your computer is connected to a phone line.
2Click the registration icon on the VAIO desktop.
3Enter the information requested on the first online registration form.
4Click the Next button to advance to the next form.
5Complete the remaining forms by clicking the Next button each time you
complete a form.
6The computer automatically transfers your registration information using
your built-in modem and a toll-free telephone number or a local number.
 Press the tab key to move from box to box.
 You may sign up for Internet access with a Sony preferred Internet Service
Provider.

Using the Standby Function
13
Using the Standby Function
When you are finished using your computer, you can put it in standby mode
rather than turn it off completely. Putting the computer in standby mode saves
energy and allows a quick return to normal computer use. You can use any of the
following three methods for activating the standby mode.
To set the computer in standby mode using the Standby key:
1Save your work, close all applications, and close your dial-up Internet
connection, if applicable.
2Press the (Standby) key on the top of the keyboard.
The computer goes into standby mode.
To set the computer in standby mode using the Windows taskbar:
1Save your work, close all applications, and close your dial-up Internet
connection, if applicable.
2From the Start menu on the Windows taskbar, select Shut Down.
3Select Standby.
4Click OK.
The computer goes into standby mode.
To let the computer go into standby mode automatically:
1Save your work, close all applications, and close your dial-up Internet
connection, if applicable.
2Click My Computer on your desktop.
3Click Control Panel.
 You can leave the Windows operating system running.
 You can leave the Windows operating system running.
 You can leave the Windows operating system running.

VAIO PCV-J100 QuickStart
14
4Click Power Management.
5On the Power Schemes tab, select an option in the Power schemes
drop-down list.
6Choose settings for the power scheme you have selected.
7Type in a name.
8Click OK.
9Click Apply to finalize your power settings.
The computer will go into standby mode according to your settings.
To resume from standby mode:
There are four ways to bring your computer back from the standby mode:
 Press the space bar on your keyboard.
 Click the left mouse button.
 Momentarily press the power button on your computer.
 Press Alt+Tab.
Standby Mode Indicators
You can tell which mode the computer is in by the color of the power indicator
light.
 To save the settings under a name that is not offered in the Power schemes
pulldown menu, choose your settings and then click Save As.
 If the display does not return from standby when you press the (Standby) button,
your system may be in video standby mode. Press the space bar on the keyboard to
return from video standby.
Color Mode
Amber Computer is in standby mode.
Green Computer is in normal mode, ready to use.
No color Computer is turned off.

Shutting Down Your Computer
15
Shutting Down Your Computer
When you are ready to turn off your computer for an extended period of time, use
the following procedure to shut down the computer.
To shut down your computer
1From the Start menu, select Shut Down to display the Shut Down Windows
dialog box.
2Select the Shut Down option.
3Click OK to complete the shutdown process.
4Wait for your computer to turn off automatically—the power indicator light
turns off.
5Turn off any peripherals connected to your computer.
About the Power Switch
If your system “locks up”or “crashes,”press and hold the power switch for more
than four seconds to force your system to power off. You may need to repeat this
procedure.
!To avoid loss of data, do not use the power switch to shut down the computer.
 If you plan to shut down your computer for a short period of time, you may want to
use standby mode instead.
 Respond to any prompts about saving documents.

VAIO PCV-J100 QuickStart
16
About the Software on Your
Computer
Yo u r VAI O ®computer is ready to help you work, play, learn, and communicate
as soon as you turn it on. This section provides an overview of the software titles
inlcuded with your computer.
Adobe®Acrobat®Reader
Adobe Systems Incorporated
Acrobat Reader software allows you to view, navigate, and print electronic documents in
Adobe’s Portable Document Format (PDF), an open file format that is intended to preserve
the fidelity of documents created on all major computer platforms.
Adobe®PhotoDeluxe®
Adobe Systems Incorporated
Create amazing photo effects with Adobe PhotoDeluxe. Without learning complex
software, you can enhance, restore, and be creative with your photos. Includes built-in
guided activities, stock photos, clip art, and templates to assist you.
America Online®
America Online
America Online is the world's most popular Internet online service. Stay in touch with
family and friends with Easy-to-Use E-mail, manage your personal finances, get the latest
news and sports scores, and chat with thousands of others who share your interests.
AT&T WorldNet®Service
AT&T
Fast, reliable Internet access from AT&T WorldNet Service. AT&T WorldNet Service
provides Web-based e-mail, a personalized start page from Excite, easy access to the
Excite search engine, free Web pages, online and live agent technical support, instant
messaging, and special shopping discounts at Market Square.
CompuServe®2000
CompuServe Interactive Services
The all-new CompuServe 2000 delivers a powerful tool for Internet users who want
serious and timely information, in-depth research, and professional communities backed
by state-of-the-art technologies, including high-speed access and powerful e-mail
messaging.

17
Digital Media Bar™
Sony Electronics
Media Bar is your all-in-one solution for audio/video playback.
Direct CD™
Adaptec
DirectCD is software that allows you to drag and drop files directly to your CD-RW drive.
In other words, you can save, rename, move or “delete”files right on your CD-RW as if it
were a giant floppy disk.
DVgate™
Sony Electronics
Sony Electronics DVgate makes editing digital video easy and fun.
EarthLink TotalAccess™
EarthLink Network, Inc.
An Internet Service Provider that supplies access, information, and assistance to its
customers, introducing them to the Internet. Member benefits include e-mail, newsgroups,
a Personal Start Page, a free 6 MB Web site, a member magazine, and 24-hour technical
support.
Easy CD Creator™
Adaptec
Easy CD Creator lets you make your own data, audio and multimedia CDs. You can back
up your important files to CD, and read them back on standard CD-ROM drives. Create
your own audio CDs right on your desktop, and play them back on your home or car stereo
CD player. You can make your own personalized color jewel case inserts with custom text
and graphics. You can even make backup copies of your existing CDs. The easy CD
Creator Wizard makes creating your own custom CDs a simple process.
McAfee’s VirusScan®
Network Associates, Inc.
Protect your computer from viruses. VirusScan can detect viruses from floppy disks,
Internet downloads, e-mail attachments, intranets, shared files, CD-ROMs, and online
services.
Microsoft®Internet Explorer
Microsoft Corporation
Internet Explorer delivers the Web the way you want it. It's safe, easy to use, and you can
personalize how you access the Web. Outlook Express and other tools in Internet Explorer
also help you have a great experience when you are on the Web!
About the Software on Your Computer

VAIO PCV-J100 QuickStart
18
Microsoft®Outlook®Express
Microsoft Corporation
Outlook Express, the messaging tool that takes your e-mail and newsgroup
communications to new heights! Outlook Express is easy to set up and use, and provides
you with secure, personalized, and complete features that make creating, sending, and
reading your e-mail a more rich and dynamic experience.
Netscape Communicator®
Netscape Communications
Netscape Communicator is the all-in-one Internet tool that makes it easy to browse the
Web, send Internet e-mail, chat, read newsgroups, and compose great Web documents.
PictureGear
Sony Electronics
This image management software displays images from your hard drive, a Sony digital
still camera, or a Sony Mavica camera. The images appear in a convenient light-table
format, so that you can easily view the contents of an entire folder.
PhotoPrinter™2000 Pro
ArcSoft
PhotoPrinter Pro is an easy-to-use, advanced printing program that lets users quickly
layout multiple images in multiple sizes on a single sheet of paper. PhotoPrinter Pro offers
a wide selection of templates including landscape, portrait, free style, mixed sizes, custom
templates and more. The application includes enhancement tools and special effects for
improving photos while giving users the ability to add text to any image.
Prodigy Internet™
Prodigy Communications Corporation
An Internet service that helps you find what you need online faster and smarter. Prodigy
delivers powerful online content, such as sports scores, stock quotes, news, and easy
access to Excite™, plus a personal e-mail account and quality customer service—all at a
competitive price.
Quicken®Basic
Intuit, Inc.
Quicken is the fastest, easiest way to organize your finances. Quicken works just like your
checkbook, so it's easy to learn and use. Quicken manages all of your finances, bank
accounts, credit cards, investments, and loans. You can even pay your bills online.

19
Smart Capture
Sony Electronics
By managing the i.LINK connection between your computer and a camera with an i.LINK
interface, Smart Capture enables you to capture and compress video or still images that
you can save or share via e-mail. A smart solution to computer, digital audio/video, and
network convergence.
Smart Connect
Sony Electronics
Smart Connect allows you to use an i.LINK cable to connect your VAIO computer to
another VAIO computer that supports Smart Connect. You can then use one computer to
copy, delete, and edit files on the other computer. You can also print from a printer
attached to either computer.
VAIO Action Setup
Sony Electronics Inc.
VAIO Action Setup manages the settings for your computer's Shortcut keys and i.LINK
interface.
WinFax™Basic Edition
Symantec Corporation
WinFax Basic Edition incorporates an easy-to-use interface that allows you to send and
receive faxes easily. Upgrade to WinFax Pro to receive additional features.
About the Software on Your Computer
