Sony a7 RV User guide

ILCE-7RM5
5-043-817-11(1)
\\Win-473\camera\CX89200(GL)_SG\03_Compose\02_EN\5043817111\5043817111ILCE7RM5AF1\EN1AF1.indd
DTP data saved: 2022/06/23 19:51
PDF file created: 2022/06/23 19:52
2 Insert the battery pack into the camera.
• Open the battery cover, and then insert the
battery pack while pressing the lock lever.
Lock lever
Inserting a memory card into the camera
You can use CFexpress Type A memory cards and SD memory cards with this
camera.
Slot 1 Slot 2
Open the memory card cover and insert the memory card into Slot 1.
• Both Slot 1 and Slot 2 support CFexpress Type A memory cards and SD memory
cards.
• Insert a CFexpress Type A memory card with the label facing the monitor, and an
SD memory card with the terminal facing the monitor. Insert the card until it clicks
into place.
• You can change which memory card slot to use by selecting MENU 
(Shooting) [Media] [ Rec. Media Settings] [ Recording Media] or
[ Recording Media].
The Slot 1 is used in the default settings.
Hint
• When you use a memory card with the camera for the first time, it is recommended that you
format the card on the camera for more stable performance of the memory card.
Attaching a lens
1 Remove the body cap from the camera and
the rear lens cap from the rear of the lens.
2 Mount the lens by aligning the two white
index marks (mounting indexes) on the lens
and camera.
3 While pushing the lens lightly toward the
camera, turn the lens slowly in the direction
of the arrow until it clicks into the locked
position.
Mounting indexes
Turning the power on and setting the language and area
ON/OFF (Power)
switch Control wheel
Select items : /////
Confirm : Center button
1 Set the ON/OFF (Power) switch to “ON” to turn on the camera.
2 Select the desired language and then press the center of the control
wheel.
• The privacy notice screen will appear. Read the privacy notice regarding
biometrics by opening the link using your smartphone, etc.
3 Press the center of the control wheel.
4 Press the top/bottom/left/right side of the control wheel to select the
area where the camera will be used, and then press the center.
5 Follow the instructions on the screen to apply the initial settings.
Setting the date and time
1 Press the MENU button to display the menu
screen.
MENU button
Control wheel
2 Press the top/bottom/left/right side of
the control wheel to select (Setup) 
[Area/Date] [Area/Date/Time Setting] 
[Date/Time], and then press the center of the
control wheel.
3 Set the date and time, and then press the
center.
Shooting
Shooting still images
1 Turn and set the Still/Movie/S&Q dial to
(Still) while pressing the lock release button
on the front of the Still/Movie/S&Q dial.
2 Turn the mode dial while pressing the mode
dial lock release button in the center of
the mode dial, and then select the desired
shooting mode.
3 Press the shutter button halfway down to
focus.
4 Press the shutter button all the way down.
Shutter button
Still/Movie/S&Q dial
Mode dial
Shooting movies
1 Turn and set the Still/Movie/S&Q dial to
(Movie) while pressing the lock release
button on the front of the Still/Movie/S&Q
dial.
2 Turn the mode dial while pressing the mode
dial lock release button in the center of
the mode dial, and then select the desired
shooting mode.
3 Press the MOVIE (Movie) button to start
recording.
4 Press the MOVIE (Movie) button again to stop
recording.
MOVIE (Movie)
button
Mode dial
Still/Movie/S&Q dial
Hint
• The start/stop movie recording function is assigned to the MOVIE (Movie) button
in the default settings. Even without switching shooting modes in Step 1, you
can start movie recording from still image shooting mode by pressing the MOVIE
(Movie) button.
Preparing to use the
smartphone application
By connecting the camera to a smartphone using the smartphone application
Imaging Edge Mobile, you can transfer images to the smartphone and view images
stored on the camera on the smartphone.
Install Imaging Edge Mobile from the following support page.
https://www.sony.net/iem/
Update to the latest version of Imaging Edge Mobile.
Interchangeable Lens Digital Camera
Startup Guide
5-043-817-11(1)
E-mount
ILCE-7RM5
©2022 Sony Corporation Printed in Thailand
Preparations
Checking the supplied items
The number in parentheses indicates the number of pieces.
• Camera (1)
• Battery charger (1)
• Power cord (mains lead) (1)*
(supplied in some countries/regions)
* Multiple power cords may be
supplied with this equipment. Use the
appropriate one that matches your
country/region. See “Notes on use.”
• Rechargeable battery pack NP-FZ100
(1)
• USB Type-C® cable (1)
• Shoulder strap (1)
• Body cap (1) (attached to the camera)
• Cable protector (1)
• Shoe cap (1) (attached to the camera)
• Eyepiece cup (1) (attached to the
camera)
• Startup Guide (this manual) (1)
• Reference Guide (1)
Preparing the battery pack
1 Insert the battery pack into the battery
charger, and connect it to a wall outlet (wall
socket) using the power cord (supplied).
• Place the battery pack on the battery charger in
the direction of . Slide the battery pack in the
direction of the arrow as far as it will go.
• When charging starts, the CHARGE lamp on the
battery charger will light up. When charging is
finished, the CHARGE lamp and all indicators turn
off.
CHARGE lamp
To a wall outlet
(wall socket)
About the manual for this camera
https://rd1.sony.net/help/ilc/2230/h_zz/
“Help Guide” (Web manual)
ILCE-7RM5 Help Guide
This guide describes the necessary preparations to start using the
product, basic operations, etc. For details, refer to the “Help Guide”
(web manual).
We use environmentally conscious packaging materials
Environmentally conscious packaging materials were used for the camera and
supplied accessories.
Note the following due to the characteristics of the packaging materials.
• Powder, etc. from the packaging materials may adhere to the camera or
supplied accessories. In this case, remove it with a commercially available
blower or cleaning paper before use.
• The packaging materials will deteriorate with continuous use. Be careful when
carrying the product by the packaging.

ILCE-7RM5
5-043-817-11(1)
\\Win-473\camera\CX89200(GL)_SG\03_Compose\02_EN\5043817111\5043817111ILCE7RM5AF1\EN1AF1.indd
DTP data saved: 2022/06/23 19:51
PDF file created: 2022/06/23 19:52
For Customers in Indonesia
IEEE802.11b/g/n 2 400 MHz
Bluetooth 2 400 MHz
For customers who purchased their camera from a store in
Japan that caters to tourists
Note
Some certification marks for standards supported by the camera can be confirmed on the screen
of the camera.
Select MENU (Setup) [Setup Option] [Certification Logo].
Specifications
Camera
[System]
Camera Type:
Interchangeable Lens Digital Camera
Lens: Sony E-mount lens
[Image sensor]
Image format: 35mm full frame (35.7 mm ×
23.8 mm), CMOS image sensor
Effective pixel number of camera:
Approx. 61 000 000 pixels
Total pixel number of camera:
Approx. 62 500 000 pixels
[Electronic Viewfinder]
Type: 1.6 cm (0.64 type)
Electronic Viewfinder
[Monitor]
8.0 cm (3.2 type) TFT drive, touch panel
[General]
Rated input: 7.2V , 4.5W
Operating temperature:
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature:
–20 °C to 55 °C (–4 °F to 131 °F)
Dimensions (W/H/D) (Approx.):
131.3 × 96.9 × 82.4mm
131.3 × 96.9 × 72.3mm
(from grip to monitor)
51/4 × 37/8 × 31/4in.
51/4 × 37/8 × 27/8in.
(from grip to monitor)
Mass (Approx.):
723g (1lb 9.6oz) (including battery
pack, SD Card)
[Wireless LAN]
WW282174 (see name plate on the bottom
of camera)
Supported format: IEEE802.11a/b/g/n/ac
Frequency band: 2.4GHz/5GHz
Security: WEP/WPA-PSK/WPA2-PSK
Connection method:
Wi-Fi Protected Setup™ (WPS)/Manual
Access method: Infrastructure mode
WW529928 (see name plate on the bottom
of camera)
Supported format: IEEE 802.11 b/g/n
Frequency band: 2.4 GHz
Security: WEP/WPA-PSK/WPA2-PSK
Connection method:
Wi-Fi Protected Setup™ (WPS)/Manual
Access method: Infrastructure mode
Battery charger BC-QZ1/BC-QZ1 T
Rated input:
100 - 240V , 50/60Hz, 0.38A
Rated output: 8.4V , 1.6A
Rechargeable battery pack
NP-FZ100
Rated voltage: 7.2V
Design and specifications are subject to
change without notice.
Trademarks
• is a trademark of Sony Group Corporation.
• USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
• Wi-Fi, the Wi-Fi logo and Wi-Fi Protected Setup are registered trademarks or trademarks of the
Wi-Fi Alliance.
• The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Sony Group Corporation and its subsidiaries is under license.
• QR Code is a trademark of Denso Wave Inc.
• In addition, system and product names used in this manual are, in general, trademarks or
registered trademarks of their respective developers or manufacturers. However, the ™ or 
marks may not be used in all cases in this manual.
Connecting the camera to a smartphone
To use Imaging Edge Mobile, you need to pair the camera with your smartphone.
Follow the steps below to perform pairing.
1 On the camera, select MENU (Network) [Smartphone Connect]
[Smartphone Regist.].
2 Following the instructions on the screen, set [Bluetooth Function] to [On].
The pairing screen will appear.
• If [Bluetooth Function] is already set correctly, the pairing screen will be
displayed immediately.
3 Launch Imaging Edge Mobile on your smartphone and follow the on-
screen instructions to perform pairing.
For details on the pairing method, refer to the following Help Guide (Web
manual) URL:
https://rd1.sony.net/help/ilc/2230_pairing/h_zz/
Note
• The operation method and screen display of the application may change without
notice due to future version upgrades.
• If you performed pairing after setting the date and time, you do not need to
perform this step.
Notes on use
Refer to “Precautions” in the “Help Guide” as well.
Notes on handling the product
• This camera is designed to be dust-and moisture-resistant, but is not waterproof or dust-proof.
• Do not leave the lens or the viewfinder exposed to a strong light source such as sunlight.
Because of the lens’s condensing function, doing so may cause smoke, fire, or a malfunction
inside the camera body or the lens. If you have to leave the camera exposed to a light source
such as sunlight, attach the lens cap to the lens.
• If sunlight or other strong light enters the camera through the lens, it may focus inside the
camera and cause smoke or fire. Attach the lens cap when storing the camera. When shooting
with backlighting, keep the sun sufficiently far away from the angle of view. Even if it is slightly
away from the angle of view, smoke or fire may still occur.
• Do not directly expose the lens or the viewfinder to beams such as laser beams. This may
damage the image sensor or the inside of the viewfinder and cause the camera to malfunction.
• Do not look at sunlight or a strong light source through the lens when it is detached. This may
result in unrecoverable damage to the eyes or cause a malfunction.
• This camera (including accessories) has magnet(s) which may interfere with pacemakers,
programmable shunt valves for hydrocephalus treatment, or other medical devices. Do not
place this camera close to persons who use such medical devices. Consult your doctor before
using this camera if you use any such medical device.
• Increase the volume gradually. Sudden loud noises can damage your ears. Be especially careful
when listening to headphones.
• Do not leave the camera, the supplied accessories, or memory cards within the reach of infants.
They may be accidentally swallowed. If this occurs, consult a doctor immediately.
Notes on the monitor and electronic viewfinder
• The monitor and electronic viewfinder are manufactured using extremely high-precision
technology, and over 99.99% of the pixels are operational for effective use. However, there
may be some small black dots and/or bright dots (white, red, blue or green in color) that
constantly appear on the monitor and electronic viewfinder. These are imperfections due to the
manufacturing process and do not affect the recorded images in any way.
• When shooting with the viewfinder, you may experience symptoms such as eyestrain, fatigue,
motion sickness, or nausea. We recommend that you take a break at regular intervals when you
are shooting with the viewfinder.
• If the monitor or electronic viewfinder is damaged, stop using the camera immediately. The
damaged parts may harm your hands, face, etc.
Notes on continuous shooting
When shooting still images continuously, the monitor or viewfinder may flash between the
shooting screen and a black screen. If you keep watching the screen in this situation, you
may experience uncomfortable symptoms such as feeling of unwellness. If you experience
uncomfortable symptoms, stop using the camera, and consult your doctor as necessary.
Notes on recording for long periods of time or recording 4K/8K movies
• The camera body and battery may become warm with use – this is normal.
• If the same part of your skin touches the camera for a long period of time while using the
camera, even if the camera does not feel hot to you, it may cause symptoms of a low-
temperature burn such as redness or blistering. Pay special attention in the following situations
and use a tripod, etc.
- When using the camera in a high temperature environment
- When someone with poor circulation or impaired skin sensation uses the camera
- When using the camera with [Auto Power OFF Temp.] set to [High]
Notes on using memory cards
• When recording is finished, the memory card may become hot. This is not a malfunction.
• If (overheating warning icon) is displayed on the monitor, do not remove the memory card
from the camera right away. Instead, wait for a while after turning off the camera, and then
remove the memory card. If you touch the memory card while it is hot, you may drop it and the
memory card may be damaged. Be careful when removing the memory card.
Notes on using a tripod
Use a tripod with a screw less than 5.5mm (7/32 inches) long. Otherwise, you cannot firmly
secure the camera, and damage to the camera may occur.
Sony lenses/accessories
Using this unit with products from other manufacturers may affect its performance, leading to
accidents or malfunction.
Warning on copyrights
Television programs, films, videotapes, and other materials may be copyrighted. Unauthorized
recording of such materials may be contrary to the provisions of the copyright laws.
Notes on location information
If you upload and share still images or movies taken with this camera on the
Internet while the location information is linked with the dedicated smartphone
application, you may accidentally reveal the location information to a third party.
To prevent third parties from obtaining your location information, deactivate the
[Location Information Linkage] function of the dedicated application.
Notes on discarding or transferring this product to others
Before discarding or transferring this product to others, be sure to perform the following
operation to protect private information.
• Select [Setting Reset] [Initialize].
Notes on discarding or transferring a memory card to others
Executing [Format] or [Delete] on the camera or a computer may not completely delete the data
on the memory card. Before transferring a memory card to others, we recommend that you
delete the data completely using data deletion software. When discarding a memory card, we
recommend that you physically destroy it.
Note on network functions
When you use network functions, unintended third parties on the network may access the
camera, depending on the usage environment. For example, unauthorized access to the camera
may occur in network environments to which another network device is connected or can
connect without permission. Sony bears no responsibility for any loss or damage caused by
connecting to such network environments.
Note on the 5GHz band for wireless LAN
When using the wireless LAN function outdoors, set the band to 2.4GHz by following the
procedure below. (WW282174 only)
• MENU (Network) [Wi-Fi] [Wi-Fi Frequency Band]
How to turn off wireless network functions (Wi-Fi, etc.) temporarily
When you board an airplane, etc., you can turn off all wireless network functions temporarily
using [Airplane Mode].
Power Cord
Multiple power cords may be supplied with this
equipment. Use the appropriate one that matches
your country/region.
For the customers in the UK, Ireland, Malta, Cyprus
and Saudi Arabia
Use the power cord (A).
For safety reasons, the power cord (B) is not intended
for above countries/regions and shall therefore not
be used there.
For the customers in other EU countries/regions
Use the power cord (B).
(A) (B)
For Customers in the U.S.A. and Canada
The available scientific evidence does not show that any health problems are associated with
using low power wireless devices. There is no proof, however, that these low power wireless
devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency
energy (RF) in the microwave range while being used. Whereas high levels of RF can produce
health effects (by heating tissue), exposure of low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF exposures have not found
any biological effects. Some studies have suggested that some biological effects might occur,
but such findings have not been confirmed by additional research. This equipment has been
tested and found to comply with FCC/ISED radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the
ISED radio frequency (RF) Exposure rules.
For Customers in the U.S.A.
For question regarding your product or for the Sony Service Center nearest you, call 1-800-222-
SONY (7669) .
Supplier’s Declaration of Conformity
Trade Name : SONY
Model : WW282174
Responsible Party : Sony Electronics Inc.
Address : 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone Number : 858-942-2230
Important note on use of 5 GHz wireless LAN
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC,
through the digital and analog baseband, and finally to the RF chip. Several special packets are
initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF
transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on
only while one of the aforementioned packets is being transmitted. In other words, this device
automatically discontinue transmission in case of either absence of information to transmit or
operational failure.
Frequency Tolerance: ±20 ppm
For Customers in Canada
5150-5350 MHz band is restricted to indoor operation only.
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-
5350MHz and 5650-5850MHz and that these radars could cause interference and/or damage
to LE-LAN devices.
For Customers in Europe
IEEE802.11b/g/n 2 400 MHz < 60 mW e.i.r.p.
IEEE802.11a/n/ac 5 150-5 350 MHz
5 470-5 725 MHz
< 35 mW e.i.r.p.
IEEE802.11a/n/ac 5 725-5 850 MHz < 25 mW e.i.r.p.
Bluetooth 2 400 MHz < 10 mW e.i.r.p.
Hereby, Sony Corporation declares that this equipment is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.compliance.sony.eu
Hereby, Sony Corporation declares that this equipment is in compliance with the UK relevant
statutory requirements.
The full text of the declaration of conformity is available at the following internet address:
https://compliance.sony.co.uk
For this radio equipment the following restrictions on putting into service or of requirements for
authorization of use apply in AT/BE/BG/CY/CZ/DK/EE/FI/FR/DE/EL/HU/IE/IT/LV/LT/LU/MT/NL/
PL/PT/RO/SK/SI/ES/SE/UK/UK(NI)/HR/IS/LI/NO/CH/AL/BA/MK/MD/RS/ME/XK/TR:
5150 - 5350MHz band is restricted to indoor operations only.
Additional information on this product and answers to frequently asked questions can be
found at our Customer Support Website.
