SERVICE MANUAL
LEVEL 2
Link
SERVICE NOTE
DISASSEMBLY
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAM
SCHEMATIC DIAGRAMS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
SPECIFICATIONS
SERVICE NOTE
DISASSEMBLY
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAM
SCHEMATIC DIAGRAMS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
SPECIFICATIONS
Link
Revision History
Revision History
DSC-P150
How to use
Acrobat Reader
How to use
Acrobat Reader
Sony EMCS Co.
DIGITAL STILL CAMERA
DSC-P150
•For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (987675551.pdf).
•For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (987675541.pdf).
•Reference No. search on printed wiring boards is available.
•Note in Lens Frame Installation
•Exchange Method of Barrier Assy
• HELP: Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
Ver 1.0 2004.08
On the CH-146 and SY-119 boards
This service manual procides the information that is premised
the circuit board replacement service and not intended repair
inside the CH-146 and SY-119 boards.
Therefore, schematic diagram, printed wiring board and
electrical parts list of the CH-146 and SY-119 boards are not
shown.
The following pages are not shown.
Schematic diagram ............ Pages 4-9 to 4-28
Printed wiring board ........... Pages 4-39 to 4-42
Mounted parts location....... Pages 4-50 and 4-51
Electrical parts list .............. Pages 5-6 and 5-8 to 5-12
The above-described information is shown in service
manual Level 3.
Photo: Silver
US Model
Canadian Model
AEP Model
UK Model
E Model
Hong Kong Model
Australian Model
Brazilian Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
2004H0500-1
©2004.8
Published by DITechnical Support Section9-876-755-31

— 2 —
DSC-P150
SPECIFICATIONS
[Input and Output connectors]
Multi connector
USB communication
Hi-Speed USB (USB 2.0 compliant)
[LCD screen]
LCD panel4.6 cm (1.8 type) TFT drive
Total number of dots
134 000 (560×240) dots
[Power, general]
Used battery pack
NP-FR1
Power requirements
3.6 V
Power consumption (duringshootingwith
LCD screen on)
1.4W
Operating temperature
0°C to +40°C (+32°F to +104°F)
Storage temperature
−20°C to +60°C (−4°F to +140°F)
Dimensions
108×51.5×26.6 mm
(4 3/8×2 1/8×1 1/16 inches)
(W/H/D, excluding maximum
protrusions)
Mass Approx. 183 g (6.5 oz) (including
battery pack NP-FR1, “Memory
Stick” and wrist strap)
Microphone
Electret condenser microphone
Speaker Dynamic speaker
Exif Print Compatible
PRINT Image Matching II
Compatible
PictBridgeCompatible
xAC-LS5/LS5B AC Adaptor
Input rating
100 V to 240 V AC, 50/60 Hz, 11 W,
0.16 A to 0.09 A
Output rating
4.2 V DC, 1.5 A
Operating temperature
0°C to +40°C (+32°F to +104°F)
Storage temperature
−20°C to +60°C (−4°F to +140°F)
Dimensions
Approx. 48×29×81mm
(1 15/16×1 3/16×3 1/4 inches)
(W/H/D, excluding projecting parts)
Mass Approx. 130 g (5 oz) excluding
power cord (mains lead)
xNP-FR1 battery pack
Used battery
Lithium-ion battery
Maximum voltage
DC 4.2 V
Nominal voltage
DC 3.6 V
Capacity 4.4 Wh (1220 mAh)
xAccessories
•AC-LS5/LS5B AC Adaptor (1)
•Power cord (mains lead) (1)
•NP-FR1 battery pack (1)
•Battery case (1)
•USB, A/V cable for multi-use terminal (1)
•Wrist strap (1)
•“Memory Stick” (32 MB) (1)
•CD-ROM (USB driver SPVD-012) (1)
•Operating instructions (1)
See page 5-13.
Design and specifications are subject to change
without notice.
xCamera
[System]
Image device
9.11 mm (1/1.8 type) color CCD
Primary color filter
Total pixels number of camera
Approx. 7 410 000 pixels
Effective pixels number of camera
Approx. 7 201 000 pixels
Lens Carl Zeiss Vario-Tessar
3×zoom lens
f = 7.9 −23.7 mm (38 −114 mm when
converted to a 35 mm still camera)
F2.8 −5.2
Exposure control
Automatic exposure, Manual
exposure, Scene selection (9 modes)
White balance
Automatic, Daylight, Cloudy,
Fluorescent, Incandescent, Flash
File format (DCF compliant)
Still images: Exif Ver. 2.2 JPEG
compliant, DPOF compatible
Movies: MPEG1 compliant
(Monaural)
Recording media
“Memory Stick”
Flash Recommended distance (ISO set to
Auto):
0.2mto 3.5 m (7 7/8 inches to11 feet
53/4inches) (W)
0.3mto2.5 m (11 7/8 inches to 8 feet
23/8inches) (T)

— 3 —
1. Checkthe area ofyourrepairfor unsolderedor poorly-soldered
connections. Checkthe entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Lookfor parts which, throughfunctioning, showobvioussigns
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270˚C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
DSC-P150
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
CAUTION
Dangerofexplosionif batteryisincorrectly replaced.
Replace only with the same or equivalent type.

— 4 —
DSC-P150
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. Note for Repair ································································1-1
1-2. Discharging of the ST-105 Flexible Board’s Charging
Capacitor (C550) ·····························································1-1
1-3. Note in Lens Frame Installation ······································1-2
1-4. Description on Self-diagnosis Display ····························1-2
2. DISASSEMBLY
2-1. Flow Chart ·······································································2-1
2-2. SY-119 Board Service Position ·······································2-3
2-3. Exchange Method of Barrier Assy ··································2-5
2-3-1.Peel Off Old Ornamental Ring A ····································2-5
2-3-2.Remove Old BarrierAssy················································2-6
2-3-3.Install New Barrier Assy ·················································2-6
2-3-4.Adhere the Ornamental RingA ·······································2-7
2-4. Circuit Boards Location ··················································2-8
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram (1/2)···········································3-1
3-2. Overall Block Diagram (2/2)···········································3-3
3-3. Power Block Diagram (1/2)·············································3-5
3-4. Power Block Diagram (2/2)·············································3-7
4. PRINTEDWIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. Frame Schematic Diagram ··············································4-1
4-2. Schematic Diagrams························································4-5
CD-517 FLEXIBLE (CCD IMAGER) ···························4-7
ST-105 FLEXIBLE (CHARGING CAPACITOR) ·······4-29
ST-102 (FLASH DRIVE) ·············································4-29
MS-207 FLEXIBLE
(MEMORY STICK CONNECTOR) ····························4-31
JK-266 FLEXIBLE
(DC IN, MULTI CONNECTOR) ·································4-32
CONTROL SWITCH BLOCK (SW), (RL51600) ·······4-33
4-3. Printed Wiring Boards ···················································4-35
CD-517 FLEXIBLE ······················································4-37
ST-105 FLEXIBLE ·······················································4-43
ST-102 ···········································································4-44
MS-207 FLEXIBLE ······················································4-45
JK-266 FLEXIBLE ·······················································4-46
4-4. Mounted Parts Location ················································4-49
5. REPAIR PARTS LIST
5-1. Exploded Views ·······························································5-2
5-1-1.Cabinet Block Section ·····················································5-2
5-1-2.Lens Block Section··························································5-3
5-1-3.BT Holder Block Section ················································5-4
5-2. Electrical Parts List ·························································5-5
Section Title Page

1-1
SECTION 1
SERVICE NOTE
DSC-P150
1-2. DISCHARGING OF THE ST-105
FLEXIBLE BOARD’S CHARGING
CAPACITOR (C550)
The charging capacitor (C550) of the ST-105 flexible board is
charged up to the maximum 300V potential.
There is a danger of electric shock by this high voltage when the
capacitor is handled by hand. The electric shock is caused by the
charged voltage which is kept without discharging when the main
power of the unit is simply turned off. Therefore, the remaining
voltage must be discharged as described below.
Preparing the Short Jig
To preparing the short jig, a small clip is attached to each end of a
resistor of 1 kΩ/1 W (1-215-869-11).
Wrap insulating tape fully around the leads of the resistor to prevent
electrical shock.
1 kΩ/1 W
Wrap insulating tape.
Discharging the Capacitor
Short-circuit between the positive and the negative terminals of
charged capacitor with the short jig about 10 seconds.
1-1. NOTE FOR REPAIR
Make sure that the flat cable and flexible board are not cracked of
bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
When remove a connector, don’t pull at wire of connector.
It is possible that a wire is snapped.
When installing a connector, don’t press down at wire of connector.
It is possible that a wire is snapped.
R:1 kΩ/1 W
(Part code:
1-215-869-11)
Capacitor
ST-105

1-2E
DSC-P150
Display Code
1-4. DESCRIPTION ON SELF-DIAGNOSIS DISPLAY
Self-diagnosis display
• C: ss: ss
You can reverse the camera
malfunction yourself. (However,
contact your Sony dealer or local
authorized Sony service facility
whenyou cannot recoverfrom the
camera malfunction.)
• E: ss: ss
Contact your Sony dealer or local
authorized Sony service facility.
1-3. NOTE IN LENS FRAME INSTALLATION
When tightening a screw, have both sides of the lens block assembly so as not for the load to depend.
M1.7 ×4
Lens frame
Lens block assembly
C:32:ss
C:13:ss
Countermeasure
Turn the power off and on again.
Format the “Memory stick”.
Insert a new “Memory Stick”.
Cause
Trouble with hardware.
Unformatted memory stick is inserted.
Memory stick is broken.
Caution Display During Error
SYSTEM ERROR
FORMAT ERROR
MEMORY STICK ERROR
E:61:ss
E:91:ss
Checking of lens drive circuit. When failed in the focus and zoom
initialization.
Abnormality when flash is being
charged.
Checking of flash unit or replacement
of flash unit.
—

DSC-P150 2-1 2-2
2-1. FLOW CHART
The following flow chart shows the disassembly procedure.
SECTION 2
DISASSEMBLY
HELP
HELP
Note: Mic harness is connected.
Note: When you exchange rings, be sure
to follow the procedure carried on
"2-3. Exchange Method of Barrier
Assy" (2-5 page).
1Control switch block (RL): CN003
2Screw (M1.4)
x3
3Main block assy
4Mic harness: CN707
5Claw x3
6Front cabinet
7Control switch block (RL)
1ST-105 flexible: CN706
2Claw
x2
3ST-105
4JK-266 flexible: CN704
5Tapping screw (M1.7)
x1
6Control switch block (SW): CN703
7MS-207 flexible: CN751
8SY-119
1Screw (M1.4)
x1
2Claw x1
3Claw x2
4Remove the Control switch block (SW)
in the direction of arrow A.
1Tapping screw (M1.7) x3
2Multi fixed plate
3JK-266
4Tapping screw (M1.7)
x1
5MS-207
1Ornamental ring A
2Tapping screw (M1.2) x2
3Barrier assy
1Claw
x2
2CD-517: CN101
3Lens block flexible: CN201
4Lens block
6
7
1
2
4
31
1
2
1
2
1
4
2
1
3
12
3
53
3
3
5
5
5
2
3
1Screw (M1.4) x4
2Remove the boss, pushing Aportion.
3Remove the rear cabinet from battery lid side.
4Claw
x1
5Rear cabinet
6Panel block assy
7LCD flexible: CN001
8Back light flexible: CN002
6
1
4
3
8
7
2
A
A
1
1
5
4
1
2
2
47
8
5
6
Note: High-voltage cautions
Discharging the Capacitor
Short-circuit between the two
points with the short jig about 10
seconds.
R:1 kΩ/1 W
(Part code:
1-215-869-11)
Capacitor
ST-105

DSC-P150 2-3 2-4
2-2. SY-119 BOARD SERVICE POSITION
Lens block
Panel block
To turn on/off the power, short
the circuit between pin 5and
pin 6(GND) of CN003 on Control
switch block (SW) for 1 second.
CN003
6
5
ST-105 flexible board
MS-207 flexible board
JK-266 flexible board
SY-119 board
Control switch block (SW)
Color monitor
A/V multi cable
AC power
adaptor
AC IN
5
1
4
3
7
6
2
A
1
1
6
7
1
2
4
3
5
5
5
2
1
1
2
3
4
3
1
2
2
47
8
5
6
1
2
3
3A
1
4
2
1
3
5

2-5
DSC-P150
2-3. EXCHANGE METHOD OF BARRIER ASSY
Service parts
Part Number Part Name Quantity
13-091-427-01 Ring (A), Ornamental 1
2X-3954-476-1 Barrier Assy 1
33-086-156-31 Tapping screw (P2) 2
Tools used
Torque driver
Soldering iron
Weight about 60g
Adhesive (Super X) (Note)
Note: Use adhesive (Super X) or an equivalent article.
Don’t use what becomes white after drying like a quick-drying glue.
2-3-1. PEEL OFF OLD ORNAMENTAL RING A
The Ornamental Ring A has adhered to the Barrier Assy strongly and accordingly, use a soldering iron to weaken the adhesive force.
Heat four circled portions with the soldering iron.
Heating temperature is about 300ºC.
Beware of a burn since the entire Ornamental Ring becomes hot.
*As the adhesive force of Ornamental Ring A is considerably large, the forced peeling will damage the group-1 frame.
Insert the tip of tweezers, etc. into a notch of the group-1 frame and prize the ring.
*Take extreme care so as not to damage the coated surface of the group-1 frame.
In case of difficult peeling, heat the ring again with the soldering iron.
If this re-heating failed, it may be advisable that the ring be peeled while heating the portions 1→2→3→4in the under figure one
by one sequentially.
*Discard the removed Ornamental Ring A.
1
2
3
1
Tip
3
4
2

2-6
DSC-P150
2-3-2. REMOVE OLD BARRIER ASSY
1Remove two screws.
*Discard the removed screws.
2Remove the Barrier Assy.
*Discard the removed Barrier Assy.
*After removing the Barrier Assy, if the “G1 Dust-Proof Ring” was removed, it must be returned to the home position.
In returning the ring, adjust the location of a projection to the lens direction.
This is an important part to prevent the dust and light from coming in.
*After removing the Barrier Assy, take extreme care not to drop dust or foreign substances in the lens barrel.
2-3-3. INSTALL NEW BARRIER ASSY
1Install new BarrierAssy by paying attention to the projection of the BarrierAssy in relation to the position shown in the under figure.
2Tighten two screws.
*Tightening torque = 0.5 kgf
1
1
2
Projection
2
2
1

2-7
DSC-P150
2-3-4. ADHERE THE ORNAMENTAL RING A
Apply an adhesive to four recesses on the top surface of the BarrierAssy.
*Do not apply too much adhesive.(Make quantity of adhesives into the quantity in which a groove hides.)
Meeting a “notch” of the Ornamental RingA with a “projection” of the group-1 frame, push the Ornamental RingA into the group-1 frame.
*The projection of the spring for preventing static electricity must be tilted.
Put the 60g weight on the Ornamental Ring A so that the Ornamental Ring A does not float up until the adhesive hardens.
Note: Be careful not to give a shock.
*After the weight was put, no gap must be present in full circumference between Ornamental Ring A and group-1 frame.
A gap, if present, causes the crackle sound NG.
*The weight must push in the Ornamental Ring A only.
If the weight is put on the mold part of the Barrier Assy, the Ornamental Ring A will float up.
Completion after 30 minutes.
Notch
Adhesive Adhesive
Adhesive
Do not put the weight on a black mold part.
Not gap in full circumference.
Adhesive
Projection

2-8E
DSC-P150
2-4. CIRCUIT BOARDS LOCATION
CD-517 flexible
SY-119
(including CP-101 (CH-146 board)
and IC301 (KWF board))
ST-105 flexible
(including ST-102)
CH-146
(included in SY-119)
MS-207 flexible
JK-266 flexible
Board Name Function
CD-517 flexible CCD IMAGER
CH-146 CCD SIGNAL PROCESS
(included in SY-119)
JK-266 flexible DC IN, MULTI CONNECTOR
MS-207 flexible MEMORY STICK CONNECTOR
ST-102 FLASH DRIVE
ST-105 flexible CHARGING CAPACITOR
SY-119 CAMERA MODULE, CAMERA DSP, LENS DRIVE,
(including CP-101 SH DSP, FRONT CONTROL,
LCD DRIVE, AUDIO,
(CH-146 board) and DC/DC CONVERTER
IC301 (KWF board))

HELP
DSC-P150
CN751
SY spacer (MS)
Shield sheet (SY)
Battery holder assy
HELP
Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.

DSC-P150
Link
Link
3. BLOCK DIAGRAMS
OVERALL BLOCK DIAGRAM (2/2) POWER BLOCK DIAGRAM (2/2)
POWER BLOCK DIAGRAM (1/2)OVERALL BLOCK DIAGRAM (1/2)
OVERALL BLOCK DIAGRAM (2/2) POWER BLOCK DIAGRAM (2/2)
POWER BLOCK DIAGRAM (1/2)OVERALL BLOCK DIAGRAM (1/2)

3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
DSC-P150
LENS IRIS
(METER)
CCD
IMAGER
IC101
CD-517 FLEXIBLE BOARD (1/2) SY-119 BOARD (1/2)
17
19
86
133
CAMERA
MODULE
(1/9)
AU AIN
V OUT
PANEL R
HR EN2,
HR DIR2A,
HR DIR2B
STRB CHRG
XSTRB FULL
ST UNREG
48 MCKTG
XFE CS, XTG CS
47
CP101
22
ı
35
40
ı
42
23
25
24
A12
B12
C23
B13
D13
C13
AC8
AC4
AC22
33
42
51
IRIS
MOTOR
M
LENS BLOCK (1/2)
XFC RST SENS
XSYS RST
SYS V
1
OVERALL (2/2)
(PAGE 3-3)
2
OVERALL (2/2)
(PAGE 3-3)
USB PHY D±
FR SI, FR SO, XFR SCK
P4
C6
D7
F1
G1
AC12
AC15
Y11 AB11 Y10
AA11 AB10 Y9
AB9 AA10 AA9
Y8 AB8 AA8
AB7
AA7
U20 V21 V23 U22
V20
V22 W20 Y20
W22
Y23 W21 Y22
Y21
AA22 AA21 AB22
J21 L22 L20 L23 K21
L21
M21 M23 M20 M22
N21
N22 N20 P20 P21
P23
R21 P22 T21 R23
R20
R22 T20 T23 U21
L21 L23 M24 K23
H22
J21 J22 F24
K21
H21 M23 K22
G21
L24 F23 E23
V22 V21 V23 R22 W22
U22
W21 T22 R23 N21
P22
P21 P23 R21 M22
T21
P24 U21 U23 N22
U24
N23 T24 M21 T23
B16
B15
D16
IC502
CN101
(1/2)
THERMISTOR (+)
IC201
ZOOM
MOTOR
M
ZOOM
FG
ZOOM
SENSOR
FOCUS
MOTOR
M
FOCUS
SENSOR
J1
K1
L1
M1
A: VIDEO SIGNAL
A: AUDIO SIGNAL
A: VIDEO/AUDIO SIGNAL
4
10
7
34
30
ı
23
16
C1
D2
G5
H6
G4
H4
MC MSDIO,
MC MSBS,
MC MSCLK
CN751
7
9
3
BACKLIGHT
COLOR
LCD
MONITOR
D11
L7
L8
J11
L6
A5
B4
A4
A11
B11
C11
VR
VG
VB
COM
VR
VG
VB
COM
BL H
5
3
23
24
2
6
ı
8
11
ı
14
19
ı
22
4
CN001
1
BL THL 4
CN002
D901
LCD901
RGT, HCK1, HCK2,
HST, PCG, XSTBY,
DWN, EN, VST,
VCK, REF, VP
RGT, HCK1, HCK2,
HST, PCG, XSTBY,
DWN, EN, VST,
VCK, REF, VP
HDO
PANEL V
LCD DRIVE
(6/9)
IC801
B1
A2
SYS V
MC D0 – D15
MC A1 – A25
Q601, 602
D8
J23
J22
AA12
D14
A17
C18
D21
G22
AD16
K2
A7
H1
AA8
M
SHUTTER
MOTOR
LENS TEMP
SENSOR
23
ı
26
9
ı
12
17
ı
20
13
ı
10
33
29
F4
F3
U3
T2
T3
U2
T4
AA19
AB20
E7
D7
MSHUT EN
MSHUT DIR
F8
F7
IRIS S EN
IRIS S IN
G2
G1
IRIS M EN
IRIS M IN
XZM DC BR
G3
H2
B1
FOCUS
MOTOR
DRIVER
ZOOM
MOTOR
DRIVER
IRIS
MOTOR
DRIVER
SHUTTER
MOTOR
DRIVER H8 MSHUT REF
HR EN0,
HR DIR0A
IRIS M±, S±
Z DC MOTOR (+), (–)
F MOTOR A, A, B, B
SHUTTER MOTOR (+), (–)
CN201
(1/2)
BUFFER
Q103
IC301
XTG CS
XFE CS
CAM F
XSYS RST
MC XCS IC 301REG
MC XCS IC 301SDRAM
XSYS RST
XPANEL TG CS
XPANEL TG CS
VIDEO AMP ON
P1 MC CKIO
A2
A6
G2
AC12
AA9
AC16
AC15
AD19
LENS TEMP
VER EXTAL
PANEL B
PANEL G
D1
E1
E11
F11
CONTROL SWITCH
BLOCK (SW) (1/2)
E1 F1 G2
H2 H1 J2
J1 K1 K3
L3
H11
K11
L10
PANEL UNIT
30
XZM RST SENS1
ZM DC FG A, B
F PI SENS OUT
Z PI SENS OUT
Z BOX1 PI SENS OUT,
Z BOX2 PI SENS OUT
IRIS M±, S±
ZOOM DC ±
FOCUS A, A, B, B
SHUTTER±
AU AOUT
A6
B5
A4
B4
1
6
7
36
32
33
26
28
29
19
135
37
48
9
6
4
7
13
10
20
17
113 109
112 115
7 125
119 118
121
6
37
5
2
4
21
36
1
3
7
11
10
9
12
ı
14
20
15
ı
18 CAMERA DSP,
SDRAM
(KWF BOARD)
(2/9)
CA AD00 – CA AD13
AB6
46
CAM SO, XCAM SCK, XCAM RST
CAM SO, XCAM SCK, XCAM RST
CAM SO, XCAM SCK, XCAM RST
LENS DRIVE
(3/9)
MSHUT REF
AA19
XZM DC BR
ST-102 BOARD
ST-105 FLEXIBLE BOARD
CN706
05
Q506
FLASH
UNIT
Q101
Q102
9
1
FLASH
CONTROL 4
2
IC501
VIDEO AMP
(2/9)
24
1
IC302
3
ı
5
Q603
XE_H CL003 – 005
CL002
CL010
CL011 – 014, 027
TRIG 300V
XE_L
+
C550
CHARGING
CAPACITOR
D502
2
5 4
1
3
TRANS
DRIVE
Q503
T501
STB FLL
ST UNREG
STRB ON
STB FLL
STRB ON
STRB CHRG
XSTRB FULL
STRB ON
MEMORY
STICK
4
2
8
56
DIO, BS, SCLK
INT
MS-207 FLEXIBLE BOARD
CN001
AD14
AB7
MELODY
F1 PRELAMP AF CONT
H23
SELF TIMER LED
C22
XACCESS LED
L22
TALLY LED
AB5
XAE LOCK ON
XMS IN
AD20
AE LOCK LED
AB13
XSHTR ON
AD11
FR INT
D11
XCS MC
MELODY ENV
D22
AA18
AU SEN
XAU LINE MUTE
BL LEV
BL H
BL L
BL H
BL THL
BL MODE
BL MODE
OVERALL (2/2)
(PAGE 3-4)
3
C1
G10
25
24
26
9
CN703
(1/2)
35 BL L 6
BL L 32
33
B5
BL LEV
MC CAM,
SH DSP,
FLASH
(4/9)
CAM F
CAM F
Y7
45 CA HD
4
8
ı
15
CCD OUT
PWR SAVE
22
RG, H1B, H2B
V1, V3A, V3B
21
VSUB
H1A, H2A
27
Q103
Q104
VSUB CONT
38
39
99
84
134 136 2 4
6 9 12 15
18 21 24
27 30 32
3 123
126
– 129
49 105
132
124
B7
B8
C7
C8
B3
A2
K4
J3
G4 J2 Y4
G3 H4 W4
N3
K3
M4
SYS SO, XSYS SCK
SYS SI, SYS SO, XSYS SCK
SYS SI, SYS SO, XSYS SCK
Q752
LED
DRIVE
D753
(MS ACCESS)
CH-146 BOARD
CCD SIGNAL
PROCESSOR,
TIMING
GENERATOR
IC101
66 101 120
Q803
27
23
ı
17
13
ı
8
Q205
V2, V4, V5A, V5B,
V6, V7, V8, V9, V10
531 1119
VHLD
335 138
VST
X101
27MHz
3-1. OVERALL BLOCK DIAGRAM (1/2)
3-1 3-2
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
SECTION 3
BLOCK DIAGRAMS

3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
DSC-P150
A: VIDEO SIGNAL
A: AUDIO SIGNAL
A: VIDEO/AUDIO SIGNAL
V OUT
SP ±
A OUT L
XAV JACK IN
ACV UNREG
BATT XEXT
USB VBUS
SY-119 BOARD (2/2)
CD-517 FLEXIBLE BOARD (2/2)
AUDIO AMP
(7/9)
IC901
H7 F1
A7
05
MIC901
MICROPHONE
V OUT
AU AIN
AU AOUT
AU SEN
MELODY ENV
PRELAMP AF CONT
SELF TIMER LED
TALLY LED
AE LOCK LED
TALLY LED
AE LOCK LED
TALLY LEDXTALLY LED
XAE LOCK LED
XCHARGE/XSTRB LED
XCHARGE/XSTRB LED
XCHARGE/XSTRB LED
BATT SIG
AE LOCK LED
MELODY
H6
H4
SP901
SPEAKER
V OUT
CN704
(1/2)
CN704
(2/2)
CN201
(2/2)
MIC IN
CN707
SP ±
1
OVERALL (1/2)
(PAGE 3-2)
MODE
DIAL
S001
(SHUTTER)
POWER
CONTROL SWITCH
BLOCK (RL51600)
CONTROL SWITCH
BLOCK (SW) (2/2)
CN703
(2/2)
S002
6
7
8
XPWR ON
30
39
B8
B2
29
31
J8
J9
D1
D2
E1
4XPWR LED
D001
(POWER)
S401
BT001
LITHIUM
BATTERY
USBPHY D±USBPHY D±
FR INT
XCS MC
XAE LOCK ON
IC401
D9
E2
DC/DC
CONTROL,
RESET
(8/9)
IC002
DDCON SO, DDCON SCK
C1
D3
L8
K8
D 1.2V
ACV UNREG
PANEL 8.5V
BACK UP VCC
EVER 3.0V
A 3.1V
D 2.8V
CAM 15.5V
A 2.8V
CAM –7.5V/–8.0V
CAM 3.3V
ST 5V
M 5V
CAM –0.5V
A7
A8
G1
G2
H2
26
J7
H7
J6
H6
C7
D7
SYS SO, XSYS SCK H2
H3
34
32
CN101
(2/2)
41
USB JACK IN
XAV JACK IN
2
OVERALL (1/2)
(PAGE 3-2)
Q406
Q502
MODULATOR
SYS V
FR SI, FR SO, XFR SCK
B9
XSYS RST B3
J5
J4
D7
X401
32.768kHz
RESET
S004 – 011
FUNCTION
KEY
S002
W
S003
T
(ZOOM)
MODE DIAL0, 1
KEY AD0, 1
KEY AD2
A2
A4
AU OUT 29
A3
XMULTI JACK IN C4
XAV JACK IN 18
C8
XMS IN Q401
B6
36
21
22
1
2
USB JACK IN
D±10
12
6
XMULTI IN
19
XMULTI JACK IN 24
20
16
26
CN101
(MULTI CONNECTOR)
JK-266 FLEXIBLE BOARD
3
2
CN003
5XPWR ON
3XPWR LED
1
2
XAE LOCK ON
XSHTR ON
CHG SW
ACV W SENS
FAST CHARGE
XRSTX
Q008,
009
BATT/XEXT
ACV UNREG
DC IN
J101
+
−
BT901
BATTERY
TERMINAL
BATT UNREG
BATT /XEXT D
S
BATT SIG
BATT SIG
BATT UNREG1
G6
ACV UNREG
ST UNREG
BATT UNREG
BEEP C1
XAU LINE MUTE G4
XSHTR ON
B1
FRONT
CONTROLLER
(5/9)
IC403
CRADLE LED CONTROL
(5/9)
IC402
DC JACK/MULTI DOUBLE
INSERTION DETECT
(5/9)
D8
E4
E3
J1 INIT CHARGE D2
A9 BATT IN A7
H1 XCS DDCON K7
E8 SYS DD ON
B7
A10
VL 3V VL 3V
Q701
LED
DRIVE
Q402
Q503
LED
DRIVE
Q407
D104
SELF TIMER/
AF ILLUMINATOR
D103
SELF TIMER/
RECORDING
D102
(AE/AF LOCK)
D101
(FLASH/CHG)
PRELAMP AF ON
2
43
44
38
LENS BLOCK (2/2)
21
23
25
19 XBATT CHARGE
17
XLANC POWER ON
KEY ADA, ADB
7
15
9
4537–44
ACV UNREG1
2–9
KEY ADA, ADB
22 23
BATT XEXT D
1
BATT XEXT M
20
XLANC POWER ON
24
XBATT CHARGE
21
BATTERY
CHARGE
DETECTOR
BUFFER
J2
J3
B1
G2
OVERALL (1/2)
(PAGE 3-2)
3
BL L
BL LEV
G1 BL H
PLL
LOOP
FILTER
3-3 3-4
3-2. OVERALL BLOCK DIAGRAM (2/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
DSC-P150
POWER 2
(PAGE 3-7)
A
05
SY-119 BOARD (1/2)
CONTROL SWITCH
BLOCK (RL51600)
VCH1A D 2.8V
VCH2
VCC1A
G11
CHG SW
E4
VDCIN
D1
OUT8B
E9
VCC8
B11
OUT8A
D9
L10
VCH1B K9
VCH7 K3
E11
OUT2
F10
IC002
DC/DC CONTROL, RESET
(8/9)
VCC2
F9
VLDO2
B9
VLDO3
A10
VLDO1 EVER 3.0V
A11
D 1.2V
M 5V
ST 5V
A 2.8V
CAM –0.5V
VCC1C
G9
VCC1B
G10
VBCK
D8
BATT
MARK
D4
E5
OUT3C
J2
OUT3B
K1
VCH3A (FB3) J1
VCH3B H4
VCH3C (FB6) H3
VCH3S H2
VCC GD H1
D006
D005
BATT UNREG
D 1.2V
D404 D403
ACV UNREG
D 1.2V
ACV UNREG
L001, 010
L009
L011
L002
VCH4 J6
OUT4 K6
CAM 15.5V
VLDO4 C8 A 3.1V
L006
D009
BL THH
EVER 3.0V
EVER 3.0V
IC401
FRONT CONTROLLER
(5/9)
ST UNREG
G8
A7
ACV SENS
F8 DD CON SENS
BATT/XEXT
A8 XLANC PWR ON
H8 BATT SENS
BATT SI
BATT SO
F002
F001
F004
4
CN003
BACK UP VCC
BT001
LITHIUM
BATTERY
2
ı
9
1
37
ı
44
OUT3A
J3
VCC5
DIN
CLK
SYSDDON
USB PWR ON
LD
CS
FCHG
K5
Q008,
009
D004
D002
CN704
CN703
(1/2)
45
ACV UNREG1
JK-266 FLEXIBLE BOARD
CONTROL SWITCH
BLOCK (SW) (1/2)
DC IN
J101
BT901
BATTERY
TERMINAL
BATT UNREG1
BATT SIG
BATT/XEXT D
20
24
BATT/XEXT M
39
VL 3V VL 3V
VCH5 J5
OUT5 L5
CAM –7.5V/–8.0V
VLDO5 B8 PANEL 8.5V
BL H
L007
D008
VCH6 G1
OUT6 F1
BL L
BL LEV
SYS DD ON
ICH6 G2
REF6 B1
D007
D003
L005
L003
DDCON SO,
DDCON SCK
C1
D3
L8
K8
H2
C7
D7
FAST CHARGE E3
ICHG
J1 INIT CHARGE D2
A9 BATT IN A7
H1 XCS DDCON K7
E8 SYS DD ON
D001
(POWER)
ACV UNREG
CN101
MULTI
CONNECTOR
+
−
S
21
23
25
19
XLANC POWER ON
7
5
IC402
DC JACK/MULTI DOUBLE
INSERTION DETECT
(5/9)
Q402
BUFFER
G1
G2
Q407
BATTERY
CHARGE
DETECTOR
2
14
IC403
CRADLE LED
CONTROL
(5/9)
VCH1C (FB4) L9
CBG B5
Q001
DC
CONTROL
DC
CONTROL
(8/9) 4
IC003
1
3-5 3-6
3-3. POWER BLOCK DIAGRAM (1/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
DSC-P150
EVER 3.0V
FB801
SY-119 BOARD (2/2)
CN201
IC501
11
18
CN001
CN002
F PI SENS Vcc
PU[6]
Q201 (1/2)
REF
BL THH
VDD
Z BOX1 PI
SENS Vcc
05
3
6
ST UNREG
STRB CHRG
CAM DD ON
MS POWER ON
ST 5V
BL THH
BL LEV
PANEL 8.5V
BL H
BL L
CONTROL SWITCH
BLOCK (SW) (2/2)
BL L
1BL H
REF
BL THH
VDD
BL L
BL H
CAM 15V
12
1
CN101
45
D 2.8V (XAE LOCK)
42
M 5V
39
D 2.8V (XTALLY)
40
L103
L102
L101
L503
L104
FB105
FB102
CCD IMAGER
IC101
CD-517 FLEXIBLE BOARD
POWER 1
(PAGE 3-6)
CAM 15.5V
EVER 3.0V
A 3.1V
D 1.2V
A 3.1V
D 1.2V
CAM –0.5V
SYS DD ON
CAM –7.5V/–8.0V
M 5V
A 2.8V
M 5V (AUDIO_5V)
A 2.8V
D 2.8V
D 2.8V
D 1.2V
CAM 15.5V
EVER 3.0V
CAM –0.5V
SYS DD ON
CAM –7.5V/–8.0V CAM –7.5V
M 5V
A 2.8V
D 2.8V
A
Q751
Q101, 102
L901
REF
2.8V
REG
(6/9)
L813
L804
CN706
ST UNREG
ST 5V
CL003 – 005
CL009
AUDIO AMP
(7/9)
IC901
AC20
PU[0]
AD19
SDA(O/D)
AD18
ZOOM
SENSOR
LENS BLOCK
ZOOM
SENSOR
ZOOM
FG
14
CN703
M 5V (PANEL 4.9V)
20
A 2.8V
(PANEL 2.8V)
32
35
34
IC802
H11
EXTDA G10
5 4
1.8V
REG
(4/9)
IC501
4 1
3.3V
REG
(8/9)
IC004
5 4
53
56
51
49
AU 2.8V
A 2.8V
32
1
Z PI SENS Vcc FOCUS
SENSOR
28
Z BOX2 PI
SENS Vcc
6
2
VIDEO AMP
(2/9)
IC302
L302
L303
PI006 V4
VCC 9
XLENZ RST LED
PI007 V3 XZM RST LED
ST-102 BOARDST-105 FLEXIBLE
BOARD
T501
FLASH
UNIT
L601 Q601, 602 3
ı
5
2FLASH
CONTROL
BACKLIGHT
COLOR
LCD
MONITOR
D901
LCD901
LCD DRIVE
(6/9)
IC801
PANEL UNIT
CH-146 BOARD
CCD SIGNAL
PROCESSOR,
TIMING
GENERATOR
CAMERA MODULE
(1/9)
IC101
CP101
FB103
50
L105
FB108
FB305
FB304
FB301
FB302
D104
SELF TIMER/
AF ILLUMINATOR
D102
(AE/AF LOCK)
D101
(FLASH/CHG)
D103
SELF TIMER/
RECORDING
CN751
MEMORY
STICK
MS-207 FLEXIBLE BOARD
CN001
IC502
MC CAM,
SH DSP,
FLASH
(4/9)
D2.8V
A 2.8V
M 5V
D 2.8V
D 2.8V
Q201 (2/2)
D 2.8V
IC301
CAMERA DSP,
SDRAM
(KWF BOARD)
(2/9)
IC201
LENS DRIVE
(3/9)
54
55
71
52
57
L502
L301
1
3-4. POWER BLOCK DIAGRAM (2/2)
3-7 3-8E
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS
4-2. SCHEMATIC DIAGRAMS 4-3. PRINTED WIRING BOARDS
DSC-P150
2PCN707
1 2
CN751 10P
1
2
3
4
5
6
7
8
9
10
33P
CN201
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
10P
CN706
1
2
3
4
5
6
7
8
9
10
39PCN703
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
45PCN704
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45
6PCN002
1
2
3
4
5
6
J101
28P
CN101
(MULTI CONNECTOR)
TO AV/USB MULTI CABLE OR CRADLE
2
4
68
101214
16
1820
22
24
26
13
5
79
15
1719
21
23
25
6PCN003
1XAE_LOCK_ON 2XSHTR_ON 3XPWR_LED 4EVER_3.0V 5XPWR_ON 6REG_GND
24P
CN001
1TEST
2RGT
3VB
4VR
5VG
6VP
7HCK1
8HCK2
9NC
10 NC
11 REF
12 HST
13 PCG
14 XSTBY
15 VSSG
16 NC
17 REG_GND
18 VDD
19 DWN
20 EN
21 VCK
22 VST
23 CS
24 COM
1
2
45PCN101
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
CN001 12P
1
2
3
4
5
6
7
8
9
10
1
A
LENS
OVF
CCD
MIC_SIG MIC_GND
GEAR
BOX
DATA3
DATA2
SCLK
VSS
DATA1
BS
INT
VSS
VCC
DIO
ST_GND
ST_5V
ST_UNREG
STRB_ON
ST_UNREG
ST_UNREG
ST_GND
STB_FULL
ST_GND
STB_VOLT
BATT_UNREG1 NC V_OUT BATT_UNREG1 ACV_UNREG1 GND XAV_JACK_IN ACV_UNREG1 GND USB/LANC_GND A_OUT_L BATT_UNREG1 USB/LANC_GND BATT_UNREG1 V_GND V_GND GND GND USB_VBUS ACV_UNREG1 D+ KEY_ADB BATT/XEXT_D BATT/XEXT_M ACV_UNREG1 BATT_UNREG1 KEY_ADA XMULTI_IN A_GND GND GND BATT_UNREG1 GND BATT_SIG XBATT_CHARGE XLANC_POWER_ON A_GND ACV_UNREG1 ACV_UNREG1 BATT_UNREG1 GND ACV_UNREG1 ACV_UNREG1 D- BATT_UNREG1
NC
BL_THH
BL_L
NC
BL_H
BL_THL
USB_VBUS
D+
V_OUT
USB_GND
NC(FR_LOW_BATT)
D-
V_GND
USB_GND
A_OUT_L
A_GND
XMULTI_IN
XAV_JACK_IN
NC(FR_EXT_BATT)
VB
BL_THH
KEY_AD2
KEY_AD1
VR
VL_3V
EVER_3.0V
KEY_AD0
EN
NC
MODE_DIAL0
VG
VCK
XPWR_LED
DWN
VP
HCK2
HCK1
REG_GND
REF
VDD
REG_GND
VSSG
XPWR_ON
BL_H
COM
XAE_LOCK_ON
REG_GND
RGT
REG_GND
BL_L
NC
HST
PCG
VST
BL_THL
XSTBY
XSHTR_ON
MODE_DIAL1
SP-
SP+
LENS FLEXIBLE
SPEAKER
SP901
CD-517
FLEXIBLE
FLEXIBLE
MS-207
BOARD
BOARD
LENS BLOCK
BOARD
CH-146
CP101
BOARD
KWF
IC301
JK-266 FLEXIBLE BOARD
1113
DC IN
MIC
MIC901
BACKLIGHT
D901
LCD MONITR
1.8INCH
COLOR
LCD901
(SW)
SWITCH
BLOCK
CONTROL
CONTROL SWITCH
BLOCK(RL51600)
C550
FLASH UNIT
BOARD
ST-102
FLEXIBLE BOARD
ST-105
MEMORY STICK
MEMORY
STICK
SY-119 BOARD
11
12
27
28
D
137
I
B
5
H
8
E
15 1792
05
1643
F
C
G
M
10 11 12
K
J
L
146 201918
PANEL UNIT
BATTERY
TERMINAL
BT901
CAPACITOR
CHARGING
ACV_GND
ACV_UNREG
ACV_GND
XBATT_CHARGE
ACV_UNREG
KEY_ADA
KEY_ADB
XLANC_POWER_ON
ACV_UNREG
ACV_GND
BATT_XEXT
N.C
N.C
VSS
VCC
SCLK
DATA3
INT
DATA2
SDIO/DATA0
DATA1
BS
VSS
RG
M_5V
V5A
GND
V5B
H1B
V7
CCD_OUT
GND
NC
XCHARGE/XSTRB_LED
V1
GND
VSUB
H2B
V9
CCD_GND
GND
D_2.8V(XAE_LOCK)
EVER_3.0V
D_2.8V(XTALLY)
V3B
NC
V3A
CAM_15V
V10
GND
XAE_LOCK_LED
XTALLY_LED
V4
GND
V2
H1A
VSUB_CONT
H2A
GND
CAM_-7.5V
PRELAMP_AF_ON
VHLD
PWR_SAVE
VST
GND
V8
GND
V6
REG_GND
F_PI_SENS_Vcc
IRIS_M_+
Z_BOX2_PI_SENS_Vcc
IRIS_M_-
REG_GND
SP-
SHUTTER_MOTOR(-)
Z_BOX1_PI_SENS_Vcc
Z_BOX1_PI_SENS_Col
Z_DC_MOTOR(-)
SHUTTER_MOTOR(+)
Z_BOX2_PI_SENS_Col
REG_GND
N.C.
IRIS_S_-
Z_PI_SENS_Vcc
Z_PI_SENS_OUT
SP+
Z_DC_MOTOR(-)
SHUTTER_MOTOR(+)
THERMISTOR(+)
F_MOTOR B
F_MOTOR A
Z_BOX1_PI_SENS_OUt
SHUTTER_MOTOR(-)
Z_DC_MOTOR(+)
Z_BOX2_PI_SENS_OUT
F_PI_SENS_OUT
F_MOTOR B
F_MOTOR A
IRIS_S_+
Z_DC_MOTOR(+)
4-1 4-2
4-1. FRAME SCHEMATIC DIAGRAM
FRAME
SECTION 4
PRINTEDWIRING BOARDS AND SCHEMATIC DIAGRAMS

DSC-P150
Link
Link
4-2. SCHEMATIC DIAGRAMS
CONTROL SWITCH BLOCK (SW), (RL51600)
ST-102 BOARD (FLASH DRIVE)
JK-266 FLEXIBLE BOARD
(DC IN, MULTI CONNECTOR)
MS-207 FLEXIBLE BOARD
(MEMORY STICK CONNECTOR)
ST-105 FLEXIBLE BOARD
(CHARGING CAPACITOR)
CD-517 FLEXIBLE BOARD (CCD IMAGER)
CONTROL SWITCH BLOCK (SW), (RL51600)
ST-102 BOARD (FLASH DRIVE)
JK-266 FLEXIBLE BOARD
(DC IN, MULTI CONNECTOR)
MS-207 FLEXIBLE BOARD
(MEMORY STICK CONNECTOR)
ST-105 FLEXIBLE BOARD
(CHARGING CAPACITOR)
CD-517 FLEXIBLE BOARD (CCD IMAGER)
COMMON NOTE FOR SCHEMATIC DIAGRAMS
COMMON NOTE FOR SCHEMATIC DIAGRAMS
