Sony MPK-THH User manual

SERVICE MANUAL
MPK-THH
WATERPROOF CASE
US Model
Canadian Model
AEP Model
Chinese Model
MPK-THH
Ver. 1.0 2009.02
SPECIFICATIONS
Sony EMCS Co.
9-852-666-11
2009B0500-1
© 2009.2
Published by Kohda TEC
MAIN FEATURE
Material
Plastic (PC, ABS), Glass
Water-resistance
O-ring, Buckle
Pressure-resistance
To a depth of up to 40 m (132 feet) underwater
Switches that can be externally operated
ON/OFF (Power), Shutter, Playback, Zoom (W/T), Shooting mode, Underwater
white balance, Flash, Macro, Image size
Dimensions
Approx. 134 × 94 × 42 mm (5 3/8 × 3 3/4 × 1 11/16 in.) (w/h/d)
(excluding the projecting parts)
Mass
Approx. 310 g (11 oz.) (marine pack only)
Included items
Wate rproof Case (1)
Hand strap (1)
LCD hood (1)
Grease (1)
O-ring (1)
Desiccant (two-pack) (1)
Spacer (1)
Set of printed documentation
Optional accessories
Arm kit VCT-MP1K
Underwater video light HVL-ML20M (must be used together with arm kit
VCT-MP1K and “InfoLITHIUM” (M series) battery pack, (M series battery
charger))
O-ring kit ACC-MP101
(Check for on the package at the time of purchase.)
Design and specications are subject to change without notice.
Useable at a depth of up to 40 m (132 feet) underwater.
is Marine Pack MPK-THH (referred to below as “this unit”) is exclusively for
use with the Sony Digital Still Camera (referred to below as “camera”) DSC-
T900.
is unit is waterproof so the camera can be used in the rain, snow, at the beach,
or underwater.
Using this unit with the camera setting to (Underwater) or (Underwater)
will enable you to record beautiful underwater images.



Before using the camera underwater, rst take this unit to a depth of about
1 m (3.3 feet) and check that the camera is operating properly and that this
unit is not leaking, then commence your dive.
In the unlikely event that a malfunction of this unit causes damage due to
water leakage, Sony does not guarantee against damages to the equipment
contained in it (camera, battery pack, etc.) and the recorded contents, nor
expenses entailed in the photography.



– 2 –
MPK-THH
1
(Note)
2
21
23
26
24
25
44
3
5
4
14
(Note)
14
(Note)
6
7
8
9
12
12
10 11
13
13
15 16
17
18
19
20
20
Front Case Section
(See Page 3)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-1. REAR CASE BLOCK
NOTE:
• -XX and -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• The mechanical parts with no reference number in
the exploded views are not supplied.
• Accessories are given in the last of the electrical
parts list.
• Abbreviation
CH : Chinese model
CND : Canadian model
01 4-115-566-01 O RING, MAIN (Note)
2 4-136-935-01 ATTACHMENT (R)
3 A-1703-787-A BUCKLE ASSY
4 2-589-173-01 RING (DIA. 1.5), E
5 4-115-555-01 LEVER (A), BUTTON
6 4-115-556-01 LEVER (B), BUTTON
7 4-115-557-01 LEVER (C), BUTTON
8 4-115-558-01 LEVER (D), BUTTON
9 4-115-559-01 LEVER (E), BUTTON
10 4-119-161-01 SHAFT (DIA. 2.5X55), BUCKLE
11 4-115-553-01 PUCH BUTTON C ( )
12 4-147-497-01 SPRING, PUCH BUTTON
13 4-115-536-01 RETAINER, O RING
014 3-099-234-01 O RING (P2-A) (Note)
15 4-115-551-01 PUCH BUTTON A ( )
16 4-115-552-01 PUCH BUTTON B ( )
17 4-115-552-11 PUCH BUTTON B ( )
18 4-115-552-21 PUCH BUTTON B ( )
19 4-115-552-31 PUCH BUTTON B ( )
20 3-099-285-01 SHAFT, HINGE
21 4-115-550-01 CASE, REAR
23 4-136-936-01 REINFORCEMENT (PLAY)
24 4-136-937-01 LEVER (PLAY), BUTTON
25 4-119-159-01 SCREW (1.7X4 #0-3), TP
∗26 3-209-949-01 LABEL, O RING CAUTION (US, CND, AEP)
∗26 3-209-950-01 LABEL, O RING CAUTION (CN) (CH)
The marked “0” are parts in relation
to waterproof.
Replace these components with Sony
parts.
Be sure to check up waterproof after
repair.
La 0marquée sont des pièces par
rapport à imperméable à l’eau.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Soyez sûr de vérifier vers le haut
d’imperméable à l’eau après la
réparation.
Note: When putting grease the O ring (Ref. No. 1 and 14), always
use the grease of the blue tube of the accessory. When using
the grease of the yellow tube and the grease of the other Inc.,
it hurts a O ring and it causes the water leakage.

– 3 –
MPK-THH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1-2. FRONT CASE BLOCK
51 4-136-924-01 PROTECTOR, FRONT
52 3-099-238-01 TP2.6X8 (PLATE)
53 3-099-221-01 PLATE, TRIPOD SCREW
54 X-2349-425-1 FRONT CASE ASSY (SERVICE)
55 4-136-930-01 COVER, BUTTON
056 2-591-447-01 O RING (P4) (Note 1)
57 4-115-531-01 KNOB, ZOOM
58 4-115-533-01 SHEET, ZOOM ADHESIVE
59 4-115-532-01 COVER, ZOOM KNOB
60 4-115-544-01 SHAFT, SHUTTER LEVER
61 4-115-543-01 LEVER, SHUTTER
62 4-115-534-01 PUCH BUTTON D
63 4-147-497-01 SPRING, PUCH BUTTON
64 4-115-536-01 RETAINER, O RING
065 3-099-234-01 O RING (P2-A) (Note 1)
66 4-115-530-01 SPRING (R), ZOOM
67 4-115-529-01 SPRING (L), ZOOM
68 4-136-948-01 COVER, ZOOM
69 4-118-571-01 SCREW (1.7X3 #0-1), TP
70 4-115-524-01 REFLECTOR (Note 2)
71 2-593-524-01 SCREW, TIP1.7X3 SPECIAL
72 4-136-926-01 ATTACHMENT (F)
73 4-141-293-01 PACKING, DROP PROTECTION
75 4-136-927-01 SLIDER, ZOOM
76 4-136-925-01 SHAFT, ZOOM
77 2-589-173-01 RING (DIA. 1.5), E
78 4-136-928-01 LEVER (SHUTTER), BUTTON
79 4-136-929-01 LEVER (PW), BUTTON
80 4-119-159-01 SCREW (1.7X4 #0-3), TP
81 4-128-054-01 SHEET, LIGHT INTERCEPTION (Note 2)
82 3-087-452-01 LABEL, CAUTION (US, CND, AEP)
82 4-146-597-01 LABEL (CN), CAUTION (CH)
83 4-145-555-01 CUSHION, GUIDE
51
52
71
82
72
73
54
53
55
80
80
80
56
(Note 1)
57
58
59 60
61
63
62
64
65
(Note 1)
67
83
A
A
66
68 69
70
(Note 2)
81
(Note 2)
75
76
77
78
79
77
77
ns
ns
ns
ns
ns
ns
ns
Note 1: When putting grease the O ring (Ref. No. 56 and 65), always
use the grease of the blue tube of the accessory. When using
the grease of the yellow tube and the grease of the other Inc.,
it hurts a O ring and it causes the water leakage.
The marked “0” are parts
in relation to waterproof.
Replace these compo-
nents with Sony parts.
Be sure to check up wa-
terproof after repair.
La 0marquée sont des pièces par rap-
port à imperméable à l’eau.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Soyez sûr de vérifier vers le haut
d’imperméable à l’eau après la réparation.
ns: not supplied
Note 2: When the reflector (Ref. No.70) is replaced, the light inter-
ception sheet (Ref. No.81) is needed at the same time.

– 4 –
MPK-THH
1-3. ACCESSORIES
Spacer
(Note 1)
O-ring
04-115-566-01
(Note 2)
LCD Hood Strap
3-099-290-01
Hand Strap
2-591-542-31
Grease
02-582-620-01
(Note 2)
LCD Hood
3-273-528-01
Desiccant (Two-pack)
3-876-901-01
Operating Instructions
4-132-683-11 (ENGLISH, FRENCH, SPANISH, DUTCH) (US, CND, AEP)
4-132-683-21 (GERMAN, ITALIAN, PORTUGUESE, SWEDISH) (AEP)
4-132-683-31 (RUSSIAN, ARABIC) (AEP)
4-132-683-41 (TRADITIONAL CHINESE, SIMPLIFIED CHINESE, KOREAN) (AEP, CH)
O-ring Maintenance Manual
2-674-692-01 (JAPANESE, ENGLISH, FRENCH,
GERMAN, ITALIAN, DUTCH,
SPANISH, PORTUGUESE, SWEDISH,
RUSSIAN, TRADITIONAL CHINESE,
SIMPLIFIED CHINESE, KOREAN,
ARABIC)
The marked “0” are parts
in relation to waterproof.
Replace these compo-
nents with Sony parts.
Be sure to check up wa-
terproof after repair.
La 0marquée sont des pièces par rap-
port à imperméable à l’eau.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Soyez sûr de vérifier vers le haut
d’imperméable à l’eau après la réparation.
Note 1: This item is supplied with the unit as an accessory, but is
not prepared as a service part.
Note 2: When putting grease the O-ring (4-115-566-01), always use
the grease of the blue tube of the accessory. When using the
grease of the yellow tube and the grease of the other Inc., it
hurts a O-ring and it causes the water leakage.

Revision History
Reverse
MPK-THH
Ver.
1.0
Date
2009.02
History
Official Release
Contents
—
S.M. Rev.
issued
—
985266611.pdf
