Sony MVC-CDZOO/CD300 User manual

3-067-951-l l(1)
Digital Still Camera
Operating Instructions
Before operatingtheunit, pleasereadthis manualthoroughly, andretainit
for future reference.
Owner’s Record
The modelandserialnumbersarelocatedon thebottom. Recordtheserial
numberin thespaceprovidedbelow. Referto thesenumberswheneveryou
call uponyour Sonydealerregardingthis product.
Model No.
SerialNo.
pi
MVGCD300
CDMavica
m 4
InfoLfTHfLlM
MVC-CDZOO/CD300
02001 Sony Corporation

RegulatoryInformation
Declaration of Conformity
TradeName: SONY
Model No.: MVC-CD200
ResponsibleParty:SonyElectronicsInc.
Address: 680Kinderkamack
Road,Oradell,NJ
07649 U.S.A.
TelephoneNo.: 201-930-6972
This devicecomplieswith Part 15of the
FCCRules.Operationis subjectto the
following two conditions:(1)This device
maynot causeharmful interference,and
(2) this devicemustacceptany
interferencereceived,including
interferencethatmay causeundesired
operation.
lo prevent fire or shock hazard, do
not expose the unit to rain or
moisture.
This symbolis intendedto
alerttheusertothepresence
of uninsulated“dangerous
voltage” within the
product’senclosurethat
maybeof sufficient
magnitudeto constitutea
risk of electric shockto
persons.
n
This symbol is intendedto
I
alerttheuserto thepresence
of importantoperatingand
maintenance(servicing)
l
instructionsin theliterature
accompanyingthe
appliance.
CAUTION
The useof optical instrumentswith this
productwill increaseeyehazard.As the
laserbeamusedin this camerais harmful to
eyes,donot attemptto disassemblethe
cabinet.
Referservicingto qualified personnelonly.
If youhaveanyquestionsaboutthisproduct,
you ma&call:
SonyCustomerInformation Center
l-800-222~SONY(7669)
Thenumberbelow is for theFCCrelated
mattersonly.
CAUTION
J
You arecautionedthat anychangesor
modifications not expresslyapproved
in this manualcould void your
authority to operatethis equipment.
Declaration of Conformity
TradeName: SONY
Model No.: MVCCD300
ResponsibleParty:SonyElectronicsInc.
Address: 680 Kinderkamack
Road,Oradell,NJ
07649 U.S.A.
TelephoneNo.: 201-930-6972
This devicecomplieswith Part 15of the
FCCRules.Operationis subjectto the
following two conditions:(1)This device
maynot causeharmful interference,and
(2) this devicemustacceptany
interferencereceived,including
interferencethatmaycauseundesired
operation.
Note:
This equipmenthasbeentestedandfoundto
comply with thelimits for aClassB digital
device,pursuantto Part 15of theFCC
Rules.Theselimits aredesignedto provide
reasonableprotectionagainstharmful
interferencein aresidentialinstallation.This
equipmentgenerates,uses,andcanradiate
radiofrequencyenergyand,if notinstalled
andusedin accordancewith the
instructions,maycauseharmful interference
to radiocommunications.However.thereis
2

noguaranteethatinterferencewill not occur
in aparticular installation. If this equipment
doescauseharmful interferenceto radioor
televisionreception,which canbe
determinedby turningtheequipmentoff and
on,theuseris encouragedto try to correct
theinterferenceby oneor moreof the
following measures:
-Reorient orrelocatethereceivingantenna.
-Increase theseparationbetweenthe
equipmentandreceiver.
-Connect theequipmentinto anoutleton
acircuit different from thatto which the
receiveris connected.
-Consult thedealeror anexperienced
radio/TV technicianfor help.
Thesuppliedinterfacecablemustbeused
with theequipmentin orderto comply with
thelimits for adigital devicepursuantto
SubpartB of Part 15of FCC Rules.
About Ferrite Core
Be sureto attachthesuppliedferrite coreto
thecableof theAC poweradaptor.This
ferrite corecanreducenoises.Referto the
addendumfor thedetails.
DISPOSAL OF LITHIUM ION
BATTERY.
LITHIUM ION BATTERY.
DISPOSE OF PROPERLY.
Youcanreturnyour unwantedlithium ion
batteriesto your nearestSonyService
Centeror FactoryServiceCenter.
Note:
In someareasthedisposalof lithium ion
batteriesin householdor businesstrashmay
beprohibited.
FortheSonyServiceCenternearestyoucall
I-SOO-222-SONY(United Statesonly)
FortheSonyFactoryServiceCenternearest
you call 416-4?-SONY (Canadaonly)
Caution:
Do not handledamagedor leaking lithium
ion battery.
A mouldedplugcomplying with BS 1363is
fitted to this equipmentfor your safetyand
convenience.
Shouldthefusein theplug suppliedneedto
bereplaced,a5 AMP fuseapprovedby
ASTA or BSI to BS 1362,(i.e. markedwith
v or 8 mark)mustbeused.
If theplug suppliedwith this equipmenthas
adetachablefusecover,besureto attachthe
fusecoverafteryou changethefuse.Never
usetheplug without thefusecover.If you
shouldlosethefusecover,pleasecontact
your nearestSonyservicestation.
Directive:EMC Directive 89/336/EEC,
9213 I/EEC
This equipmentcomplieswith theEMC
regulationswhenusedunderthe following
circumstances:
l Residentialarea
l Businessdistrict
l Light-industry district
(This equipmentcomplieswith theEMC
standardregulationsEN55022ClassB.)
Attention
Theelectromagneticfields atthespecific
frequenciesmayinfluencethe pictureand
soundof thiscamera.
This producthasbeentestedandfound
compliant with thelimits setsout onthe
EMC Directive for usingconnectioncables
shorterthan3meters(9.8 feet).
3

Operating instructions
Beforeoperatingtheunit, pleasereadthis
manualthoroughly,andretainit for future
reference.
The instructionsin this manualarefor the
two models:MVCCD200, MVC-CD300.
TheMVC-CD300 is themodelusedfor
illustration purposes.
Otherwise,themodelnameis indicatedin
theillustrations. Any differencesin
operationareclearly indicatedin thetext,
for example,“MVC-CD300 only.”
As you readthroughthis manual,buttons
andsettingsonthecameraareshownin
capitalletters.
e.g.PressDISPLAY/LCD BACK LIGHT
ON/OFF.
This digital still camerauses8 cm CD-Rsl
CD-RWsasrecordingmedia.“CD-R” or
“CD-RW” mentionedaboveis indicatedas
“disc” in this manual.Whenadistinction
betweenCD-RsandCD-RWs is necessary,
“disc” is indicatedas“CD-R’ or “CD-RW.”
l We reconnnend that you
use this camera with
Mavlca discs*.
l While the image is being
recorded on the disc, the
ACCESS lamp lights up
(red). When this lamp is
lit, do not shake or strike
the camera.
* TheMavica discisan8cmCD-R/CD-RW
with theMavica logo.
Trial recording
Beforeyourecordone-timeevents,you may
wantto makeatrial recordingto makesure
thatthecamerais working correctly.
No compensation for contents of
the recording
Contentsof therecordingcannotbe
f+ompensatedfor if recordingor playback is
notmadedueto amalfunction of your
cameraor recordingmedium,etc.
Notes on image data compatibility
This cameraconformswith theDesignrule
for CameraFile systemuniversalstandard
establishedby theJEITA (JapanElectrics
andInformation TechnologyIndustries
Association).
Precaution on copyright
Televisionprograms,films, videotapes,and
othermaterialsmaybecopyrighted.
Unauthorizedrecordingof suchmaterials
maybecontraryto theprovision of the
copyright laws.
Do not shake or strike the camera
In addition to malfunctionsandinability to
recordimages,this mayrenderthediscs
unusableor imagedatabreakdown,
damage
or lossmayoccur.
LCD screen, finder (only models
with a finder) and lens
l TheLCD screenandthefinder are
manufacturedusingextremelyhigh-
precisiontechnologysoover99.99%of
thepixels areoperationalfor effectiveuse.
However,theremaybesometiny black
pointsand/orbright points(white, red,
blueor greenin color) thatconstantly
appearon theLCD screenandthefinder.
Thesepoints arenormalin the
manufacturingprocessanddo not affect
therecordingin anyway.
l Becareful whenplacing thecameraneara
window or outdoors.ExposingtheLCD
screen,the tinder or thelensto direct
sunlight for long periodsmaycause
malfunctions.
Do not get the camera wet
Whentaking picturesoutdoorsin therainor
undersimilar conditions,becarefulnot to
getthecamerawet.If moisture
condensationoccurs,referto page87and
follow theinstructionsonhow to removeit
beforeusingthecamera.
Back up recommendation
To avoidthepotentialrisk of dataloss,
alwayscopy (backup)datato adisc.
When the camera is used for long
periods
Notethat thecamerabodymaybecome
hot.
Handling of the movable lens
This camerausesamovablelens.Be
careful
notto strikeor apply excessiveforceto the
lensportion.

Table of contents
Introduction ........................................6
Identifying theparts............................7
Preparingthepowersupply ................9
Settingthedateandtime ..................14
Insertingadisc .................................. 16
b Recording
Initializing adisc(INITIALIZE) .. 18
Recordingstill images......................20
Recordingmoving images. . . . . 26
F Playback
Playingbackstill images .. . . . 28
Playingbackmoving images . . .29
Preparationfor viewing imagesusinga
computer ....................................31
Viewing imagesusingacomputer ...35
Imagefile storagedestinationsand
imagefile names . .. . . . . 43
Recordingtext documents(TEXT) ...61
Recordingstill imagesasuncompressed
files (TIFF) .................................62
Recordingthreeimageswith the
exposureshifted(only for MVC-
CD300)(EXP BRKTG) .............63
CreatingClip Motion Files ................64
Settingthedistanceto thesubject .....66
Recordingimagesin macro . . . 66
Adjusting theexposure
(EXPOSURE) . .. . . .. . . . .67
Adjusting thewhite balance
(WHITE BALANCE) .................68
Enjoying pictureeffects
(P.EFFECT) ...............................69
Recordingthedateandtime onthestill
image(DATE/TIME) . ........ .70
UsingtheSpotlight-meteringfunction 71
b Various playback
Playingbackthreeor nineimagesat
once ............................................72
Enlargingapartof thestill image
(Zoomandtrimming) . .. .73
Plavinebackthestill imaeesin order
-(SLIDE) . .. .T . .. 74
Rotatingastill image(ROTATE) .....75
Viewing imagesonaTV screen. 76
Before performing
advanced operations
How to usethemodedial .................4.5
How to usethecontrol button . . 46
How to usethejog dial .....................48
Menu settings....................................49
Settingtheimagesize
(IMAGE SIZE) ..........................53
b Various recording
Recordingwith theexposurefixed
(AE LOCK) . . . . .. . . . .. . 55
Recordingwith themanualadjustments
. .. .. .. . .. . . . . . . . . ... 56
Recordingimagesaccordingtoshooting
conditions
(SCENESELECTION) .............58
Recordingthreeimagescontinuously
(B ‘RST)
u(on y for MVC-CD300) .............59
Recordingstill imagesfor e-mail
(E-MAIL) ...................................59
Adding audiofiles to still images
(VOICE) ....................................60
F Editing
Deletingimages(DELETE) ..............77
Preventingaccidentalerasure
(PROTECT) .. .......... . . . . .78
Changingtherecordedstill imagesize
(RESIZE) .................. . . . . 80
Selectingstill imagesto print
(PRINT) ......................................81
FormattingaCD-RW . . . . . . . 82
Changingthesetupsettings
(SETUP) . . . . . . .84
.,:
‘__
Precautions........................................87
Ondiscs .............................................89
Usingyour cameraabroad ................90
About “InfoLITHIUM” batterypack 91
Troubleshooting ................................93
Warningandnoticemessages........,100
Self-diagnosisdisplay ....................,102
Specifications.................................,103
LCD screenindicators .....................105
Index ...................................Backcover
5

introduction
Captures images with your computer
You caneasily copy imagesonto your computerthroughaCD-ROM drive, CD-R
drive, CD-RW drive, or the USB cableandview andmodify imageson your
computerusing application software.When usingaCD-ROM drive to view images
on your computer,thefinalization is required(page32).
Flow chart for disc operations
piq 0 : CD-R
: CD-RW
:Required
l Thediscfinalizedwith acomputerorotherequipment time
Recordingis complete
Discpreparationfor
recordingis complete.
Blaedisc [About7 minl
(paw 82)
Thediscspaceis fully
available.
Discpreparation
forviewingthrough
aCD-ROMdriveis
complete.
6

Identifying the parts
Seethepagesin parenthesesfor detailsof operation.
d
q Shutter button (20,26)
q Built-in microphone
Do not touch while recording.
q Bgery cover (bottom surface)
q Lens
q Tripod receptacle (bottom surface)
Useatripod with ascrewlengthof
lessthan6.5 mm (7/32 inch). You
cannotfirmly securethecamerato
tripods having longer screws,and
maydamagethecamera.
q Accessory shoe
q Photocell window for flash
Do not block while recordingwith
theflash.
q Flash (24)
q
? If-timer IamplAF illuminator
( 4925)
q Hook for strap and lens cap
q Disc cover OPEN lever (16)
q ACC (Accessory) jack
Connectsanexternalflash or other
equipment.
q Lens cap (supplied)
q USB jack (36)
q AN OUT (MONO) jack (76)
Audio output is monaural.
About the Carl Zeiss lens (MVC-
CD300 only)
This camerais equippedwith aCarl Zeiss
lenswhich is capableof reproducingfine
images.Thelensfor this camerausesthe
MTF* measurementsystemfor cameras
developedjointly by Carl Zeiss,in
Germany,andSonyCorporation,and
offers thesamequality asotherCarl Zeiss
lenses.
* MTF is anabbreviationof Modulation
TransferFunctioniFactor,anumeric
valueindicatingtheamountof light from
aspecificpartof thesubjectgatheredat
thecorrespondingposition in theimage.
7

IA-
Mode dial (45)
POWER switch (14)
q (Exposure) button (67)
$ /CHG (Charge) lamp (10,25)
FOCUS button (66)
Photocell window for LCD
screen
The LCD screenbecomesbrighter
whenexposedto sunlight.
LCD screen
Disc window
DISPLAY/LCD BACK LIGHT ON/
OFF-button (23)
AC&S lamp (20)
Hook for strap
[a] (Spot meter) button (71)
AE LOCK button (55)
Zoom W/T buttons (22)
Jog dial (48)
POWER ON/OFF (CHG) lamp
(14)
Speaker
Control button (46)
MENU button (46)
q Reset button (99)
q DC IN cover/DC IN jack (10,13)
8

Preparing the power supply
installing the battery pack
Your cameraoperatesonly with theNP-PM50 (supplied)“InfoLITHIUM” battery 3.
pack* (M series).Seepage91 for moreinformation about“InfoLITHIUM” battery z
pack.
@ Open the battery cover.
Slide thebattery coverin thedirection of the arrow.
@ Install the battery pack.
Insertthebattery packwith theA mark facing toward thebatterycompartment
asillustrated.
0 Close the battery cover.
To remcve the battery pack
Open the battery cover. Slide the battery eject lever in the arrow direction,
and remove the battery pack.
Be careful not to drop thebatterypackwhen removing it.
Batteryeject lever
* What is “Vi?foLITHIlJM”?
“InfoLITHIUM” is alithium ion battery pack which canexchangeinformation suchasbattery
consumptionwith compatiblevideoequipment.“InfoLITHIUM” M seriesbatterypackshave
the @-?a mark. “InfoLITHIUM” is atrademarkof SonyCorporation.
.,*,,*
9

Charging the battery pack
Whenthecamerais turnedon, you cannotchargethebatterypack.Besureto turn off
thepower of thecamera.
0 Insert the battery pack into your camera.
0 Open the DC IN cover and connect the AC power adaptor to the DC
IN jack of your camera with the A mark facing up.
0 Connect the power cord (mains lead) to the AC power adaptor and
then to a wall outlet (mains).
The 5 /CHG lamp (orange)abovetheLCD screenlights up whencharging
begins.When the 5 KHG lamp goesoff, full charge is completed.
After charging the battery pack
DisconnecttheAC power adaptorfrom the DC IN jack on your camera.
Battery remaining indicator
The LCD screenon thecamerashowsthe remainingtime for which you canstill
recsd or play backimages.
This indication may not beentirely accuratedependingon the conditionsof useand
theoperatingenvironment.
Chargingat aroom temperatureof 10°Cto 30°C (50°F to 86°F) is recommended.
10

NPFM50 (supplied) battery pack
When you record imagesin anextremelycold location or usingtheLCD backlight,
theoperatingtime becomesshort.When usingthe camerain anextremely cold
location, placethebattery packin your pocketor otherplacesto keepit warm, then
insert thebattery packinto thecamerajust before recording.Whenusing apocket
heater,takecarenot to let the heaterdirectly contactthebattery. g
Note on the 5 /CHG lamp during charging tz
The 5 KHG lamp mayflash:
l When amalfunction occursin thebattery pack (page99).
The f /CHG lamp doesnot light up:
l Whenthebattery packis not installed properly. b
Approximatetime to chargeacompletelydischargedbatterypackatatemperatureof
25°C (77°F).
Still image recording/playback
Continuousplayback** Approx. 120 Approx. 1000
Approximate battery life andnumberof imagesthatcanberecorded/playedbackata
temperatureof 25°C (77°F) with afully chargedbatterypack,using640x480 image
size,standardimagequality, andNORMAL recordingmode.
* Recordingat aboutSsecondintervals
**Playing backsingle-displayedimagescontinuously at about7-secondintervals
Moving image recording
1Contint& recording 1 Approx. 120 1
Approximate time that canberecorded160x112-sizedimagesatatemperatureof
25°C (77°F) with afully chargedbattery pack.
11

Notes
l Thebatterylife andnumberof imageswill bedecreasedwhenusingat low temperature,using
theflash, turning thepoweron/off frequently,or usingthezoom.
l Thenumbersof imagesshownon tablesaboveareasaguide.Thenumbersmaybesmaller
dependingonconditions.
l If sufficient batteryremainingtime is indicatedbutthe powerrunsoutsoon,fully chargethe
batterysothat thecorrectbatteryremainingtime appears.
l Do not shorttheDC plug of theAC poweradaptorwith ametallic object,asthis maycausea
malfunction.
12

Using the AC power adaptor
@ Open the DC IN cover and connect the AC power adaptor to the DC
IN jack of your camera with the A mark facing up.
0 Connect the power cord (mains lead) to the AC power adaptor and
then to a wall outlet (mains).
Using a car battery
UseaSonyDC adaptor/charger.
Using your camera abroad
For details,seepage90.
When using the AC power adaptor
Be sureto useit nearthe wall outlet (mains).If amalfunction occurs,disconnectthe
plug from thewall outlet (mains).
13

Setting the date and time
When you first useyour camera,setthe dateandtime. If thesearenot set,the
CLOCK SET screenappearswheneveryou turn on your camera.
@ Set the mode dial to m, S, A, M, a, SCN, or q .
0 Push the POWER switch in the arrow direction to turn on the
power.
The POWER ON/OFF (CHG) lamp (green)lights up.
The CLOCK SET screenappears.
Whenresettingthedateandtime onceyou set,setthemodedial to SET UP
(page84) andthenfollow theprocedurefrom step0.
0 Select the desired date display format with
AIV on the control button, then press the
center 0.
Selectfrom [Y/M/D] (year/month/day), [M/D/Y]
(month/day/year),or [D/M/Y] (day/month/year).
0 Select the year, month, day, hour or minute
item you want to set with 4+ on the control
button.
The item to besetis indicatedwith &I.
F
14

@ Set the numeric value with A/V on the
control button, then press the center 0 to
enter it.
After enteringthe number,A/I movesto the next
item. If you selected[D/M/Y] in step0, setthe
time on a24-hourcycle.
0 Select [OK] with F on the control button, u,
then press the center 0 at the desired B
moment to begin clock movement. 2
The dateand time areentered. b
To cancel the date and time setting
Select[CANCEL] with A/I/d/b on thecontrol button,thenpressthecenter0.
P
15

n useonly the 8 cm CD-Rs or 8 cm CD-RWs that havethese
0 While sliding the lock tab to the left, slide down the disc cover
OPEN lever.
Openthedisc coverby your handafter thecoveris unlocked.
0 Place a disc with the printed side up.
Pushdown thecenterof thedisc until it clicks. When installing, do not push
with too much force anddo not touch thepickup lens.
0 Close tile disc cover.
16

While sliding thelock tabto t
thedisc coverafterthecoveris unlocked.Then,removethedisc asillustrated below.
.
Notes
l Beforeremovingthedisc, besureto checkthat thedisc is not rotating.
l Donot openthedisccoverwhile theACCESSlamp is lit. If you do,therecordedimagemaybe
damagedor thediscmaybecomeunusable.
l Whenwriting dataon adisc or conhectingwith acomputerusingtheUSB connection,thedisc
coverOPEN leveris locked.
17

Initializing a disc (INITIALIZE)
When you useanewdisc or the disc which wasfinalized with otherequipmentthan
this camera(page32), you haveto initialize thedisc.Before initializing thedisc,
pushthe POWER switch in the arrow direction to turn on thepower andinsertthe
disc.
0 Set the mode dial to m, S, A, M, SCN, or ll3.
“INITIALIZE PLACE ON LEVEL SURFACE” appearson theLCD screen.
Be sureto avoid anyvibration during the initialization in step0.
0 Select [OK] with A on the control button, then press the center 0.
Initialization starts.
To cancel the initialization
Select[CANCEL] with v on thecontrol button, thenpressthe center0.
To initialize after canceling the initialization
Opekand closethedisc cover.Or setthe modedial to m, S,A, M, SCN, or [#1,
pressA on thecontrol button, thenpressthecenter0.
18

what is initialization?
The initialization is requiredto recordimageson adisc.
In casethat you haveexecutedthefinalization (page32) usingthecamerato view
imageson a CD-ROM drive, theinitialization is automatically executed.Youcan
continuouslyrecordimages.When executingthefinalization usingacomputeror
otherequipment,executethe initialization to recordnewimages.Imagesrecorded
beforefinalization will remainon thedisc.
Tip
Youcanalsoexecutetheinitialization using [@ ] (DISC TOOL) in thesetupsettings
(page84).
F
19

Recording still images
Still imagesarerecordedin JPEGformat. Before recording still images,pushthe
POWER switch in thearrow direction to turn on thepowerandinsert adisc.
@ Set the mode dial to m, S, A, M, or SCN.
Press and hold the shutter button halfway down.
The beepssound.However, the image has not been recorded yet. While the
AE/AF lock indicator is flashing, thecameraautomaticallyadjuststhe
exposureandfocusof ecapturedimage.When th erafinishesthe
automaticadjustments, the AE/AF lock indicator ps flashing, then
lights up, and the camera is ready for recording.
If you releasetheshutterbutton, therecordingwill becanceled.
AE/AFlockindicator(green)
flashes-+ lightsup
20
