Sony AWP-ZX7 User manual

©2004 Sony Corporation
4-254-179-11(2)
Operating Instructions
Owner’s Record
The model and serial numbers are located on the rear of the unit. Record the
serial number in the space provided below. Refer to them whenever you call
upon your Aiwa dealer regarding this product.
Model No. ______________ Serial No. ______________

2GB
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To prevent fire, do not cover the ventilation of the
apparatus with news papers, table-cloths, curtains, etc.
And don’t place lighted candles on the apparatus.
To prevent fire or shock hazard, do not place objects
filled with liquids, such as vases, on the apparatus.
This appliance is
classified as a CLASS 1
LASER product. This
markingislocatedonthe
rear exterior.
Don’t throw away the battery with
general house waste, dispose of it
correctly as chemical waste.
NOTICE FOR THE CUSTOMERS IN THE
U.S.A.
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operatingandmaintenance(servicing)
instructions in the literature
accompanying the appliance.
CAUTION
The use of optical instruments with this product will
increase eye hazard.
WARNING
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV
technician for help.
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building, as
close to the point of cable entry as practical.
CAUTION
You are cautioned that any changes or modifications
not expressly approved in this manual could void your
authority to operate this equipment.
WARNING
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.

3GB
NOTICE FOR THE CUSTOMERS IN THE
U.S.A.
If you have any questions about this product, you may
call; Aiwa Customer Information Service Center
1-800-289-2492 or http://www.us.aiwa.com/
The Number below is for the FCC related matters only.
Regulatory Information
NOTICE FOR THE CUSTOMERS IN CANADA
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
CAUTION
The use of optical instruments with this product will
increase eye hazard.
Except for European model
ENERGY STAR®is a U.S.
registered mark. As an ENERGY
STAR®partner, Sony Corporation
has determined that this product
meets the ENERGY STAR®
guidelines for energy efficiency.
Declaration of Conformity
Trade name: AIWA
Model No.: AWP-ZX7
Responsible Party: Sony Electronics Inc.
Address: 16450 W. Bernardo Dr, San
Diego, CA 92127 U.S.A.
Telephone No.: 858-942-2230
This device complies with Part 15of the FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• Microsoft, Windows and Windows NT are
trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
• IBM and PC/AT are registered trademarks of
International Business Machines Corporation.
• Macintosh is a trademark of Apple Computer, Inc. in

4GB
How to use this manual...........................5
Playable discs..........................................5
Getting Started
Hooking up the system............................7
Setting the clock......................................9
CD/MP3 – Play
Loading a disc.......................................10
Playing a disc........................................10
— Normal Play/Shuffle Play
Playing repeatedly.................................12
— Repeat Play
Creating your own program..................13
— Program Play
Tuner
Presetting radio stations........................14
Listening to the radio............................15
— Preset Tuning
— Manual Tuning
Using the Radio Data System (RDS)....16
(European model only)
Tape – Play
Loading a tape.......................................17
Playing a tape........................................17
Tape – Recording
Recording your favorite CD tracks on a
tape..................................................18
— CD-TAPE Synchro Recording
Recording on a tape manually...............19
— Manual Recording
Sound Adjustment
Adjusting the sound ..............................20
Timer
Falling asleep to music......................... 20
— Sleep Timer
Waking up to music.............................. 21
— Play Timer
Timer recording radio programs........... 22
— Rec Timer
Display
Turning off the display......................... 23
— Power Saving Mode
Viewing information about the disc in the
display ............................................ 23
Optional Personal Computer
Connecting a personal computer to the
system............................................. 25
Installing the driver............................... 26
Listening to audio files on a personal
computer......................................... 29
Optional Components
Hooking up optional components......... 30
Listening to audio from a connected
component...................................... 31
Troubleshooting
Problems and remedies......................... 32
Messages............................................... 35
Additional Information
Precautions ........................................... 36
Specifications ....................................... 37
List of button locations and reference
pages............................................... 39
Table of Contents

5GB
This manual mainly explains operations using
the remote, but the same operations can also be
performed using the buttons on the system
having the same or similar names.
You can play back the following discs on this
system. Other discs cannot be played back.
List of playable discs
Discs that this system cannot
play
• An 8 cm disc
• An 8 cm disc converted to a standard disc
using an adaptor
•CD-ROMs
• CD-Rs/CD-RWs other than those recorded in
the following formats:
– music CD format
– MP3 format that conforms to ISO9660

6GB
Notes on CD-R and CD-RW
• Some CD-Rs or CD-RWs cannot be played
on this system depending upon the recording
quality or physical condition of the disc, or
the characteristics of the recording device.
Furthermore, the disc will notplayif it has not
been correctly finalized. For more
information, see theoperatinginstructions for
the recording device.
• Discs recorded on CD-R/CD-RW drives may
not be played back because of scratches, dirt,
recording condition or the driver’s
characteristics.
• CD-R and CD-RW discs recorded in multi-
session that have not ended by “closing the
session” are not supported.
• The system may be unable to play MP3
format files that do not have the “.MP3”
extension.
• Attempting to play non-MP3 format files that
havethe“.MP3”extensionmayresultin noise
or malfunction.
• With formats other than ISO9660 level 1 and
2, folder names or file names may not be
displayed correctly.
• The following discs take a longer time to start
playback.
– a disc recorded with complicated tree
structure.
– a disc recorded in Multi Session.
– a disc to which data can be added (non-
finalized disc).
Music discs encoded with
copyright protection
technologies
This product is designed to playback discs that
conform to the Compact Disc (CD) standard.
Recently, various music discs encoded with
copyright protection technologies are marketed
by some record companies. Please be aware that
among those discs, there are some that do not
conform to the CD standard and may not be
playable by this product.
Cautions when playing a disc
that is recorded in Multi
Session
• If the disc begins with a CD-DA session, it is
recognized as a CD-DA (audio) disc, and
playback continues until an MP3 session is
encountered.
• If the disc begins with an MP3 session, it is
recognized as an MP3 disc, and playback
continues until a CD-DA (audio) session is
encountered.
• The playback range of an MP3 disc is
determined by the tree structure of files
produced by analyzing of the disc.
• A disc with a mixed CD format will be
recognized as a CD-DA (audio) disc.

Getting Started
7GB
Perform the following procedures 1to 4to hook up your system using the supplied cords and
accessories.
1Connect the speakers.
Connect the right and left speaker cords to
the SPEAKER terminals as shown below.
Main Unit
Speakers
Getting Started
Hooking up the system
AM loop antenna
Right speaker Left speaker
FM lead antenna
Copper (3) Silver (#)
Insert only the stripped portion
Copper (3)Silver (#)
Insert only the stripped portion
continued

8GB
2Connect the FM and AM antennas.
Set up the AM loop antenna, then connect
it.
Plug type A
Plug type B
Note
Keep the antennas away from the speaker cords.
3For models with a voltage selector, set
VOLTAGE SELECTOR to the local
power line voltage.
Refer to the print on your system’s
VOLTAGE SELECTOR for available
settings.
4Connect the power cord to a wall
outlet.
If the plug does not fit the wall socket,
detach the supplied plug adaptor (only for
models equipped with an adaptor).
To turn on the system, press ?/1.
Inserting two R6 (size AA)
batteries into the remote
Note
If you do not use the remote for a long period of time,
remove the batteries to avoid possible damage from
battery leakage and corrosion.
Tip
When the remote no longer operates the system,
replace both batteries with new ones.
AM
LOOP
FM 75 Ω
(COAXIAL)
Extend the FM lead antenna horizontally
AM loop antenna
AM
LOOP
FM 75 Ω
(COAXIAL)
Extend the FM lead antenna horizontally
AM loop antenna

Getting Started
9GB
Attaching the speaker pads
Attach the supplied speaker pads to the bottom
of the speakers to stabilize the speakers and
prevent them from slipping.
Use buttons on the remote for the operation.
1Press ?/1 to turn on the system.
2Press CLOCK/TIMER SET.
3Press .or >repeatedly to set the
hour.
4Press ENTER.
5Press .or >repeatedly to set the
minute.
6Press ENTER.
The clock starts working.
To adjust the clock
1Press CLOCK/TIMER SET.
2Press .or >until “CLOCK SET?”
appears, then press ENTER.
3Do the same procedures as step 3 to 6
above.
Notes
• The clock settings are canceled when you disconnect
the power cord or if a power failure occurs.
• You cannot set the clock in Power Saving Mode
(page 23).
When carrying this system
Perform the following procedure to protect
the CD mechanism.
1Make sure that all discs are removed
from the system.
2Press FUNCTION repeatedly to switch
the function to CD.
3Hold down ZCD and then press Mon
the unit until “STANDBY” appears.
After “STANDBY” disappears, then
“LOCK” appears.
4Unplug the power cord.
Setting the clock

10GB
Use buttons on the unit for the operation.
1Press DISC 1 – 5 to select a disc
stocker.
If a disc is loaded, press ZCD to remove a
disc from the disc slot. “No Disc” appears.
2Insert a disc in the disc slot with the
label side facing right.
To insert additional discs, repeat steps 1
through 2.
Notes
• When you turn on the system, the disc is not
pulled into the disc slot until “No Disc”
appears in the display. Do not attempt to
push in the disc until “No Disc” appears.
• When pressing ZCD and then reinserting the disc
that appears inthe disc slot, donot simply push inthe
disc. Remove the disc from the disc slot and then
reinsert it.
• Do not turn off the system with a disc halfway
inserted in the disc slot. Doing so may cause the disc
to fall.
• Do not use a disc with tape, seals or paste on it as this
may cause malfunction.
• Do not load an 8 cm disc with an adaptor. Doing so
may cause the system to malfunction.
• When you eject a disc, handle the disc by its edge. Do
not touch the surface.
• If you load a disc that is not playable by this system,
it will be ejected automatically.
This system lets you play audio CDs and discs
with MP3 audio tracks.
Example: When a disc is loaded
1Press CD (or FUNCTION repeatedly) to
switch the function to CD.
CD/MP3 – Play
Loading a disc
Whenyouplay
a disc, insert it
with the label
side facing
right.
Playing a disc
— Normal Play/Shuffle Play
PLAYTITLEID3TRKALBM
AUTOPRESETMP3 MONOSTEREO TUNEDTRACKALBUM
DISC S ALBM REP1 PGM SHUF
TREBLE
LEVEL R i - Bass
BASS
00
LEVEL L
SYNC
REC
ALL SLEEPREC
1
2
3
4
5
1
Track number
Playing time
Disc indicato
r

CD/MP3 – Play
11GB
2Press PLAY MODE in stop mode
repeatedly until the mode you want
appears.
3Press N(or CD NX on the unit).
Other operations
1) You may not be able to search between multiple
files. Also, the time may not be displayed correctly
for some files.
2) You cannot select an empty disc stocker.
Select To play
ALL DISCS
(Normal Play) All discs in the disc slot continuously.
1DISC
(Normal Play) The tracks on the disc you have selected in original
order.
ALBM
(Normal Play) All MP3 audio tracks in the album on the disc you have
selected in original order.
When playing a non-MP3
disc, Album Play becomes
1DISC Play.
ALL DISCS
SHUF (Shuffle
Play)
The tracks on all discs in
random order.
1DISC SHUF
(Shuffle Play) The tracks on the disc you have selected in random
order.
ALBM SHUF
(Shuffle Play) The MP3 audio tracks in the album on the disc you have
selected in random order.
When playing a non-MP3
disc, Album Shuffle Play
becomes 1DISC SHUF Play.
PGM
(Program Play) The tracks on the disc in the order you want them to be
played (see “Creating your
own program” on page 13).
To Do this
Stop play Press x.
Pause Press X(or CD NX on the unit).
Press again to resume play.
Select a track Press .or >repeatedly.
Select an album
of MP3 Press ALBUM – or + repeatedly after step 2.
Find a point in a
track1) Keep pressing mor Mduring playback and release it at the
desired point.
Select a disc Press DISC SKIP2) (or DISC 1 – 5
on the unit).
Switch to CD
function from
another source
Press DISC 1 – 5 on the unit
(Automatic Source Selection).
Remove a disc Press DISC 1 –5, then press ZCD
on the unit.
continued

12GB
Notes
• You cannot change the play mode during playback.
• Some time may be needed to start playback of discs
recorded in complex configurations such as many
layers.
• When the disc is inserted, the player reads all the
tracks on that disc. If there are many albums or non-
MP3 audio tracks on the disc, it may take a long time
for play to begin or for the next MP3 audio track to
start play.
• Do not save unnecessary albums or tracks other than
MP3 ones in the disc to be used for MP3 listening.
We recommend that you do not save other types of
tracks or unnecessary albums on a disc that hasMP3
audio tracks.
• An album that does not include an MP3 audio track
is skipped.
• Maximum album number: 150 (including root
folder)
• The maximum number of MP3 audio tracks and
albums that can be contained on a single disc is 300.
• Playback is possible up to 8 levels.
• MP3 audio tracks are played back in alphabetical
order.
• Depending on the encoding/writing software,
recording device, or the recording media used at the
time an MP3 audio track is recorded, you may
encounter such problems as disabled playback,
sound interruptions, and noise.
Tip
When disc access takes a long time, set “CD POWER
ON” by CD power manage function (page 15).
You can play all the tracks or a single track on a
disc repeatedly.
Press REPEAT repeatedly during playback
until “REP” or “REP1” appears.
REP: For all the tracks on a disc, or all the MP3
audio tracks in an album up to five times.
REP1: For a single track only.
To cancel Repeat Play
Press REPEAT repeatedly until both “REP” and
“REP1” disappear.
Notes
• You cannot select “REP” and “ALL DISCS SHUF”
at the same time.
• When you select “REP1”, that track is repeated
endlessly until “REP1” is canceled.
Playing repeatedly
— Repeat Play

CD/MP3 – Play
13GB
You can make a program of up to 25 steps from
all the discs in the order you want to play them.
You can synchro record the programmed tracks
onto a cassette tape (page 18).
1Press CD (or FUNCTION repeatedly) to
switch the function to CD.
2Press PLAY MODE in stop mode
repeatedly until “PGM” appears.
3Press DISC SKIP (or DISC 1 – 5 on the
unit) to select a disc.
To program all the tracks on a disc at once,
proceed to step 5 with “AL” displayed.
4Press .or >repeatedly until the
desired track number appears.
When programming the MP3 audio tracks,
press ALBUM – or + to select album, then
press .or >repeatedly until the
desired track number appears.
5Press ENTER (or PLAY MODE).
The track is programmed.
The step number appears, followed by the
last programmed track number.
6Program additional discs or tracks.
7Press N(or CD NX on the unit).
Program Play starts.
Other operations
Tips
• The program you made remains after Program Play
finishes. To play the same program again, press CD
(or FUNCTION repeatedly) to switch the function to
CD, then press N(or CD NX on the unit). When
you eject a disc after programming tracks from
multiple discs, only the tracks contained on the
ejected disc are deleted from the program.
• “– –.– –” appears when the total CD program time
exceeds 100 minutes, or when you select a CD track
whose number is 21 or over, or when you select an
MP3 audio track.
Creating your own
program
— Program Play
PLAYTITLEID3TRKALBM
AUTOPRESETMP3 MONOSTEREO TUNEDTRACKALBUM
DISC S ALBM REP1 PGM SHUF
TREBLE
LEVEL R i - Bass
BASS
00
LEVEL L
SYNC
REC
ALL SLEEPREC
1
2
3
4
5
1
Selected track number
Total playing time
To program Repeat steps
Other discs 3 and 5
Othertracksonthe
same disc 4 and 5
Other tracks on
other discs 3 to 5
To Do this
Cancel Program Play Press PLAY MODE in
stopmoderepeatedlyuntil
“PGM” disappears.
Clear a track from the end Press CLEAR in stop
mode.

14GB
You can preset up to 20 FM stations and 10 AM
stations. You can then tune in any of those
stations simply by selecting the corresponding
preset number.
Automatic tuning preset
You can automatically tune in all of the stations
that can be received in your area and then store
the radio frequency of the desired stations.
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“AUTO” appears in the display.
4Press – or + (or TUNING – or + on the
unit).
The frequency changes as the system scans
for a station. Scanning stops automatically
when a station is tuned in. At that time,
“TUNED” and “STEREO” (for stereo
program only) appear.
If “TUNED” does not appear and the
scanning does not stop
Set the frequency of the desired radio
station as described in steps 3 and 4 of
“Manual tuning preset” (page 14).
5Press TUNER MEMORY.
The preset number flashes. Perform steps 6
and 7 while the preset number flashes.
6Press – or + (or TUNING – or + on the
unit) repeatedly to select the desired
preset number.
7Press ENTER.
8Repeat steps 2 through 7 to preset
other stations.
Tip
Press xto stop scanning.
Manual tuning preset
You can manually tune in and store the radio
frequency of the desired stations.
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“AUTO”and“PRESET”disappearfrom
the display.
4Press – or + (or TUNING – or + on the
unit) repeatedly to tune in the desired
station.
5Press TUNER MEMORY.
6Press – or + (or TUNING – or + on the
unit) repeatedly to select the desired
preset number.
7Press ENTER.
8Repeat steps 2 through 7 to preset
other stations.
Tuner
Presetting radio stations
PLAYTITLEID3TRKALBM
AUTOPRESETMP3 MONOSTEREO TUNEDTRACKALBUM
DISC S ALBM REP1 PGM SHUF
TREBLE
LEVEL R i - Bass
BASS
00
LEVEL L
SYNC
REC
ALL SLEEPREC
1
2
3
4
5
1
Preset number

Tuner
15GB
Other operations
To improve tuner reception
When tuner reception is poor, set CD player
power off by CD power manage function.
CD power is factory set to on.
1Press FUNCTION repeatedly to switch the
function to CD.
2Press ?/1 to turn off the system.
3Press ?/1 while holding xon the unit.
“CD POWER OFF” appears.
To set CD power on
Repeat the procedure above and “CD POWER
ON” appears.
Notes
• When “CD POWER OFF” is selected, disc access
time is increased.
• You cannot change the setting in Power Saving
Mode.
To change the AM tuning interval
(except for European models)
The AM tuning interval is factory-preset to
9 kHz (or 10 kHz for some areas). To change the
AM tuninginterval, tune in any AM station first,
then turn off the system. While holding M,
press ?/1 on the unit. When you change the
interval, all the AM preset stations are erased.
To reset the interval, repeat the same procedure.
Note
You cannot change the AM tuning interval in Power
Saving Mode.
Tips
• The preset stations are retained for about a day even
if you disconnect the power cord or if a power failure
occurs.
• To improve broadcast reception, adjust the supplied
antennas, or connect a commercially available
external antenna.
You can listen to a radio station either by
selecting a preset station, or by manually tuning
in the station.
Listening to a preset station
— Preset Tuning
Preset radio stations in the tuner’s memory first
(see “Presetting radio stations” on page 14).
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“PRESET” appears in the display.
4Press – or + (or TUNING – or + on the
unit) repeatedly to select the desired
preset station.
Listening to non-preset radio
station
— Manual Tuning
1Press TUNER BAND (or FUNCTION
repeatedly) to switch the function to
tuner.
2Press TUNER BAND repeatedly to
select “FM” or “AM”.
3Press TUNING MODE repeatedly until
“AUTO”and“PRESET”disappearfrom
the display.
4Press – or + (or TUNING – or + on the
unit) repeatedly to tune in the desired
station.
Note
When tuner function is selected as the current function
and CD is pressed to select CD during “CD POWER
OFF”, it may take some time to switch the function
(page 15).
To Do this
Tune in a station
with a weak signal Follow the procedure described in “Manual tuning preset”
(page 14).
Set another station
to the existing
preset number
Start over from step 2. After
step 5, press – or + (or
TUNING – or + on the unit)
repeatedly to select the preset
number you want to store the
station.
Listening to the radio
continued

16GB
Tips
• To improve broadcast reception, adjust the supplied
antennas, or connect a commercially available
external antenna.
• When an FM stereo program has static noise, press
FM MODE repeatedly until “MONO” appears.
There will be no stereo effect, but the reception will
improve.
• Press TUNING MODE repeatedly until “AUTO”
appears in step 3 above, then press – or + (or
TUNING – or + on the unit). The frequency
indication changes and scanning stops when the
system tunes in a station (Automatic Tuning).
• To record the radio programs, use manual recording
(pages 19 and 22).
What is the Radio Data
System?
Radio Data System (RDS) is a broadcasting
service that allows radio stations to send
additional information along with the regular
program signal. RDS is available only on FM
stations.*
Note
RDS may not work properly if the station you aretuned
in is not transmitting the RDS signal properly or if the
signal is weak.
* Not all FM stations provide RDS service, nor do they
provide the same types of services. If you are not
familiar with the RDS system, check with your local
radio stations for details on RDS services in your
area.
Receiving RDS broadcasts
Simply select a station from the FM band.
When you tune in a station that provides RDS
services, the station name appears in the display.
To check the RDS information
Each time you press DISPLAY, the display
changes cyclically as follows:
Station name1) tPreset number2) and
frequency tClock display tBass level t
Treble level
1) If the RDS broadcast is not properly received, the
station name may not appear in the display.
2) Preset number is displayed only if you preset radio
stations.
Using the Radio Data
System (RDS)
(European model only)

Tape – Play
17GB
1Press ZPUSH on the unit.
2Load a recorded/recordable tape into
the cassette holder.
You can use TYPE I (normal) tape.
1Press TAPE (or FUNCTION repeatedly)
to switch the function to TAPE.
2Press DIRECTION on the unit
repeatedly to select “g” to play one
side of a tape, “h” to play both sides,
or “j”*to play both sides
repeatedly.
* The tape deck stops automatically after
repeating the sequence five times.
3Press N(or TAPE nN on the unit).
The tape starts playing. Press the button
again to play the reverse side.
Other operations
Tape – Play
Loading a tape
With the side
you want to
play/record
facing towards
you.
Playing a tape
To Do this
Stop play Press x.
Pause Press X. Press again to resume
play.
Fast-forward or
rewind Press mor M.
Remove a tape Press ZPUSH on the unit in stop
mode.

18GB
You can record a whole CD on a tape.
You can use TYPE I (normal) tape.
Use buttons on the unit for the operation.
1Load a recordable tape.
2Load a CD you want to record.
If you have already loaded the disc, press
DISC 1 – 5 to select the disc, then press x.
When you want to record an album from an
MP3 disc, be sure to press PLAY MODE
repeatedly to select ALBM, then use
ALBUM – or + on the remote to select the
desired album before proceeding.
3Press CD SYNC.
“CD SYNCHRO” appears. “REC” flashes.
The tape deck stands by for recording and
the CD player pauses for play.
4Press DIRECTION repeatedly until g
appears to record on one side or h(or
j) to record on both sides.
5Press TAPE nN repeatedly to select
recording side.
If you select both sides recording or front
side recording, press TAPE nN to light
up the Nindicator. If you record on the
reverse side, press TAPE nN again to
light up the nindicator.
6Press zREC PAUSE/START.
Recording starts.
When the recording is completed, the CD
player and the tape deck stop automatically.
To stop recording
Press x.
To record a disc by specifying
track order
You can record only your favorite CD tracks
using Program Play. Between steps 2 and 3,
perform steps 1 to 6 of “Creating your own
program” (page 13).
Tip
If you select both sides recording and the tape reaches
the end of the front side part-way through a track, the
entire track is recorded again from the beginning of the
reverse side.
Tape – Recording
Recording your favorite
CD tracks on a tape
— CD-TAPE Synchro Recording

Tape – Recording
19GB
You can record just the portions you like from a
CD, tape or radio program on a tape.
You can also record from connected
components (see “Hooking up optional
components” on page 30).
Use buttons on the unit for the operation.
1Load a recordable tape.
2Press FUNCTION repeatedly to select
the desired source to record.
• CD: To record from this system’s CD
player.
• FM or AM: To record from this system’s
tuner.
• AUX: To record from the optional
component connected to the AUX IN
jacks.
• PC: To record from the personal
computer connected to the USB port.
3Press zREC PAUSE/START.
“REC” flashes and the tape deck stands by
for recording.
4Press DIRECTION repeatedly until g
appears to record on one side or h(or
j) to record on both sides.
5Press TAPE nN repeatedly to select
recording side.
If you select both sides recording or front
side recording, press TAPE nN to light
up the Nindicator. If you record on the
reverse side, press TAPE nN again to
light up the nindicator.
6PresszRECPAUSE/START,thenstart
playing the desired source to record.
Recording starts.
To stop recording
Press x.
Notes
• You cannot listen to other sources while recording.
• If you press CD, TUNER BAND, TAPE or
FUNCTION during recording and select a sound
source different from the sound source being
recorded, the recording stops.
Tips
• When you record on both sides, be sure to start from
the front side. If you start from the reverse side,
recording stops at the end of the reverse side.
• For recording from the tuner:
If noise is heard while recording from the tuner,
move the respective antenna to reduce the noise.
Recording on a tape
manually
— Manual Recording

20GB
Adjusting the bass and treble
You can adjust the bass and treble to enjoy more
powerful sound.
1Press EQ repeatedly to select “BASS”
or “TREBLE”.
Each time you press the button, the display
changes as follows:
BASS yTREBLE
2Press – or + repeatedly to adjust the
level while “BASS” or “TREBLE”
appears.
To adjust the bass on the unit
Turn BASS control.
To adjust the treble on the unit
Turn TREBLE control.
To exit the bass and treble
settings
Press any button other than EQ or +/–.
Also, if you do not perform any operations for a
fewseconds,thedisplayautomaticallyreturnsto
the original display.
Adjusting the i-Bass
You can reinforce the bass and create a more
powerful sound.
Press i-Bass on the unit.
Each time you press the button, the display
changes cyclically as follows:
i-Bass 1* ti-Bass 2* ti-Bass OFF
* The i-Bass indicator changes.
You can set the system to turn off after a certain
time, so that you can fall asleep to music.
Press SLEEP.
Each time you press the button, the minute
display (the turn-off time) changes cyclically as
follows:
AUTO* t90min t80min t… t10min
tOFF
* The system automatically turns off in 100 minutes or
after the current CD or tape finishes playing.
Other operations
* You cannot check the remaining time if you select
“AUTO”.
Tip
You can use the Sleep Timer, even if you have not set
the clock.
Sound Adjustment
Adjusting the sound
Timer
Falling asleep to music
— Sleep Timer
To Press
Check the
remaining time* SLEEP once.
Change the time
to turn off SLEEP repeatedly to select the time you want.
Cancel the Sleep
Timer Function SLEEP repeatedly until “OFF” appears.
