Sony BDV-N5200W User manual

SERVICE MANUAL
Published by Sony EMCS (Malaysia) PG Tec
Sony Corporation
BLU-RAY DISCTM/DVD HOME THEATRE SYSTEM
9-890-637-02
2014C80-1
© 2014.03
Ver. 1.1 2014.03
BDV-N5200W/N7200W/N7200WL/
N9200W/N9200WL
• BDV-N5200W/N7200W/N7200WL/N9200W/N9200WL are com-
posed of following models. As service manual are issued for each
component model, please refer to them.
COMPONENT MODEL NAME
BDV-
N5200W
BDV-
N7200W
BDV-
N7200WL
BDV-
N9200W
BDV-
N9200WL
Blu-ray discTM/
DVD receiver
HBD-
N5200W
HBD-
N7200W
HBD-
N7200WL
HBD-
N9200W
HBD-
N9200WL
Front
speaker SS-TSB137 SS-TSB135 SS-TSB136 SS-TSB133 SS-TSB134
Center
speaker SS-CTB127 SS-CTB125 SS-CTB126 SS-CTB125 SS-CTB126
Surround
speaker SS-TSB142 SS-TSB140 SS-TSB141 SS-TSB138 SS-TSB139
Subwoofer SS-WSB128 SS-WSB126 SS-WSB127 SS-WSB126 SS-WSB127
Wireless
amplifier
TA-
SA700WR
TA-
SA500WR
TA-
SA600WR
TA-
SA500WR
TA-
SA600WR
SPECIFICATIONS
– Refer to the next page –
US Model
BDV-N5200W/N7200W
Canadian Model
BDV-N9200W
AEP Model
BDV-N5200W/N7200W/N7200WL/
N9200W/N9200WL
UK Model
BDV-N5200W/N7200W/N7200WL
Russian Model
Australian Model
Chinese Model
Saudi Arabia Model
Thai Model
BDV-N9200W/N9200WL
E Model
BDV-N7200W/N9200W/N9200WL
Mexican Model
PX Model
BDV-N5200W
Singapore Model
BDV-N5200W/N9200W/N9200WL
Taiwan Model
BDV-N9200WL
General
Main unit
Power requirements
US, CND models:
120V AC, 60Hz
PX model:
110V - 240V AC, 50/60Hz
MX model:
120V AC, 60Hz
MX6, E32 models:
110V - 240V AC, 50/60 Hz
Other models:
220 V – 240 V AC, 50/60 Hz
Power consumption
On: 95 W (HBD-N9200W/HBD-N7200W/
HBD-5200W)
105 W (HBD-N9200WL/HBD-
N7200WL)
Standby: 0.3 W
Dimensions (w/h/d) (approx.)
480 mm × 78 mm × 212.5 mm
(19 in x 3 1/8in x 8 3/8in)
incl. projecting parts
Mass (approx.)
3.1 kg (6 lb 14 oz)
Surround amplifier (TA-SA500WR) for
BDV-N9200W/BDV-N7200W
Surround amplifier (TA-SA600WR) for
BDV-N9200WL/BDV-N7200WL
Surround amplifier (TA-SA700WR) for
BDV-N5200W
Amplifier Section
US model only:
TA-SA500WR
AUDIO POWER SPECIFICATIONS POWER
OUTPUT AND TOTAL HARMONIC DIS-
TORTION:
(FTC)
With 6 ohms loads, both channels driven,
from 180 Hz – 20,000 Hz; rated 55 watts
per channel minimum RMS power, with
no more than 1% total harmonic distortion
from 250 milliwatts to rated output.
TA-SA700WR
AUDIO POWER SPECIFICATIONS POWER
OUTPUT AND TOTAL HARMONIC DIS-
TORTION:
(FTC)
With 6 ohms loads, both channels driven,
from 180 Hz – 20,000 Hz; rated 45 watts
per channel minimum RMS power, with
no more than 1% total harmonic distortion
from 250 milliwatts to rated output.
Other models:
TA-SA500WR/TA-SA600WR:
POWER OUTPUT (reference)
Surround L/Surround R:
200 W (per channel at 6 ohms, 1 kHz)
TA-SA700WR:
POWER OUTPUT (reference)
Surround L/Surround R:
100 W (per channel at 6 ohms, 1 kHz)
Rated impedance
6 Ω
Communication system
Wireless sound Specification version 3.0
Frequency band
US, CND, PX, AEP, UK, AUS, E12, E3,
EA, E32, MX, MX6 models:
5.2 GHz, 5.8 GHz
Modulation method
DSSS
Power requirements
US, CND models:
120V AC, 60Hz
PX model:
110V - 240V AC, 50/60Hz
MX model:
120V AC, 60Hz
MX6, E32 models:
110V - 240V AC, 50/60 Hz
Other models:
220 V – 240 V AC, 50/60 Hz
Power consumption
On: 55 W (TA-SA500WR)
70 W (TA-SA600WR)
45 W (TA-SA700WR)
Standby power consumption
0.5 W (standby mode)
0.3 W (turned off)
Dimensions (w/h/d) (approx.)
200 mm × 64 mm × 211.5 mm
(7
7/8in × 2 5/8in × 8 3/8in)
Mass (approx.)
1.3 kg (1 lb 14 oz)
Design and specifications are subject to change
without notice.

BDV-N5200W/N7200W/N7200WL/N9200W/N9200WL
2
ACCESSORIES
Ref. No. Part No. Description Remark
– Continued on next page –
• Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canadian model
E3 : 240 V AC area in E model
E12 : 220-240 V AC area in E model
E32 : 110-240 V AC area in E model
EA : Saudi Arabia model
MX : Mexican model
MX6 : Latin-American model
PX : PX model
RU : Russian model
SP : Singapore model
TH : Thai model
TW : Taiwan model
4-485-799-12 MANUAL, INSTRUCTION (ENGLISH (US)
(US, CND)
4-485-799-22 MANUAL, INSTRUCTION (FRENCH) (CND)
4-485-799-32 MANUAL, INSTRUCTION (SPANISH) (US)
4-485-799-41 MANUAL, INSTRUCTION (ENGLISH) (PX)
4-485-799-51 MANUAL, INSTRUCTION (SPANISH)
(MX, E32, MX6)
4-485-800-13 MANUAL, INSTRUCTION (ENGLISH)
(SP, E12, E3, EA, AUS)
4-485-800-21 MANUAL, INSTRUCTION (RUSSIAN/UKRAINIAN)
(RU)
4-485-800-33 MANUAL, INSTRUCTION (FRENCH) (E3)
4-485-800-43 MANUAL, INSTRUCTION (ARABIC) (E3, EA)
4-485-800-53 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (SP, TW)
4-485-800-63 MANUAL, INSTRUCTION (THAI) (TH)
4-485-800-71 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE)
(CH)
4-485-800-81 MANUAL, INSTRUCTION (PERSIAN) (E3)
Unpacking
• Front speakers (2)
• Surround speakers (2)
• Center speaker (1)
• Subwoofer (1)
• Speaker cords (5, red/white/gray, blue/green) (BDV-N7200W/N9200W), (1 green) (BDV-N7200WL/N9200WL)
• Bases (4)(BDV-N9200W/N9200WL)
• Lower parts of the front and surround speakers (4) (BDV-N9200W/N9200WL)
• Stand (for front and surround speakers) (4) (BDV-N7200W/N7200WL)
• Screws (4) (BDV-N9200W/N9200WL), (8) (BDV-N7200W/N7200WL), (12) (BDV-N9200W/N9200WL)
• Remote control (1)
• R03 (size AAA) batteries (2)
• AC plug adaptors (2) (PX model)
• FM wire antenna (aerial)(1)
• Calibration mic (BDV-N7200W/N7200WL/N9200W/N9200WL)
• High Speed HDMI cable (1) (except US, CND, PX models)
• Surround amplifier (1)
• Operating Instructions
• Quick Setup Guide
• Speaker Installation Guide
• Reference Guide (AEP, UK models)
Ver. 1.1

BDV-N5200W/N7200W/N7200WL/N9200W/N9200WL
3
Ref. No. Part No. Description Remark
• Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canadian model
E3 : 240 V AC area in E model
E12 : 220-240 V AC area in E model
E32 : 110-240 V AC area in E model
EA : Saudi Arabia model
MX : Mexican model
MX6 : Latin-American model
PX : PX model
RU : Russian model
SP : Singapore model
TH : Thai model
TW : Taiwan model
• Color variations
BDV-N5200W/N7200W/N9200W : Black
BDV-N7200WL/N9200WL : White
1 A-1976-261-A STAND ASSY (TB) (Stands) (1 piece) (N9200W)
1 A-1976-923-A STAND ASSY (TB) (Stands) (1 piece) (N9200WL)
2 1-492-776-11 REMOTE COMMANDER (RM-ADP120W)
(Remote control) (N7200WL/N9200WL: EXCEPT
MX6)
2 1-492-777-11 REMOTE COMMANDER (RM-ADP120)
(Remote control) (N5200W: AEP, UK, SP/N7200W:
AEP, UK, E12/N9200W: EXCEPT CND, MX6)
2 1-492-778-11 REMOTE COMMANDER (RM-ADP118W)
(Remote control) (N9200WL: MX6)
2 1-492-779-11 REMOTE COMMANDER (RM-ADP118)
(Remote control) (N5200W: MX/N7200W: E32/
N9200W: MX6)
2 1-492-780-11 REMOTE COMMANDER (RM-ADP117)
(Remote control) (US, PX, CND)
3 1-542-903-11 MEASUREMENT MIC (STEREO) (Calibration mic)
(N7200W/N7200WL/N9200W/N9200WL)
4 1-754-060-21 ANTENNA (FM) (FM wire antenna (aerial))
(EXCEPT US, PX, CND)
4 1-754-848-11 ANTENNA ISOLATOR (CH)
4 1-793-184-41 CONNECTOR (F TYPE ADAPTOR)
(FM wire antenna (aerial)) (US, PX, CND)
5 1-785-504-21 ADAPTOR, CONVERSION (PX, E32, MX6)
6 1-835-855-31 CORD WITH CONNECTOR (HDMI CABLE)
(MX, SP, E12, E32, E3, EA, TH, CH, MX6, TW)
7 1-846-401-41 CABLE (WITH CONNECTOR) (SPEAKER)
(Speaker cords (1, green))
(N7200WL/N9200WL)
7 1-846-401-51 CABLE (WITH CONNECTOR) (SPEAKER)
(Speaker cords (5, red/white/gray/blue/green))
(N9200W)
7 1-846-401-61 CABLE (WITH CONNECTOR) (SPEAKER)
(Speaker cords (5, red/white/gray/blue/green))
(N7200W)
8 A-1976-265-B BASE ASSY (TB)
(Lower parts of the front and surround speakers)
(1 piece) (N9200W)
8 A-1976-924-B BASE ASSY (TB) (1 piece) (N9200WL)
9 4-488-333-01 FOOT (1 piece) (N9200W/N9200WL)
10 A-1979-287-A BASE (SAT) ASSY (W) (1 piece) (N7200WL)
10 4-480-329-01 STAND, BASE (1 piece) (N7200W)
11 2-893-646-01 FOOT (1 piece) (N7200W/N7200WL)
12 4-533-400-11 SCREW +B 4X10 (WASHER) (1 piece)
(N9200W/N9200WL)
13 7-682-562-09 SCREW +B 4X10 (1 piece) (N7200W/N7200WL)
14 7-682-973-31 SCREW +PSW 5X14 (1 piece)
(N9200W/N9200WL)
15 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3 (1 piece)
(N9200W/N9200WL)
16 4-477-465-31 HI-RES LABEL
(N7200W/N7200WL/N9200W/N9200WL)
2 Remote commander
(remote) (1)
3 Calibration mic (1)
(N7200W/N7200WL/N9200W/
N9200WL)
6 High Speed HDMI cable (1)
(MX, SP, E12, E32, E3, EA,
TH, CH, MX6, TW)
5 Adaptor Conversion
(PX, E32, MX6)
4 FM wire antenna (aerial) (1)
or
1 Lower parts of the front and surround
speakers (4)
(4: N9200W/N9200WL)
12 Screws (small)
(12: N9200W/N9200WL)
7 Speaker cords
(N7200WL/N9200WL: 1, green)
(N7200W/N9200W: 5, red/white/
gray/blue/green)
14 Screws (large)
(4: N9200W/N9200WL)
15 Screws
(7: N9200W/N9200WL)
16 Hi-Res Label
13 Screws
(8: N7200W/N7200WL)
9
9
8 Bases
(6: N9200W/N9200WL)
10 Stands (for front and surround
speakers
(5: N7200W/N7200WL)
11
11 11
11
11
Ver. 1.1

BDV-N5200W/N7200W/N7200WL/N9200W/N9200WL
REVISION HISTORY
Ver. Date Description of Revision
1.0 2014.01 New
1.1 2014.03 Addition of Singapore model (BDV-N5200W).
Addition of Russian, Singapore, Chinese and Thai models (BDV-N9200W).
Addition of Russian, Singapore, Chinese, Thai and Taiwan models (BDV-N9200WL).
Change P/N of Ref. No. 8 and 12 in page 3.
Change of description for STAND, BASE (BDV-N7200W).
