Sony HT-7200DH User manual

SERVICE MANUAL
Published by Sony Techno Create Corporation
Sony Corporation
Audio Business Group
HT-7200DH
DVD HOME THEATRE SYSTEM
9-887-946-01
2008B05-1
© 2008.02
US Model
Ver. 1.0 2008.02
• HT-7200DH is composed of following models.
As service manuals are issued for each component model, please
refer to them.
SPECIFICATIONS
Power requirements 120 VAC, 60 Hz
Power output (DIGITAL MEDIA PORT)
DC OUT 5 V, 0.7A MAX
Power consumption 170 W
Power consumption (during standby mode)
0.3 W (when “CONTROL FOR HDMI” in
VIDEO menu is set to “CTRL OFF”)
Dimensions (w/h/d) (Approx.)
17 × 6 1/4 × 12 5/8 inches
(430 × 157.5 × 318 mm) including
projecting parts and controls
Mass (Approx.) 17 lb 4 oz (7.8 kg)
Supplied speakers
• Front speakers (2) • Center speaker (1)
• Surround speakers (2) • Sub woofer (1)
Supplied accessories
Operating instructions
Quick Setup Guide (1)
FM wire antenna (1)
AM loop antenna (1)
Monaural audio cord (1)
Speaker cords
• Long (2)
• Short (3)
Footpads
• Speakers (20)
• Sub woofer (4)
Remote commander (RM-AAU021) (1)
R6 (size-AA) batteries (2)
Optimizer microphone (ECM-AC2 or ECM-AC2a) (1)
Design and specifications are subject to change without notice.
COMPONENT MODEL NAME
HT-7200DH
Multi Channel AV Receiver STR-K7200
Front speaker SS-MSP890
Center speaker SS-CNP890
Surround speaker SS-SRP890
Sub woofer SA-WP890
CD/DVD Player DVP-NS700H
ACCESSORIES
1-480-588-11 REMOTE COMMANDER (RM-AAU021)
1-501-374-12 ANTENNA, LOOP (AM loop antenna)
1-542-670-11 MEASUREMENT MIC (MONO)
(Optimizer microphone (ECM-AC2))
1-769-329-21 CORD, CONNECTION (PIN-PIN) (Monaural audio cord)
1-769-433-71 CORD, SPEAKER (Short: 3 m)
1-769-433-81 CORD, SPEAKER (Long: 8 m)
1-793-184-23 CONNECTOR (F TYPEADAPTOR) (FM wire antenna)
2-655-032-11 CUSHION (FOOT) (20 pieces) (Foot pads for Speakers)
2-682-469-01 FOOT (SW) (4 pieces) (Foot pads for Sub woofer)
3-283-377-11 INSTRUCTION MANUAL (ENGLISH)
3-283-377-21 INSTRUCTION MANUAL (SPANISH)
Part No. Description Remark

HT-7200DH
REVISION HISTORY
Checking the version allows you to jump to the revised page.
Also, clicking the version at the top of the revised page allows you to jump to the next revised page.
Ver. Date Description of Revision
1.0 2008.02 New
