HT-CT550W
3D Sound Bar Home Theater System with wireless subwoofer
Key Features
2.1 ch 400W simulated surround sound system for 40”and above HDTV
6
Wireless active subwoofer for flexible placement
Three HDMI™inputs: single - cable AV connections
7
HDMI ™Repeater with 3D pass - through
Dolby ® TrueHD and dts ® HD enhanced audio codecs
5
3D Surround Sound (S - Force ® Pro Front Surround 3D)
BRAVIA ® Widget unified on - screen interface
4
Audio Return Channel: just one cable for TV audio
1
HDMI ™standby pass - through when system is off
BRAVIA ® Sync multi - device control with one remote
3
Key Technologies
2.1- channel sound bar The fast and easy way to add great sound to any HDTV, this sound bar
matches the design of Sony ® televisions and is the perfect complement for 40”and larger
televisions.
7
Wireless Subwoofer Place the subwoofer just about anywhere in the room. Sony’s clever
input/output box enables the sound bar to offer both a wireless subwoofer and HDMI™connections
to other equipment.
7
Three HDMI ™ inputs Connect three HD sources via HDMI™and easily switch between them. HDMI
connections combine the quality of pure digital - to - digital signal transfer with the simplicity of a single
connection for audio, video and control.
7
HDMI 3D Pass-Through Enjoy 3D Blu - ray Disc™movies, video games and other 3D content with
compatible players and HDTVs.
2
Dolby® TrueHD and dts® Master Audio5 Experience theater - like sound in your home with Dolby ®
TrueHD and dts ® Master Audio HD enhanced audio.
5
3D surround sound Using Sony’s S - Force ® Surround technology, the HT - CT350 can deliver simulated
surround sound from just the bar and the subwoofer. You get a powerful surround sound effect
without the need to connect multiple speakers throughout the room.
BRAVIA® Widget Control4 Controlling sound bars just got easier. With select 2011 BRAVIA HDTVs,
you can pull up a menu on the TV screen to make comprehensive audio adjustments.
4
400 Watts for powerful sound Hear everything with incredible impact. The sound bar delivers 400
Watts total power (133 Watts x 2 +134 Watts, measurements at 3 Ohms, 80 Hz –1 kHz with a THD of
1%).
Audio Return Channel1 Eliminate the need for extra cables connected to your TV. Send audio from
a compatible TV to the sound bar through the same HDMI™cable already being used to send audio
and video to your TV.
1
HDMI standby pass- through Conveniently access all your HDMI™sources without having to power
on the sound bar.
1
BRAVIA® Sync Capable Easily control an entire system with one remote. Operates Sony ®
equipment connected via HDMI™cables, including compatible Blu - ray Disc™players, BRAVIA ®
HDTVs, Handycam ® camcorders and Cyber - shot ® digital cameras.
3

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 02/10/2011
HT-CT550W
3D Sound Bar Home Theater System with wireless subwoofer
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
Amplifier/Receiver
General
AutoStandby: YES
(30min/OFF)
PinJack: Nickel
PowerConsumption: STR - CT550WT:50W/
SA - WCT550W:30W
PowerRequirement: 120V, 60Hz
Power Stand By: 0.3Watt
RemoteControl: RM - AAU113
HotelMode: YES
InputSelector: TV; BD/DVD; GAME;
SAT/CATV; VIDEO; LINE IN; TUNER FM
Amplifier
Advanced Auto Volume: YES
Equalizer(F/C/Sur/Sur B): Bass,Mid,Treble:
Bass(+ - 6), Treble(+ - 6)
NightMode: YES
Number of amp. channels: 2 + 1ch
Sound Field Program :2CH STEREO: YES
Sound Field Program :GAMING: YES
Sound Field Program :NEWS: YES
Sound Field Program :SPORTS: YES
Speaker Level Control: Center (+ - 6),
Subwoofer (+ - 6)
SpeakerTerminal: Colores Speaker Clips
DSP: Yes
S- Force PRO Front Surround 3D: YES
Sound Field Program :DRAMA: YES
Sound Field Program :MOVIE: YES
Sound Field Program :MUSIC: YES
Sound Field Program :STANDARD: YES
Sub Woofer X' Over: Fixed 200Hz (Measured
using the Standard Sound Mode)
Type: Digital
Video
1080/24p: YES
1080p: YES
A/V SYNC: YES(Fixed)
DeepColor: YES
x.v.Color (xvYCC): YES
A/V Sync Time(msec): ON(70ms)/OFF
Front Speaker
General
SpeakerSystem: Bass Reflex
Front Grille Material: Punched Metal
Front Grille Type: Fixed
SpeakerType: Bass Reflex
Tweeterunit: 65mm, conetype
Wooferunit: 80mm, conetype
Specifications
Amplifier/Receiver
Decoding Format(s)
96k/24BitPCM: YES
DTS96/24: YES
DTS HD/DolbyTruHD/Dolby Digital+:
YES/YES/YES
DolbyDigital/DTS: YES/YES
Dolby Dual Mono: YES
LPCM (2CH/5.1CH/7.1CH) thru HDMI:
YES/YES/YES
192kHz
HDMI™Specs
3D signal pass thru: YES
Audio Return Channel: YES
BRAVIA ® SYNC ™( CEC Control): YES
Home Theatre Control: YES
Scene Select Sync: YES
HDMI Pass Through: YES
Position Control Sync: YES
TV Theater Mode: YES
Inputs and Outputs
Analog Audio In(Inc TV CEC)/Out(excl.
tuner)/TV(CEC): Single Line In
Coax.: 1 Input
HDMI In/Out : (Front input): 3 In / 1 Out
Opt. In/Out/TV(CEC) : incl Front input & TV
(CEC): 2 In
Tuner
DirectTuning: YES
FM MODE: MONO/STEREO
Preset Channel (Sirius/XM/FM/AM): 20 FM
StationName: YES
Front Speaker
Audio Specs
Impedance: 8 ohms
Weight and Measurements
Dimensions (Approx.)
Center Speaker (WxHxD): 37 3/8in x 3in x 1
5/8in (948.2mm x 75mm x 40mm)
Weight (Approx.)
CenterSpeaker: 5lb 2oz (2.3kg)
General
Form
ExtensionBracket(Optional): WS -
CT550B46 (46") / WS - CT550B40 (40")
Color: Black
UPC Code: 027242806368
1.RequiressourcesconnectedwithHDMI ™ cables(soldseparately)and
compatible HDTV. Sound quality will vary depending on source.
2.3Dviewingrequires3Dcontent,3D - readyHDTVandhighspeed
HDMI™ cable.Other3Daccessories(including3Dglassesand
emitter)mayalsoberequiredfor3Dviewing.
3.Works with other BRAVIA® Sync orTheatreSync™ labeledhome
audio/videoproductswhen connected via HDMI ™ interface.
4.BRAVIA Widget unified control can be usedonlywhenreceiver is
connectedto a Sony XBR - EX620,EX630, EX720,EX820, EX830,NX830,
HX820,HX830, or HX930 series BRAVIA HDTVviaHDMI™ cable(sold
separately).
5.Dolby® True - HD and dts ® - HDMasterAudiodecodingrequire HDMI ™
cable and capable source device (both sold separately).
6.Measurements at4 ohms,180Hz - 20kHz withaTHDof 1%
7.HDMI™ cable required, sold separately
