Sony HT-SS2000 - Blu-ray Disc™ Matching Component Home Theater... User manual

HT-SS2000
Blu - rayDisc ™ MatchingComponentHomeTheaterSystem
Key Features
Accepts 1080p signal and Linear PCM via HDMI™
1
DIGITAL MEDIA PORT
3
A/V Receiver with HDMI™Active Intelligence (3 In/1 Out)
5.1 Channel Home Theater System
1000W RMS Rating (1KHz,<10%THD)
Portable Audio Enhancer with Front Audio Input
Digital Cinema Auto Calibration (Mono Mic Included)
Slim Receiver Design to Match Blu - ray Disc™Player (sold
separately)
5 Speakers + Passive Sub
Key Technologies
BRAVIA ® Theatre Sync ™ As a leader in products with HDMI™connectivity, Sony has created BRAVIA® Theatre
Sync™technology to go beyond simple audio and video transmission. When combined with a select number of
BRAVIA ®LCD televisions and other Sony audio and video products, control functions will also be transmitted via
the HDMI cable (sold separately) . With“One Touch Play”, operations that took several steps have been reduced to
one. Press the PLAY button on the remote, watch the audio and/or the video component(s) turn on, then the BRAVIA ®
television will turn on and switch to the correct video input.
2
2
DIGITAL MEDIA PORT Play and control your favorite stored music seamlessly from your home theater system.
Connect DMP accessories to play back music from Bluetooth - enabled mobile phones, networked computers or
select iPod®or Network Walkman™digital music players (optional accessories sold separately). The DMP
accessories include a PC Client Ready device (TDM - NC1), Bluetooth ®receiver (TDM - BT1) and Docking Stations
compatible with select Network Walkman™players (TDM - NW1) and iPod® products (TDM - iP1).
3
HDMI "Active Intelligence" The receiver detects and receives the best possible video and audio signals from all
connected devices; making connection and performance as simple as plugging in a single wire. Sony's HDMI
"Active Intelligence" produces both audio and video through one HDMI cable (sold separately).
Digital Cinema Auto Calibration Connect the microphone and push a single button, the speakers are
automatically adjusted to your favorite listening position.
S -Master ® Digital Amplifier Superb accuracy using a digital - to - digital process. Clear separation of signals and
balanced sound reproduction.
Portable Audio Enhancer with Front Audio Input Sony's Component Home Theater Systems are ideal for
today's portable audio players. A powerful Digital Signal Processor expands the quality of sound from any
connected device. Simplified front - side audio and video connections make it easy to play music stored on
portables through the receiver.
Accepts 1080p signal and Linear PCM via HDMI™
1
DIGITAL MEDIA PORT
3
A/V Receiver with HDMI™Active Intelligence (3 In/1 Out)
5.1 Channel Home Theater System
1000W RMS Rating (1KHz,<10%THD)
Portable Audio Enhancer with Front Audio Input
Digital Cinema Auto Calibration (Mono Mic Included)
Slim Receiver Design to Match Blu-ray Disc™Player (sold separately)
5 Speakers + Passive Sub

SonyElectronicsInc. • 16530ViaEsprillo • SanDiego,CA92127 • 1.800.222.7669 • www.sony.com
LastUpdated:08/21/2007
HT-SS2000
Blu - rayDisc ™ MatchingComponentHomeTheaterSystem
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Specifications
General
Inputs and Outputs
HDMI ™ Connection Input(s): Yes
Receiver
Audio
Audio Power Output: 1000W (143w x 5 + 285w
(1KHz, 10% THD))
Impedance: 3 ohms
Inputs and Outputs
Analog Audio Input(s): 3 (Rear)
Coaxial Audio Digital Input(s): 1 (Rear)
Optical Audio Input(s): 2 (Rear)
HDMI ™ Connection Input(s): 3 (Rear) up to
1080p
HDMI ™ Connection Output(s): 1 (Rear) up to
1080p
Digital Media Port (Input): 1 (Rear)
Power
Power Requirements: AC 120V, 60 Hz
Power Consumption (in Operation): 165W
Power Consumption (in Standby): 0.3W
Amplifier
Inputs and Outputs
Digital Media Port (Input): Yes
Tuner
Audio
Tuner Frequency Range: AM: 530-1,710 kHz, FM:
87.5-108.0 MHz
Station Preset(s): 30 AM, 30 FM
Tuner Type: AM, FM
Inputs and Outputs
Antenna Terminal (AM Loop): Yes
Antenna Terminal (FM 75 Ohm): Yes
Front Speaker
Speaker
Speaker Type: Enclosure- Bass Reflex
Speaker Unit: Magnetically Shielded
Speaker System: bass reflex
Speaker Dimensions: 8cmX1, 4cm TWx1
3
Weights and Measurements
Dimensions (Approx.): 3.5 x 5.9 x3.5" (80 x 150 x
88 mm)
Weight (Approx.): 1.1 lbs (0.5kg)
Center Speaker
Speaker
Speaker Type: Enclosure- Bass Reflex
Speaker System: bass reflex
Speaker Dimensions: 5.7cmx1
Weights and Measurements
Dimensions (Approx.): 9.8 x 3.3 x 3.5" (250 x 85 x
88mm)
Weight (Approx.): 1.5 lbs (0.7kg)
Surround Speaker
Speaker
Speaker Type: Enclosure- Bass Reflex
Weights and Measurements
Dimensions (Approx.): 3.1” x 5.9” x 3.5" (80x 150
x 88mm)
Weight (Approx.): 0.9 lbs (0.4kg)
Subwoofer Speaker
Speaker
Speaker Unit: Magnetically Shielded
Speaker Type: Enclosure- Bass Reflex
Weights and Measurements
Dimensions (Approx.): 7.9 x 15.0 x 13.3 x" (200 x
382 x 337mm
Weight (Approx.): 9.9 lbs (4.5 kg)
Dimensions
Weight: Receiver: 7.9 lbs (3.6 kg); Front Speaker:
1.1 lbs (0.5kg); Center Speaker: 1.5 lbs (0.7kg);
Surround Speaker: 0.9 lbs (0.4kg); Subwoofer:
9.9 lbs (4.5 kg)
Measurements: Receiver: 16.9 x 2.6 x13.1" (430 x
66.5 x 333 mm); Front Speaker: 3.5 x 5.9
x3.5" (80 x 150 x 88 mm); Center Speaker: 9.8 x
3.3 x 3.5" (250 x 85 x 88mm); Surround
Speaker: 3.1 x 5.9 x 3.5" (80x 150 x 88mm);
Subwoofer: 7.9 x 15.0 x 13.3 x" (200 x 382 x
337mm)
Supplied Accessories
Remote (RM- AAU017)
Coaxial Cable (1)
Speaker Cable (3m x 3) (8m x 2)
1.Requires HDMIcompatible HDTVwithequivalent displaycapability.
2.Each productmust includeBRAVIATheatreSyncfeature. Pleaserefer to
ownersmanual forcompatability.
3.Requires DigitalMedia Portaccessorycompatiblewiththe device(sold
separately).
©2007Sony ElectronicsInc. Allrightsreserved.
Reproductionin wholeor inpartwithoutwrittenpermission isprohibited.
Sony,BRAVIA, DigitalCinema Sound,TheatreSync,and"like.no.other" are
trademarksof Sony.Blu - rayDisc isa trademark.Dolby, DolbyDigital,
ProLogicare registeredtrademarks ofDolbyLaboratories.dtsis a
trademarkof DigitalTheater Systems,L.P.HDMI, theHMDI logoand High -
DefinitionMultimedia Interfaceare trademarksor registeredtrademarks
ofHDMI LicensingLLC. Allothertrademarksareproperty oftheir respective
owners.
Featuresand specificationsare subjecttochange withoutnotice. Non -
metricweights andmeasures areapproximate.
