Sony HT-SS370 - 10htib User manual

HT-SS370
Sony Blu - ray Disc Matching Surround Sound Home Theater System
Key Features
HDMI™Repeater for simplified audio and video
signal transfer
1000watt (165X5 +175, 3ohm, 1kHz, 10%THD)
5.1 channel surround sound
Wireless S-AIR™Rear Speakers & Wireless multi-
room capability
2
Blu -ray Disc™ Audio Decoding (Linear PCM
only)
2010 Blu-ray Disc players Matching design for
clean esthetics
BRAVIA® Sync ™ controls compatible devices
w/ one remote
2
Digital Media Port for iPod® ( iPod cradle sold
separately)
4
2 Digital Audio Inputs (1 Coax, 1 Optical)
Digital Cinema Audio Calibration for quick
speaker set-up
Dolby ® Digital, dts® and LPCM Audio
Decoding
1
Key Technologies
HDMI™ Repeater Connect multiple devices via HDMI™to your surround sound system, easily switch
between them, and then connect everything to your HDTV with just one HDMI cable.
1
Wireless S -AIR™ Rear Speakers & multi -room capability Enjoy 5.1 channel surround sound without
needing to run wires across the room to the rear speakers. Easily stream audio to up to 10 rooms
when you add optional S - AIR ™receiver/speaker systems (AIR - SA10) and a S - AIR ™ Card (EZW - T100) to
your S - AIR Capable System (EZW - T100 and each S - AIR Speaker System sold separately).
2
BRAVIA® Sync ™Capable Conveniently operate and control all your HDMI™connected BRAVIA ®
Sync™devices with one remote including: Blu - ray Disc™Players, BRAVIA ® HDTVs, home theater
products, Handycam ® Camcorders and Cyber - shot ® Digital Cameras.
3
Digital Media Port Connect a Digital Media Port (DMP) adapter (sold separately) to your audio
system and access music from your iPod ® , Walkman ® player, or PC device.
4
Blu - ray Disc ™HD Audio (Linear PCM) With Linear PCM support, when you connect via HDMI a Blu -
ray Disc player that can decode the latest high definition audio formats, including Dolby ® TrueHD™
and DTS ® - HD Master Audio you can experience sound closer to the way it was captured.
5
Digital Cinema Auto Calibration Ensure you get the best sound experience from your surround
sound system with Digital Cinema Auto Calibration. Simply place the included microphone where
you will be seated and settings are automatically optimized based on the distance, delays and
placement of your speakers.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 09/15/2010
HT-SS370
Sony Blu - ray Disc Matching Surround Sound Home Theater System
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
General
Convenience
Digital Cinema Auto Calibration: Yes
HDMI™ActiveIntelligence: Yes
AM/FM Memory Presets: 20 FM 10 AM
DVD, VCD, CD Player
Video
HDMI™Upscaling: Yes
Receiver
Audio
Dolby ® DigitalDecoding: Yes
Dolby ® Pro Logic ® IIDecoding: Yes
dts ® - ES Decoding: no
DigitalAmplifier: Yes (S - Master ® Digital
Amplifier)
96k/24bitPCM: Yes
LPCM: 2CH/5.1CH thru HDMI™
AudioModes: 11 (2 Movie, 3 Music, 5
A.F.D., 1 2ch)
Dolby ® Pro Logic ® Decoding: yes
dts ® Decoding: Yes
Dolby ® Digital EX Decoding: no
Specifications
General
Video
1080/24p: Pass through
1080p: Pass through
DeepColor: Pass through
HDMIRepeater: Yes (3 in / 1 Out)
x.v.Color (xvYCC): Pass through
Audio
Channel Power Rating: 5.1 Channel
SoundEnhancer: Yes (Portable Audio
Enhancer)
Audio Return Channel: Yes
Inputs and Outputs
HDMI™ConnectionInput(s): Yes
Service and Warranty Information
LimitedWarranty: 1 year parts / 1 year
labor
Amplifier
Inputs and Outputs
Digital Media Port (Input): Yes
3
Receiver
Audio
Audio Power Output: 1000W (165X5 +175,
3ohm, 1kHz, 10%THD)
Impedance: 3 ohms
Inputs and Outputs
Analog Audio Input(s): 3 (Rear)
Coaxial Audio Digital Input(s): 1 (Rear)
Optical Audio Input(s): 2 (Rear)
HDMI™ConnectionInput(s): 3 (Rear) up
to 1080/24p
HDMI™ConnectionOutput(s): 1 (Rear) up
to 1080/24p
Digital Media Port (Input): 1 (Rear)
Power
PowerRequirements: AC 120V, 60 Hz
Power Consumption (in Operation): 165W
Power Consumption (in Standby): 0.3W
Weights and Measurements
Dimensions(Approx.): 17 ” x 2.6 ”
x13.1" (430 x 66.5 x 333mm)
Weight(Approx.): 7.5 lbs (3.4kg)
Tuner
Audio
Tuner Frequency Range: AM: 530 - 1,710 kHz,
FM: 87.5 - 108.0 MHz
TunerType: AM, FM
Inputs and Outputs
Antenna Terminal (AM Loop): Yes
Antenna Terminal (FM 75 Ohm): Yes
Wireless
S - Air
S- AirReady: Yes
Center Speaker
Speaker
SpeakerType: Enclosure - Bass Reflex
SpeakerSystem: bass reflex
Weights and Measurements
Dimensions(Approx.): 15 x 2 x 2 5/8 (with
foot) (380 x 50 x64mm)
Weight(Approx.): 0 lb 14oz (.38kg)
Front Speaker
Speaker
SpeakerType: Enclosure - Bass Reflex
SpeakerUnit: Magnetically Shielded
SpeakerSystem: bass reflex
Weights and Measurements
Dimensions(Approx.): 4 1/8 x 6 1/2 x 3
1/8 (with foot) (102 x 163 x 77mm)
Weight(Approx.): 1lb 32oz (.52kg)
Surround Speaker
Speaker
SpeakerType: Enclosure - Bass Reflex
Weights and Measurements
Dimensions(Approx.): 4 1/8 x 6 1/2 x 3
1/8 (with foot) (102 x 163 x 77mm)
Weight(Approx.): 1lb 32oz (.52kg)
Subwoofer Speaker
Speaker
SpeakerUnit: Magnetically Shielded
SpeakerType: Enclosure - Bass Reflex
SpeakerDimensions: 6 3/8" (160mm)
Weights and Measurements
Dimensions(Approx.): 8 3/4 x 16 5/8 x 12
7/8 (with foot) (220 x 395 x 325mm)
Weight(Approx.): 12lb 6oz (5.6kg)
Supplied Accessories
Remote (RM - AAU057)
Speaker Cable (3m x 2) (10m x 2) (3m x 1)
(2m x 1)
Waranty Card
Users Guide
FM Wire Antenna
AM Loop Antenna
Microphone (EMC - AC2)
Color: Black
UPC Code: 027242781276
1.RequiressourceswithHDMI ™ cables(soldseparately).Soundquality
will vary depending on source.
2.Transmitsup to 164 feet. Signal and sound quality may vary. S - AIR
wireless accessories required, sold separately.
3.WorkswithotherBRAVIA®Sync™orTheatreSync™ labeledhome
audio/videoproducts when connected via HDMI ™ interface.
4. iPod ® supportislimitedtothe following players with the optional TDM -
IP20dock:iPod ® touch, iPod ® classic, iPod ®Nano1st,2nd&3rd
generation, iPod ®4th&5th generation &iPod® Mini.The optional
TDM - IP50willsupportiPhone ® device as well.
5.LPCMdecoding requires HDMI ™ cable (sold separately).
©2010Sony Electronics Inc.Allrights reserved. Reproductionin whole or
inpart without writtenpermissionis prohibited.Sony,BRAVIA, BRAVIA
Sync,TheatreSync, Cyber - shot,Handycam,Walkman, S - Air,
make.believeandtheirrespectivelogosaretrademarksof Sony. Blu - ray
Discisatrademark. HDMI is a trademark of HDMI Licensing LLc. Dolby is a
trademarkofDolby Laboratories. iPod, iPhone are trademarksofApple
ComputersInc.. All othertrademarksare trademarksoftheir respective
owners.Featuresandspecificationsaresubjecttochangewithoutnotice.
Non - metricweightsand measures are approximate and may vary.
