Home Theater In A Box System
• 510 Watts Total System Power
• 85 Watts x 5 Receiver + 85W Subwoofer with 8" Driver
• Combination VHS/DVD Player with Progressive Scan Output
• DVD/CD/VCD/CD-R/CD-RW* & MP3 Playback
• Dolby® Digital, dts®, and Dolby® Pro-Logic® II MP3 Playback
• Preprogrammed Remote Commander® Remote Control
HT-V2000DP

Home Theater In A Box System
For more information:
http://www.sony.com/dn
HT-V2000DP
Features
General
• Silver Color Components:
Receiver/DVD Player
• Combination VHS/DVD Player
• DVD/CD/VCD/CD-R/CD-RW* &
MP3 Playback
• Complementary WEGA® TV
Styling
• 4-Head Hi-Fi VHS Video Cassette
Recorder
• Remote Commander® Remote
Control
DVD/VHS
• SLV-D350P
• 19 Micron Heads for Optimized EP
Recording
• 1 Month/8 Event Recording
• Progressive Scan Output
• S-VHS Quasi Playback
• Inputs and Outputs Component
Video Output & S-Video Output for
DVD
• Inputs and Outputs: Coaxial &
Optical Digital Output for DVD
• Inputs and Outputs: RF Output for
DVD & VCR
• Inputs and Outputs: dts® Digital
Output
• Convenience Features Auto Head
Cleaner
• Convenience Features
Multi-Lingual On-Screen Display
• Convenience Features 60 Second
High Speed Rewind (w/T120 Tape)
• Convenience Features Auto
Tracking for VHS Playback
• Convenience Features Parental
Lock
Receiver Section
• STR-K665P
• 510 Watt Receiver: 85 Watts x 6 (8
ohms, 1 kHz, 10% THD)
• Dolby® Digital, dts®, and Dolby®
Pro-Logic® II Decoding
• Digital Cinema Sound™ (Cinema
Studio EX) processing
• Tuner w/20FM + 10 AM Station
Presets
• Inputs and Outputs: 1 Coaxial
Digital Input, 1 Optical Digital Input
• Inputs and Outputs: Headphone
Jack 1/4" Type
• Inputs and Outputs: Analog Audio
Inputs x 2
• Inputs and Outputs: Analog Audio
Output x 1
• Convenience Feature: Plug and
Play Easy Setup for Tuner & Clock
Speaker
• SA-VE66P
• Slim Center Speaker, 4 Satellite
Speakers, Subwoofer
• Magnetically Shielded Front,
Center, Rear, Subwoofer
Subwoofer
• SA-WMSP66
• Subwoofer with 8" Driver
Specifications
General
• Power Requirements AC120V, 60
Hz
• Power Consumption 190 W
Amplifier Section
• Power Output 85 Watts x 2
• Multi-Channel Output 85 Watts x 6
(8 ohms 1 kHz, 10% THD)
• Discrete Output Transistors
DVD/VHS
• Video Horizontal Resolution >500
TV lines
• Audio Frequency Response (DVD,
96 kHz PCM) 2-44,000Hz, ?1.0dB
• Audio Signal-to-Noise Ratio (DVD,
96 kHz PCM)>110 dB
• Audio Dynamic Range >100 dB
• Harmonic Distortion <0.003%
Tuner
• AM Tuner Section 530 - 1,710 kHz
• FM Tuner Section 87.5 - 108.0
MHz
Front/Rear Speaker
• System Impedance 6 ohms
• Power Handling 100 Watts
Maximum
• Sensitivity 86 dB (dB/W/m)
• Speaker System 1 Way
• Speaker Unit Front/Rear Full
Range Woofer 3 1/4"
Center Speaker
• Power Handling 100 Watts
Maximum
• Sensitivity 86 dB (dB/W/m)
• Speaker System 1 Way
• Speaker Unit Full Range Woofer 3
1/4"
Subwoofer
• Speaker System Bass Reflex
Design
• Speaker Unit Subwoofer Driver
Size 8"
Weights and Measurements
• Front/Rear Dimensions 4.7" x 4.8"
x 3.9" (120 x 122 x 100mm)
• Front/Rear Weights 1.7 lbs. (0.8 kg)
• Center Dimensions 4.7" x 4.8" x
3.91" (120 x 122 x 100mm)
• Center Weights 2.2 lbs. (1 kg)
• Subwoofer Dimensions 10.6" x
12.8" x 13.1" (270 x 325 x 333mm)
• Subwoofer Weights 19.8 lbs. (9.0
kg)
Supplied Accessories
• Instruction Manual
• Remote Commander® Remote
Control RM-V66
• Speaker Cable 3.5M x 3 (11.4 ft x
3); 10M x 2 (32.8 ft x 2); 5M x 2
(16.4 ft x 1)
Optional Accessories
• WS-FV11D - Floor Speaker Stands
(1 pair)
• WS-WV10D - Wall Mount Speaker
Brackets (1 pair)
Weights & Measures
• Main Unit: 7.94 lbs (3.6kg)
• main unit: 16.93" x 3.35" x 11.3"
(430 x 85 x 287mm)
UPC Codes
• 0272422520970
©2004 Sony Electronics Inc. All rights reserved.
Features and specifications are subject to
change without notice. All trademarks
referenced herein are trademarks of Sony or
their respective owners.
*CD-R/RW playback may not be compatible
with all discs, depending on recording
conditions.
