Sony 60NX800 User manual

4-180-474-16(1)
LCD
Digital Colour TV
Operating Instructions GB
操作手冊 CT
KDL-60NX810 / 60NX800 / 55NX810 / 52NX800 / 46NX710 / 46NX700 / 40NX800 / 40NX710
KDL-40NX700

2GB
Introduction
Thank you for choosing this Sony product.
Before operating the TV, please read this
manual thoroughly and retain it for future
reference.
~
•The illustrations used in this manual are
of the KDL-40NX800 unless otherwise
state.
•The illustrations of the remote used in
this manual are of the RM-GD010 unless
otherwise stated.
•Only KDL-NX810 and NX710 series
supports Divx®.
Trademark information
HDMI, the HDMI Logo, and High-
Definition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC in the United States
and other countries.
DLNA®, the DLNA Logo and DLNA
CERTIFIED®are trademarks, service
marks, or certification marks of the Digital
Living Network Alliance.
DivX®is a video file compression
technology, developed by DivX, Inc.
DivX®, DivX Certified®and associated
logos are registered trademarks of DivX,
Inc. and are used under license.
ABOUT DIVX VIDEO: DivX®is a
digital video format created by DivX,Inc.
This is an official DivX Certified device
that plays DivX video. Visit
www.divx.com for more information and
software tools to convert your files into
DivX video.
ABOUT DIVX VIDEO-ON-DEMAND:
This DivX Certified®device must be
registered in order to play DivX Video-on-
Demand (VOD) content. To generate the
registration code, locate the DivX VOD
section in the device setup menu. Go to
vod.divx.com with this code to complete
the registration process and learn more
about DivX VOD.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D
symbol are trademarks of Dolby
Laboratories.
“BRAVIA” and are
trademarks of Sony Corporation.
“XMB” and “xross media bar” are
trademarks of Sony Corporation and Sony
Computer Entertainment Inc.
The typefaces used on the screen display
are solely developed by DynaComware.
Location of the
identification label
Labels for Model No. and Power Supply
rating (in accordance with applicable
safety regulation) are located on the rear of
the TV. For KDL-NX800 series models,
they can be found by removing the bottom
cover.
This television is designed for
use in Hong Kong and ensured
the usage in Hong Kong only.

3GB
GB
Table of Contents
Checking the accessories.............................................................................................................. 4
Inserting batteries into the remote................................................................................................. 4
Setting Up
Attaching the Table-Top Stand...................................................................................................... 5
Connecting an antenna (aerial)/cable/VCR................................................................................... 7
Preventing the TV from toppling over ............................................................................................8
Bundling the cables ....................................................................................................................... 8
Performing the initial set-up........................................................................................................... 9
Detaching the Table-Top Stand from the TV................................................................................. 9
Watching TV
To watch programmes................................................................................................................. 10
To utilise the TV’s features .......................................................................................................... 10
To use i-Manual........................................................................................................................... 11
Additional Information
Troubleshooting........................................................................................................................... 12
Specifications .............................................................................................................................. 13
Installing the Accessories (Wall-Mount/Wall-Hanging Bracket)................................................... 16
Safety Information ....................................................................................................................... 24
Precautions.................................................................................................................................. 25
• Operating instructions are built into your BRAVIA TV. Refer to “To use i-Manual” for operation (page 11).
• Before operating the TV, please read “Safety Information” (page 24). Retain this manual for future reference.

4GB
Checking the accessories
For all models
Remote (1)
Size AAA batteries (R3 type) (2)
Table-Top Stand (1)*1
For KDL-60/52/40NX800, KDL-46/
40NX700 models
AC power cord (mains lead) (1)
Cable holder (1) (except KDL-60NX800)
Black spacers (4) (KDL-60/52/40NX800
only)
Screws (M6 × 20) (4) (KDL-60NX800
only)
Stand rear cover (1)*2
Bottom cover (1)*2(KDL-60/52/
40NX800 only)
Fixing screws for Table-Top Stand
(M5 × 16) (4)
Assembling screws for Table-Top
Stand (M5 × 16) (4) (KDL-40NX800 and
KDL-40NX700 only)
For KDL-60/55NX810, KDL-46/
40NX710 models
Hexagon wrench (1)
Assembling screws for Table-Top
stand (4) (except KDL-40NX710)
Assembling screws for Table-Top
stand (2) (KDL-40NX710 only)
*1For KDL-60NX800, attached to the TV.
Disassembled except for KDL-60/52NX800 and
KDL-46NX700.
Refer to the supplied Table-Top Stand leaflet to
assemble the stand.
*2For KDL-60NX800, attached to the TV.
Inserting batteries into the
remote
1Remove the protection sheet.
2Push and slide the cover upward.

5GB
Setting Up
Attaching the Table-Top
Stand
Refer to the supplied Table-Top Stand leaflet
for proper attachment for some TV models.
~
•For best picture quality, do not expose the screen
to direct illumination or sunlight.
•If the TV is brought directly from a cold to a warm
location, or is placed in a very damp room, or is
placed in a room in which heating has just been
turned on, moisture may condense on the surface
or inside the TV. Should this occur, turn off the
TV and leave the TV off until the moisture
evaporates, and then the TV can be used. If you
notice moisture condensation between the glass
panel and the LCD, turn on the TV and the
condensation will evaporate after the TV has
warmed up.
For KDL-52/40NX800, KDL-46/
40NX700
1Place the TV set on the Table-Top
Stand.
2Fix the TV to the Table-Top Stand
according to the arrow marks that
guide the screw holes using the
supplied screws.
~
•If using an electric screwdriver, set the tightening
torque at approximately 1.5 N·m {15 kgf·cm}.
3After all the screws are tightened,
attach the supplied stand rear cover to
the Table-Top Stand.
For KDL-60/55NX810, KDL-46/
40NX710
1Align with the two dowels of the Table-
Top Stand, and gently place the TV,
checking the fmark is facing the front.
2Attach the TV and Table-Top Stand
with the supplied screw and hexagon
wrench.
~
•Set the torque setting to approximately 3 N·m {30
kgf·cm}.
Reattaching the Table-Top Stand to the
TV
Attach to the original position using the
removed screws. See “Detaching the Table-
Top Stand form the TV” (page 9).
Setting Up
(Continued)

6GB
Adjusting the viewing angle of
the TV (except 60-inch models)
This TV can be adjusted within the angles
shown below.
~
•To return to 0°, reverse the below procedure.
For KDL-52/40NX800, KDL-46/
40NX700
For KDL-55NX810, KDL-46/40NX710
14
23
Remove screw as
shown.
6º0º
Install screw into
the top screw hole
of the Table-Top
Stand.
Slide in.Lift up and tilt.
6º0º

7GB
Connecting an antenna
(aerial)/cable/VCR
Connecting an antenna (aerial)/cable
Connecting an antenna (aerial)/cable
and VCR
~
•For KDL-60/52/40NX800, after connecting
cables, install the bottom cover and stand rear
cover.
Antenna (aerial) cable
(not supplied)
Antenna (aerial) cable
(not supplied)
Antenna (aerial)
cable
(not supplied)
Antenna
(aerial) cable
(not supplied)
AV cable
(not supplied)
VCR
Setting Up

8GB
Preventing the TV from
toppling over
1Install a wood screw (4 mm in
diameter, not supplied) in the TV stand.
2Install a machine screw (not supplied)
into the screw hole of the TV.
For KDL-60/52/40NX800, KDL-46/
40NX700
Use M4 × 16 screw
For KDL-60/55NX810, KDL-46/
40NX710
Use M4 × 8 screw
3Tie the wood screw and the machine
screw with a strong cord (not supplied).
z
•An optional Sony support belt kit is used to secure
the TV. Contact your nearest Sony service centre
to purchase a kit. Have your TV model name
ready for reference.
Bundling the cables
~
•Do not bundle the AC power cord (mains lead)
together with other cables.
•A cable holder is available for KDL-52/40NX800
and KDL-46/40NX700. To bundle the cables,
follow steps 3 to 5.
For KDL-60/52/40NX800, KDL-46/
40NX700
For KDL-60/55NX810, KDL-46/
40NX710
*KDL-60/52/
40NX800 only
*

9GB
Performing the initial set-up
1Connect the TV to your AC power
outlet (mains socket).
2Check the ENERGY SAVING
SWITCH setting is on (z).
3Press 1on the TV.
When you switch on the TV for the first
time, the Language menu appears on the
screen.
Follow the instructions on the screen.
Programme Sorting: Changes the order of
analogue channels stored in the TV.
1Press F/fto select the channel you want
to move to a new position, then press .
2Press F/fto select the new position for
the channel, then press .
~
•You can also tune channels manually.
Detaching the Table-Top
Stand from the TV
~
•Remove the screws guided by the arrow marks
of the TV.
•Do not remove the Table-Top Stand for any
reason other than to install corresponding
accessories on the TV.
For KDL-60/52/40NX800, KDL-46/
40NX700
For KDL-60/55NX810, KDL-46/
40NX710
4
KDL-60/52/
40NX800
KDL-46/
40NX700
KDL-60/55NX810,
KDL-46/40NX710
KDL-60NX810
Joint
Setting Up

10 GB
Watching TV
To watch programmes
To utilise the TV’s features
z
•The number 5, N, PROG + and AUDIO
buttons on the remote have a tactile dot.
Use the tactile dots as a reference when
operating the TV.
1Turn on the TV.
1Switch ENERGY SAVING SWITCH
on (z).
2Press 1on the TV to turn on the TV.
2Select a mode.
3Select a TV channel.
Using Digital Electronic Programme
Guide
Press GUIDE in digital mode to display the
programme guide.
HOME button
Press to display various operation and setting
screens.
OPTIONS button
Press to display convenient functions based
on the current input or content.
GUIDE
HOME
2
3
OPTIONS
Settings
TV
System Settings
Sound
BRAVIA ENGINE 3 PRO
Add to Favourites
Lock/Unlock
PAP
Motionflow
Sleep Timer
Headphone Volume
Speaker
System Information

11 GB
To use i-Manual
xWelcome to i-Manual
x“BRAVIA” TV Features
xWatching TV
Introduces convenient features such as EPG
Guide, Favourites, etc.
xUsing the Home Menu
Customise your TV settings, etc.
xFun Features with Connected
Equipment
Introduces how to connect optional equipment.
xParts Description
xTroubleshooting
Find solutions for your problem.
xIndex
~
•Images and illustrations may differ from what is displayed on the screen.
Operating instructions are built into your BRAVIA
TV and can be displayed on the screen.
You can browse your i-Manual anytime you need
to find the varieties of convenient functions.
1Press i-MANUAL.
2Press G/g/F/f/ to select items.
1
2
Watching TV

12 GB
Additional Information
Troubleshooting
Check whether the 1(standby) indicator is flashing in red.
When the 1(standby) indicator is flashing
The self-diagnosis function is activated.
1Count how many times the 1(standby) indicator flashes between each three second
break.
For example, the indicator may flash three times, go off for three seconds, then flash again three
times.
2Press 1on the TV to turn it off, disconnect the AC power cord (mains lead), and inform
your dealer or Sony service centre of how the indicator flashes (number of flashes).
When the 1(standby) indicator is not flashing
1Check the items in the tables below. (Also refer to “Troubleshooting”in the i-Manual.)
2If the problem persists, have your TV serviced by qualified service personnel.
Condition Explanation/Solution
There is no picture (screen
is dark) and no sound.
•Check the antenna (aerial)/cable connection.
•Connect the TV to the AC power (mains), and press 1on the TV.
•If the 1(standby) indicator lights up in red, press TV"/1.
Tiny black points and/or
bright points appear on the
screen.
•The screen is composed of pixels. Tiny black points and/or bright
points (pixels) on the screen do not indicate a malfunction.
General
The TV’s power cannot be
turned on.
•Check if ENERGY SAVING SWITCH is on (z).
The TV turns off
automatically (the TV
enters standby mode).
•Check if the “Sleep Timer” is activated, or confirm the
“Duration” setting of “On Timer”.
•Check if the “Idle TV Standby” is activated.
The remote does not
function.
•Replace the batteries.
•Your TV may be in SYNC mode.
Press SYNC MENU, select “TV Control” and then select “Home
(Menu)” or “Options” to control the TV.
The “Parental Lock” password
has been forgotten.
•Enter 9999 for the PIN code. (PIN code 9999 is always accepted.)
The TV surrounds become
warm.
•When the TV is used for an extended period, the TV surrounds
become warm.
You may feel hot when touching there by the hand.

13 GB
Specifications
System
Panel system LCD (Liquid Crystal Display) Panel
TV system Analogue: B/G, I, D/K, M
Digital: DTMB
Colour/video system Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video
input)
Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4
Channel coverage Analogue:B/G: VHF: E2–E12/UHF: E21–E69/CATV: S01–S03, S1–S41
I: UHF: B21–B69/CATV: S01–S03, S1–S41
D/K: VHF: C1–C12, R1–R12/UHF: C13–C57, R21–R60/CATV: S01–S03,
S1–S41
M: VHF: A2–A13/UHF: A14–A79/CATV: A8–A2, A–W+4, W+6–W+84
Digital: UHF
Sound output KDL-60/52/40NX800, KDL-46/40NX700
10 W + 10 W
KDL-60/55NX810, KDL-46/40NX710
8 W + 8 W + 10 W
Input/Output jacks
Antenna (aerial)/cable 75 ohm external terminal for VHF/UHF
1Video input (phono jack)
1, 2 Audio input (phono jacks)
/2 COMPONENT IN
Supported formats: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
2 Video input (phono jacks)
HDMI IN1, 2, 3, 4 Video:
KDL-60/52/40NX800, KDL-46/40NX700
1080/24p, 1080p, 1080i, 720p, 576p, 576i, 480p, 480i
KDL-60/55NX810, KDL-46/40NX710
1080/24p, 1080p, 1080i, 720/24p, 720p, 576p, 576i, 480p, 480i
Audio: Two channel linear PCM 32, 44.1 and 48 kHz, 16, 20 and 24 bits, Dolby Digital
Analogue audio input (minijack) (HDMI IN4 only)
DIGITAL AUDIO OUT (OPTICAL) Digital optical jack (Two channel linear PCM, Dolby Digital)
(VAR/FIX) Audio output (phono jacks)
PC IN PC Input (Mini D-sub 15-pin)
PC audio input (minijack)
USB port
iHeadphones jack
LAN 10BASE-T/100BASE-TX connector (Depending on the operating environment of the
network, connection speed may differ. 10BASE-T/100BASE-TX communication rate and
communication quality are not guaranteed for this TV.)
* For LAN connections, use a Category 7 10BASE-T/100BASE-TX cable (not supplied).
3D SYNC (KDL-60/55NX810, KDL-46/
40NX710 only)
3D Sync terminal for optional transmitter
(Continued)
Additional Information

14 GB
Model name KDL- 60NX800 52NX800 46NX700
Power and others
Power requirements 220 V – 240 V AC, 50 Hz
Screen size (measured diagonally) 60 inches
(Approx. 152.5 cm)
52 inches
(Approx. 132.2 cm)
46 inches
(Approx. 116.8 cm)
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Power consumption Indicated on the rear of the TV
Dimensions
(Approx.)
(w × h × d)
with Table-Top Stand
(mm)
1,440 × 921 × 380 1,261 × 819 × 400 1,127 × 748 × 320
without Table-Top Stand
(mm)
1,440 × 889 × 64 1,261 × 787 × 64 1,127 × 716 × 64
Mass (Approx.) with Table-Top Stand 50.6 kg 36.1 kg 27.8 kg
without Table-Top Stand 43.3 kg 30.1 kg 24.0 kg
Supplied accessories See “Checking the accessories” (page 4).
Optional
accessories
Wall-Mount Bracket SU-WL500/WL50B SU-WL700/WL50B
Wall-Hanging Bracket SU-WH500
TV Stand* — SU-52NX1 SU-46NX1
Model name KDL- 40NX800 40NX700
Power and others
Power requirements 220 V – 240 V AC, 50 Hz
Screen size (measured diagonally) 40 inches (Approx. 101.6 cm)
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Power consumption Indicated on the rear of the TV
Dimensions
(Approx.)
(w × h × d)
with Table-Top Stand
(mm)
994 × 669 × 290 994 × 673 × 290
without Table-Top Stand
(mm)
994 × 635 × 64 994 × 641 × 64
Mass (Approx.) with Table-Top Stand 23.8 kg 22.6 kg
without Table-Top Stand 20.1 kg 19.2 kg
Supplied accessories See “Checking the accessories” (page 4).
Optional
accessories
Wall-Mount Bracket SU-WL700/WL50B
Wall-Hanging Bracket SU-WH500
TV Stand* SU-40NX1

15 GB
* TV Stand may not be available depending on your region/country.
Design and specifications are subject to change without notice.
Model name KDL- 60NX810 55NX810 46NX710 40NX710
Power and others
Power requirements 220 V – 240 V AC, 50 Hz
Screen size (measured diagonally) 60 inches
(Approx. 152.5 cm)
55 inches
(Approx. 138.8 cm)
46 inches
(Approx. 116.8 cm)
40 inches
(Approx. 101.6 cm)
Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical)
Power consumption Indicated on the rear of the TV
Dimensions
(Approx.)
(w × h × d)
with Table- Top S tan d
(mm)
1,400 × 865 × 303 1,276 × 800 × 323 1,083 × 690 × 270 944 × 612 × 245
witho ut Ta ble-Top St an d
(mm)
1,400 × 836 × 45 1,276 × 770 × 32 1,083 × 660 × 31 944 × 582 × 32
Mass (Approx.) with Table-Top Stand 43.0 kg 32.2 kg 24.4 kg 19.8 kg
witho ut Ta ble-Top St an d 36.6 kg 26.9 kg 20.5 kg 16.1 kg
Supplied accessories See “Checking the accessories” (page 4).
Optional
accessories
Wall-Mount Bracket SU-WL500 SU-WL700/WL500 SU-WL700/WL500/WL50B
Wall-Hanging Bracket SU-WH500
TV Stand* — SU-B550S SU-B460S SU-B400S
Additional Information

16 GB
Installing the Accessories (Wall-Mount/Wall-Hanging
Bracket)
To Customers:
For product protection and safety reasons, Sony strongly recommends that installing of your TV be
performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the installation, periodic maintenance and examination of this
product.
Your TV can be installed using the SU-WL500 (except KDL-52/40NX800, KDL-46/40NX700)/
SU-WL50B (except KDL-60/55NX810), or SU-WL700 (except KDL-60NX810 / 60NX800) Wall-
Mount Bracket or SU-WH500 Wall-Hanging Bracket (sold separately).
• Refer to the Instructions supplied with the Wall-Mount Bracket or Wall-Hanging Bracket to
properly carry out the installation.
• Refer to “Detaching the Table-Top Stand from the TV” (in this manual).
Be sure to remove the joint when the Table-Top Stand is not attached to the TV. (KDL-60/
55NX810, KDL-46/40NX710 only)
Sufficient expertise is required for installing this product, especially to determine the strength of
the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the
wall to Sony dealers or licensed contractors and pay adequate attention to safety during the
installation. Sony is not liable for any damage or injury caused by mishandling or improper
installation.

17 GB
SU-WL500, SU-WL50B
For KDL-60/52/40NX800, KDL-46/40NX700
~
•When installing the TV on a wall, remove the four screws from the rear of the TV. (They are fastened in the
screw holes for wall mounting.) Be sure to store the removed screws in a safe place, keeping them away from
children.
•Attach the Mounting Hook
–For KDL-60NX800: Use the supplied four spacers and four M6 × 20 screws.
–For KDL-52NX800/40NX800: Use the supplied four spacers and the four +PSW 6 × 16 screws supplied
with SU-WL50B.
–For KDL-46/40NX700: Use the four +PSW 6 × 16 screws supplied with SU-WL50B.
•Place the TV on the Table-Top Stand, when securing the Mounting Hook.
•Remove the bottom cover and terminal cover first before detaching the Table-Top Stand. See step 4 (page 20)
for details.
•When attaching the Table-Top Stand again, be sure to fasten the four screws (previously removed) to the
original holes on the rear of the TV.
For KDL-60/55NX810, KDL-46/40NX710
~
•Attach the Mounting Hook using four +PSW6 × 16 screws supplied with the Wall-Mount Bracket.
Mounting Hook
Screw (M6 × 20)
SU-WL500 (KDL-60NX800 only)
Spacer
Mounting
Hook
Screw (M6 × 20) (KDL-60NX800)
Screw (+PSW 6 × 16) (KDL-52/
40NX800, KDL-46/40NX700)
Spacer (KDL-60/52/
40NX800 only)
SU-WL50B
Screw
(+PSW6 × 16)
Mounting Hook
SU-WL500
Soft cloth
SU-WL50B (KDL-46/40NX710 only)
Screw
(+PSW 6 × 16)
Soft cloth
Mounting
Hook
Additional Information
(Continued)

18 GB
TV installation dimensions table
SU-WL500
SU-WL50B
Unit: mm
Figures in the above table may differ slightly depending on the installation.
The wall that the TV will be installed on should be capable of supporting a weight of at least four
times that of the TV. Refer to “Specifications” (page 14, 15) for its weight.
Model Name
KDL-
Display
dimensions
Screen
centre
dimension
Length for each mounting angle
Angle (0°)Angle (20°)
AB
CDEFGH
SU-
WL500
SU-
WL50B
SU-
WL500
SU-
WL50B
SU-
WL500
SU-
WL50B SU-WL500 only
60NX810 1,400 836 53 – 482 – 93 – 342 785 496
60NX800 1,440 889 31 59 490 518 121 122 384 842 514
55NX810 1,276 770 86 – 482 – 92 – 318 723 495
52NX800 1,261 787 – 110 – 518 – 116 – – –
46NX710 1,083 660 141 169 482 510 91 92 280 620 495
46NX700 1,127 716 – 149 – 524 – 116 – – –
40NX800 994 635 – 169 – 518 – 116 – – –
40NX710 944 582 178 206 482 510 91 92 252 547 495
40NX700 994 641 – 169 – 524 – 116 – – –
Screen centre point
Screen centre point
WARNING

19 GB
Screw and Hook locations diagram/table
SU-WL500
SU-WL50B
Model Name KDL- Screw location Hook location
SU-WL500 SU-WL50B SU-WL500 SU-WL50B
60NX810 d, g – a –
60NX800 e, j a
55NX810 e, j – b –
52NX800 – e, j – b
46NX710 e, j b
46NX700 – e, j – b
40NX800 – e, j – b
40NX710 e, j b
40NX700 – e, j – b
Screw location
When installing the Mounting Hook on the
TV.
Hook location
When installing the TV onto the Base Bracket.
b
a
c*
*Hook location “c” cannot be used
for the models.
a
b
cc
b
a
Screw location
When installing the Mounting Hook on the
TV.
Hook location
When installing the TV onto the Base Bracket.
b
a
c*
*Hook location “c” cannot be used
for the models.
Base Bracket
Mounting Hook
Additional Information
(Continued)

20 GB
SU-WL700 (except KDL-
60NX810, KDL-60NX800)
Installing on a wall
~
•Remove the bottom cover and terminal cover
when installing on a wall (KDL-52/40NX800
only).
•Be sure to use the black spacers supplied with the
TV when installing on a wall (KDL-52/40NX800
only).
Be sure to install the Wall-Mount Bracket securely
to the wall following the instructions in this as well
as the manual provided with the Wall-Mount
Bracket. The numbers given in the parentheses
indicate the installation steps described in the
instruction manual provided with Wall-Mount
Bracket.
1Check the parts supplied with the Wall-
Mount Bracket (1).
Refer to the instruction manual provided
with the Wall-Mount Bracket.
2Decide on the installation location.
(2-1)
Refer to the following “TV installation
dimensions table”. Allow for suitable
clearance between the TV, the ceiling and
protruding parts of the wall as instructed.
3Install the Base Bracket on the wall.
(2-2 through 3)
Decide the positions of the screw on the
wall and install the Base Bracket. Refer to
the instruction manual provided with the
Wall-Mount Bracket for details.
4Detach the Table-Top Stand from the
TV, if necessary. (4-1)
•See “Detaching the Table-Top Stand
from the TV” (in this manual) for details.
5Connect the supplied AC power cord
(mains lead). (5-1) (KDL-52/
40NX800, KDL-46/40NX700 only)
~
•Do not attach the bottom cover and terminal
cover.
6Place the Spacers (KDL-52/40NX800
only).
~
•When attaching the Table-Top Stand again, be
sure to fasten the four screws (previously
removed) to the original holes on the rear of
the TV.
7Attach the Mounting Bracket and the
Lock Bracket. (4-3 through 4-7)
Refer to the instruction manual provided
with the Wall-Mount Bracket.
8Prepare the paper template. (5-2)
1. Refer to the following “TV installation
dimensions table” and mark the TV outline
on the template.
2. Tape the template to the wall as
instructed in the manual provided with the
Wall-Mount Bracket.
Follow the instruction manual provided
with the Wall-Mount Bracket to complete
the installation. (5-3 through 6)
Precautions
1Remove the four screws, and be
sure to store them in a safe place,
keeping them away from children.
2Place the four
spacers (supplied).
