KDL- 46Z5100
46" BRAVIA® Z Series LCD TV
Key Features
16:9 Full HD 1080p Resolution Panel (1920x1080)
Motionflow ™ 240Hz technology
BRAVIA® Internet Video
3
BRAVIA® Widgets
BRAVIA Engine ™3 fully digital video processor
USB with photos, music, and video
DLNA ® support for photos, music, and video
TV Guide® Interactive Program Guide
Thin and slim design
HD input x 7
Xross Media Bar™ w/ enhanced 3D favorites menu
Scene Select
Bravia® Link module compatible
BRAVIA® Sync ™capable
1
Key Technologies
16:9 Full HD 1080p Resolution Panel (1920x1080) 16:9 Full HD 1080p resolution panel (1920x1080)
accepts any high definition video signal and renders it with optimum resolution, so you can take full
advantage of Blu - ray Disc™players and Sony PLAYSTATION 3 entertainment systems that can
deliver 1080p content.
®
®
Motionflow™240Hz technology Motionflow 240Hz technology is Sony’s highest level of motion
detail and clarity so you enjoy unprecedented motion detail in sports, movies and games.
Motionflow 240Hz technology quadruples the frame rate, resulting in a crisp fluid motion and a
natural, realistic viewing experience.
BRAVIA™ Internet Video With BRAVIA Internet Video you can enjoy one of the largest collections
of premium and free on - demand entertainment directly to your HDTV. Use your in - home broadband
connection and the BRAVIA HDTV remote control to access online video, music, and more content
from over 20 providers including Amazon Video On Demand, YouTube™, Sports Illustrated, Sony
Pictures, Sony Music,Slacker, and Epicurious.com.
4
4
BRAVIA widgets Personalize your viewing experience by selecting, positioning, and resizing widgets
on your BRAVIA HDTV display. BRAVIA widgets are small icons that can be accessed with the touch of
one button providing you with the latest in news, weather, sports, and much more right on your
BRAVIA Z - Series HDTV.
®
BRAVIA Engine ™ 3 fully digital video processor BRAVIA Engine 3 is the newest fully digital video
processor from Sony . It uses a collection of enhanced algorithms to significantly reduce noise,
enhance overall image detail, and optimize contrast so every scene produces sharp, vibrant, life - like
images.
®
USB with photos, music, and video Connect your camera, USB - enabled MP3 player, or USB
storage device directly to the HDTV's USB input to view photos on the big screen or listen to your
favorite MP3s. BRAVIA Z - Series HDTVs also include mpeg2 video file support, so you can go straight
from shooting video to screening it via USB.
®

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 06/25/2009
KDL- 46Z5100
46" BRAVIA® Z Series LCD TV
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
ClosedCaptions(CC): Analog, Digital
On - ScreenDisplay: 3DXMB
IlluminatedSonyLogo: Yes
Finish(SurfaceColor): Black
SupportsRear Mounting ofDMeX ™ Module: Yes
DemoMode: Yes
BRAVIA® LinkModule support: DMX - NV1,DMX - SW1,DMX - CT1,DMX -
DVD,DMX - WL1
Display
BacklightType: CCFL
DisplayDevice: LCD
Video
VideoProcessing: BRAVIAEngine 3™ Technology
CineMotion ® Reverse3:2PulldownTechnology: Yes
GameMode: Yes
WideMode: Wide Zoom, Normal, Full (Full1 - 2for PC), H Stretch,Zoom
DeepColor: Yes
3DCombFilter: Yes
MPEGNoiseReduction: Yes
AutoWide: Yes
4:3Default: Yes
24p True Cinema ™ Technology: Yes
PictureMode: Vivid,Standard, Custom, Cinema, Sports,Game, Graphics,
Photo - Vivid,Photo - Stardard,Photo - Original, Photo - Custom
AdvancedContrastEnhancer (ACE): Yes
Motionflow ™ Technology: 240Hz
Audio
DigitalAmplifier: S - MasterDigital Amplifier
VoiceZoom: Yes
AutoSAP: Yes
AutoMute(on no signal): Yes
SteadySound ® AutomaticVolumeControl: Yes
AudioOut: Variable/Fixed
SonyOriginal Surround: S - Force
StereoSystem: MTS
Dolby® : Dolby Digital
AlternateAudio(Digital): Yes
SurroundEffect: Sports,Music, Cinema, Game
SoundBooster: Yes
5.1ChannelAudioOut: Yes
SoundMode: Dynamic,Standard, Clear Voice, Custom
5.1chThroughOut(Handycam): Yes
SoundEnhancer: Yes
Convenience
ChannelJump: Yes
FavoriteChannel: Yes
MultipleLanguageDisplay: English, French, Spanish
InfoBanner: TVGuide on Screen,PSIP, XDS
SleepTimer: Yes
InputSkip: Automatic
ChannelSurf: Yes
RemoteControl: RM - YD029
ChannelBlock(withpassword): Yes
EditChannelLabels: Yes
LabelInputs: Yes
ID - 1Detection: Yes
On/OffTimer: Yes
USBApplication(s): MusicPlayer(mp3), Photo Viewer (jpeg),VideoPlayer
(mpeg2TS)
TheatreMode(Theatre Button): Yes
Show/HideChannels: Yes
BRAVIA®Sync™ : Yes
ParentalControl: Yes
BRAVIA®Sync™MenuButton: Yes(onRemote Control)
On - ScreenDisplayforExternalInput: Yes
ChannelLabels: Yes
ProgramBlock: Yes
Controlfor HDMI™ ( HDMI™ CEC): Yes
AutoPhotoMode: Yes(DLNA, USB)
On - ScreenClock: Yes
PictureAdjustmentsLock: Yes
WhiteBalance: RGBGain/Bias
AutoPicture Setting w/HDMI™ : Game, Graphics, Photo, Cinema
InternetRadio: Yes
®
SceneSelect: Cinema,Sports, Photo, Music, Game,Graphics, General,
Auto
TheatreModewithCinemaSurround: Yes
StartUp BRAVIA® LogoDisplay: Yes
FavoritesMenu: Graphic
NewTheatreModewithsurround: Yes
TV Guide On - Screen: Yes(Gemstar ver.10)
Network
DLNA: Client(Photo), Client (Music), Client (Video)
BRAVIA® InternetVideo: Yes
BRAVIA® InternetWidgets: Yes
Specifications
General
TelevisionType: FlatPanel LCD HDTV
Display
ViewingAngle(Right/Left): 178(89/89)
ViewingAngle(Up/Down): 178(89/89)
On - screenContrastRatio: 3,800:1
DynamicContrastRatio: 100,000:1
ScreenSize(measureddiagonally): 46"
NativeResolution: 1920x 1080
DisplayResolution: 1920x 1080p (FullHD)
PanelBit: 10 - bit
AspectRatio: 16:9
ColorRange(u'v'): 90%of NTSC
ColorRange (xy): 72%of NTSC
TV System
Tuner(Cable): ClearQAM
Tuner(Terrestrial): ATSCTuner, NTSC Tuner
ChannelCoverage: VHF: 2 - 13
UHF: 14 - 69
CATV (analog): 1 - 135
CATV (digital) : 1 - 135
TVSystem (Analog): M
NumberofTuners(Analog): 1
NumberofTuners(Digital): 1(Hybrid)
TVSystem (Digital): ATSC
ColorSystem: NTSC3.58
Video
VideoSignal: 1080/60p(HDMI™/ COMPONENT),1080/60i,1080/24p
(HDMI™ONLY),720/60p, 480/60p, 480/60i
Audio
AudioPowerOutput: 20W(10W+10W)
Speakers(Total): 2
SpeakerConfiguration: DirectSpeaker - 4.5 x 20 mm
Inputs and Outputs
ComponentVideo(Y/Pb/Pr ) Input(s): 2 (Rear) (1 fixed/1 selectable)
CompositeVideoInput(s): 2(1Side/1Rear - selectable)
DigitalAudio Output(s): OpticalDigitalOutput - 1(Rear)
RFConnectionInput(s): 1(Rear)
S - VideoInput(s): 1(Side)
AnalogAudioInput(s) (Total): 3(1 Side/2 Rear)
AudioOut: 1(Rear)
HDMI™ Connection(s)(Total): 4(3 Side/1 Rear)
PCIn (D - Sub)+Audio In (Stereo Mini): 1(Side)see owner's manual for
supportedtimings
USB2.0: 1(Side)
HDMI™ PCInput: Yes (see owner's manual for supported timings)
S - VideoDetection: Yes
ACPowerInput: 1(Rear)
EthernetConnection(s): 1(Rear)
Analog Audio Input(s) for HDMI ™ : 1(Rear)
USB1.1: 1(Rear) for Service only
Power
PowerConsumption(inStandby): Lessthan 0.1W (120VAC)
PowerRequirements(voltage): AC120 - 240V
PowerRequirements(frequency): 50/60Hz
PowerConsumption(inOperation) max.: 240W (max)
PowerConsumption(in Download AcquisitionMode): Lessthan 20W
Regulation and Standard Compliance
VESA® HoleSpacingCompatible: Yes
VESA® HolePitch: 300x300M6
Service and Warranty Information
LimitedWarrantyTerm: 1 YearParts/ 1 Year Labor
OnlineInstructionManual (Reference Book): Yes
Energy Saving & Efficiency
LightSensor ™ Technology: Yes
PowerSaving Modes: Yes
EnergyStar® compliant: ExceedsEnergy Star Version3.0byatleast
15%
EcoSettings: Yes
DynamicBacklightControl: Yes
BacklightOffMode: Yes
PCPowerManagement: Yes
EstimatedAnnualEnergyConsumption(kWh): 346kWhr
IdleTVStandby: Yes
PowerConsumption(OnMode) for Energy Star: 189.3W
PowerConsumption(StandbyMode) for Energy Star: Lessthan0.1W
(120VAC)
Recycled & Recyclable Materials
ProductMaterials: RecycledPlastic
PackagingMaterials: RecycledCarton (more than 40%)
PrintedMaterials: RecycledPaper
LED
HDIndicator: Yes
Dimensions
Weight: 52.9 lbs. (24kg) with pedestal; 45.6 lbs. (20.7kg) without pedestal
Measurements: 431/8x29 3/8 x 13 in (1094x743x330mm)with
pedestal;431/8x 27 3/8 x 33/8in(1094x 695 x 85mm) without
pedestal
Supplied Accessories
RemoteControl RM - YD029
Batteries(Type AA x2)
ACPower Cord (separate)
Screws(4) for Stand
OperatingInstructions
QuickSetup Guide
WarrantyCard
Table Top Stand (separate, assembly required)
Optional Accessories
SU - WL500Wallmount Bracket
UPCCode: 027242756861
2Works with other BRAVIA®Sync™ orTheatreSyncTMlabeledhome
audio/videoproducts when connected via HDMI.
3Limited to resolutionssupported by both thePC and theSony ® HDTV.
Forsupported resolutions, seeSony TV user's manualand PC
documentation.
4Video quality andpicture size willvary depending onyour broadband
connectionspeed (we recommendatleast 2.5Mbps and10Mbpsfor
HDcontent)and the contentitself.Selectcontent provided and
subject to change. ”
5. See product specifications for power consumption details.
6.Distance will vary depending uponenvironmental conditions
©2009SonyElectronics Inc. All rights reserved. Reproduction inwhole or
inpartwithoutwrittenpermissionisprohibited. Sony, HDNA, BRAVIA,
BRAVIAEngine,BRAVIASync, Cybershot, DMex, Handycam, Motionflow,
24pTrue Cinema, Xross MediaBar, and their respectivelogos are
trademarksofSony.PlayStationisatrademark of Sony Computer
EntertainmentInc. HDMI, theHDMI logo andHigh - DefinitionMultimedia
Interfacearetrademarks of HDMI LicensingLLC.Energy Star and the
EnergyStar mark are registeredU.S.marks. Blu - rayDisc is atrademark.
TVGuide is atrademark of TVGuide Magazine Group,Inc. All other
trademarksaretrademarksoftheirrespectiveowners.Featuresand
specifications are subject to change without notice. Non - metricweights
and measures areapproximate.
