KDL- 52XBR3
BRAVIA® XBR® LCD Television
Key Features
16:9 Native 1080p Full HD Resoluton Panel (1920x1080)
7000:1 Dynamic Contrast Ratio (On-Screen CR 1700:1)
BRAVIA Engine ™PRO featuring DRC-MFv2.5
Live Color Creation featuring WCG -CCFL backlight
1080p HD Inputs -HDMI™1080p (x3), YPbPr (x2)
16:9 1080p HD Resolution Panel (1920 x 1080)
BRAVIA Engine ™PRO Video Processor
Live Color Creation System featuring WCG -CCFL backlight
ATSC Digital Tuner with unscrambled digital cable (QAM)
capability
HDMI (High Definition Multimedia Interface) x3 (1080/60p)
Key Technologies
Full HD 1080 There are a lot of ways to define high-definition but BRAVIA Full HD means you’ re getting the best resolution that high -
definition has to offer consumers. With Sony BRAVIA XBR HDTVs, Full HD 1080 means 1920 x 1080 pixels and 1080p video inputs. Your
lifestyle demands the best in high-definition and with BRAVIA Full HD 1080 products you get it.
1920 x 1080 Panel Resolution When it comes to high -definition TV the pinnacle of performance is achieved by using 1920 x 1080
display panels. And BRAVIA V-Series televisions have them. Full HD 1920 x 1080 panel resolution with over 2 million pixels (more than
twice that of 720p HDTV) is exactly what you need to reproduce the 1080p content that can be delivered by our cutting edge 1080p Blu-
ray disc™player. And working with BRAVIA Engine™PRO everything from standard definition and high definition is upconverted to
1080p for a picture so real it’s like you’ re actually there.
BRAVIA Engine™PRO Full Digital Video Processor Presenting the next evolution of the BRAVIA Engine ™: BRAVIA Engine™PRO.
Sony improved on the great benefits of the BRAVIA Engine™by adding a picture quality enhancement circuit called Digital Reality
Creation Multi-function v2.5. DRC-MFv2.5 now has the added ability to process interlace and progressive video signals and because it
has twice the processing power of previous DRC-MF circuits, it can do its processing and output them to 1080p. (Native 1080p input
signals are not processed through DRC-MFv2.5.) Add to this the crisp details, outstanding contrast, eye popping colors, and
dramatically reduced digital artifacts that DRC-MF circuitry is known for. And the best part of all is that DRC-MFv2.5 is user adjustable
according to the video source. All of this helps define the reason why people want Sony TVs to begin with unparalleled picture quality.
Live Color Creation System featuring WCG - CCFL Decades of television know how allow us to realize that an LCD TV is more
than just the panel; it ’s actually a system. Uncompromised picture quality starts with combining carefully chosen components and
circuits to optimize system quality, among these are the color creation and processing functions. That’s what Live Color Creation is all
about. It starts with the BRAVIA Engine™PRO video processing system, which enhances primary colors and corrects half-tone colors for
natural overall color. Next, a WCG-CCFL backlight using Sony’s phosphor formula delivers a specific spectrum of light designed to
work with our specially formulated color filters. The combination of these three components creates deep, deep blues and natural
greens for overall colors that draw you right into the picture.
Advanced Contrast Enhancer (ACE) Function Sony’s Advanced Contrast Enhancer (ACE) builds on our excellent on- contrast
ratio performance. A Dynamic Contrast Ratio of up to 7000:1 is achieved by using real-time image processing to adjust the contrast
along with optimizing backlight levels. But rather than focus on the "numbers", Sony focuses on actual picture performance avoiding
exaggerated blacks where detail can be lost. ACE translates to blacker blacks in darker scenes, as well as better shadow detail in
other scenes for a difference that you can see.
2
HDMI™and PC Connectivity Designed for maximum versatility, Sony’s BRAVIA XBR-Series LCD TVs are equipped with a
comprehensive range of input interfaces. The HDMI (High -Definition Multimedia Interface) is the first industry- supported, uncompressed,
all-digital audio/video interface. HDMI technology supports enhanced or High Definition video, together with multi-channel digital
audio to provide matchless image and sound reproduction. BRAVIA XBR Series TVs include (3) HDMI 1080/60p inputs. The PC input
(HD-15-pin) offers easy connection to your PC, allowing you to use your high resolution BRAVIA XBR-Series Digital TV as a computer
monitor.
4

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 800.222.7669 • www.sony.com
Last Updated: 05/23/2008
KDL- 52XBR3
BRAVIA® XBR® LCD Television
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Video Label: Yes
RS-232C Control: Yes
Closed Captions (CC): Yes
Video
Video Processing: Yes (BRAVIA Engine™PRO)
Noise Reduction: Yes
DRC® MultiFunction Circuitry: Yes (DRC MF V2.5)
Game Mode: On/Off
Picture Modes: Vivid, Standard, Custom
Display Technology: LCD (178°wide viewing
angle LCD display panels)
High Definition: Yes (Full HD 1080)
3D Comb Filter: Yes
Live Color Creation™Technology: Yes
Audio
MTS Stereo Decoder: Yes
A/V Synch: Off/1/2/3
Digital Amplifier: Yes
Steady Sound® Automatic Volume Control: Yes
Dolby® : Dolby® Digital (AC3/ATSC only)
Convenience
Favorite Channel: Yes
Speed Surf ™ Channel Selection: Yes
Parental Control (V-Chip): Yes
Programmable Timer: Yes
Sleep Timer: 15, 30, 45, 60, 90, Off
Timer Events: Timer 1, Timer 2
Power Save Mode: Standard, Reduced, Picture Off
Picture Freeze: Yes
Input Skip: Yes
Remote Control: Yes
ID- 1 Detection: Yes
LightSensor ™ : Yes
Specifications
General
Aspect Ratio: 16:9
Television Type: Flat Panel LCD HDTV
Audio
Audio Power Output: 22W (11W x2)
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 3 (2 Rear/1 Side)
Digital Audio Output(s): 1 (Rear)
S-Video Input(s): 1 (Rear)
Headphone Output(s): 1 (Side)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear) with D-sub 15 and L/R
stereo mini plug connection
Analog Audio Input(s) (Total): 5 (4 Rear/1 Side)
Audio Out: 1 (Rear)
HDMI™ Connection(s) (Total): 3 (2 Rear/1 Side)
HDMI™Connection(s) (w/ Analog Audio In): 1
rear input included L/R audio inputs
4
Power
Power Consumption (in Operation): 298W
Power Consumption (in Standby): Less than 0.5W
Regulation and Standard Compliance
Energy Star ® Compliant: Yes
Service and Warranty Information
Limited Warranty: 18 Months Parts / 18 Months
Labor
Dimensions
Weight: 119.05lbs (54kg) with pedstal; 102.51lbs
(46.5kg) without pedestal
Supplied Accessories
Remote Control (RM-YD010)
Battery (AA x2)
HD-15 to HD15 Cable
Operating Instructions
Quick Setup Guide
Optional Accessories
Wall Mount Bracket (SU- WL51)
Color: High Gloss Piano Black
UPC Code: 027242699083
1.Black - whiterangeseenatthesametime.
2.Black - whiterange seen over a period of time.
3. Screen Size measured diagonally.
4.LimitedtoresolutionssupportedbyboththePCandtheSonyTV. See
SonyTV users manual and PC documentation for supported
resolutions
©2006Sony Electronics Inc. All rights reserved
Sony,BRAVIA, BRAVIAEnginePro, XBR, DRC,Speed Surf, andCineMotion
aretrademarks ofSony.SRS and theSRS symbol, TruSurroundare
trademarksof SRS Labs, Inc. Dolby Digitalisa registered trademark of
Dolby Laboratories. This TV incorporates High - DefinitionMultimedia
Interface(HDMI™ ) technology. HDMI, the HMDI logo and High - Definition
MultimediaInterface aretrademarks or registeredtrademarks of HDMI
LicensingLLC. Allothertrademarks arepropertyof their respective
owners.
Features and specifications are subject to change without notice. Non -
metricweights and measures are approximate.
VESAis a trademark of Video Electronics Standards Association Inc.
Lampin this product contains mercury. Disposal ofthesematerials may
beregulated due to environmental considerations. For disposal or
recyclinginformation, please contact your localauthoritiesor the
ElectronicIndustries Alliance (www.eiae.org)
