SERVICE MANUAL
Version Date Subject
1.0 04/2015 Original manual issue.
2.0 05/2015 Part Information Addition due to KDL-55W800C, 805C model addition
(P. 20~24, P. 76, P. 77, P. 84~92)
LCD TV
9-888-172-A2
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 04/2015 GN1G CHASSIS
Segment: XM-A

SERVICE MANUAL
LCD TV
GN1G CHASSIS
Segment: XM-A
9-888-172-A2

KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C 3
MODEL LIST
MODEL COLOR COMMANDER DEST.
KDL-50W800C Silver RMT-TX100U (LA1)
MX
Black RMT-TX100U (UC2)
US, CND
KDL-50W805C Silver RMT-TX100B (BR6)
BRAZIL
(CR1)
COSTA RICA
(LA8)
CHILE, PERU,
VENEZUELA
(AR4)
ARGENTINA
KDL-50W807C Silver RMT-TX100B (CO1)
COLOMBIA
KDL-50W809C Silver RMT-TX100B (ECU)
ECUADOR
MODEL COLOR COMMANDER DEST.
KDL-55W800C Silver RMT-TX100U (LA1)
MX
Black RMT-TX100U (UC2)
US, CND
KDL-55W805C Silver RMT-TX100B (BR6)
BRAZIL
(LA8)
CHILE, PERU,
VENEZUELA

44
WARNINGS AND CAUTIONS - ENGLISH
CAUTION
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis.
The chassis of this receiver is directly connected to the ac power line.
CARRYING THE TV
Be sure to follow these guidelines to protect your property and avoid causing serious injury.
• Carry the TV with an adequate number of people; larger size TVs require two or more people.
• Correct hand placement while carrying the TV is very important for safety and to avoid damages.
SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony
parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
Follow these procedures whenever critical components are replaced or improper operation is suspected.
CAUTION ABOUT THE LITHIUM BATTERY
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
• Outer case broken battery should not contact to water.
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

55
WARNINGS AND CAUTIONS - FRENCH
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifi é seulement.
Pour prévenir le risque de choc électrique, ne pas faire l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifi é faire ainsi.
WARNING!!
Afi n d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage. Le chássis de ce récepteur est
directement raccordé à l’alimentation du secteur.
POUR TRANSPORTER LE TÉLÉVISEUR
Tenez compte de ce qui suit pendant l’installation du téléviseur :
• Débranchez tous les câbles avant de transporter le téléviseur.
• Transportez le téléviseur avec le nombre de personnes approprié ; un téléviseur de grande taille doit être transporté par au moins deux personnes.
• Lors du transport du téléviseur, l’emplacement des mains est très important pour votre sécurité, ainsi que pour éviter de causer des dommages.
ALERTE!!
Afi n d’eviter tout risque d’electrocution provenant d’un chassis sous tension, un transformateur d’isolement doit etre utilise lors de tout depannage. Le chassis de ce recepteur est
directement raccorde a l’alimentation du secteur.
ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifi es par une trame et par une marque sur les schemas de principe, les vues explosees et les listes de pieces sont d’une importance critique pour la securite
du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les
reglages de circuit dont l’importance est critique pour la securite du fonctionnement sont identifi es dans le present manuel. Suivre ces procedures lors de chaque remplacement de
composants critiques, ou lorsqu’un mauvais fonctionnement suspecte.
AVERTISSEMENT CONCERNANT LA BATTERIE AU LITHIUM
• Il existe un risque d’explosion si la batterie n’est pas correctement remplacée. Utilisez uniquement un type de batterie similaire ou équivalent.
• Lorsqu’il est endommagé, le boîtier externe de la batterie ne doit pas entrer en contact avec l’eau.
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

6
WARNINGS AND CAUTIONS
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When repairing the LCD panel on the wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
1) Do not press on the panel or frame edge to avoid the risk of electric shock.
2) Do not scratch or press on the panel with any sharp objects.
3) Do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
4) Do not expose the LCD panel to direct sunlight.
5) Avoid contact with water. It may cause a short circuit within the module.
6) Disconnect the AC power when replacing the backlight (CCFL) or inverter circuit. (High voltage occurs at the inverter circuit at 650Vrms.)
7) Always clean the LCD panel with a soft cloth material.
8) Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
9) Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
10) It is recommended not to exceed 1 hour of Power-On nor Burn-in period with LCD panel face down condition, in repair activity.
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

77
SAFETY CHECK-OUT
After correcting the original service problem, perform the following safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered connections. Check the entire board surface for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and mounting hardware have been replaced. Be absolutely certain that you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below.
8. For safety reasons, repairing the Power board and/or Inverter board is prohibited.
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

88
SAFETY CHECK-OUT
Leakage Test
The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed
metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’
instructions to use these instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245 digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The
“limit” indication is 0.75 V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of passive VOMs that are suitable. Nearly all
battery-operated digital multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining screw on most AC outlet boxes is also
at earth ground.
If the retaining screw is to be used as your earth ground, verify that it is at ground by measuring the resistance
between it and a cold-water pipe with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble- light (not a neon lamp) between the hot
side of the receptacle and the retaining screw. Try both slots, if necessary, to locate the hot side on the line; the
lamp should light at normal brilliance if the screw is at ground potential (see Figure B).
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

99
SAFETY CHECK-OUT
Lead Free Information
The circuit boards used in these models have been processed using Lead Free
Solder. The boards are identified by the LF logo located close to the board
designation.
Handling the FLEXIBLE FLAT CABLE (FFC)
When you insert / pull out FFC, please grasp a reinforcement board and main
body of FFC
Figure 4: LF Logo Figure 5: LF logo on circuit board
Please hold reinforcement board and plunge
it to depths. Please pull out FFC while pushing the
button of both ends at the same time.
< Insertion> <Pull out>
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
Main board Main board
Release Button
of Connector
FFC connector broken if pull out FFC without
press and hold both Release Button of
connector. Symptom 5X blinking will be
appear due to improperly seated.

OUTLINE OF SELF DIAGNOSIS FUNCTION
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY LED will automatically begin to flash.
The number of times the LED flashes translates to a probable source of the problem.
A definition of the STANDBY LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often these
problems occur.
10
SELF DIAGNOSIS FUNCTION
ABOUT ILLUMINAITION LED
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
Status
White
Center
LED
Side RGB LED
Side Amber
LED Remarks
Power Off
( by power saving switch off and *1) Off Off Off
*1 power switch off (by side key)
Power On White Off Off
STBY/i.LINK STBY/PC STBY
( by remote control off only ) Off Off Off
Picture Off White looping White one shot
Off
Device Connection White Cyan one shot Off
Power ON Animation White White one shot
Off
Sleep Timer/On Timer/Reminder/REC
Timer/Photo Frame
( Power On ) White Amber
One shot
-
> Lit*2
Off *2 One Shot is only user action.
On Timer/Reminder/REC Timer
( Deep Standby ) Off Off Amber
After 5 minutes, side amber LED
On
Self Diagnosis Off Red
Blinking Off The number of LED blinking
indicates cause of failure
( refer to
Led Error / Triage chart
)
Aging mode White Green Blinking Off Blinking:0.5sec On / 0.5sec Off
Software Updating white blinking white blinking off
Software Updating finish White Blue lit off
Test Reset White white blinking Amber
blinking
Error of panel ID White Green /Amber
Blinking Off Blinking:0.5sec On / 0.5sec Off
REC (SCART REC & HDD REC/LIVE
PAUSE) [AEP/J only] White Red(Pink)
One shot
-
> Lit*2
Off *2 One Shot is only user action.
ePOP/
Shop Illumination White Cyan loop Off One shot Center White when feature change

SELF DIAGNOSIS FUNCTION
11
DIAGNOSTIC TEST INDICATORS
When an error occurs, the STANDBY LED will flash a set number of times
to indicate the possible cause of the problem.
If there is more than one error, the LED will identify the first of the problem
areas.
Result for all of the following diagnostic items are displayed on screen.
If the screen displays a “0”, no error has occurred .
0.5
0.5 3
DISPLAY OF STANDBY LED FLASH COUNT
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
STANDBY
LED
blinking
count
Detection Items Board Error Item
2x Main 19.5V overvoltage [MAIN_POWE]
* This failure is not saved
Power Adapter
BMX Board Error
3x Main 5.0V failure [DC_ALERT] BMX Board Error
Audio amp. protection [AUD_ERR] BMX Board Error
Speaker
5x
Panel ID EEPROM I2C No ACK (Also panel
power failure is a suspect) [P_ID_ERR]
-detect at startup sequence only
Panel module
Tcon board
BMX Board Error
-FRC device I2C No ACK [FRCTC_I2C]
-FRC device Initialization failure [FRCTC_I2C]
-detect at startup sequence only Tcon board
6x LED driver [BACKLIGHT] LED driver (LD) board
7x Over temperature protection [TEMP_ERR]
Temp. sensor I2C NACK [TEMP_ERR] BMX Board Error

12
SELF DIAGNOSIS FUNCTION
SELF-DIAGNOSTIC SCREEN DISPLAY
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes out” that cannot be confirmed, it is possible to bring up past occurrences of failure for
confirmation on the screen:
[To Bring Up Screen Test]
In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below:
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen.
After you have completed the repairs, clear the result display to “0”.
Clearing the Self Check Diagnostic List
Panel operation time : Press the Channel 7 => Channel 0 .
Exiting the Self-diagnostic screen
To exit the Self Diagnostic screen, turn off the power to the TV by pressing the POWER button on the remote or the POWER button on the TV.
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

13
SELF DIAGNOSIS FUNCTION
[SELF DIAGNOSTIC SAMPLE SCREEN DISPLAY]
Format of error timestamps
YYMMDDhhmmss (in UTC)
Example:120823132523 -> Aug 23 2012 13:25:23 UTC
* Only when time is set, an error timestamp
is saved.
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
•Panel Operation Time is recorded every
30 min, but Total Operation Time is recorded every 1 hr. Therefore,
the panel op. time might become larger than the total op. time.
Error count
Error timestamp for 3rd last recorded error
Error timestamp for second last
recorded error
Error timestamp for last recorded error
Error Naming
Smart Core Red LED
blinking count
Total operation time by hour
Boot count
Panel operation time by hour

• Items with no part number and no description are not stocked because they are seldom required for routine service.
• The construction parts of an assembled part are indicated with a collation number in the remark column.
• Items marked " * " are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.
14
SEC 1. DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
Note: About the procedure to disassemble under cover(standing position), please refer to “APPENDIX-1”.

15
1-1. KDL-50W800C/805C/807C/809C
1-1-1. Disassembly, Exploded View
DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
9
BRACKET SIDE
BRACKET,
SC
16
5
6
UNDERCOVER
4
LABEL, SIDE
TERMINAL
LABEL, UNDER
TERMINAL
BMX BOARD
7
8
BRACKET UNDER
11
SWITCH
UNIT
LABEL, UNDER
TERMINAL (TU)
3
BRACKET
UNDER, TU
17
55
BRACKET, WIFI
51
PANEL,
ORNAMENT
WLAN/BT
MODULE COVER, TOP
LIGHT, GUIDE
SHEET,
THERMAL (SC)
HSC3_S M MOUNT
CASE,
BOTTOM (L)
53
54
52
56
57
58
SMART CORE BLOCK
POWER SUPPLY
CORD
2
This part is not stocked.
The purpose of indicated
in this illustrator is just for
reference only.
15
BRACKET, SP 14
SPEAKER BOX ASSY (R) 13
BT ANTENNA 10
SHEET, THERMAL
BRACKET, SP
14
12 SPEAKER BOX
ASSY (L)
19
LCD PANEL
GASKET
18
1
AC ADAPTOR
Stand exploded view are for reference purpose. (Child parts are UNSTOCKED
unless specified at 1-1-2: Screws)
STAND BLOCK
STAND, SHAFT
72
STAND NECK ASSY
71
SCREW, M4 LOCK
FOOT, REAR
FOOT, FRONT
STAND, SHAFT
SCREW, M4 LOCK
ARM L
ARM R
STAND, NECK

REF. No. PART No. DESCRIPTION MARK
1 1-493-003-12 AC ADAPTOR (120W) CO1/LA1/UC2/
LA8/CR1
1 1-493-004-11 AC ADAPTOR (120W) BR6
1 A-2077-271-A ACC-280 (AR) AR4
2 1-846-090-31 CORD SET, POWER-SUPPLY CO1/LA1/UC2
/ECU
2 1-846-420-11 CORD SET, POWER-SUPPLY LA8/CR1
2 1-846-607-11 POWER-SUPPLYCORD (SET) BR6
2 1-846-716-21 POWER SUPPLYCORD SET AR4
3 4-563-190-02 LABEL, UNDER TERMINAL (TU) LA1
3 4-563-190-12 LABEL, UNDER TERMINAL (TU) BR6/CO1/LA8/
CR1/AR4/ECU
3 4-563-190-22 LABEL, UNDER TERMINAL (TU) UC2
4 4-563-273-01 LABEL, UNDER TERMINAL UC2
4 4-563-273-11 LABEL, UNDER TERMINAL Except UC2
5 4-563-252-01 LABEL, SIDE TERMINAL
6 A-2077-616-B UNDER COVER (ML LAK) A AR4
6 4-558-774-62 UNDER COVER (ML LAK) A ECU
6 4-566-274-51 UNDER COVER (ML LAK) A UC2
6 4-566-274-61 UNDER COVER (ML LAK) A LA1/LA8/CR1
6 4-566-274-91 UNDER COVER (ML LAK) A CO1
6 A-2070-158-A UNDER COVER (ML LAK) A BR6
7 4-546-909-02 BRACKET, UNDER TU (MOLD) LA1
7 4-546-909-12 BRACKET, UNDER TU (MOLD) CO1/LA8/CR1
7 4-546-909-32 BRACKET, UNDER TU (MOLD) UC2
7 4-546-909-42 BRACKET, UNDER TU (MOLD) BR6
7 4-566-679-11 BRACKET, UNDER TU (MOLD) ECU
7 4-566-679-41 BRACKET, UNDER TU (MOLD) AR4
8 4-545-088-11 BRACKET, UNDER (MOLD) CO1/LA1/UC2/
LA8/CR1
8 4-545-088-41 BRACKET, UNDER (MOLD) BR6
8 4-566-678-11 BRACKET, UNDER (MOLD) ECU
8 4-566-678-41 BRACKET, UNDER (MOLD) AR4
16
1-1. KDL-50W800C/805C/807C/809C
1-1-1. Disassembly, Exploded View
REF. No. PART No. DESCRIPTION MARK
9 4-545-087-01 BRACKET, SIDE (MOLD) CO1/LA1/UC2/
LA8/CR1
9 4-545-087-11 BRACKET, SIDE (MOLD) BR6
9 4-566-677-01 BRACKET, SIDE (MOLD) ECU
9 4-566-677-11 BRACKET, SIDE (MOLD) AR4
10 1-754-950-11 BT ANTENNA CO1/LA1/UC2/
LA8/CR1
10 1-754-955-11 BT ANTENNA BR6/AR4
11 1-798-510-31 SWITCH UNIT (SM-G-WW) CO1/LA1/UC2/
LA8/CR1/ECU
11 1-798-510-41 SWITCH UNIT (SM-G-KIT) BR6
11 A-1993-236-A SWITCH UNIT (SM-WW) AR4
12 1-859-100-11 SPEAKER BOXASSY
13 1-859-100-21 SPEAKER BOXASSY
14 4-547-988-01 BRACKET, SP (LAK)
15 4-547-989-01 BRACKET, SC (LAK)
16 A-2069-652-A COMPL SVC BMX_XMA_BR GINGA BR6/CR1/ECU
16 A-2069-653-A COMPL SVC BMX_XMA_COL CO1
16 A-2069-654-A COMPL SVC BMX_XMA_UC UC2
16 A-2069-655-A COMPL SVC BMX_XMA_MX LA1
16 A-2073-260-A COMPL SVC BMX_XMA_BR LA8
16 A-2077-627-A COMPL SVCBMX_XMA_AR4 GINGA AR4
17 4-549-186-01 SHEET, THERMAL (BM)
18 4-569-179-01 GASKET (LAK)
19 1-812-086-11 LCD PANEL (W50HFWS) Except UC2
19 1-812-087-11 LCD PANEL (W50HFWB) UC2
DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

REF. No.
PART No. DESCRIPTION MARK
51 4-547-397-02 BRACKET, WIFI BR6/AR4/ECU
51 4-564-318-01 BRACKET, WIFI UC2/LA1/LA8/
CR1/CO1
52 1-458-854-11 WLAN/BT MODULE (11N) Except BR6
52 1-458-854-21 WLAN/BT MODULE (11N) BRZ BR6
53 4-549-528-11 SHEET, THERMAL (SC)
54 4-547-395-01 COVER, TOP BR6/AR4/ECU
54 4-564-317-01 COVER, TOP UC2/LA1/LA8/
CR1/CO1
55 4-547-389-01 PANEL, ORNAMENT BR6/AR4/ECU
55 4-564-312-01 PANEL, ORNAMENT UC2/LA1/LA8/
CR1/CO1
56 4-547-390-01 LIGHT, GUIDE BR6/AR4/ECU
56 4-564-313-02 LIGHT, GUIDE UC2/LA1/LA8/
CR1/CO1
57 A-2066-088-A HSC3_S_MMOUNT UC2/LA1/LA8/
CR1/CO1/BR6
57 A-2074-616-A HSC3_S_MMOUNT KIT AR4/ECU
58 4-547-392-01 CASE, BOTTOM(M) BR6/AR4/ECU
58 4-564-315-01 CASE, BOTTOM(M) UC2/LA1/LA8/
CR1/CO1
71 4-559-310-01 STAND NECK ASSY(LAK) UC2/LA1/LA8/
CR1/CO1/ECU
71 A-2070-161-A STAND, NECK ASSY(LAK) SBR BR6
71 A-2076-425-A STAND, NECK ASSY (LAK) AR4
72 4-559-316-01 STAND, SHAFT (ML LAK) A UC2/LA1/LA8/
CR1/CO1/ECU
72 A-2070-160-A STAND, SHAFT (ML LAK) A SBR BR6
72 A-2076-424-A STAND, SHAFT (ML LAK) A AR AR4
17
1-1. KDL-50W800C/805C/807C/809C
1-1-1. Disassembly, Exploded View
DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C

18
1-1. KDL-50W800C/805C/807C/809C
1-1-2. Screws
DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
Ref Part No
Description
2
-580-639-
01
SCREW, +BVTP 4X12 TYPE2
IT-3
2
-990-421-
41
SCREW
(+PSW) (M3X6)
4
-256-393-
11
SCREW, +PSW M3X6
W12
4
-452-935-
11
SCREW , +PWH
M3X6
4
-449-743-
01
SCREW, +PSW M5X16

19
REF. No. PART No. DESCRIPTION MARK
81 1-910-805-05 CONNECTOR ASSY30P CN9000 (BMX) -CN4001 (LDB3B) (1)
(UC2/LA1/LA8/CR1/CO1/BR6)
81 1-910-805-07 CONNECTOR ASSY30P (ECU) CN9000 (BMX) -CN4001 (LDB3B) (1)
81 1-910-805-43 CONNECTOR ASSY30P (AR4) CN9000 (BMX) -CN4001 (LDB3B) (1)
82 1-910-805-03 HARNESS ASSY CN1000 (BMX) -CN203 (SM) -CN101 (HSC3-S-M) - (WIFI/BT) /CN7751 (BMX) -SP (1)
(UC2/LA1/LA8/CR1/CO1/BR6)
82 1-910-805-06 HARNESS ASSY(ECU) CN1000 (BMX) -CN203 (SM) -CN101 (HSC3-S-M) - (WIFI/BT) /CN7751 (BMX) -SP (1)
82 1-910-805-42 HARNESS ASSY(AR4) CN1000 (BMX) -CN203 (SM) -CN101 (HSC3-S-M) - (WIFI/BT) /CN7751 (BMX) -SP (1)
83 1-910-805-04 FLEXIBLE FLATCABLE 51P CN8400 (BMX) -T-CON (1)
(UC2/LA1/LA8/CR1/CO1/BR6)
83 1-848-900-11 FLEXIBLE FLATCABLE 51P CN8400 (BMX) -T-CON (1)
(AR4/ECU)
1-1. KDL-50W800C/805C/807C/809C
1-1-3. Connectors
DISASSEMBLY AND PARTS LIST
KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C
83
82
81

KDL-50W800C, 805C, 807C, 809C/KDL-55W800C, 805C 20
STAND BLOCK
STAND, SHAFT
72
STAND NECK ASSY
71
SCREW, M4 LOCK
FOOT, REAR
FOOT, FRONT
STAND, SHAFT
SCREW, M4 LOCK
ARM L
ARM R
STAND, NECK
Stand exploded view are for reference purpose. (Child parts are
UNSTOCKED unless specified at 3-3-2: Screws & 3-3-4: Other
Parts )
56
BRACKET, WIFI
51
PANEL,
ORNAMENTAL
WLAN/BT
MODULE COVER, TOP
LIGHT, GUIDE
SHEET,
THERMAL (SC)
HSC3_S MOUNT
CASE,
BOTTOM (M)
53
55
52
57
58
59
SMART CORE BLOCK
54
HEAT SINK(SC)
LABEL, UNDER
TERMINAL (TU)
10
BRACKET SIDE
BRACKET,
SC
17
6
7
UNDERCOVER
5
LABEL, SIDE
TERMINAL
LABEL, UNDER
TERMINAL
BMX BOARD
8
9
BRACKET UNDER
12
SWITCH
UNIT
4
BRACKET
UNDER, TU
18
POWER SUPPLY
CORD
2
This part is not stocked. The
purpose of indicated in this
illustrator is just for reference
only.
16
BRACKET,
SP 15
SPEAKER BOX
ASSY (R)
14
BT ANTENNA 11
SHEET, THERMAL
BRACKET, SP
14
13 SPEAKER BOX
ASSY (L)
19
LCD PANEL
1
AC ADAPTOR
3
LABEL, REAR
TERMINAL
1-2. KDL-55W800C/805C
1-2-1. Disassembly, Exploded View
