Sony KDL-32ML130 - 32" Bravia M-series Digital Lcd... User manual

KDL-32ML130
32"ClassBRAVIA® M - SeriesDigitalLCDTelevision(31.5"diagonal)
Key Features
16:9HDResolutionPanel(1366x768)
3DCombFilter
SpaceSavingBottomSpeaker
Channellabels
Favoritechannels
ClockandSleepTimer
Digitalaudioamplifier
Fastpanelresponse
Wide178 ° ViewingAngles
HDMI™(x2)
Key Technologies
HDMI™and PC Connectivity Designed for maximum versatility, Sony’ s BRAVIA ®M - Series Digital LCD TV line is
equipped with a comprehensive range of input interfaces. The HDMI™ ( High - Definition Multimedia Interface) is the
first industry - supported, uncompressed, all - digital audio/video interface. HDMI™ technology supports enhanced or
High Definition video, together with multi - channel digital audio to provide matchless image and sound
reproduction. The HDMI™ and PC inputs (HD - 15 - pin) offer easy connection to your PC, allowing you to use your high
resolution BRAVIA®M - Series Digital TV as a computer monitor.
1
Light Sensor Intelligently adjusts the screen brightness to match the ambient light in a room, ensuring a
comfortable viewing experience. In a dim room for example the screen automatically reduces brightness making
it much more comfortable for viewing.
Inputs HDMI™ ( x2), YPbPr (x2), PC Input x1, S - video x1, Composite x3
1
16:9 HD Resolution Panel (1366 x 768)
3D Comb Filter
Space Saving Bottom Speaker
Channel labels
Favorite channels
Clock and Sleep Timer
Digital audio amplifier
Fast panel response
Wide 178 ° Viewing Angles
Light sensor backlighting control
HDTV with ATSC™Digital Tuner with QAM
Remote

SonyElectronicsInc. • 16530ViaEsprillo • SanDiego,CA92127 • 1.800.222.7669 • www.sony.com
LastUpdated:08/14/2007
KDL-32ML130
32"ClassBRAVIA® M - SeriesDigitalLCDTelevision(31.5"diagonal)
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Features
General
Auto SAP: Yes
Closed Caption (CC): Yes
ID1 Detection: Yes
Video Label: Yes
Video
Tuner: ATSC with QAM
Video Processing: Yes
Comb Filter: 3D Digital Comb Filter
Light Sensor: Yes
Picture Modes: Vivid, Standard, Cinema
Wide Mode: Wide Zoom/ Normal/ Full/ Zoom
High Definition: 720p
Audio
MTS Stereo Decoder: Yes
Dolby® Digital: Yes (AC3/ATSC only)
Convenience
Channel Label: Yes
Channel Skip/Add: Yes
Favorite Channel: Yes
Parental Control (V-Chip): Yes
Programmable Timer: Yes
Sleep Timer: 15, 30, 45, 60, 90, Off
Timer Events: Timer 1
Clock: Yes
On Screen Display: Menu
Input Skip: Yes
Specifications
General
Aspect Ratio: 16:9
Screen Size: 32 inch class (31.5 inches
measured diagonally)
Television Type: Flat Panel
Video
Native Resolution: 720p
Contrast Ratio: 2500:1 Dynamic
Display Resolution: 1366 x 768
Viewing Angle: Right/Left: 178 ° , Up/Down: 178 °
Panel Response Time: 8ms (gray to gray)
Convenience
Timer Clock: Yes
Inputs and Outputs
Analog Audio Input(s): 5 (4 Rear/1 Side)
Audio Out (Variable/Fixed): 1 (Rear) Fixed Only
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 3 (2 Rear/1 Side)
Digital Audio Output(s): 1 (Rear) Coax
RF Connection Input(s): 1 (Rear) RF in / Cable
in
S -Video Input(s): 1 (Rear)
Headphone Output(s): 1 (Side)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear) with D-sub 15 and
L/R stereo mini plug connection
HDMI ™ Connection(s): 2 (Rear) 1 with L/R RCA
audio connections
Power
Power Consumption (in Operation): 170W
Power Consumption (in Standby): Less than
0.1W
Power Requirements: AC 120-240V, 50/60Hz
Regulation and Standard Compliance
Energy Star ®Compliant: Yes
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year Labor
Dimensions
Weight: 36 lbs with pedestal; 31 lbs without
pedestal
Measurements: 32 3/8" x 23 3/16" x 8 7/16" with
pedestal; 32 3/8" x 21 7/16" x 3 15/16" without
pedestal
Supplied Accessories
Tabletop Stand
Remote Control
AA x 2 Batteries
Support belt and screws
Operation Manual
Optional Accessories
SU -FL300M TV Stand
SU -WL500 Wall Mount Bracket
RHT-G800 Audio Stand
UPC Code: 027242719989
1
1.Limited toresolutions supportedbyboth thePC andthe SonyTV. See
SonyTV usersmanual andPCdocumentation forsupported resolutions
©2007Sony ElectronicsInc. Allrightsreserved.
Sony,BRAVIA, BRAVIAEngine, andCineMotionaretrademarksof Sony.
DolbyDigital isa registeredtrademarkofDolbyLaboratories. ThisTV
incorporatesHigh - DefinitionMultimedia Interface(HDMI™ ) technology.HDMI,
theHMDI logoand High - DefinitionMultimedia Interfaceare trademarksor
registeredtrademarks ofHDMI LicensingLLC.VESAisa trademarkof Video
ElectronicsStandards AssociationInc. ATSCisatrademarkof Electronic
IndustriesAssociation. Allother trademarksarepropertyoftheir respective
owners.
Featuresand specificationsare subjecttochange withoutnotice. Non -
metricweights andmeasures areapproximate.
