Sony Bravia XR-50X9 J Series User manual

SERVICE MANUAL (COMMON)
GR1VH CHASSIS
Segment : AR
9-888-792-01
LCD TV
Sony EMCS (M) Sdn. Bhd., SHES-M
©2021.03
ORIGINAL MANUAL ISSUE DATE: 2021.03
Conditions of Use:
(1) Please use this information only for the purpose of performing repair, maintenance and/or configuration services of the Sony products (hereinafter
the “Repair services”) under the service agreement entered into with the Sony group company (hereinafter the “Service agreement”).Using this
information for any purpose other than the purpose described foregoing is forbidden.
(2) Only the Authorized Servicer’s officers, employees or subcontractors (including their officers and employees) whose duties justify aneed-to-know
and who have agreed to hold confidential this information (collectively hereinafter the ”Permitted users”) are permitted to access and use this
information.To disclose or disseminate to any person other than the Permitted users is forbidden.
(3) Destroy or erase any and all portion of this information promptly in an irrecoverable and secure fashion after achieving the purpose described in
Section (1) above.
(4) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior written
permission of the author.
(Notwithstanding foregoing, it is permitted to copy and distribute this information to the Permitted users.)
(5) Please notify immediately any leakage, loss, theft, misappropriation, or other misuse of this information by e-mail to the following address:
[e-mail]
(6) In addition to the above, the terms and conditions of the Service agreement shall be applied to using this information.
Revision of Information:
This information may be changed or updated at any time without any prior notice.Please confirm that this information is up-to-date before using it.
SYSSET
2021/02/2522:52:59(GMT+09:00)

Version Date Subject
12021.03 1st Issue
REVISION HISTORY
SYSSET
2021/02/2522:52:59(GMT+09:00)

THIS SERVICE MANUAL CONTAINS COMMON INFORMATION FOR BELOW REGIONS AND MODELS:
REGION
AMERICA ASIA CHINA
MODEL
XR-50X9*J XR-55X9*J XR-65X9*J XR-75X9*J XR-100X9*
XRM-50X9*J XRM-55X9*J XRM-65X9*J XRM-75X9*J
MODEL LISTS
SYSSET
2021/02/2522:52:59(GMT+09:00)

Note: Pictures provided in this manual may have difference from actual
sets
Please refer Service Manual –Unique for
below information :
Disassembly and Removal Caution
Wire Dressing
Circuit Board Location
Exploded Views and Part Lists
TABLE OF CONTENTS
Title Page
SAFETY
NOTES 5
SELF DIAGNOSTIC FUNCTION
11
TROUBLE SHOOTING
16
SERVICE ADJUSMENT
96
DIAGRAMS
107
HANDLING GUIDE 112
SYSSET
2021/02/2522:52:59(GMT+09:00)

Whenever a TV Mainboard is replaced, the correct TV ModelandSerial number must be
reinserted into memory.
This is a MANDATORY procedure thateach service center must apply.
Please refer to the chapter of ADJUSTMENT in this service manual to findouthow to set the
modelnumberand serial number in service mode.
1-2-1. Caution Handling of LCDPanel
When repairing the LCDPanel, make sure you are grounded with a wrist band.
When repairing the LCDPanel on the wall, the panel must be secured using the 4 mounting
holes on the rear cover.
1) Do not press the panel or frame edge to avoid the risk of electric shock.
2) Do not scratch or press on the panel with any sharp objects.
3) Do notleave the moduleinhigh temperature or in areas of high humidity for an
extendedperiod of time.
4) Do not expose the LCDpanel to direct sunlight.
5) Avoid contact with water. It may cause short circuit within the module.
6)Disconnect the AC power when replacing the backlight (CCFL)or inverter circuit. (High
voltage occurs at the inverter circuit at 650Vrms)
7) Always clean the LCDpanel with a soft cloth material.
8) Use care whenhandling the wires or connectors of the inverter circuit. Damaging the wires
may cause a short circuit.
9) Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
1-1. WarningsandCaution
1) CAUTION :These servicing instructions are for use by qualified service personnel
only.
2) To reduce the risk of electric shock, do notperform any servicing other than that contained
in the operatinginstructionsunless you are qualified to do so.
3) WARNING!!:An isolation transformer should be used duringany service to avoid
possible shock hazard, because of live chassis. The chassis of this receiver is directly
connected to the ac power line.
The replaceable fuse could be in the neutral of the mains supply. When replacing the fuse,
the mains shall be disconnected for de-energize the phase conductors.
(*Except AC ADAPTOR, Because it doesnot carry out replacing an internal fuse.)
4) CARRYING THE TV : Be sure to follow these guidelines to protect your property and
avoid causing seriousinjury :
•Carry the TV with an adequate number of people; larger size TVs require two or more
people.
•Correct handplacement while carrying the TV is very important for safety and to
avoiddamages.
5) SAFETY-RELATED COMPONENT WARNING!! : Components identified by shadingand
! mark on the exploded views, and in the parts list are critical for safe operation. Replace
these components with Sonyparts whose part numbers appear as shown in this manual
or in supplements published by Sony. Circuit adjustments that are critical for safe
operation are identified in this manual.Follow these procedures whenever critical
components are replaced or improperoperation is suspected.
6) IMPORTANT REMINDER FOR TV MAINBOARD REPLACEMENT :
It is mandatory for service centers to confirm the TV‘s system information after each repair
carriedout with Mainboard replacement.
SAFETY NOTES
5
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 5
SYSSET
2021/02/2522:52:59(GMT+09:00)

10)During the repair, DO NOT leave the Power On or Burn-in period for more than1hour
while the TV is face down on a cloth. Refer Figure 1
6
Figure 1.
SAFETY NOTES
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE
1-3. Caution_for_Board_handling
Symptom : The following problems will occur due to handling of the IC
mounted on the board
・Solder crack due to substrate handling (stress)
・IC breakdown due to static electricity (ESD)
When repairing the TV at the customer‘s home or service station or
Repair of defect board, please pay attention to the handling of the board
※Substrate that needs attention for handling
・Main Board（B** -Board）
・Backend Board（D** -Board）
ESD wrist-strap
ESD wrist-strap to be checked daily.
Use Multi-meter to make sure resistance of ESD wrist-strap is OK.
(R=750K Ohms to 35Mega Ohms)
ESD cushion/sheet
Please use a bag containing the board or a special seat
※Things to prepare in advance
6
SYSSET
2021/02/2522:52:59(GMT+09:00)

7
1) Caution for Board handling(Stress)
Be sure to observe the following contents.
③Handle with care. Do not swing.
①Hold the board with both hands
②Do not hold/push Heat-Sink
SAFETY NOTES
④Regardless of Good board or Defective board, always put it
on ESD cushion/sheet slowly.
⑤Do not stack up
⑥Keep vertical position and put in/take out from Box.
Always put in to ESD bag then place into Box/Container Box.
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 7
SYSSET
2021/02/2522:52:59(GMT+09:00)

8
⑦Do not hold Heat-Sink when take out or install it..
2) Caution for Board handling(ESD)
Be sure to observe the following contents.
①When take off Rear-Cover,
do not touch to board ②Use ESD wrist-strap
SAFETY NOTES
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE
※Installation example of wrist-strap
Please connect the clip to the metal part of the chassis of the TV with the
wristband grounded. Below is a grounding example of each model.
＜K*-55/65A9F＞
＜K*-65Z9F＞
※Caution
ESD wrist-strap to be checked daily.
Use Multi-meter to make sure resistance of ESD wrist-strap is
OK.(R=750K Ohms to 35Mega Ohms)
8
SYSSET
2021/02/2522:52:59(GMT+09:00)

9
9
③When holding board, do not hit/touch to Plastic part(s)
④After take defective board out from TV, put it into ESD bag.
Do not place on floor mat/carpet direct. And, always put it on
ESD cushion
SAFETY NOTES
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE
1-5. Safety Check-Out
After correcting the original service problem, perform the following safety checks
before releasing the set to the customer:-
1)Check the area of your repair for unsoldered or poorly soldered connections. Check the
entire board surface for solder splashes and bridges.
2)Check the inter board wiring to ensure that no wires are pinchedor contact high-
wattage resistors.
3)Check all control knobs, shields, covers, ground strapsand mounting hardware have
been replaced. Be absolutely certain you have replaced all the insulators.
4) Look for unauthorized replacement parts, particularly transistors that
were installed during aprevious repair.Point them out to the customer and recommend their
replacement.
5) Look for parts which, though functioning show obvious signs of deterioration.Point them
out to the customer and recommend their replacement.
6) Check the line cords for cracks and abrasion.Recommend the replacement of any such
line cord to the customer.
7) Check the antenna terminals, metal trim, metalized knobs, screws and all other exposed
metal parts for AC leakage.Check leakage test as described next.
8. For safety reasons, repairing the Power board and/or Inverter board is prohibited.
1-6. Leakage Test
(To protect electric shock when customer touch the terminal.)
Leakage current can be measured by V: Voltmeter or oscilloscope (r.m.s. or peak reading)
Stabilized power supply instrument and isolated voltage transformer:
Use too much current capacity and isolated voltage transformer does not need to use
stabilized power supply equipment.
Specification of RMS volt meter: Input resistance > 1 Mohm, Input capacitance < 200 pF,
Frequency range: 15 Hz –1MHz . Refer Figure 2. Isolated type volt -meter (FLUKE 8921A
etc *1)
1-4. Caution About the Lithium Battery
1) Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type.
2) Outer case broken battery shouldnot contact to water.
9
SYSSET
2021/02/2522:52:59(GMT+09:00)

10
Stabilized power supply instrument and isolated voltage transformer:
Use too much current capacity and isolated voltage transformer does not need to use
stabilized power supply equipment.
Specification of RMS volt meter: Input resistance > 1 Mohm, Input capacitance < 200 pF,
Frequency range: 15 Hz –1MHz . Refer Figure 2. Isolated type volt -meter (FLUKE 8921A
etc *1)
*1 Not use FLUKE 8920A that connected to protective earth by diode
# Leakage current of measurement instrument is less than 10μArms when under test
equipment AC plug is opened
# Set up the following condition and turn on the set. Applied voltage: Nominal input voltage
(Description on Nameplate)
# Measure the leakage current between one phase conductor and neutral for terminal A and
terminal B.
Read rms value, and then calculate to peak value PEAK VALUE =√2 RMS VALUE
Comply with the following requirement
Class II equipment (2-pinplug): for each terminal, the worst valueof measurement must
not exceed AC 350uA peak).
Note: including AC adaptor, AC adaptor/DC operated unit combination
Figure 2 – Measuring network
for Leakage Current
SAFETY NOTES
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE
1-8. Lead Free Information
The circuitboards used in these modelshave been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation.
Figure 4: LF Logo Figure 5: LF logo on circuit board
1-7. Howto Find a GoodEarth Ground
1)A cold-water pipe is a guaranteedearth ground; the cover-plate retaining screw on most
AC outletboxes is also at earth ground.
2)If the retaining screw is to be used as yourearth ground, verify that it is at ground by measuring
the resistance between it and a cold-water pipe with an ohmmeter. The reading should be zero
ohms.
3)If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble- light (not a neonlamp)
between the hot side of the receptacle and the retaining screw. Try both slots, if necessary, to
locate the hot side on the line; the lamp should light at normal brilliance if the screw is at ground
potential(see Figure 3).
Figure 3. Checking for earth ground.
The servicing of these boards requires special precautions. It is
strongly recommended to use Lead Free Solder material in order to
guarantee optimal quality of new solder joints.
10
SYSSET
2021/02/2522:52:59(GMT+09:00)

SELF DIAGNOSTIC FUNCTION
11
The units in this manual contain a self-diagnostic function. If an error occurs, the Smart Core Red LED willautomaticallybegin to flash. The number of times the LED flashes translates to a probable
source of the problem.
Adefinition of the Smart Core Red LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
DIAGNOSTIC TEST INDICATORS
Whenan error occurs, the Smart Core Red LED will flash aset number of times to indicate the possible cause of the problem. If there is more than one error, the LED will identify the first of
the problem areas.
Result for all of the following diagnostic items are displayed on screen. If the screen displays a “0”, no error has occurred .
Self Diag.Quick Reference (LED blinking)
Smart Core RED LED blinking
count Error Item AR
2x MAIN_POWER <B/G> Main 12V over voltage
3x
DC_ALERT <B/G> Main 5.0V failure
AUD_ERR <B/S> Audio amp. protection
4x
LD_ERR <LD/P/B/G> LED driver failure/LED voltage
protection
BCM_ERR
<LD/B> LD IC initialize failed. Error detection of the
I2C communication between the Main device and the
LD IC.
5x P_ID_ERR <B/T/P/G> Panel ID EEPROM I2C No ACK (Also
panel power failure is a suspect)
6x BACKLIGHT_ERR <B/G/P/LD> Backlight failure
7x TEMP_ERR <B/H/P> Over temperature protection
8x 4KBE_ERR <B> 4KBE WDT
Blue italic: detect at startup sequence only.
<G>: Power Supply board, <B>: Main board, <T>: T-con board,
<LD>: LD board, <Tu>: Tuner board, <A>: Power Adapter,
<P>: Panel module, <S>: Speaker, <H>: H-board
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 11
SYSSET
2021/02/2522:52:59(GMT+09:00)

SELF DIAGNOSTIC FUNCTION
12
Self Diag. Quick Reference (Not LED blinking) –Record Only
Error Item AR
TCON ERR <T> T-CON device I2C communication failure
AUD_ERR_I2C <B> Audio amp I2C communication failure
TEMP_ERR_I2C <B/H> Temp sensor I2C communication failure
TU_DEMOD_I2C <B> Tuner & Demodulator I2C communication failure
Blue italic: detect at startup sequence only.
<G>: Power Supply board, <B>: Main board, <T>: T-con board,
<LD>: LD board, <Tu>: Tuner board, <A>: Power Adapter,
<P>: Panel module, <S>: Speaker, <H>: H-board
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 12
SYSSET
2021/02/2522:52:59(GMT+09:00)

SELF DIAGNOSTIC FUNCTION
13
Entry (Self Diagnosis Display)
-Go to the standby by a remote.
-Push the buttons sequentially:
<Display><5><Vol-><Power>
Exit
-If you want to finish service mode app, do AC OFF/ON
→*Service mode app is disable perfectly
-if you want to move home menu, push <HOME>button
→*Service mode app do background(not disable perfectly)
Self Diagnosis Display [Example]
SELF CHECK
00034 00231 00034 [Home]Exit [Up/Down]Scroll
Self Diagnosis Service Menu
002 MAIN POWER 050121081135 041231123456 031111182547 003
003 DC ALERT 000000000000 000000000000 000000000000 000
003 AUD ERR 000000000000 000000000000 000000000000 000
003 AUD ERR I2C 000000000000 000000000000 000000000000 000
003 TU DEMOD I2C 000000000000 000000000000 000000000000 000
004 LD ERR 000000000000 000000000000 000000000000 000
004 BCM ERR 000000000000 000000000000 000000000000 000
005 TCON ERR 000000000000 000000000000 000000000000 000
005 P ID ERR 000000000000 000000000000 000000000000 000
006 BACKLIGHT ERR 000000000000 000000000000 000000000000 000
007 TEMP ERR 000000000000 000000000000 000000000000 000
007 TEMP ERR I2C 000000000000 000000000000 000000000000 000
008 4KBE ERR 000000000000 000000000000 000000000000 000
SELF CHECK
00034 00231 00034 [Home]Exit [Up/Down]Scroll
Back
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 13
SYSSET
2021/02/2522:52:59(GMT+09:00)

SELF DIAGNOSTIC FUNCTION
14
Self Diagnosis Display
Format of error timestamps
YYMMDDhhmmss (in UTC)
Example:
120823132523 -> Aug 23 2012 13:25:23 UTC
* Only when time is set, an error timestamp
is saved.
Panel Operation Time clear
<7> -> <0>
Timestamps and Error Count clear
<8> -> <0>
Total Operation Time and Boot Count clear
<9> -> <0>
•Panel Operation Time is recorded every
30 min, but Total Operation Time is recorded
every 1hour.Therefore, the panel op.time
might become larger than the total op.time.
;
SELF CHECK
<<
002 MAIN POWER 000000000000 000000000000 000000000000 000
003 DC ALERT 000000000000 000000000000 000000000000 000
003 AUD ERR 150101000018 150101000018 150101000018 003
003 TU DEMOD 150101000218 150101000223 150101000105 003
003 AUD ERR I2C 000000000000 000000000000 000000000000 000
003 TU DEMOD I2C 000000000000 000000000000 000000000000 000
004 LD ERR 000000000000 000000000000 000000000000 000
004 BCM ERR 000000000000 000000000000 000000000000 000
005 TCON ERR 150101000504 000000000000 000000000000 001
005 P ID ERR 000000000000 000000000000 000000000000 000
006 BACKLIGHT ERR 000000000000 000000000000 000000000000 000
007 TEMP ERR 150101000200 150101000002 000000000000 002
007 TEMP ERR I2C 000000000000 000000000000 000000000000 000
008 4KBE ERR 000000000000 000000000000 000000000000 000
Back
00005 00414 00002
[Home]Exit [Up/Down]Scroll
Smart Core Red LED
blinking count
Error Item Error count
Total Operation Time [hr] –Boot Count –Panel Operation Time [hr]
Error
timestamp
for last
recorded
error
Error
timestamp
for second
last
recorded
error
Error
timestamp
for 3rd last
recorded
error
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 14
SYSSET
2021/02/2522:52:59(GMT+09:00)

SELF DIAGNOSTIC FUNCTION
15
Retry Limitation by Remote / Power Key
Smart Core
Red LED blinking
count
Error Name Retry Permission Times *1 Note
2x MAIN_POWER STDWN_RTRY_LIMIT_MAINPOWR = 1
3x
DC_ALERT (5V) STDWN_RTRY_LIMIT = 2
AUD_ERR STDWN_RTRY_LIMIT = 2
4x
LD_ERR STDWN_RTRY_LIMIT = 2
BCM_ERR STDWN_RTRY_LIMIT = 2
5x P_ID_ERR STDWN_RTRY_LIMIT = 2
6x BACKLIGHT STDWN_RTRY_LIMIT = 2
7x TEMP_ERR STDWN_RTRY_LIMIT = 2
8x 4KBE_ERR STDWN_RTRY_LIMIT = 2
Number of off/on action during the error shutdown is
recorded to STDWN_OFFON_CNT.
*1) If STDWN_OFFON_CNT <= STDWN_RTRY_LIMIT, and STDWN_OFFON_CNT_MAIN_POWER <= STDWN_RTRY_LIMIT_MAINPOWR, you can turn the set on by
remote/power key. At this time, if the error occurs again, the STDWN_OFFON_CNT is incremented by 1.
*2) When the main micro operates normally for STDWN_OFFON_CLR = 60 minutes, STDWN_OFFON_CNT and STDWN_OFFON_CNT_MAIN_POWER are cleared.
Number of off/on action for MAIN_POWER shutdown
is recorded to STDWN_OFFON_CNT_MAIN_POWER.
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 15
SYSSET
2021/02/2522:52:59(GMT+09:00)

No
Power
Remote Network Audio Smart Core Bluetooth (BT) Built in MIC
2 3 4 5 6 7 8
TU_
DEM
OD
TU_
DEM
OD_I
2C
TCO
N_E
RR
FRCT
C_I2
C
AUD
_ER
R_I2
C
4KP
Q_E
RR_I
2C
TEM
P_ER
R_I2
C
EAR
C_ER
R_I2
C
Does not reponse
to remote (Dead
Set)
Stationa
ry
colored
lines or
dots
No video
One of
Inputs
NO RF
input
No video all
Inputs
No Re mo t e
Wireless
c an't
connec t
No Audio
Smart Core no LED
(Set is st ill alive)
Bluetooth / One St ep
Re mo t e ( OS R) c a n't
connec t
"OK Google"
de tec t ion f ail
B* Board ■          
G* Board   ■  ▲
H* Board   
Speaker 
Wif i & BT Module  
LD* Board 
V By One FFC    
Tcon   ■
LCD Panel ■■■
Power Power LD
Panel
(Communication)
Panel
(Bac klight )
TEMP 4KBE
Audio BCM
Reference
Symptoms - Shutdown. Power LED
blinking red diagnostics sequences
Video
- missing or distor ted
Proble m
Symptoms - no shutdown
Error log record only
TROUBLESHOOTING
16
Triage Chart
Before you make the service call…
1. Confirm the symptom from the customer.
2. Select that symptom from the chart.
3. Bring all the boards and cables listed for that symptom.
4. Follow the troubleshooting charts in the technical guides to isolate the board.
5. Chart Color Code
RED DOT: Most likely defective part
BLUE TRIANGLE: Secondary possible defective part
GREEN SQUARE: Tertiary possible defective part
BLACK TEXT: Board that may correct the symptom
Receiver Board
Local Dimming
Board
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE
Power Board
Main Board
16
SYSSET
2021/02/2522:52:59(GMT+09:00)

TROUBLESHOOTING
17
1.1 No Power
No Power
Check STBY 3.3V
C1708
near CN1700 on
BM5ST board
Harness
Power Board
Replace
Between Power Board to
BM5ST Board
Harness
BM5ST
Board
NG
OK
NG
OK
u-Com Failure
DDCON/LDO
Main Device Failure
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 17
SYSSET
2021/02/2522:52:59(GMT+09:00)

TROUBLESHOOTING
18
1.1 No Power –Power board ( Tv Condition )
START
Power board: F6101
Fuse OPEN check
STBY output check
(3.35~3.55V)
Power board
CN6401PIN 5
Yes
No
No
Yes
Power ON
Input check (~3.3V)
Power board
CN6401PIN 3
Yes
Can TV power on?
Case 1
Case 2 12V output check
(12.2~13.2V)
Power board
CN6401 PIN 9~16
No
AC connect (80~288V)
Replace Power Supply
Replace Power Supply
No
Replace Power Supply
RC can turn TV ON?
Yes
Main board problem
Yes
Yes
No
No
VLED VCC
(refer voltage page)
Power board
CN6601 Pin10~14
No Replace Power Supply
Yes
Check Local Dimming board
Refer Local Dimming Troubleshoot
BL_ON active HIGH
(~3.3V)
Power board
CN6401PIN 2
Main board/LD problem
No
Yes
BL_ERR
(3.3V)
END
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 18
SYSSET
2021/02/2522:52:59(GMT+09:00)

TROUBLESHOOTING
19
1.1 No Power –Checking Point board BM5ST
C1708
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 19
SYSSET
2021/02/2522:52:59(GMT+09:00)

TROUBLESHOOTING
20
1.2 No Power U-Com Failure P-on u-com control signal path summary
P-on u-com
IC401
Power Board
or
Local Dimming
Board
DDC : 0.8V_M5_CORE (IC804)
DDCs:
5V_MAIN&5.0V_VBUS&5V_AUDIO (IC600),
1.0V_TU_P(IC603), 1.8V_M5 (IC813), 1.0V_M5 (IC812),
0.8V_M5_CPU (IC810), 0.8V_M5_GPU (IC811), 1.8V_BE_DDC
(IC4800)
LDOs:
3.3V_MAIN_H (IC403)
FET SW :
3.3V_TU_P (Q602), 3.3V_MAIN &3.3V_AUDIO(Q611),
SOC Muffin 5 (IC1000)
P_ON_#1
PGOOD_1
P_ON_#2
OPWRSB
R457
#pin14
#pin9
#pin12
#pin13
#pin10
#pin6
3.3V_STBY
POWER_ON
ORESETB
#pin7
BL_ON
DC_OFF_DET
#pin18 P_ON_HL FET SW : 12.7V_LNB (Q604)
SW IC : 3.3V_TU_P (Q609)
USB VBUS SW (IC3803/IC3804)
#pin11
ADC port
#pin8
19.5V_12.7V_AUDIO
R462
#pin16
ADC port
R444
X_BL_MUTE
#pin3
12.7V_MAIN R450
VDD
12V_MON
GND
TYPE_DET
DC_MON
GND
#pin17
GND
3.3V_STBY
R445 R446
#pin2
DDCs:
0.9V_BE_DDC_1 (IC4802), 0.9V_BE_DDC_2 (IC4803), 0.8V_BE
(IC4809), 0.7V_BE (IC4810)
LDO :
1.8V_EMMC (IC2201)
SAFETY NOTES SELF DIAGNOSTIC FUNCTION TROUBLESHOOTING SERVICE ADJUSMENT DIAGRAMS HANDLING GUIE 20
SYSSET
2021/02/2522:52:59(GMT+09:00)
