KDF-50E3000
50" Class (49.5") Grand WEGA™ E Series 3LCD Microdisplay TV
Key Features
Full HD 1080p (1920 x 1080) Picture Resolution
3LCD Technology
BRAVIA Engine™EX full digital video processing
system
1080p Input, HDMI™ x2 (1080/60p, 24p)
DMe compatible - BRAVIA ® Internet Video Link
Ready
X
1
Full HD 1080p (1920 x 1080) Picture Resolution
3LCD Technology
BRAVIA Engine™EX full digital video processing
system
1080p Input, HDMI™ x2 (1080/60p, 24p)
DMe compatible - BRAVIA ® Internet Video Link
Ready
X
1
Key Technologies
BRAVIA Engine™EX Full Digital Video Processor The BRAVIA Engine EX full digital video processing system is based on Sony’ s
famous BRAVIA Engine video processing system. It has all of the same video processing functions of BRAVIA Engine plus the added
ability to upconvert 480i standard definition signals via Digital Reality Creation Multi Function v1.0 technology for a picture with more
detail and definition.
Full HD 1080 There are a lot of ways to define high-definition but BRAVIA Full HD means you’ re getting the best resolution that high -
definition has to offer consumers. With Sony BRAVIA XBR HDTVs, Full HD 1080 means 1920 x 1080 pixels and 1080p video inputs. Your
lifestyle demands the best in high-definition and with Sony Full HD 1080 products you get it.
1920 x 1080 Panel Resolution When it comes to high -definition TV the pinnacle of performance is achieved by using 1920 x 1080
display panels. And BRAVIA® MDPJ high definition televisions have them. Over six million pixels create a native 1080p resolution,
which is exactly what you need to reproduce the 1080p content that 1080p video delivery sources such as Blu-ray disc™can deliver for
a picture so real it’s like you’ re actually there.
Live Color Creation technology Live Color Creation is a special Sony function that achieves precise, wide color reproduction
using a combination of advanced chroma signal processing algorithms. Working with a special optical engine, Sony's Live Color
Creation circuitry creates clear blues, natural greens and vibrant colors in all scenes.
DMe Ready (Digital Module Extender) Sony’s Digital Media Expander (DMe ) ready televisions offer a digital connection path
for the addition of the optional modules like the new BRAVIA Internet Video Link. With innovative DMeX expansion capabilities
featuring the Emmy® award winning XMB user interface select 2007 models are not merely TVs, but powerful entertainment platforms
that not only meet your needs today, but expands easily to meet tomorrow’s needs as well.
X
X
Xross Media Bar™(XMB) When was the last time you saw an on-screen display that was fast, fun and easy to use— Sony’ s
Emmy® award-winning Xross Media Bar (pronounced Cross) provides a logical and fast way to access set up menus, user controls,
and more. The on-screen display comes to life by pushing the XMB menu button on the remote. Navigation through the menus is
smooth and fast.
BRAVIA ® Theatre Sync™ Sony® created BRAVIA® Theattre Sync to go beyond basic digital audio and video transmission. Based
on the HDMI -CEC function. BRAVIA® Theatre Sync ™will be included on select BRAVIA® Theatre home A/V systems and components.
This useful function reduces the hassle and time consuming job of powering up, routing signals, etc. to the simple push of one button.
There different functions are included:> One Push Play, which provides one -button activation of disc- based content such as DVDs and
CDs.
>One - Push Theatre Settings, which provide one -touch optimal picture and sound settings for movies.
>One - Push System Shut Down, which turns off the entire home entertainment system.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 11/21/2008
KDF-50E3000
50" Class (49.5") Grand WEGA™ E Series 3LCD Microdisplay TV
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Closed Captions (CC): Yes
On - Screen Display: XMB ®
DMeX ™ support: Yes
Video
Video Processing: Yes (BRAVIA Engine™ EX)
Color Temperature: Cool, Neutral, Warm
Noise Reduction: Yes
Black Corrector: Yes
Clear White: Yes
Gamma Compensation: High, Medium, Low, Off
CineMotion® Reverse 3:2 Pulldown Technology:
Yes
Advanced Iris: Yes
DRC® Mode: Yes
DRC® Palette Presets: Yes
Game Mode: On/Off
Vertical Correction: Yes
Vertical Position: Yes
Display Technology: 3LCD
Horizontal Size: Yes
Screen Mode: Wide Zoom, rmal (480 only), Full,
Zoom, Auto Wide
Live Color Creation™Technology: Yes
Picture Mode: Vivid, Standard, Cinema, Custom
Audio
Steady Sound® Automatic Volume Control: Yes
Dolby® : Dolby® Digital (AC3/ATSC only)
Audio Mode: Dynamic, Custom, Standard
Dolby® Digital Decoding: Yes
Sound Booster: Yes
Convenience
Channel Jump: Yes
Favorite Channel: Yes
Programmable Timer: Yes
Sleep Timer: 15, 30, 45, 60, 90, Off
Clock: Yes
Channel Surf: Yes
Remote Control: Yes
Optimized Theater Mode: Yes
On/Off Timer: Yes
BRAVIA® Theatre Sync ™ : Yes (One -Button Home
Theater Control (HDMI-CEC))
Show/Hide Channels: Yes
Parental Control: Yes
Freeze: Yes
Channel Labels: Yes
Specifications
General
Television Type: Micro Display HDTV
Video
Type: 3LCD Technology
Audio
Audio Power Output: 24W (12W x2)
Inputs and Outputs
Audio Out (Variable/Fixed): 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 3 (2
Rear/1 Side; up to 1080i)
Composite Video Input(s): 3 (2 Rear/1 Side)
Digital Audio Output(s): 1 (Rear) Optical Digital
Output
RF Connection Input(s): 2 (Rear) 1 UHF/VHF / 1
Cable In
S-Video Input(s): 1 (Rear)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (HDMI-DVI)
VHF/UHF Input(s): 1 (Rear)
1080/24p Input Capable: Yes (via HDMI™ )
Analog Audio Input(s) (Total): 5 (4 Rear/1 Side)
HDMI™ Connection(s) (Total): 2 (Rear; up to
1080p)
HDMI™Connection(s) (w/ Analog Audio In): 1
rear input included L/R audio inputs
Power
Power Requirements: AC 120V, 60Hz
Regulation and Standard Compliance
Energy Star ® Compliant: Yes
Service and Warranty Information
Limited Warranty Term: 1 Year Parts / 1 Year Labor
Dimensions
Weight: 62.8 lbs (28.5kg)
Supplied Accessories
Remote Control (RM-YD016)
Instruction Manual
Quick Set Up Guide
Warranty Card
Optional Accessories
SU -RG13M floor stand
DMX -NV1 BRAVIA® Internet Video Link
XL -2500 Replacement Lamp
UPC Code: 027242709683
3
1.Connectionspeedofatleast3Mbpsrecommended.Videoqualityand
picturesize varies and is dependent upon broadband speed and
deliverybycontentprovider.
2.Emmyisthecopyrightedproperty of theAcademyof Television Arts
&Sciencesand the National Academy ofTelevisionArts& Sciences
(ATAS/NATAS).
3.Limitedtoresolutions supported by both the PC andtheSonyTV.See
SonyTVusersmanual and PC documentation for supported
resolutions.
©2007SonyElectronics Inc. All rights reserved.
Sony,BRAVIA, BRAVIA EngineEX,BRAVIA Internet VideoLink,BRAVIA
TheatreSync,DRC,SpeedSurf,Cin eMotion,S - Force,XMBare
trademarksof Sony. DolbyDigitalis a registeredtrademarkof Dolby
Laboratories. This TV incorporates High - DefinitionMultimediaInterface
(HDMI™ ) technology. HDMI, the HMDI logo and High - Definition
MultimediaInterface are trademarksorregistered trademarksofHDMI
LicensingLLC.ATSCis a trademark of Electronic IndustriesAssociation.All
othertrademarksare property of their respective owners.
Features and specifications are subject to change without notice. Non -
metricweights and measures are approximate.
