KDL- 32LL150
32" Class BRAVIA® LL Series LCD TV (31.5" Diagonally)
Key Features
16:9 HD 720p Resolution Panel (1366 x 768)
Dynamic Contrast Ratio: 13,000:1
USB photo viewer
HD input x 6
BRAVIA® Link compatibility
BRAVIA Sync capable
®
3
24p True Cinema™capable
Advanced Contrast Enhancer w/ dynamic backlight control
ATSC™ / NTSC tuner with QAM
Exceeds ENERGY STAR 3.0 requirements
®
Key Technologies
16:9 720p Resolution Panel (1366 x 768) 16:9 720p resolution panel (1366 x 768) provides crisp,
detailed, and vibrant images for movies, sports, and prime - time HD television broadcasts.
Dynamic contrast 13,000:1 Dynamic contrast involves real - time image processing that results in
deep blacks in darker scenes, as well as fine details in shadows and other dark areas of the picture
for a difference you can truly see.
USB photo viewer Connect your USB - enabled camera or USB storage device directly to your HDTV's
USB input to view photos on the big screen.
HD input x 6 Get versatile HD connection options with six HD inputs. Three HDMI™inputs (up to
1080/60p capable) let you connect a Sony PlayStation 3 entertainment system, Blu - ray Disc™
player, or any other HDMI - capable equipment and get uncompressed digital video and multi -
channel digital audio on a single cable. An HD component input and an HD combo input (1080/60i
capable) provide added HD - capable connectivity, and a PC input (HD - 15 pin) offers the added
versatility of using your HDTV as a computer monitor.
1
®
®
2
BRAVIA Link compatibility BRAVIA Link compatibility expands your HDTV’s capabilities by letting you
connect optional BRAVIA Link modules, including the BRAVIA DVD Link, BRAVIA Wireless Link, and
BRAVIA Input Link (all sold separately).
®
BRAVIA Sync ™capable BRAVIA Sync capability combines the one - touch access and control
functionality of BRAVIA Theatre Sync™with the ability to control CEC - enabled Sony Handycam
camcorders and Cybershot digital still cameras using the TV’s remote and an on - screen display .
®
®
®
®
3
ENERGY STAR® 3.0 Sony ® LL - series HDTVs exceed Energy Star 3.0 requirements.
24p True Cinema™ 24p True Cinema support provides a direct connection to 24p video sources,
avoiding conversions and allowing users to enjoy films at their intended 24 fps (frames per second)
cinematic picture quality when using a 24p - capable output device, such as a Blu - ray Disc™player or
Sony PlayStation ® entertainment system.
®
3
Advanced Contrast Enhancer (ACE) w/ dynamic backlight control This powerful combination
of features adjusts the brightness of the backlight both to optimize image quality and reduce power
consumption. It works in real time, controlling bright outdoor images and dark interior shots scene
by scene for better video quality and a reduction in power use.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 04/30/2009
KDL- 32LL150
32" Class BRAVIA® LL Series LCD TV (31.5" Diagonally)
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Closed Captions (CC): Analog, Digital
On-Screen Display: Traditional
Finish (Surface Color): Black
BRAVIA® Link Module support: Yes (except BRAVIA®
Internet Video Link)
Display
Backlight Type: CCFL
Display Device: LCD
Video
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Wide Mode: Normal, Zoom, Wide Zoom, Full (Full1-2 for
PC)
3D Comb Filter: Yes
MPEG Noise Reduction: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema™Technology: Yes
Picture Mode: Vivid, Standard, Cinema
Advanced Contrast Enhancer (ACE): Yes
Audio
Digital Amplifier: Standard
Auto SAP: Yes
Auto Mute (on no signal): Yes
Steady Sound® Automatic Volume Control: Yes
Audio Out: Fixed
Stereo System: MTS
Dolby ®: Dolby Digital
Alternate Audio (Digital): Yes
5.1 Channel Audio Out: Yes
Sound Mode: Dynamic, Standard, Clear Voice
5.1ch Through Out (Handycam): Yes
Convenience
Channel Jump: Yes
Favorite Channel: Yes
Multiple Language Display: English, French, Spanish
Info Banner: XDS
Sleep Timer: Yes
Input Skip: Manual
Channel Surf: Yes
Channel Block (with password): Yes
Edit Channel Labels: Yes
Label Inputs: Yes
ID-1 Detection: Yes
USB Application(s): Photo Viewer (jpeg)
Theatre Mode (Theatre Button): Yes
Show/Hide Channels: Yes
Auto Shut-off: Yes
BRAVIA® Sync™: Yes
Parental Control: Yes
BRAVIA® Sync™Menu Button: Yes (on Remote
Control)
On-Screen Display for External Input: Yes
PIP (Picture in Picture): PC Input/TV Channel
Channel Labels: Yes
Program Block: Yes
Short Banner: Yes
Auto Photo Mode: Via USB
Picture Adjustments Lock: Yes
White Balance: RGB Gain/Bias
Favorites Menu: Text
®
Specifications
Display
Viewing Angle (Right/Left): 168(79/89)
Viewing Angle (Up/Down): 168(79/89)
On-screen Contrast Ratio: 3,000:1
Dynamic Contrast Ratio: 13,000:1
Screen Size (measured diagonally): 31.5"
Native Resolution: 1366 X 768
Display Resolution: 1366 X 768P (HD)
Panel Bit: 8 - bit
Aspect Ratio: 16:9
Color Range (xy): 72% OF NTSC
TV System
Tuner (Cable): Clear QAM
Tuner (Terrestrial): ATSC / NTSC
Channel Coverage: VHF: 2- 13 UHF: 14 -69 CATV (analog):
1 - 135 CATV (digital) : 1 - 135
TV System (Analog): M
Number of Tuners (Analog): 1
Number of Tuners (Digital): 1(Hybrid)
TV System (Digital): ATSC
Color System: NTSC 3.58
Video
Video Signal: 1080/60p (HDMI ™ / COMPONENT), 1080/60i,
1080/24p (HDMI ™ ONLY), 720/60p, 480/60p, 480/60i
Audio
Audio Power Output: 20W (10W X 2)
Speakers (Total): 2
Speaker Configuration: 2
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear) (1
fixed/1 selectable)
Composite Video Input(s): 2 (1 Side/1 Rear -selectable)
Digital Audio Output(s): Optical Digital Output -1 (Rear)
RF Connection Input(s): 1 (Rear)
S -Video Input(s): 1 (Side)
Analog Audio Input(s) (Total): 5 (1 Side/4 Rear)
Audio Out: 1 (Rear)
HDMI™Connection(s) (Total): 3 (1 Side/2 Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1 (Rear) (see
owner's manual for supported timings)
USB 2.0: 1 (Side)
HDMI™PC Input: Yes (see owner's manual for
supported timings)
S -Video Detection: Yes
AC Power Input: 1 (Rear)
Analog Audio Input(s) for HDMI™: 1 (Rear)
Power
Power Consumption (in Standby): Less Than 0.5W
Power Management: Yes (for PC input only)
Power Requirements (voltage): AC 120V
Power Requirements (frequency): 50/60Hz
Power Consumption (in Operation) max.: 135W
Regulation and Standard Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: 200x200 M6/8 - 12 mm
Service and Warranty Information
Limited Warranty Term: 1 Year Labor / 1 Year Parts
Energy Saving & Efficiency
Power Saving Modes: Yes
Energy Star® compliant: Exceeds Energy Star Version 3.0
Eco Settings: Yes
®
Dynamic Backlight Control: Yes
Backlight Off Mode: Yes
PC Power Management: Yes
Estimated Annual Energy Consumption (kWh): 182kWh
Idle TV Standby: Yes
Power Consumption (On Mode) for Energy Star: 99.3 W
(Energy Star Version 3.0)
Power Consumption (Standby Mode) for Energy Star:
0.12 W
Dimensions
Weight: 28 lbs. (12.7kg) with pedestal; 25.1 lbs. (11.4kg)
without pedestal
Measurements: 31.625 x 21.875 x 8.75 in (801 x 554 x
222mm) with pedestal; 31.625 x 20 x 3.75 in (801 x 505 x
94mm) without pedestal
Supplied Accessories
RM-YD028 Remote Control
Batteries (AA x2)
AC Power Cord (attached)
Screws (4 ea.) for Pedestal
Operating Instructions
Quick Setup Guide
Warranty Card
Pedestal (separate, assembly required)
Optional Accessories
SU-WL500 Wallmount Bracket
BRAVIA DVD Link
BRAVIA Input Link
BRAVIA Wireless Link
UPC Code: 027242753273
1.HDMI™ connectorrequiredandsoldseparately.2.Limitedto
resolutionssupported by both the PC and the Sony ® HDTV.SeeSony
TVuser'smanual and PC documentation for the supported resolutions.
3.WorkswithBRAVIA®Sync™ orTheatreSyncTM labeled home
audio/videoproducts when connected via HDMI ™ . 4.Distancewill
varydependinguponenvironmentalconditions.5.Requireswall
mountbracket sold separately.
©2009SonyElectronicsInc. All rights reserved.Reproductioninwholeor
inpartwithout written permission isprohibited.Sony,HDNA,BRAVIA
Sync,BRAVIA,,TheatreSync,Cyber - shot,Handycam,24pTrueCinema,
andtheirrespectivelogosaretrademarksofSony.PlayStationis a
trademarkofSony Computer Entertainment Inc.HDMIandtheHDMI
logoare trademarks of HDMI LicensingLLC. Blu - rayDisc isatrademark.
ENERGYSTARandthe ENERGY STAR markareregisteredU.S.marks.
ENERGYSTARisa registered mark owned bytheU.S.government.All
othertrademarksare trademarks of theirrespectiveowners.Features
and specifications are subject to change without notice. Non - metric
weightsand measures are approximate andmay vary.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddue to environmental considerations. For disposal or
recyclinginformation,pleasecontactyourlocalauthoritiesorthe
Electronic Industries Alliance (www.eiae.org).
®
®
