Sony KDL-32W6100 Operation instructions

Dismantling information for use
by professional recyclers
LCD TV
9-888-729-41
Conditions of Use:
(1) Please use this information only for the purpose of repair and recycling of Sony products. Using this information for any
purpose other than the purpose described foregoing is forbidden.
(2) Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part
without the prior written permission of the author.
Revision of Information:
This information may be changed or updated at any time without any prior notice. Please confirm that this information is up-
to-date before using it.
Sony Home Entertainment & Sound Products Inc.
© 2021.02
Model
：
KDL-32W6100
KDL-32W6105
ORIGINAL MANUAL ISSUE DATE: 2021.02

MODEL REMOTE DESTINATION
KDL-32W6100 RM-ED062 CEI
KDL-32W6105 RM-ED062 CEI
2
MODEL LIST

3
TOOLS & EQUIPMENTS
1 LIST OF ITEMS TO BRING
1. Screwdriver (e.g. #2 Phillips Screwdriver)
2. Multimeter
3. ESD Wrist Straps
4. Metal Washer (Flat) or Coin (for remove Rear Cover)
5. Ruler (for remove Rear Cover)
2 OPTIONAL EQUIPMENT
1. Screwdriver (e.g. #0 Phillips Screwdriver)
2. Parts Tray for loose screws and small items
3. Flashlight
For Surface Mounted Parts/Connectors;
Hot-Air Type soldering Iron is needed.
Thickness: approx. 1.5mm
Diameter: 20~25mm
(wrap in tape (L=50mm))
Plastic or Metal Ruler
(In case of Metal ruler, wrap
in tape (L=50mm) for prevent
scratches)

4
DISSASSEMBLY

REAR
COVER
LOUD
SPEAKER
27
P-MOD
BRACKET, SIDE (FRE)
3
SWITCH UNIT
4
UNIVERSAL
SIL-TU
11
BLM BOARD
12
15
LK1 BRD
14
9
SHEET,
THERMAL (BM)
1LABEL, UNDER
TERMINAL
13
5
BRACKET
SWITCH
HKT-E MOUNT
10
GUIDE, LIGHT
LOUDSPEAKER
7
5
51
STAND, ASSY
•Place the TV set facing downwards on a stable, level surface before disassembly and assembly of parts.
• and shaded parts are critical for safety. Replace only with part number specified.
• Parts contain confidential information. Strictly follow the instruction whenever the components are
repaired and/or replaced.
(*) Parts are not stocked since they are seldom required for routine service.
Some delays should be anticipated when ordering these components.
Picture provided in this section might have slight difference from the actual sets.
Lines that indicate parts are shown in blue in the illustration.
The reference number beside the part description indicates the disassembly sequence.
Remove screws before disassembly. Unplug connectors before disassembly
!
3-1. KDL-32W61*
3-1-1. Disassembly, Exploded View
BEZEL
PANEL,
ORNAMENT (MZT)
16
DISASSEMBLY, EXPLODED VIEWS AND OTHER PARTS

6
81 82
83
REF. NO. PART NO. DESCRIPTION REMARKS
81 1-912-036-11 FLEXIBLE FLAT CABLE 30P CN8501(BLM)-
SOURCE BOARD (1)
KDL-32W6100/6103/6105 (CEI)
82 1-849-993-11 FLEXIBLE FLAT CABLE 40P CN9601(BLM)-
CN9901(LK1) (1)
KDL-32W6100/6103/6105 (CEI)
83 1-910-805-95 HARNESS ASSY CN9602(BLM)-CN100(HKT)-CN1(3KEY)/CN4001(LK1)-
SP (1)
HARNESS/CABLE

7
REF. NO. PART NO. DESCRIPTION REMARKS
12 A-2180-708-A COMPL SVC BLM_KML_AEP_WXGA
14 A-2179-427-A SPRO MODULE LK1_M32_M40
15 A-2180-817-A P-MOD (IS7S320HNO0101)(SERVICE
!
SET PART LIST
PART NO. DESCRIPTION REMARKS
1-493-332-11 AC ADAPTOR(60W) KDL-32W6100/6103 (CEI)
1-493-000-51 AC ADAPTOR(85W) KDL-32W6105 (CEI)
1-846-420-11 CORD SET, POWER-SUPPLY KDL-32W6100/403/405 (CEI)
!
External Power Supply
Cable
Other Parts
PARTS LIST
Liquid Crystal Display
Printed Circuit Board, incl. capacitors
Printed Circuit Board, incl. capacitors

8
9-888-729-E4 English
© 2021.02
Sony Home Entertainment & Sound Products Inc.
