Sony WEGA KLV-23HR1 User guide

MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
VHF/UHF VIDEO/AUDIO
IN S VIDEO
IN
AUDIO IN
TOP VIEW
FRONT VIEW
SIDE VIEW
BACK VIEW
AUDIO OUT
(fix/var)
COMPONENT
IN
15
3
16.5V DC IN
(HEADPHONES) JACK
22 5/8"
7 1/4"
3 5/8"
23 3/4"
19 1/2"
19 3/4"
12" 17"
13 1/4"
LCD TV 120VAC
60Hz
88 W
1.2 (stby)
23 3/4 " x 19 1/2" x 7 1/4"*
19 lbs 6 oz
KLV-23HR1
Approx
RM-928Y REMOTE CONTROL
OPTIONAL WALL MOUNT SU-W200
INCLUDES SUPPLIED STAND
*
R
15 7/8"
2 1/2"
10 1/2"
1 1/4"
