Sony MOD-RF1 User manual

MOD-RF1
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Chinese Model
PX Model
SERVICE MANUAL
RF DEMODULATOR
MICROFILM
SPECIFICATIONS
Inputs
AC-3 RF IN : 75Ω
Outputs
COAXIAL DIGITAL OUT : 0.5 Vp-p, 75Ω
OPTICAL DIGITAL OUT : —
General
Power requirements : US, Canadian, PX models: 120V, 60Hz
Other models: 220 – 230V, 50/60Hz
Power consumption : 6W
Dimensions (w/h/d) : Approx. 85 ×70 ×185 mm
(33/8×27/8×73/8inches)
Mass : Apporox. 780g
(1 lb. 11 oz.)
Supplied accessories : Digital optical cable (1)

— 2 —
SAFETY-RELATED COMPONENTWARNING!!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED LINEWITH
MARK !ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
Checktheantennaterminals,metaltrim,“metallized”knobs,screws,
and all other exposed metal parts forAC leakage. Check leakage as
described below.
LEAKAGE
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. Acommercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operatedAC voltmeter.The “limit” indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples of
a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2VAC range are suitable. (See
Fig. A)
SAFETY CHECK-OUT
To Exposed Metal
Parts on Set
0.15
µ F1.5 k
Ω
AC
Voltmeter
(0.75V)
Earth Ground
Fig.A. Using an AC voltmeter to check AC leakage.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE !SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

MOD-RF1
For schematic diagrams.
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
• % : indicates tolerance.
•2: nonflammable resistor.
•1: fusible resistor.
•C: panel designation.
•U: B+ Line.
•V: B– Line.
•H: adjustment for repair.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
No mark : POWER ON
• Voltagesare taken with a VOM (Inputimpedance10MΩ).
Voltagevariations may be noted due to normalproduction
tolerances.
• Waveforms are taken with a oscilloscope.
• Circled numbers refer to waveforms.
• Signal path.
c: DIGITAL OUT
• Abbreviation
CND : Canadian
For printed wiring boards.
Note:
•X: parts extracted from the component side.
•®: Through hole.
•b: Pattern from the side which enables seeing.
THIS NOTE IS COMMON FOR PRINTEDWIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this necessary note is printed in each
block.)
Note:
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
Note:
Les composants identifiés par
une marque !sont critiques
pour la sécurité.
Ne les remplacer que par une
pièceportant lenuméro spécifié.
•Waveform
1IC114 %∞ (VIN)
4.0Vp-p
18.432MHz
SECTION 1
GENERAL This section is extracted
from instruction manual.
— 3 — — 4 —
SECTION 2
DIAGRAMS

MOD-RF1
2-1. PRINTED WIRING BOARD
— 5 — — 6 —
Ref. No. Location
D101 H-4
D110 C-3
D801 C-11
D802 B-11
D901 D-9
D902 D-9
D903 D-9
D904 D-9
D905 H-5
IC104 C-2
IC105 I-2
IC110 F-3
IC111 H-3
IC113 F-5
IC114 G-5
IC901 D-6
IC902 C-6
Q101 F-3
Q102 G-3
Q103 G-4
Q104 G-3
Q105 G-3
Q106 I-3
Q107 F-5
• Semiconductor
Location
11
(11)
11
(11)
11
(11)
11
(11)
MAIN BOARD (CONDUCTOR SIDE)
MAIN BOARD (COMPONENT SIDE)
PANEL BOARD
(CONDUCTOR SIDE)
PANEL BOARD
(COMPONENT SIDE)
1
4
8
5
1
4
8
5
E
E
E
E
E
E
E1
4
8
5
12
3
1-669-803-
1-669-803-
1-669-802-
1-669-802-
1
8
1
8
C905
C117
C904
C903
C902
C901
FB902
FB901
IC901
C906
C126
C111
C131
C110
X101
D110
IC902
3
2
1
3
2
1
NOT REPLACEABLE:
BUILT IN
TRANSFORMER
4
3
2
1
5
6
7
8
9
T901
EPT101
EPT102
CN101
EXCEPT
US,CND,PX
US,CND,PX
D802
S801
D801
LOCKED
CN801
AC
IN
C951
CN901
EPT103
C132
C114
FL101
IC104
IC104
J102
1
2
3
1 5 2
34
87
T401
AC-3
RF IN
COAXIAL
INPUT
DIGITAL
OUT OPTICAL
X
X
16
IC114
12
A
B
C
D
E
F
G
H
I
3456789101112

MOD-RF1
2-2. SCHEMATIC DIAGRAM
— 7 — — 8 —
• See page 4 for Waveforms. • See page 9 for IC Pin Function.

MOD-RF1
2-3. IC PIN FUNCTION DESCRIPTION
IC114 SN-PM4007A
— 9 — — 10 —
Pin No.
51
52
53
54
55
56
57
58
59
60
61, 62
63
64
65
66
67
68, 69
70
71
72
73
74 to 77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92 to 96
97
98
99
100
I/O
I/O
—
—
I
I
O
I
I
I
I
—
O
I
I
O
I
—
O
—
I
I
—
I
—
—
—
I
I
—
I
—
I
O
O
—
—
—
I
I
—
—
Description
External RAM data terminal. Data bus 0
Power supply (+5 V)
GND (0 V)
For IC test Normally connected to VDD
VCXO input
VCXO output
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
Not used.
Phase comparator output. (3-state)
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
Muting output. H: mute
IC test pin. Normally connected to GND (or no connection)
Not used.
DIGITAL OUT output (serial data stream output)
Not used.
DIGITAL OUT selection
IC test pin. Normally connected to GND (or no connection)
Not used.
Muting input H: mute
Power supply (+5 V)
GND (0 V)
Power supply for analog comparator (+5 V)
Analog comparator input. Positive side (non-inverted side : OPSK input)
Analog comparator input. Negative side (inverted side)
GND forAnalog comparator (0 V)
IC test pin. Normally connected to GND (or no connection)
Power supply (+5 V)
IC test pin. Normally connected to GND (or no connection)
Analog comparator output
Analog comparator output. Inverted output
Not used.
GND ( 0 V)
Not used.
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
GND for 46.08 MHz oscillator. (0 V)
Power supply for 46.08 MHz oscillator. (+5 V)
Pin Name
DB0
VDD
GND
TI1
VIN
VOUT
T12
T13
TLDB
TCK
NC
PDO
T14
PDDIS
MUTO
T15
NC
DAOUT
NC
DASEL
T18
NC
MUTI
VDD
GND
AVDD
CPIN
CMIN
AGND
TM4
VDD
DIN
DOUT
DOUTB
NC
GND
NC
TM5
BUNRI
AGND
AVDD
Pin No.
1
2
3
4
5
6
7
8 to 10
11
12 to 15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
I/O
—
—
I
I
I
I
I
—
I
—
I
O
O
O
O
O
O
I
I
—
I
I
—
—
O
O
—
—
O
O
O
O
O
O
—
O
O
O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
Description
GND. (0 V)
Power supply. (+5 V)
System reset. L: reset
Oscillation control. H: ON to oscillate. Normally H , Standby mode: L
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
Not used.
IC test pin. Normally connected to GND (or no connection)
Not used.
IC test pin. Normally connected to GND (or no connection)
External RAM address output. Address 0 (LSB)
External RAM address output. Address 1
External RAM address output. Address 2
External RAM address output. Address 3
External RAM address output. Address 4
External RAM address output. Address 5
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
Not used.
IC test pin. Normally connected to GND (or no connection)
IC test pin. Normally connected to GND (or no connection)
GND (0 V )
Power supply (+5V)
External RAM address output.Address 6
External RAM address output.Address 7
GND (0V)
Power supply (+5V)
External RAM address output.Address 12
External RAM address output.Address 14 (MSB)
External RAM write enable signal L: active
External RAM address output.Address 13
External RAM address output.Address 8
External RAM address output.Address 9
GND (0 V)
External RAM address output. Address 11
External RAM write enable signal L : active
External RAM address output.Address 10
External RAM data terminal. Data bus 7
External RAM data terminal. Data bus 6
External RAM data terminal. Data bus 5
External RAM data terminal. Data bus 4
External RAM data terminal. Data bus 3
External RAM data terminal. Data bus 2
External RAM data terminal. Data bus 1
Pin Name
GND
VDD
RESET
OSCON
DATA
MCK
MLTB
NC
TM0
NC
TM1
A0
A1
A2
A3
A4
A5
TM2
TM3
NC
XIN
NEXT
GND
VDD
A6
A7
GND
VDD
A12
A14
WE
A13
A8
A9
GND
A11
OE
A10
DB7
DB6
DB5
DB4
DB3
DB2
DB1

SECTION 3
EXPLODEDVIEWS
NOTE:
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delayshouldbe anticipatedwhen orderingthese
items.
• Abbreviation
CND : Canadian
CH : Chinese
— 11 —
When indicating parts by reference number,
please include the board name.
The components identified by mark !or
dotted line with mark !are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
!sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Themechanicalparts with noreference number
in the exploded views are not supplied.
11
5
7
4
3
2
1
11
11
10
10
11
11
11
8
6
9
9
9
US, CND, PX
CH
EXCEPT
US, CND, PX, CH
not supplied
*1 4-900-317-01 PLATE (F), INDICATION
2 4-991-632-11 PANEL, FRONT
3 3-380-952-21 BUTTON
*4 1-669-803-11 PANEL BOARD
*5 4-900-315-01 CASE (8565165)
*6 A-4407-981-A MAIN BOARD, COMPLETE
7 1-543-653-11 CORE ASSY, BEAD (DIVISION TYPE)
*8 3-703-244-00 BUSHING (2104), CORD (EXCEPT US, CND, PX)
8 3-703-571-11 BUSHING (S) (4516), CORD (US, CND, PX)
!9 1-558-945-21 CORD, POWER (POLAR. SPT-1) (US, CND, PX)
!9 1-575-651-21 CORD, POWER (EXCEPT US, CND, PX, CH)
!9 1-782-510-11 CORD, POWER (CH)
10 4-965-822-01 FOOT
11 7-685-646-79 SCREW +BVTP 3 ×8 TYPE2 IT-3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks

The components identified by mark !or
dotted line with mark !are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
!sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
NOTE: • Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delayshouldbe anticipatedwhen orderingthese
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METALOXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 12 —
SECTION 4
ELECTRICAL PARTS LIST
• Abbreviation
CND : Canadian
AUS : Australian
G : German
SP : Singapore
EE : East European
EA : Saudi Arabia
MY : Malaysia
CH : Chinese
*A-4407-981-A MAIN BOARD, COMPLETE
*********************
7-685-646-79 SCREW +BVTP 3 ×8 TYPE2 IT-3
< CAPACITOR >
C101 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C102 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C104 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C105 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C107 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C109 1-163-248-11 CERAMIC CHIP 75PF 5% 50V
C110 1-136-921-11 FILM 1uF 5% 50V
C111 1-136-921-11 FILM 1uF 5% 50V
C112 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C113 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C114 1-136-165-00 FILM 0.1uF 5% 50V
C115 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C117 1-126-964-11 ELECT 10uF 20% 50V
C119 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C120 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C121 1-163-085-00 CERAMIC CHIP 2PF 50V
C122 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C123 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C124 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C125 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C126 1-126-964-11 ELECT 10uF 20% 50V
C127 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C128 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C129 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C130 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C131 1-126-966-11 ELECT 33uF 20% 16V
C132 1-126-967-11 ELECT 47uF 20% 50V
C133 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C134 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C135 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C901 1-126-768-11 ELECT 2200uF 20% 16V
C902 1-126-935-11 ELECT 470uF 20% 16V
C903 1-126-934-11 ELECT 220uF 20% 16V
C904 1-126-934-11 ELECT 220uF 20% 16V
C905 1-126-767-11 ELECT 1000uF 20% 16V
C906 1-126-934-11 ELECT 220uF 20% 16V
C911 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C912 1-165-319-11 CERAMIC CHIP 0.1uF 50V
!C951 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C991 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C992 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C993 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C994 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
*CN101 1-770-392-11 PIN, CONNECTOR (PC BOARD) 8P
CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D101 8-719-061-62 DIODE KV1851
D110 8-719-914-42 DIODE DA204K
D901 8-719-210-33 DIODE EC10DS2
D902 8-719-210-33 DIODE EC10DS2
D903 8-719-210-33 DIODE EC10DS2
D904 8-719-210-33 DIODE EC10DS2
D905 8-719-801-78 DIODE 1SS184
< EARTH >
EPT101 1-537-770-21 TERMINAL BOARD, GROUND
EPT102 1-537-770-21 TERMINAL BOARD, GROUND
EPT103 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB901 1-410-397-21 FERRITE BEAD INDUCTOR
FB902 1-410-397-21 FERRITE BEAD INDUCTOR
< FILTER >
FL101 1-233-866-11 FILTER, BAND PASS
< IC >
IC104 8-749-923-04 IC TOTX178 (OPTICAL)
IC105 8-759-242-70 IC TC7WU04F
IC110 8-759-262-03 IC MC14577CF
IC111 8-759-636-55 IC M5218AFP
IC113 8-759-476-29 IC N341256SJ-20-TE1
IC114 8-759-463-68 IC SN-PM4007A
IC901 8-759-231-53 IC TA7805S
IC902 8-759-700-65 IC NJM79L05A
MAIN

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 13 —
< JACK >
J102 1-784-902-11 JACK, PIN 2P (AC-3RF IN/COAXIAL)
< JUMPER RESISTOR >
JW101 1-216-295-91 SHORT 0
JW901 1-211-950-11 SHORT 0 (EXCEPT US, CND, PX)
JW902 1-211-950-11 SHORT 0 (US, CND, PX)
< COIL >
L101 1-410-391-11 INDUCTOR CHIP 68uH
< TRANSISTOR >
Q101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q102 8-729-230-49 TRANSISTOR 2SC2712-YG
Q103 8-729-216-22 TRANSISTOR 2SA1162-G
Q104 8-729-230-49 TRANSISTOR 2SC2712-YG
Q105 8-729-230-49 TRANSISTOR 2SC2712-YG
Q106 8-729-216-22 TRANSISTOR 2SA1162-G
Q107 8-729-216-22 TRANSISTOR 2SA1162-G
< RESISTOR >
R101 1-216-041-00 METAL CHIP 470 5% 1/10W
R102 1-216-022-00 METAL CHIP 75 5% 1/10W
R103 1-216-073-00 METAL CHIP 10K 5% 1/10W
R104 1-216-043-91 RES, CHIP 560 5% 1/10W
R105 1-216-024-00 RES, CHIP 91 5% 1/10W
R106 1-216-049-91 RES, CHIP 1K 5% 1/10W
R107 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R108 1-216-073-00 METAL CHIP 10K 5% 1/10W
R109 1-216-073-00 METAL CHIP 10K 5% 1/10W
R110 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R111 1-216-049-91 RES, CHIP 1K 5% 1/10W
R112 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R113 1-216-049-91 RES, CHIP 1K 5% 1/10W
R114 1-216-049-91 RES, CHIP 1K 5% 1/10W
R115 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R116 1-216-049-91 RES, CHIP 1K 5% 1/10W
R117 1-216-073-00 METAL CHIP 10K 5% 1/10W
R118 1-216-029-00 METAL CHIP 150 5% 1/10W
R119 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R120 1-216-049-91 RES, CHIP 1K 5% 1/10W
R121 1-216-049-91 RES, CHIP 1K 5% 1/10W
R122 1-216-049-91 RES, CHIP 1K 5% 1/10W
R123 1-216-049-91 RES, CHIP 1K 5% 1/10W
R124 1-216-049-91 RES, CHIP 1K 5% 1/10W
R125 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R126 1-216-049-91 RES, CHIP 1K 5% 1/10W
R127 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R128 1-216-097-91 RES, CHIP 100K 5% 1/10W
R129 1-216-081-00 METAL CHIP 22K 5% 1/10W
R130 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R131 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R132 1-216-089-91 RES, CHIP 47K 5% 1/10W
R133 1-216-089-91 RES, CHIP 47K 5% 1/10W
R134 1-216-089-91 RES, CHIP 47K 5% 1/10W
R135 1-216-027-00 METAL CHIP 120 5% 1/10W
R136 1-216-089-91 RES, CHIP 47K 5% 1/10W
R137 1-216-073-00 METAL CHIP 10K 5% 1/10W
R138 1-216-073-00 METAL CHIP 10K 5% 1/10W
R139 1-216-083-00 METAL CHIP 27K 5% 1/10W
R140 1-216-093-00 METAL CHIP 68K 5% 1/10W
R141 1-216-017-91 RES, CHIP 47 5% 1/10W
R142 1-216-025-91 RES, CHIP 100 5% 1/10W
R143 1-216-081-00 METAL CHIP 22K 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-037-00 METAL CHIP 330 5% 1/10W
R146 1-216-025-91 RES, CHIP 100 5% 1/10W
R147 1-216-073-00 METAL CHIP 10K 5% 1/10W
R148 1-216-073-00 METAL CHIP 10K 5% 1/10W
R149 1-216-081-00 METAL CHIP 22K 5% 1/10W
R150 1-216-081-00 METAL CHIP 22K 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-001-00 METAL CHIP 10 5% 1/10W
R153 1-216-001-00 METAL CHIP 10 5% 1/10W
< TRANSFORMER >
T401 1-421-946-11 TRANSFORMER, PULSE
!T901 1-431-874-11 TRANSFORMER, POWER
< VIBRATOR >
X101 1-767-434-21 VIBRATOR, CRYSTAL (18.432MHz)
************************************************************
*1-669-803-11 PANEL BOARD
************
< CONNECTOR >
CN801 1-770-401-11 HOUSING, CONNECTOR (PC BOARD) 8P
< DIODE >
D801 8-719-313-48 DIODE SEL6210S-TH12 (LOCKED)
D802 8-719-018-46 DIODE SEL3510C-CD
< RESISTOR >
R801 1-216-025-91 RES, CHIP 100 5% 1/10W
R802 1-216-025-91 RES, CHIP 100 5% 1/10W
< SWITCH >
S801 1-554-118-00 SWITCH, PUSH (1 KEY) (POWER)
************************************************************
MISCELLANEOUS
**************
7 1-543-653-11 CORE ASSY, BEAD(DIVISION TYPE)
!9 1-558-945-21 CORD, POWER (POLAR.SPT-1) (US, CND, PX)
!9 1-575-651-21 CORD, POWER (EXCEPT US, CND, PX, CH)
!9 1-782-510-11 CORD, POWER (CH)
************************************************************
MAIN PANEL
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque !sont critiques
pour la sécurité.
Ne les remplacer que par une
pièceportant lenuméro spécifié.

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 14 —
MOD-RF1
Sony Corporation
Home A&V Products Company
9-922-898-11 98F1690-1
Printed in Japan ©1998.6
Published by Quality Assurance Dept.
(Shibaura)
ACCESSORIES & PACKING MATERIALS
********************************
1-574-264-11 CORD, OPTICAL PLUG
3-862-543-11 MANUAL, INSTRUCTION (ENGLISH/FRENCH)
3-862-543-21 MANUAL, INSTRUCTION (SPANISH/GERMAN)
(EXCEPT US, CND, PX, CH)
3-862-543-31 MANUAL, INSTRUCTION (DUTCH/SWEDISH)
(AEP, EE, E, EA, UK, G, AUS)
3-862-543-41 MANUAL, INSTRUCTION
(ITALIAN/PORTUGUESE)
(AEP, EE, E, EA, UK, G, AUS)
3-862-543-51 MANUAL, INSTRUCTION (CHINESE)
(SP, MY, CH)
