Specifications
MODEL NUMBER LMD-DM50 LMD-DM30 LMD-DM20 LMD-DM30C LMD-DM20C
MONOCHROME COLOR
LCD panel a-Si TFT Active Matrix LCD a-Si TFT Active Matrix LCD (B&W) a-Si TFT Active Matrix LCD (B&W) a-Si TFT Active Matrix LCD (Color) a-Si TFT Active Matrix LCD (Color)
Effective Picture
(W × H, Diagonal)
Approx. 165/8× 13 in
(422.4 × 337.9 mm)
(W/H, Diagonal)
Approx. 1611/16 × 121/2 in
(423.9 × 318.0 mm)
(W/H, Diagonal)
Approx. 17 × 123/4 in
(432.0 × 324.0 mm)
(W/H, Diagonal)
Approx. 171/16 × 1213/16 in
(433.2 × 324.9 mm)
(W/H, Diagonal)
Approx. 171/16 × 1213/16 in
(433.2 × 324.9 mm)
(W/H, Diagonal)
Size* 21.3 in (541.02 mm) 20.8 in (528.32 mm) 21.3 in (541.02 mm) 21.3 in (541.02 mm) 21.3 in (541.02 mm)
Viewing angle (H,V) 85°/85°/85°/85° (typical)
(up/down/left/right contrast > 20:1)
85°/85°/85°/85° (typical)
(up/down/left/right contrast > 10:1)
85°/85°/85°/85° (typical)
(up/down/left/right contrast > 10:1)
85°/85°/85°/85° (typical)
(up/down/left/right contrast > 10:1)
85°/85°/85°/85° (typical)
(up/down/left/right contrast > 10:1)
Resolution
Portrait 5MP (2048 × 2560) 3MP (1536 × 2048) 2MP (1600 × 1200) 3MP (1536 × 2048) 2MP (1200 × 1600)
Landscape 5MP (2560 × 2048) 3MP (2048 × 1536) 2MP (1200 × 1600) 3MP (2048 × 1536) 2MP (1600 × 1200)
Pixel pitch
Normal 5MP 165 μm pitch 3MP 207 μm pitch 2MP 270 μm pitch N/A N/A
Independent Sub-pixel
Drive** ON 15MP 55 μm pitch 9MP 69 μm pitch N/A N/A N/A
Aspect
Landscape 5:4 4:3 4:3 4:3 4:3
Portrait 4:5 3:4 3:4 3:4 3:4
Pixel efficiency 99.99% 99.99% 99.99% 99.99% 99.99%
Display Color N/A N/A N/A Approx. 16,770,000 Approx. 16,770,000
Number of Grayscale
256 out of 12241 shades of gray
1024 shades of gray
(Display Port 10-bit input)
2048 simultaneous shades of gray
256 out of 12241 shades of gray
1024 shades of gray
(Display Port 10-bit input)
2048 simultaneous shades of gray
256 out of 12241 shades of gray
1024 shades of gray
(Display Port 10-bit input)
2048 simultaneous shades of gray
N/A N/A
Number of Grayscale with
Independent Sub-pixel Drive**ON
1276 shades of gray with
Independent Sub-pixel Drive**
1276 shades of gray with
Independent Sub-pixel Drive** N/A N/A N/A
Maximum luminance 1100 cd/m² (panel typical) 1000 cd/m² (panel typical) 1800 cd/m² (panel typical) 800 cd/m² (panel typical) 950 cd/m² (panel typical)
Contrast ratio 850:1 (typical) 900:1 (typical) 700:1 (typical) 750:1 (typical) 900:1 (typical)
Backlight CCFL CCFL CCFL CCFL CCFL
Mounting standard VESA (100 mm) VESA (100 mm) VESA (100 mm) VESA (100 mm) VESA (100 mm)
Video input DVI-D Dual Link/DisplayPort
(per display)
DVI-D Dual Link/DisplayPort
(per display)
DVI-D Dual Link/DisplayPort
(per display)
DVI-D Dual Link/DisplayPort
(per display)
DVI-D Dual Link/DisplayPort
(per display)
USB ports 2 2 2 2 2
Power AC 100~240V 50/60 Hz AC 100~240V 50/60 Hz AC 100~240V 50/60 Hz AC 100~240V 50/60 Hz AC 100~240V 50/60 Hz
Power consumption 90W 90W 90W 120W 120W
Mass Approx.27 lb 1.9 oz (12.3 kg) Approx.25 lb 9.2 oz (11.6 kg) Approx.26 lb 7.3 oz (12.0 kg) Approx.27 lb 1.9 oz (12.3 kg) Approx.27 lb 1.9 oz (12.3 kg)
Operating conditions
Temperature 41°F to 104°F (5°C to 40°C) 41°F to 104°F (5°C to 40°C) 41°F to 104°F (5°C to 40°C) 41°F to 104°F (5°C to 40°C) 41°F to 104°F (5°C to 40°C)
Recommended temperature 68°F to 86°F (20°C to 30°C) 68°F to 86°F (20°C to 30°C) 68°F to 86°F (20°C to 30°C) 68°F to 86°F (20°C to 30°C) 68°F to 86°F (20°C to 30°C)
Humidity 30% to 80% 30% to 80% 30% to 80% 30% to 80% 30% to 80%
Pressure 700 hPa to 1060 hPa (Operating) 700 hPa to 1060 hPa (Operating) 700 hPa to 1060 hPa (Operating) 700 hPa to 1060 hPa (Operating) 700 hPa to 1060 hPa (Operating)
Storage and transport conditions
Temperature -4°F to 140°F (-20°C to 60°C) -4°F to 140°F (-20°C to 60°C) -4°F to 140°F (-20°C to 60°C) -4°F to 140°F (-20°C to 60°C) -4°F to 140°F (-20°C to 60°C)
Humidity 10% to 85% 10% to 85% 10% to 85% 10% to 85% 10% to 85%
Pressure 266 hPa to 1060 hPa (Storage) 266 hPa to 1060 hPa (Storage) 266 hPa to 1060 hPa (Storage) 266 hPa to 1060 hPa (Storage) 266 hPa to 1060 hPa (Storage)
Dimensions (W × H × D)
Landscape 1811/16 × 18 7/8 - 215/16 × 82/3 in
(474.5 × 479.9 - 541.4 × 220 mm)
183/4× 18 7/16 - 207/8× 8 2/3 in
(474.0 × 468.4 - 529.9 × 220 mm)
183/4× 18 7/16 - 207/8× 8 2/3 in
(474.0 × 468.4 - 529.9 × 220 mm)
183/4× 18 7/16 - 207/8× 82/3 in
(474.0 × 468.4 - 529.9 × 220 mm)
183/4× 18 7/16 - 207/8× 82/3 in
(474.0 × 468.4 - 529.9 × 220 mm)
Portrait 14 7/16 × 20 9/16 - 23 × 82/3 in
(390 × 523.9 - 584.2 × 220 mm)
147/16 × 20 9/16 - 23 × 82/3 in
(367 × 521.9 - 583.4 × 220 mm)
147/16 × 20 9/16 - 23 × 82/3 in
(367 × 521.9 - 583.4 × 220 mm)
147/16 × 20 9/16 - 23 × 82/3 in
(367 × 521.9 - 583.4 × 220 mm)
147/16 × 20 9/16 - 23 × 82/3 in
(367 × 521.9 - 583.4 × 220 mm)
Safety Compliance
U.S.A
UL60601-1
ANSI/AAMI/ ES60601-1:2005
Class B FCC-DoC
UL60601-1
ANSI/AAMI/ ES60601-1:2005
Class B FCC-DoC
UL60601-1
ANSI/AAMI/ ES60601-1:2005
Class B FCC-DoC
UL60601-1
ANSI/AAMI/ ES60601-1:2005
Class B FCC-DoC
UL60601-1
ANSI/AAMI/ ES60601-1:2005
Class B FCC-DoC
Canada No60601-1
Class B Digital Apparatus
No60601-1
Class B Digital Apparatus
No60601-1
Class B Digital Apparatus
No60601-1
Class B Digital Apparatus
No60601-1
Class B Digital Apparatus
China
GB49493 (IEC60950)+
GB9254 (CISPR22)
GB17625.1(IEC61000-3-2)
GB49493 (IEC60950)+
GB9254 (CISPR22)
GB17625.1(IEC61000-3-2)
GB49493 (IEC60950)+
GB9254 (CISPR22)
GB17625.1(IEC61000-3-2)
GB49493 (IEC60950)+
GB9254 (CISPR22)
GB17625.1(IEC61000-3-2)
GB49493 (IEC60950)+
GB9254 (CISPR22)
GB17625.1(IEC61000-3-2)
Accessories
Supplied Accessories AC power cord, DVI cable
(Dual link), USB cable, CD-ROM
AC power cord, DVI cable
(Dual link), USB cable, CD-ROM
AC power cord, DVI cable
(Single link), USB cable, CD-ROM
AC power cord, DVI cable
(Dual link), USB cable, CD-ROM
AC power cord, DVI cable
(Single link), USB cable, CD-ROM
Optional Accessories
LMD-KT10: Calibration kit
LMD-SN10: Display Network
Manager
LMD-KT10: Calibration kit
LMD-SN10: Display Network
Manager
LMD-KT10: Calibration kit
LMD-SN10: Display Network
Manager
LMD-KT10: Calibration kit
LMD-SN10: Display Network
Manager
LMD-KT10: Calibration kit
LMD-SN10: Display Network
Manager
Warranty
Warranty 5 year Advanced Replacement
Program
5 year Advanced Replacement
Program
5 year Advanced Replacement
Program
5 year Advanced Replacement
Program
5 year Advanced Replacement
Program
FDA Clearance
FDA 510(k) Clearance Yes for mammography and
general imaging Yes for general imaging Yes for general imaging Yes for general imaging Yes for general imaging
FDA 510(k) Clearance
when used with Independent
Sub-pixel Drive
Yes for mammography and
general imaging
Yes for mammography and
general imaging N/A N/A N/A
*Viewable area, measured diagonally.
**Independent Sub-pixel Drive technology was licensed by Totoku Electric Co.,Ltd.
