Sony Srx-t110 Reference manual

[SRX-T110/T105]

Product Introduction Letter

[SXRD]

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

Contents

1. Introduction ...................................................................................... 3

2. Product Positioning............................................................................ 3

3. Target markets & Applications........................................................... 3

4. Benefits & Unique Selling Points........................................................ 3

5. Competitive Analysis.......................................................................... 5

6. Product Features ............................................................................... 5

6.1. 8.8 million pixel resolution at 4096 x 2160 ...................................... 5

6.2. High brightness and contrast ratio.................................................. 5

6.3. Accurate color reproduction with wide color space ............................ 5

6.4. High Installation flexibility ............................................................. 6

6.5. Uniformity stability ....................................................................... 6

6.6. Convenient image projection modes................................................ 7

6.7. New DVI-D card with HDCP............................................................ 7

6.8. Lower fan noise............................................................................ 8

6.9. Improved chassis for installation convenience .................................. 8

6.10. New Projector control software SRX-C............................................. 9

6.11. Dual lamp system......................................................................... 9

6.12. Comparison SRX-T110/T105 vs SRX-S110/S105 .............................10

7. Pricing ..............................................................................................11

8. Marketing Communications...............................................................11

9. Appendix...........................................................................................11

9.1. Specifications..............................................................................11

9.2.Preset signal ...............................................................................12

9.3. Displayed image size in multiple screen mode.................................13

9.4. External Dimensions ....................................................................13

9.5. Mounting platform Dimensions ......................................................14

9.6. Preparation for installation............................................................16

9.7. Throwing distance.............................................................17

9.7.1 Using LKRL-Z115 lens....................................................... 18

9.7.2 Using LKRL-90 lens..................................................................... 18

9.8. Optional Accessories ....................................................................19

9.9. PrimeSupport..............................................................................19

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

1. Introduction

The SRX-T110/T105 ultra high resolution projectors are successor models to SRX-R1xx and SRX-S1xx

series, combining the features and functions of two predecessor models.

With the unique Sony SXRD panel technology incorporated, the new projectors inherit the high quality image

projection capability, clearly showing tiny details even on a big screen. Furthermore, the new T series have

the improved stability of performance and the convenient functions added, all of which are crucial

requirements for the target applications.

In a variety of applications, such as industrial design, data analysis for utility market or medical/research

field, or virtual reality display for entertainment market, the SRX-T110/T105 projectors will not only

streamline, but enhance the total system operation with their superb projection performance.

2. Product Positioning

Positioned as the top-end product in Sony entire projector line-up, the SRX-T110/T105 are unique in the

market place as there are not comparative projectors in the target markets in terms of brightness and native

resolution.

On top of that, in the target markets, except auditorium presentation, a plural number of projectors are

usually used in a system to artificially create one high resolution image on the large screen. Therefore, an

end user is keen on a simple system configuration while keeping the highest image precision, rather than

single projector performance and cost. The below example show how SRX-T110 projector simplify the

system against competitor’s configuration;

Powerwall for automotive design

6m x 2.5 m screen (4 door sedan car)

a. SRX-T110 x 1 piece WITHOUT edge blending and color matching adjustments

4096 x 1100 pixels

b. SXGA Projector x 3 pieces WITH edge matching and color matching adjustments

3760x 1024 pixels

3. Target markets & Applications

••Digital design for manufacturing industries, such as

automotive, aerospace and marine construction

••Data visualization for utility industry, scientific research,

medicine.

••Virtual Reality display for entertainment industries, such as

planetarium and theme park

••Simulation for training in military/defence, commercial sectors

••Multiwall/command & control for broadcast stations and corporate

••Auditorium presentation for corporate and museum

4. Benefits & Unique Selling Points

••Ultra high resolution projection to clearly show the image details without door effects

observed with DLP projector.

For design review, a designer wants to get closer to the screen but does not want to be

annoyed by the pixel effects.

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

••8.8M pixel native resolution for cost effective, simplified system configuration.

••Quick panel response time

<5 msec panel response time assures a realistic rendering of the precise

image.

••Wide color space for workflow improvement as well as for superb color reproduction

A wide color space of the projector assures the accurate color reproduction. Moreover, its rich tone

of color reproduction helps color confirmation to be done with the projector, eliminating a separate

or review process, such as print-out of the image.

••Installation/system configuration friendly projector

With horizontal/vertical image flip and +/- 90 degree vertical tilting angle, the projector is more

flexible than the predecessor models, and can easily be configured in particular visualization

structure, such as cave. In addition, the new projector GUI SRX-C can control up to 4 projectors

with one PC.

4K view point 2K/HD view point SXGA+ view point

x 1.5 screen height x 3 x 4.3

Invisible pixel view point

4K view point 2K/HD view point SXGA+ view point

x 1.5 screen height x 3 x 4.3

Invisible pixel view point

S X GA SXGA SXGA

4K

1100pixels

2.5meter

6meter

3700pixels

1.9mm/pixel

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

5. Competitive Analysis

Based on its propriety LCOS technology, JVC announced its 4K projector development, and the product

release is expected later this year. This projector is also OEMed to Barco with slight difference in brightness.

The ultra high resolution of the SRX projectors is the biggest factor to attract the customers in high-end

visualization/simulation customers, so that in this section we will discuss comparison between SRX-T105 and

JVC/Barco 4K projectors.

Advantages of Sony 4K SXRD projectors are;

- Higher brightness; 11klm and 5.5klm models

- Compability of variety of signals;

*Barco/JVC projector accepts only progressive signals via DVI-D inputs.

The external signal processor boxes will be separately introduced to cope

with a variety of signals.

- Track record

* More than 350 units of SRX-R1xx/S1xx series have been sold world-wide in

Outside D-cinema market.

6. Product Features

Added to the features and convenient functions from the previous models, the SRX-T110/T105 have further

improvements for better operability of the projectors.

6.1. 8.8 million pixel resolution at 4096 x 2160

Thanks to the SXRD panel technology, a native resolution of 4096 x 2160 pixels can be achieved. The

projectors thus can deliver huge amount of image data on a large screen.

6.2. High brightness and contrast ratio

The newly designed optical unit enables the projectors to achieve the higher brightness and contrast ratio,

compared with the predecessor models. The typical brightness of the new projectors are 11K lumen for

SRX-T110 and 5.5K lm for SRX-T105 while the typical contrast ratio is 2500:1.

6.3. Accurate color reproduction with wide color space

Thanks to the xenon lamp used in the projector, the SRX-T110/T105 have wide color space to assure the

accurate color reproduction, and also offer rich tone of color. To maximize its color reproduction capability,

the projector provides color space selection and gamma curve selection, making it possible to set the

projector conditions properly according to the operation needs.

a. When an input signal to analogue RGB card LKRI-001 or 4:2:2 HD SDI card LKRI-002 is selected;

Color space : sRGB(ITU 709), DCDM, Adobe RGB*

Gamma : 1.8, 2.2, or custom value which is to be manually set from 1.8 to

2.59 by 0.01 value

b. When an input signal to 4:4:4 HD SDI card LKRI-003 is selected;

Color space : sRGB(ITU 709), DCDM, CIE-XYZ

Gamma : 1.8, 2.2, or custom value which is to be manually set from 1.8 to

2.59 by 0.01 value

c. When an input signal to DVI-D card LKRI-004 or LKRI-005 is selected;

Color space : sRGB(ITU 709), DCDM, Adobe RGB

Gamma : 1.8, 2.2, or custom value which is to be manually set from 1.8 to

2.59 by 0.01 value

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

6.4. High Installation flexibility

To meet demands for variety of installation position, the SRX-T110/T105 have wider tilting angle of +/- 90

degrees and horizontal/vertical image flip.

Ex. SRX-T110/T105 SRX-S110/S105

The horizontal/vertical image flip is set on projector control GUI. When the image can be flipped up side

down, an under the floor projection style for cave type system or image table can be made easily.

1. When the projector is tilted at the maximum 90 degree, the projector must be

NOTE

connected to the external duct via the optional duct adaptor LKRA-001.

6.5. Uniformity stability

Uniformity performance is crucial for critical viewing applications, such as design review and post-production.

Sony original PCAT adjustment system makes it possible to conduct precise uniformity calibration, and,

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

what’s more, with the new SRX-T110/T105, the result of the adjustment can be maintained for a long time

with small uniformity shift.

1. Regular adjustment is required to maintain the uniformity performance, and its frequency is

determined according to the application needs. The general recommendations are as follows;

NOTE

- For design review, post-production and multi-wall applications

•Readjustment to be made when a lamp bulb is exchanged.

- For visual simulation, virtual reality and auditorium/hall presentation

•Readjustment to be made every 2nd time when a lamp bulb is exchanged.

*Recommended lamp replacement time:

SRX-T110 = 800 hrs, SRX-T105 = 1000 hrs

The above is Sony recommendation, but it should be better to discuss the end user needs

beforehand and arrange the customized adjustment scheme.

2. For critical viewing applications, PCAT adjustment is required for the initial projector setup and

maintenance. For other applications, it is recommended, but it depends on the customer needs.

3. For details on PCAT adjustment, please consult local Sony Field Support team which received the

training.

6.6. Convenient image projection modes

With more than 4 times of HD resolution, the projector can show up to 4 input signals simultaneously while

keeping the original quality of images. Furthermore, de-squeeze function allows the squeezed image to be

expanded to the original aspect ratio without anamorphic lens.

Multi-display mode

De-squeeze function

Original squeezed signal Aspect ratio After de-squeezed aspect ratio

525/60 4:3 squeeze 16:9

625/50 4:3 squeeze 16:9

1920 x 1080 16:9 squeeze 2.39 : 1

2048 x 1080 1.896:1 squeeze 2.39 : 1

6.7. New DVI-D card with HDCP

Replacing the current DVI-D card LKRI-004, the LKRI-005 is added to a range of optional interface cards.

The new DVI-D card also has the HDCP (High-bandwidth digital content protection) compliance, which

enables a projector to receive an encrypted signal from PS3 and Blue ray disc player.

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

Signal compatibility LKRI-005 vs LKRI-004

Resolution fV

(Hz)

LKRI-005 LKRI-004

1024x768p (XGA)

60

Yes Yes

1280x960p (Quad-VGA) 60 Yes Yes

1280x720p 60 Yes (HDCP) No

1280x720p 50 Yes (HDCP) No

1280 x1024p (SXGA) 60 Yes Yes

1400 x1050p (SXGA+) 60 Yes Yes

1600 x1200p (UXGA) 60 Yes Yes

1920 x1200p (WUXGA) 60 Yes Yes

1920 x1080p (Progressive

HD) 60 Yes (HDCP) Yes (No for HDCP)

1920 x1080p (Progressive

HD) 50 Yes (HDCP) No

1920 x1080p (Progressive

HD) 24 Yes (HDCP) Yes (No for HDCP)

2048 x1080p 60 Yes Yes

2048 x1080p 24 Yes Yes

LKRI-005 PS3 output signal compatibility

PS3 HDMI output

(Encrypted by HDCP) fV

(Hz) LKRI-005

480i

60

No

576i 50 No

480p 60 No

576p 50 No

1280x720p 60 Yes

1280x720p 50 Yes

1920x1080i 60 No

1920x1080i 50 No

1920x1080p 60 Yes

1920x1080p 50 Yes

1920x1080p 24 Yes

1. One piece of the LKRI-005 is installed in INPUT A of the SRX-T110/T105 as standard accessory.

NOTE

2. The LKRI-004 can be used with the SRX-T110/T105 for DVI-D signal connection. However, the

LKRI-005 cannot be used with the SRX-R1xx/S1xx series of projectors.

3. When connected to PS3, HDMI –DVI-D conversion cable is required.

6.8. Lower fan noise

With the new cooling system incorporated, the fan noise is reduced to 59dB for SRX-T110 and 57dB for SRX-

T105.

6.9. Improved chassis for installation convenience

Responding to projector installers’ demands, the projector chassis has been re-designed to more effectively

absorb the stray light from the lamp and optical unit and to have hanger hook holes added for use of crane.

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

6.10. New Projector control software SRX-C

The SRX-T110/T105 comes with the new projector control software SRX-C, with which up to 4 projectors can

be controlled with a single PC. This will help to simplify the system configuration.

6.11. Dual lamp system

The dual lamp system is applied to the projectors for fail safe. Depending on the operation needs, either

dual lamp system or single lamp system with automatic switching can be set. In addition, by changing the

lamp power setting, the brightness can be reduced by almost half of the maximum brightness.

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

6.12. Comparison SRX-T110/T105 vs SRX-S110/S105

SRX-S110/S105 SRX-T110/T105

Brightness

10,000lm +10% (SRX-S110),

5,000lm +10% (SRX-S105)

11,000lm typical (SRX-T110),

5,500lm typical (SRX-T105)

Congtrast ratio >1800:1 (minimum) 2500:1 (typical)

Color space ITU-R BT.709 (100%) sRGB (100%)

DCDM (100%) ITU-R BT.709 (100%)

DCDM (100%)

Adobe RGB (95%)

Mass Approx. 110kg Approx. 120kg

Tilting angle +/-45 degrees +/-90 degrees

Fan noise 64 dB

57-59 dB for SRX-T110,

57dB for SRX-T105

Input terminals

INPUT A : LKRI-004 x 1 fixed,

INPUT B/C/D : Open for option I/F

card

INPUT A : LKRI-005 x 1 installed,

but removal

INPUT B/C/D : Open for option I/F

card

Hanger hook No

Yes

HDCP support No

Yes

Package Cardboard box

Wood palletize package, heavy duty

cardboard box (same as for R2xx

series)

Controllable PJ with

SRX-Control software

1 projector Up to 4 projectors

Service Standard 1-year warranty

Standard 1-year PrimeSupport for

Ads

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

7. Pricing

Please contact your local Sony sales office for current pricing on the SRX-T series projectors and accessories.

1. 2 x lamp house (LKRX-B110 for SRX-T110 and LKRX-B105 for SRX-T105) have to be purchased

together with the SRX-T110 projector body. Xenon bulbs are fitted inside lamp houses as standard.

NOTE

2. Visualization packages include optional SRX-T110 projector body, 2 x LKRX-B110 lamp houses (or

LKRX-B105 for T105), 3 x LKRI-005 DVI-D card plus LKRL-lens (typically LKRL-90 or LKRL-Z115)

8. Marketing Communications

At time of product launch:

20 October week : SRX-T110/T105 brochure completion

27 October week : T Series press release, Product Information on-live in Sonybiz.net, Revised throwing

distance calculator on-live in Sonybiz.net

9. Appendix

9.1. Specifications

Model Name SRX-T110 SRX-T105

Optical Projection system 3 SXRD panels, 1 lens projection system

Projection lens Optional

Lamp

2KW xenon x 2

1KW xenon x 2

Lamp power control 100-51% (7% step)

Recommended lamp

replacement time 800H 1000H

Screen coverage 4.5m to 15.5m screen width on 16:9 screen (200” to 700”

viewable area, measured diagonally on 16:9 screen)

Light output 11,000lm (typical) 5,500lm (typical)

Contrast ratio (all white &

black)

2500:1 (typical)

Signals Color Space sRGB(100%)/ITU-R BT.709(100%), DCDM(100%), Adobe

RGB(95% coverage)

Resolution (pixel counts) 600TV lines (SDI input/SMPTE-259M ITU-R.BT601)

1920 x 1080 pixels (HD-SDI input, SMPTE 292M ITU-R.BT709

BTA-S004)

2048 x 1080 pixels (with LKRI-003, LKRI-004 or LKRI-005)

3840 x 2160 pixels (with 4 pcs of LKRI-003, LKRI-004 or LKRI-

005)

4096 x 2160 pixels (with 4 pcs of LKRI-003, LKRI-004 or LKRI-

005)

Acceptable computer signals (Standard DVI1.0 compliances)

XGA (1024 x 768), SXGA1(1280 x 960), SXGA2(1280 x 1024),

SXGA+(1400 x 1050), UXGA(1600x 1200), HD(1920 x 1080),

2K(2048x 1080), WUXGA(1920 x 1200)

Acceptable video signals SD Component (Y, Cb, Cr)

HD (G, B, R/Y, Pb, Pr)/DC (G, B, R/Y, Pb, Pr/X, Y, Z)

Computer : G, B, R(Analog)

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

General

Dimensions (W x H x D) 740 x 500 x 1320mm (without lens)

Mass Approx. 120kg (excluding the optional lamp houses and lens)

Power requirements AC 200 to 240V, 50/60Hz AC100 to 240V, 50/60Hz

Power consumption 2.9KW-5.4KW 1.9KW-3.0KW

Heat dissipation 18.36KBTU 10.2KBTU

Fan noise 59dB or less (lamp power

>/=86%)

57dB or less (lamp power

<86%)

57dB or less

Tilt angle +/- 90degree

Operating temperature 5 to 35 C degrees

Operating humidity 35 to 85% (no condensation)

Storage temperature -20 to 60C degrees

Storage humidity 10 to 90%

Interfaces

Input A LKRI-005 is pre-installed.

Input B/C/D Open for optional signal interface card

Remote RS232C : D-sub 9 pin (female)

RJ-46 : 10BASE-T/100BASE-TX

Supplied accessories

Remote commander RM-PJ4K (1), Size AA (R8) batteries (2),

SRX-Controller (CD-ROM) (1), Ethernet cable (cross cable

manufactured by Sony: 1-830-803-12) (1), M8 screws for lens

mounting (4), Operating instructions for SRX-T110/T105 and

LKRI-005 (1 each), Operating instructions (CD-ROM), Installation

Manual for dealers (1)

Design and specifications are subject to change.

[Spec page/table]

9.2. Preset signal

Prset signal fH (KHz) fV(Hz) Aspect ratio

VIDEO60 15.73 59.94 4:3

VIDEO50 15.63 50.00 4:3

HDTV 33.75 60.00 16:9

1024x768_VESA60 48.36 60.00 4:3

1024x768_VESA70

56.48

70.07

4:3

1024x768_VESA75 60.02 75.03 4:3

1024x768_VESA85 68.68 85.00 4:3

1280x960_VESA60 60.00 60.00 4:3

1280x1024_VESA60 63.97 60.01 5:4

1280x1024_VESA75 79.98 75.03 5:4

1280x1024_VESA85 91.15 85.02 5:4

1600x1200_VESA60

75.00

60.00

4:3

720/60P 45.00 60.00 16:9

720/50P 37.50 50.00 16:9

1080/48I(24PsF) 27.00 48.00 16:9

1080/50I 28.13 50.00 16:9

1080_24P 27.00 24.00 16:9

DC2048x1080_48P 27.00 48.00

DC2048x1080_24P 27.00 24.00

1400x1050_60P 65.30 60.00 4:3

1920x1080_60P

67.50

60.00

16:9

1920x1200_60P 74.038 60.00

2048x1080_48P 54.00 48.00

2048x1080_60P 67.50 60.00

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

9.3. Displayed image size in multiple screen mode

S

creen mode

Signal Type Single screen Dual screen Quad screen

H.size

V.size

H.size

V.size

H.size

V.size

VIDEO60 2880 2156 2003 1499 1440 1078

VIDEO50 2880 2146 2003 1504 1440 1073

XGA 2849 2137 2048 1536 1432 1074

SXGA1 2560 2048 2048 1638 1280 1024

SXGA2 2560 1920 2048 1536 1280 960

SXGA+ 2800 2100 1400 1050 1400 1050

UXGA

1

2864 2148 1600 1200 - -

WUXGA

1

3437 2148 1920 1200 - -

720p 3810 2143 2048 1152 1916 1077

HD 3840 2160 1920 1080 1920 1080

2K 4096 2160 2048 1080 2048 1080

4K 4096 2160 - - - -

1. When projecting signals with vertical frequency of more than 1080 pixels such as UXGA and WUXGA

in quad-screen mode, a part of the displayed image may be lost.

NOTE

9.4. External Dimensions

Front

Side

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

Top

9.5. Mounting platform Dimensions

It is recommended to use a platform when the projector is placed at steep angle. The below is

recommended sample of such a platform.

Material

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

Mounting platform: SECC, 3.2mm (5/32 inch) thickness

Bolt: SWCH M6 x 12mm (1/2inch) (for the mounting platform with 3.2mm (5/32 inch) thickness)

NOTE

1. The mounting platform is symmetric with respect with a point.

2. Holes other thanΦ8 are clearance holes for the projector.

3. Use M6 washers and spring washers for the M6 bolts (x 12) when fixing the projector.

Mounting Platform Dimensions

Unit : mm(inches)

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

9.6. Preparation for installation

Required clearance around the projector

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

NOTE

1. When a lamp explodes, its fragments will possibly come out from the ventilation holes. For sake of

safety, the minimum 2m of clearance area as above is required. If such a area cannot be secured,

make sure that LKRA-001 is used to have the projector connected to the external exhaust duct.

Angle projection

When the projector is installed at +/- 90 degrees as in the below illustration, attach a mounting platform to

the projector, which can move the projector to 0 degree angle.

NOTE

1. When the projector is installed at +/- 90 degrees, connect the projector to the external exhaust duct

with the optional LKRA-001. When attaching the adaptor, be sure to provide enough room for

smooth exhaust flow and take care not to bend the duct.

9.7. Throwing distance

A : Distance between the floor and the feet of the projector

A=B-310mm

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

B : Distance between the floor and the center of screen

The alphabetical characters in the following tables indicate the below measurements;

W : Screen width (mm)

L(min) : Minimum distance between the center of lens and screen

L(max) : Maximum distance between the center of lens and screen

H : Screen height (different depending on the aspect ratio of the projected

image)

9.7.1 Using LKRL-Z115 lens

9.7.2 Using LKRL-90 lens

When projecting a horizonal 4096-pixel image Unit: mm

W4500 5000 6000 7000 8000 9000 10000 12000 14000 16000

L (min) 6554 7295 8778 10261 11743 13226 14709 17674 20639 23605

L (max) 8056 8964 10780 12596 14412 16228 18044 21676 25308 28940

H1* 2373 2637 3164 3691 4219 4746 5273 8328 7383 8438

H2** 1883 2092 2510 2929 3347 3766 4184 5021 5858 6695

mm:

L(min)=(W-79.675)/0.67446 L(max)=(W-63.762)/0.55067

H1=W x 0.52730 H2=W x 0.41840

* : Screen height when projecting a4096x 2160-pixel (4K single screen) image on the screen

** : Screen height when projecting a 4096 x 1714-pixel (aspect ratio 2.39:1) imageon the screen

When projecting a horizonal 3840-pixel image Unit: mm

W4500 5000 6000 7000 8000 9000 10000 12000 14000 16000

L (min) 7001 7791 9373 10955 12537 14118 15700 18863 22027 25190

L (max) 8600 9568 11505 13442 15379 17316 19253 23127 27000 30874

H1* 2531 2813 3375 3938 4500 5063 5625 6750 7875 9000

H2** 2432 2703 3243 3784 4324 4865 5405 6486 7568 8649

mm:

L(min)=(W-73.944)/0.63223 L(max)=(W-59.873)/0.51629

H1=W x 0.56250 H2=W x 0.54050

* : Screen height when projecting a3840x 2160-pixel (aspect ratio 16:9) image on the screen

** : Screen height when projecting a 3996x2160-pixel (aspect ratio1.85:1) image on thescreen

When projecting a horizonal 2880-pixel oraspect ratio 4:3 image Unit: mm

W3500 4000 4500 5000 6000 7000 8000 9000 10000 12000

L (min) 7271 8326 9381 10436 12547 14657 16767 18878 20988 25208

L (max) 8922 10213 11504 12795 15377 17959 20541 23123 25705 30869

H1 2625 3000 3375 3750 4500 5250 6000 6750 7500 9000

mm:

L(min)=(W-73.944)/0.63223 L(max)=(W-59.873)/0.51629

* : Screen height when projecting a3840x 2160-pixel (aspect ratio 16:9) image on the screen

** : Screen height when projecting a 3996x2160-pixel (aspect ratio1.85:1) image on thescreen

When projecting a horizonal 3840-pixel image Unit: mm

W1730 2200 3300 4400 5600 8000 10000 11100 13300 15500

L1561 2016 3081 4145 5306 7629 9564 10629 12758 14887

H1* 973 1238 1856 2475 3150 4500 5625 6244 7481 8719

H2** 935 1189 1784 2378 3027 4324 5405 6000 7189 8378

mm:

L=(W-116.65)/1.0334 0.5405

H1=W x 0.56250 H2=W x 0.54050

* : Screen height when projecting a3840x 2160-pixel (aspect ratio 16:9) image on the screen

** : Screen height when projecting a 3996x2160-pixel (aspect ratio1.85:1) image on thescreen

When projecting a horizonal 2880-pixel oraspect ratio 4:3 image Unit: mm

W1300 1630 2040 3050 4070 6100 7100 8200 10200 12200

L1571 1997 2527 3831 5149 7772 9064 10485 13069 15653

H975 1223 1530 2288 3053 4575 5325 6150 7650 9150

mm:

L=(W-73.944)/0.63223

* : Screen height when projecting a3840x 2160-pixel (aspect ratio 16:9) image on the screen

** : Screen height when projecting a 3996x2160-pixel (aspect ratio1.85:1) image on thescreen

When projecting a horizonal 4096-pixel image Unit: mm

W1845 2350 3500 4700 5900 8200 10600 11800 14100 16400

L1560 2018 3061 4150 5239 7325 9503 10591 12678 14765

H1* 973 1239 1846 2479 3111 4324 5590 6223 7436 8648

H2** 772 983 1464 1966 2469 3431 4435 4937 5899 6862

mm:

L=(W-125.52)/1.1023

H1=W x 0.52730 H2=W x 0.41840

* : Screen height when projecting a4096x 2160-pixel (4K single screen) image on the screen

** : Screen height when projecting a 4096 x 1714-pixel (aspect ratio 2.39:1) image on the screen

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

9.8. Optional Accessories

Lamp house

LKRX-B110 2KW xenon lamp house with lamp bulb for SRX-T110

LKRX-B105 1KW xenon lamp house with lamp bulb for SRX-T105

Lamp bulb

LKRX-110 2KW xenon lamp bulb for LKRX-B110

LKRX-105 1KW xenon lamp bulb for LKRX-B105

Optional lens

LKRL-90 0.9x fixed focal length projection lens

LKRL-Z115 1.48 to 1.81x zoom lens

LKRL-Z117 1.72 to 2.39x zoom lens

LKRL-Z119 1.81 to 2.94x zoom lens

LKRL-Z122 2.33 to 3.96x zoom lens

LKRL-Z140 3.81 to 7.12x zoom lens

Optional interface card

LKRI-001 Analog input card

LKRI-002 4:2:2 HD-SDI input card

LKRI-003 Dual-link HD-SDI input card

LKRI-004 DVID interface card

LKRI-005 HDCP DVI-D interface card

Optional exhaust duct adaptor

LKRA-001 8-inch exhaust duct adaptor

[Different models if applicable, list of accessories.]

9.9. PrimeSupport

A 1-year prime support will be added to the SRX-T110/T105 as standard accessory. This is not for an end

user, but for a dealer involved in a deal. The table below shows the detailed conditions for the programme;

·······································································································································································································

Sony Product Information

Category: [SXRD]

Product: [SRX-T110/T105]

Dealer support programme

- Back to back support to dealers -

Registration to be made by dealers, not by end-user

Terms/conditions

- 1-year standard. Extention to be arranged as

option(charged) -

Coverage EU region only.

*A dealer can specify the destination of parts when needed.

However, it cannot be guaranteed to make quick delivery to

most CEMA countries, and he/she will have to take care of

importation formalities.

Advance parts inventory in EuroHub

- PJ and LKRI-005 -

Field replaceable items only (excl, lamp bulb, lamp house,

chassis)

- Next biz day delivery (best effort) except for CEMA regions

Telephone help desk

- 2nd line expert advice in English & German to dealers (5

days/office hour)

NOTE

1. A dealer is supposed to make the service work on a projector at the customer site as SXRD

accreditation programme includes service training. If the involvement of Sony service personnel or

service training to Non SXRD PJ accredit dealer is required, please contact the nearest Sony office.

The customized service programme could be separately arranged on a charged basis.

2. For outside EU region, the customized service programme can be prepared on a charged basis.

Please contact the nearest Sony office for further discussion.

Sony SRX-T110 Reference manual

Popular Projector manuals by other brands
