HP MP120 User manual

User
Manual
MP120
Support
For further information, download the HP MP120 User
Guide from: https://www.hp.com/support
Global Aiptek Inc. - HP Branded Product Group
1020 Milwaukee Ave, Suite 270, Deereld, IL 60015, USA
Email: [email protected]
Web: www.hp-projector.com
Mobile Projector

User Manual
1
•MP120 Mobile Projector
•Power Adapter
•Tripod
•Quick Start Guide
•Warranty Card
Package Contents
Knowing your Mobile Projector
Volume Down
LED Indicator
DC IN
Volume Up
Focus Ring
Projection Lens
Power
Brightness
Adjustment
Service Use
Vents
Tripod Socket
Speaker
Earphone /
AUX Jack
Reset Hole
HDMI Output
Connector
HDMI Input
Connector
EN

User Manual
2
The battery will be charged only when the projector is not in use (Power off).
Connect one end of the supplied power adapter to DC IN jack and the other end to
a power outlet to start charging.
During charge, the LED indicator lights will ash intermittently. When the battery
is fully charged, the LED indicator lights appears solid blue.
• Push the Power button for 2 seconds to turn on the projector.
• Push the Power button again for 3 seconds to turn off the projector.
• Standby mode: Push the Power button for 1 second to turn on / off the projector
light to save the battery and system reboot time. (The LEDs are still on when the
projector is in standby mode.)
The projector is built with an
embedded battery for mobile use.
Please charge the projector for 5
hours prior to its rst use. Repeat
charging will take around 3 hours.
Charging the product
Charging LED Indicator
LED indicators
Power On / Off / Standby
Getting Started
3 blue LEDs stay on Power capacity is between 60% to 100%
2 blue LEDs stay on Power capacity is between 35% to 60%
1 blue LED stays on Power capacity is between 10% to 35%
Power capacity is below 10%, LED will
blink for 10 secs then turn off.
LED Marquee Projector is being charged
LED Status Indication
1 blue LED blinks
EN

User Manual
3
Place the projector on a at surface and
toward a wall or a projection screen. Adjust
the focus by turning the focus ring forward
or back until you see a sharp and clear
image.
Adjusting the Focus
Note: Use a tripod to increase the height of the projection image when necessary.
The tripod socket is located under the projector.
There is a brightness adjustment button on the top of the projector. It allows you
to change the brightness.
Adjusting the brightness
Power on the projector, the following screen will appear after the projector boots up.
For rst-time use, please install the EZCast app rst, on your PC or smartphone.
Main Screen
(HDMI mode)
Mode
Normal
Eco
Brightness Battery Power
High 80 mins
120 mins
http://www.iezvu.com/download
Low
EN

User Manual
4
1.Tap Setting -> WiFi to connect iPhone to Projector-xxxxxxxx shown on
the top of projection screen.
2.Swipe up from the bottom bezel of the screen on your iOS device to bring up
Control Center.
Wireless projection via Airplay (iOS10)
3.Tap on “AirPlay Mirroring” then choose “ Projector-xxxxxxxx”.
4.After connecting, the screen will begin mirror projection .
*All iOS devices can project via the EZCast APP, the same applies fo Android devices.
5.During projection, the phone can only access the internet using mobile data on
3G/4G network. Alternatively, you can use the projector to link to a Wi-Fi network
for internet access.
6.To connect the projector to a wireless network for internet access during mirror
projection. Tap shown on the EZCast screen in the left top corner, Then, tap
"Settings" and use the keypad displayed on the mobile device to connect the projector
to an available wireless network.
EN

User Manual
5
EZCast is a mobile application that runs on your Android device (or iOS) and transmits
still images or videos to the projector. The EZCast app is only required for a wireless
connection to mirror the screen and audio on your smartphone.
Projecting from the mobile app on Android devices
For detailed information, please refer to the section, Connecting the projector to
Wi-Fi network for Internet access (page 8), further in this guide.
1.Download and install the free EZCast app. Refer to the section Main Screen(page 3)
for more details.
2.Run EZCast after installation then click shown on screen in right top corner to
search for projector.
3.Choose WiFi Projector (Name as SSID shown on the top of projection screen) and
enter the Login password shown on the projector screen as well. After connecting
to the projector , a blue connection icon will be shown on projection screen in the
top right corner.
4.You can also connect the projector to a wireless network to support mirror projection
and access the internet on Wi-Fi. To do this, tap shown on the EZCast screen
in the top left corner, tap "Settings" and use the keypad displayed to connect
the projector to an available wireless network.
EN

User Manual
6
EZMirror projection for Android MiraCast devices
For detailed information, please refer to the section, Connecting the projector to
Wi-Fi network for Internet access (page 8).
5.After connecting, tap “ Mirror ”to mirror screen to projector. For EZCast user manual,
please refer to: http://www.iezvu.com/os_help.php
EZMirror is the function within the EZCast app and is fully compatible with Miracast,
you can click the EZMirror button in EZCast to Miracast mode.
2.Tap “ON” button shown on the screen. Once you turn it on, there is a 60 second
countdown for your device to connect with the projector. Please enable the Miracast
function in your device as well.
1.Link with Projector-xxxxxxxx in Wi-Fi settings of your Android device. Then open
EZCast app, click <EZMirror> icon from the menu . The projected screen will
turn into the EZMirror screen.
EN

User Manual
7
Wireless projection from computer
3.Upon Miracast connection, the screen will be mirrored on the projector.
Note: Depending on how you setup your connection, access to the internet on
your device will be via Wi-Fi or mobile internet 3G/4G.
1. Connect the computer to an available network for Internet access.
2. Open the Internet browser on your computer then enter the IP Address
http://www.iezvu.com/download in the browser’s address bar.
3. Select the driver for Windows or Mac OS depending on your operating system
and then click <Download> to enter the download page. Follow on-Screen
instructions to complete the setup and reboot the computer.
4. When the installation completes, an icon labeled EZCast will appear on
your desktop screen.
5. Power on the projector and enter the main screen.
6.Connect your computer to the projector Wireless network by selecting
SSID: Projector-XXXXXXXX on the network list, enter the Password
shown on the top of projection main screen and click <OK> to conrm.
EN

7.Double-click EZCast icon on your computer desktop to start the application
then click . When the screen displays available projectors,
"Projector-xxxxxxxx", double-click it to connect to the projector.
User Manual
8
Connect the projector to Wi-Fi network for Internet access
In order to use your computer, tablet and smartphone at the sametime, it is recommended
that you connect the projector to a Wi-Fi network. You only need to input the network
key to set up the connection the rst time.Subsequent use of the projector will
automatically connect to the network when it is powered on .
8.Click“Mirror” to select the projection output method from Off (default) to
Mirror or Extension to start the wireless projection.
1.Go to Setting menu, select and enter ‘Internet’.
2.Select the Wi-Fi network (SSID) you would like to connect to and conrm
with OK button.
EN

User Manual
9
3. If wireless security is enabled on the Wi-Fi network, please input the password
(network key) by using the virtual keyboard on your smartphone or your computer.
4. Click OK to complete set up. It will take a while till the connection is successfully
established. In the home screen you will see the connection status in the top
right corner.
5. After the projector is connected to a Wi-Fi network, please close the APP on
your smartphone / computer. Next, please connect your smartphone to the
same Wi-Fi network and open the APP again using the serach button to connect
to the projector again.
Note:Internet access performance is affected by various factors such as physical objects,
distance, interference from other devices on similar frequencies, limited bandwidth etc. If the
internet speed drops or intermittently disconnects during projection, we recommend you to
select another access point with a stronger signal or disable internet access to ensure the
best experience for wireless projection.
