Christie LW40U User manual

Native Widescreen Projector Offers
Ideal Display for 16:9 and XGA Images
Christie's LW40U is the new benchmark for native widescreen
displays and the ultimate in video presentation.
With a true 16:9 aspect ratio and the visual power of 4000 lumens,
the LW40U displays native HD content in its purest form and expands
the capability of your presentations. Images have the “impact” factor
of widescreen format without compromising image area or screen
brightness.
The native WXGA panel provides 44% more pixels on the screen
than an XGA resolution projector displaying 16:9 content. When
displaying computer or data presentations, the image can be
centered on the screen in pixel-perfect XGA (1024x768) mode
without changing the zoom lens or cropping the image mode.
The latest 3D digital video processing produces sharp video images
from analog and digital sources. A 90% brightness uniformity and a
900:1 contract ratio take your images to a higher level of presentation.
The dual lamp design gives you the confidence of guaranteed
performance. The LW40U provides the option of projecting the full
4000 ANSI lumens for bright, large screen images or 2,400 ANSI lumens
in single-lamp mode, to extend the life of the lamp.
Feature-rich and supported by a full suite of optional lenses and
accessories for the ultimate presentation flexibility and control, the
LW40U is compatible with Christie's Real Color Management (RCM)
software. Users can target and match the displayed color to specific
gamma curves and reference monitors for picture-perfect presentation
and real-life images.
Compatible with a broad spectrum of analog and digital video and
data inputs with a range of optional interface cards including DVI-D,
SDI and HD-SDI formats to interface perfectly with the latest source
players and receivers. Network connectivity is available through
ChristieNET ™to attach the LW40U to any network to monitor lamp
life, projector temperature and other vital functions for full control
and monitoring for preventative maintenance in real time.
• True WXGA resolution (1366 x 768)
• 4000 ANSI lumens maximum
• DTV & HDTV compatible
• Progressive scan video decoding
• Motorized zoom, focus & lens shift (up/down)
• 2 lamp system - dual or single lamp operation
• Lamp redundancy and failsafe operation
• Monitor lamp usage
• Extensive optional lens suite
• Presentation support features
APPLICATIONS
• Boardrooms,
conference rooms
• Training rooms,
classrooms
• Auditoriums and
churches
• Casinos, theme parks
and museums

Copyright 2003 Christie Digital Systems, Inc. All rights reserved. All brand names and product names are trademarks,
registered trademarks or tradenames of their respective holders. MIL6084 Due to constant research, specifications and
features are subject to change without notice.
Oct 03-NA
Brightness
•4000 ANSI lumens (2-lamp mode)
•2400 ANSI lumens (1-lamp mode)
•85% brightness uniformity
Contrast Ratio
•Over 900:1 on/off
Resolution
•3 x 1.2" p-Si Active Matrix TFT High Aperture
LCD panels with Micro Lens Array
•True WXGA 1366 x 768 chip resolution
•8-bit color resolution offering 16.7 million
displayable colors
Dynamic Scaling
•Digital scaling of VGA - SXGA resolutions
•Digital de-interlacing of STV, DTV and HDTV
formats with Digital Interpolation Technology
(DIT) automatic with 2:3 pull-down
Horizontal Frequency
•15 to 120 kHz
•Automatic frequency control
Vertical Freqency
•50 to 120 Hz
•Automatic frequency control
Dot Clock
•230MHz
Standard Projection Lens
•A full suite of short/medium/long fixed and
zoom optional lenses
•Power adjustable zoom, focus, up/down,
lens shift
•Power lens shift U/D ratio of up to
10:0-0:10
•Image elevation adjustment: up 6.9 degrees
•Screen size 40" - 600" (0.15 m to 15.24 m )
diagonal
Modular Inputs
•Input 1 (removable):
•Analog RGB, (15-pin D-sub), audio input
(2 x RCA-R, L/mono),(Control - 8-pin
mini-DIN x1)
•Input 2 (removable):
•Analog RGB with 5 BNC for RGBHV, YpbPr
and YcbCr, audio input (2x RCA–R,L /mono),
Control (8-pin mini-DIN x 1)
•Input 3 (removable):
•Composite (2 x BNC), S-video, Y,C (4-pin mini-
DIN), audio – (2 x RCA -R, L/mono)
Outputs
•Two built-in 3W speakers (per channel)
and amplifier
•Audio output RCA x 2
Source Compatibility
•Compatible with VGA, SVGA, XGA, WXGA,
SXGA, UXGA and MAC sources
•Accepts Composite Video, S-Video and
component video from VCR, DVD, Laser Disc
players and video cameras
•Auto-detects PAL, PAL M, PAL N, NTSC,
NTSC4.43 and SECAM video standards
•Compatible with DTV/HDTV formats, 480 30i,
480 30p, 720p, 720 60p, 1035 30i, 1080 25i
and 1080 30i and 1035i
•HDTV compatible, 800 TV lines horizontal
resolution
•Digital Visual Interface (DVI-D) compatible
Enhanced Feature Set
•Progressive scan video decoding
•3-D digital noise reduction
•2-lamp or 1-lamp mode, user-selectable
from menu
•Motorized zoom and focus
•Motorized lens shift (up and down)
•Digital zoom function (max. x49)
•Digital keystone function (+/- 30 degrees)
•Power management function
Control/Networking
•Automatic Multi-Scanning Set-up System
(AMSS) (phase/tracking/position)
•USB Type B
•Remote control jack
•RS232-C communications port via 9-pin
D-sub terminal (in/out)
•Wire remote control
•IR remote keypad with mouse and laser
pointer
•Front and rear IR receivers
•Remote mouse control
•ChristieNET™control and monitoring via
HTML and SNMP (optional)
Graphical User Interface
•Easy set-up and intuitive multi-language on
screen displays (OSD)
(English/German/French/Spanish/Italian/
Portuguese/Dutch/Swedish/Chinese/Korean/
Japanese)
•Direct key status function
•Choice of image aspect ratios (native 16:9
and 4:3)
•Blue back display
•Standby on-screen logo display
•Picture reverse scans function (left/right and
top/bottom) for front, rear and inverted
projection
Lamp Specification
•Two 265W UHP lamps
•1000 hours lamp life at maximum brightness
•Lamp life warning indicators
•User replaceable lamp
Power Requirements
•Universal power AC 100 - 240V, 50/60Hz
•Operating voltage: 90-264V (100-120V/
200-240V +/- 10%)
•Power consumption: 660 W maximum
•Thermal dissipation: 2700 BTU/hr
•Operating temperature: 5 to 35º
(storage: -10 to 60º)
•Operating humidity: 20 - 80%
(storage 0 - 90%)
•Acoustic noise level: 45dBA (Auto fan control
for noise level reduction)
Weight and Size
•45.2 lbs (20.5 kg)
•17.3" (W) x 8.9" (H) x 23.8" (D)
•439mm (W) x 230mm (H) x 605mm (D)
Standard Accessories
•Real Color Manager (RCM) user-definable
gamma software
•Wireless/wired remote controller with mouse
control and laser pointer (two "AA" type
batteries and cable included)
•User manual
•Computer cable (D-sub-15 – D-sub-15)
•Mac/VGA adapter
•Mouse control cable (PS/2, Serial and MAC)
•Dust cover
•AC cord x 2 (UL and European)
Optional Accessories
•Fixed lenses: 1.2:1, 1.8:1 and 10.3:1
•Zoom lenses: 2.0-2.65:1, 2.95-3.85:1, 3.85-
5.2:1, 5.2-6.8:1, 6.8-8.8:1 zoom lens
•Digital Visual Interface (DVI) module
•5BNC interface module
•Y/C video interface module
•D-sub-15 interface module
•Digital HD-SDI interface module
•SDI digital interface module [tbd – needs new
electronics from L6/LX65]
•10-bit Faroudja ®interface module
•Lamp module
•Shipping case
Regulatory Approvals
•Complies with all relevant world-wide EMC
and safety standards
•The product complies with FCC class A, CE
mark and safety requirements IEC950
(EN60950), UL1950 / cUL
Warranty
•Product warranty, 3 years parts and labor
(excluding lamp)
Reliability
•Mean time between failure (MTBF) over
28,000 hrs
LW40U • 38-VIV210-02
For Boardrooms, Conference Rooms, Classrooms, Training Rooms
FEATURES
WWW.CHRISTIEDIGITAL.COM
Corporate Offices
USA
10550 Camden Drive
Cypress, CA 90630
PH: 714-236-8610
FX: 714-503-3385
Toll free: [phone] (NA only)
[email protected]
CANADA
809 Wellington Street North
Kitchener, Ontario N2G 4Y7
PH: 519-744-8005
FX: 519-749-3136
Toll free: [phone] (NA only)
[email protected]
Branch Offices
UNITED KINGDOM
PH: [phone]
FX: [phone]
[email protected]
SINGAPORE
PH: [phone]
FX: [phone]
[email protected]
FRANCE
PH: [phone]
FX: [phone]
Mobile: [phone]
[email protected]
GERMANY
PH: [phone]
FX: [phone]
[email protected]
CHINA-Shanghai
PH: [phone]
FX: [phone]
[email protected]
CHINA-Beijing
PH: [phone]
FX: [phone]
[email protected]
Designed under ISO 9001
•ChristieNETTM attaches the LW40U to
any network for monitoring and
control of vital projector functions.
•With 44% more pixels than an XGA projector
displaying 16:9 content, the LW40U provides
higher pixel density and a smoother image.
•The LW40U offers flexibility in
brightness and lamp life with dual
UHP lamps.
