SERVICE MANUAL
DVD DECK RECEIVER
US Model
Canadian Model
AEP Nodel
UK Model
E Model
SPECIFICATIONS
HCD-FL7D
Ver 1.3 2003.10
9-874-113-04 Sony Corporation
2003J05-1 Home Audio Company
C2003.10 Published by Sony Engineering Corporation
– Continued on next page –
HCD-FL7D is the amplifier, CD player,
tape deck and tuner section in DHC-FL7D.
AUDIO POWER SPECIFICATION:
(USA model only)
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION
with 8 ohm loads both channels driven, from
120 Hz – 10 kHz; rates 60 watts per channel
minimum RMS power, with no more than 10%
total harmonic distortion from 250 milliwatts to
rated output.
Continuous RMS power output
Center speaker: 60 watts
(16 ohms at 1 kHz, 10%
THD)
Rear speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Sub woofer: 120 watts
(8 ohms at 100 Hz, 10%
THD)
Amplifier section
Canadian model:
Continuous RMS power output (reference)
Front speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Center speaker: 60 watts
(16 ohms at 1 kHz, 10%
THD)
Rear speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Sub woofer: 120 watts
(8 ohms at 100 Hz, 10%
THD)
Total harmonic distortion less than 0.07%
(8 ohms at 1 kHz,
35 watts)
European model:
DIN power output at stereo mode (rated)
45 + 45 watts
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
Front speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Center speaker: 60 watts
(16 ohms at 1 kHz, 10%
THD)
Rear speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Sub woofer: 120 watts
(8 ohms at 100 Hz, 10%
THD)
Music power output (reference)
Front speaker: 120 + 120 watts
(8 ohms at 1 kHz, 10%
THD)
Center speaker: 120 watts
(16 ohms at 1 kHz, 10%
THD)
Rear speaker: 120 + 120 watts
(8 ohms at 1 kHz, 10%
THD)
Sub woofer: 240 watts
(8 ohms at 100 Hz, 10%
THD)
Model Name Using Similar Mechanism NEW
DVD DVD Mechanism Type CDM53N-DVBU14
Section Base Unit Name DVBU14
Optical Traverse Unit Name DBU-1
TAPE Model Name Using Similar Mechanism NEW
Section Tape Transport Mechanism Type TCM-230AWR41CS
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2
HCD-FL7D
Other models:
The following measured at AC 127, 220, 240 V,
50/60 Hz (Saudi Arabian model only)
The following measured at AC 120, 220, 240 V,
50/60 Hz (except for Saudi Arabian model)
MULTI mode
DIN power output at stereo mode (rated)
45 + 45 watts
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
Front speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Center speaker: 60 watts
(16 ohms at 1 kHz, 10%
THD)
Rear speaker: 60 + 60 watts
(8 ohms at 1 kHz, 10%
THD)
Sub woofer: 100 watts
(8 ohms at 100 Hz, 10%
THD)
2.1CH mode
DIN power output at stereo mode (rated)
70 + 70 watts
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
Front speaker: 120 + 120 watts
(8 ohms at 1 kHz, 10%
THD)
Sub woofer: 240 watts
(8 ohms at 100 Hz, 10%
THD)
Inputs
VIDEO (MD) IN (North American model only):
(phono jacks) voltage 250 mV/450mV
impedence 47 kilohms
MD (VIDEO) IN (other models):
(phono jacks) voltage 450 mV/250 mV,
impedance 47 kilohms
OPTICAL DIGITAL IN:
(Square optical connector jacks, rear panel)
wavelength ——
MIC: sensitivity 1 mV,
(phone jack) impedance 10 kilohms
Outputs
VIDEO (MD) OUT (North American model only) or
MD (VIDEO) OUT (other models):
(phono jacks) voltage 250 mV
impedance 1 kilohms
VIDEO OUT: 1 Vp-p, 75 ohms
S-VIDEO OUT: Y: 1 Vp-p, 75 ohms
C: 0.286Vp-p, 75 ohms
COMPONENT OUT: Y: 1 Vp-p, 75 ohm
P
B
: 0.7 Vp-p, 75 ohms
P
R
: 0.7 Vp-p, 75 ohms
PHONES: accepts headphones of
(stereo mini jack) 8 ohms or more
FRONT L/R: Use only the supplied
speaker SS-FL7
REAR L/R: Use only the supplied
speaker SS-RS7
CENTER: Use only the supplied
speaker SS-CT7
S.WOOFER: Use only the supplied
speaker SS-WG7
DVD player section
Laser Semiconductor laser
(DVD: λ=650 nm,
CD: λ=780 nm)
Emission duration:
continuous
Frequency response DVD (PCM 48 kHz):
2 Hz – 22 kHz = (±1 dB)
CD: 2 Hz – 20 kHz =
(±1 dB)
Signal-to-noise ratio More than 90 dB
Dynamic range More than 90 dB
Video color system format NTSC, PAL
OPTICAL DVD DIGITAL OUT
(Square optical connector jack, rear panel)
wavelength 660 nm
Tape player section
Recording system 4-track 2-channel stereo
Frequency response 50 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassette
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
North American model: 87.5 - 108.0 MHz
(100-kHz step)
Other models: 87.5 - 108.0 MHz
(50-kHz step)
Antenna FM lead antenna
Antenna terminals 75 ohm unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Pan American model: 530 - 1,710 kHz
(with the tuning interval
set at 10 kHz)
531 - 1,710 kHz
(with the tuning interval
set at 9 kHz)
European, Saudi Arabian models:
531 - 1,602 kHz
(with the tuning interval
set at 9 kHz)
Other models: 530 - 1,710 kHz
(with the tuning interval
set at 10 kHz)
531 - 1,602 kHz
(with the tuning interval
set at 9 kHz)
Antenna AM loop antenna
Antenna terminals External antenna terminal
Intermediate frequency 450 kHz
General
Power requirements
North American model: 120 V AC, 60 Hz
European model: 230 V AC, 50/60 Hz
Saudi Arabian model: 120 –127 V, 220 V or
230 – 240 V AC,
50/60 Hz
Adjustable with voltage
selector
Korean model: 220 V AC, 60 Hz
Mexican model: 120 V AC, 60 Hz
Other models: 120 V, 220 V or
230 – 240 V AC,
50/60 Hz
Adjustable with voltage
selector
Power consumption
North American model: 325 watts
Canadian model: 325 watts
European model: 325 watts
0.3 watts (at the Power
Saving Mode)
Other models: 425 watts
Dimensions (w/h/d)
Approx. 245 ×410 ×400 mm
Mass
North American and European models:
Approx. 14 kg
Other models: Approx. 15 kg
Supplied accessories: AM loop antenna (1)
FM lead antenna (1)
Remote commander (1)
Batteries (3)
Video cable (1)
Speaker cord (6)
Speaker support (2)
Screw 33 ×10 (8)
Stand (2 for U.S.A.
model only)
Center and rear speaker
pads (12)
Design and specifications are subject to change
without notice.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

3
HCD-FL7D
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270 ˚C dur-
ing repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED
LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
The following caution label is located inside the apparatus.
This appliance is classified as
a CLASS 1 LASER product.
The CLASS 1 LASER
PRODUCT MARKING is
located on the rear exterior.
SAFETY CHECK-OUT
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operatedAC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit” indica-
tion is 0.75 V, so analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa SH-63Trd are ex-
amples of a passive VOM that is suitable. Nearly all battery
operated digital multimeters that have a 2VAC range are suit-
able. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
1.5 k Ω 0.15 µFAC
voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

4
HCD-FL7D
This system can play the
following discs
Format of discs Disc logo
DVD VIDEO*
Super Audio CD
VIDEO CD
Music CD
*The “DVD VIDEO” logo is a trademark.
Discs that this system
cannot play
•CD-ROMs (PHOTO CDs included)
•All CD-Rs other than music and VCD format
CD-Rs
•Data part of CD-Extras
•DVD-ROMs
•DVD Audio discs
Note
Some CD-Rs/CD-RWs or DVD-Rs/DVD-RWs
cannot be played on this system depending upon the
format or the recording quality or physical condition
of the disc, or the characteristics of the recording
device.
Furthermore, the disc will not play if it has not been
correctly finalized. For more information, see the
operating instructions for the recording device.
Playing a disc with MP3
audio tracks
About MP3
MP3 (MPEG 1 Audio Layer-3) is a standard
technology and format for compressing a sound
sequence. The track is compressed to about
1/10 of its original size. Sounds outside the
range of human hearing are compressed while
the sounds we can hear are not compressed.
Noteson discs
You can play MP3 audio tracks recorded on CD-
ROMs, CD-Rs (recordable CDs), or CD-RWs
(rewritable CDs).
The disc must be in the ISO 9660* level 1, level 2 or
Joliet format.
*ISO 9660 Format
The most common international standard for the
logical format of tracks and albums on a CD-ROM.
There are several specification levels. In Level 1,
track names must be in the 8.3 format (no more than
eight characters in the name, no more than three
characters in the extension “.MP3”) and in capital
letters. Album names can be no longer than eight
characters. There can be no more than eight nested
album levels. Level 2 specifications allow album
names and track names up to 31 characters long.
Notes
•With formats other than ISO 9660 level 1, 2 and
Joliet, album names or track names may not be
displayed correctly.
•When naming, be sure to add the extension “.MP3”
to the track name.
•If you use the extension “.MP3” to a track other
than MP3, the player cannot recognize the track
properly and will generate random noise that could
damage your speakers.
•Adisc recorded with complicated tree structure
takes a longer time to start playback.
•When the disc is inserted, the player reads all the
tracks on that disc. If there are many albums or non-
MP3 files on the disc, it may take a long time for
player to begin or for the next MP3 audio tracks to
start play.
•We recommend that you do not save other types of
tracks or unnecessary albums than MP3 audio
tracks in the disc to be used for MP3 listening.
•An album that does not include an MP3 audio track
is skipped.
•Maximum album number in a disc: 99
(The maximum number of MP3 audio tracks that
can be contained on a album is 250.)
•Tracks and albums are played in the order they are
recorded on the disc.
•Only the letters in the alphabet and numbers can be
used for album or track names. Anything else is
displayed as a space.
•ID3 tags cannot be displayed in stop mode.
•The player cannot play audio tracks in MP3PRO
format.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

5
HCD-FL7D
TABLE OF CONTENTS
1. SERVICING NOTES ................................................ 7
2. GENERAL
Location of Controls ....................................................... 9
Setting the Clock............................................................. 10
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 11
3-2. Top Panel Assy ................................................................ 12
3-3. Back Cover ...................................................................... 12
3-4. Side Panel (A)/(B)........................................................... 13
3-5. Case ................................................................................. 13
3-6. Front Panel Assy ............................................................. 14
3-7. GC Board......................................................................... 14
3-8. Tape Mechanism Assy .................................................... 15
3-9. Belt .................................................................................. 15
3-10. SW Board, HEAD (A) Board, HEAD (B) Board .......... 16
3-11. DVD Mechanism Block .................................................. 16
3-12. DSP Board....................................................................... 17
3-13. DVD Mechanism Deck (CDM53N-DVBU14) .............. 17
3-14. Fitting Base (Guide)Assy, Bracket (Chassis),
Magnet Assy.................................................................... 18
3-15. Base Unit (DVBU14) ...................................................... 18
3-16. Tray (Sub)........................................................................ 19
3-17. Chassis (Mold B) Section, Stocker Section,
Slider (Selection) ............................................................ 19
3-18. VIDEO Board.................................................................. 20
3-19. SUB TRANS Board ........................................................ 20
3-20. Back Cover Section......................................................... 21
3-21. TRANS Board ................................................................. 21
3-22. SP RELAY Board............................................................ 22
4. ASSEMBLY
4-1. Assembly Flow................................................................ 23
4-2. Gears Installation ............................................................ 23
4-3. Slider (Selection) Installation ......................................... 24
4-4. Stocker Section Installation ............................................ 24
4-5. Chassis (Mold B) Section Installation............................ 25
5. TEST MODE.............................................................. 26
6. MECHANICAL ADJUSTMENTS ....................... 35
7. ELECTRICAL ADJUSTMENTS......................... 35
Deck Section ................................................................... 35
8. DIAGRAMS
8-1. Block Diagram – RF SERVO Section – ........................ 38
8-2. Block Diagram – TUNER/TAPE DECK Section – ...... 39
8-3. Block Diagram – AUDIO DSP Section (1/2) –............. 40
8-4. Block Diagram – AUDIO DSP Section (2/2) –............. 41
8-5. Block Diagram – POWER AMP Section – ................... 42
8-6. Block Diagram – VIDEO Section – .............................. 43
8-7. Block Diagram
– DISPLAY/POWER SUPPLY Section – ...................... 44
8-8. Note for Printed Wiring Boards and
Schematic Diagrams ....................................................... 45
8-9. Printed Wiring Board – RF Board – .............................. 46
8-10. Schematic Diagram – RF Board – ................................. 47
8-11. Printed Wiring Board
– MB Board (Component Side) –................................... 48
8-12. Printed Wiring Board
– MB Board (Conductor Side) –..................................... 49
8-13. Schematic Diagram – MB Board (1/7) –....................... 50
8-14. Schematic Diagram – MB Board (2/7) –....................... 51
8-15. Schematic Diagram – MB Board (3/7) –....................... 52
8-16. Schematic Diagram – MB Board (4/7) –....................... 53
8-17. Schematic Diagram – MB Board (5/7) –....................... 54
8-18. Schematic Diagram – MB Board (6/7) –....................... 55
8-19. Schematic Diagram – MB Board (7/7) –....................... 56
8-20. Printed Wiring Boards – CHANGER Section –............ 58
8-21. Schematic Diagram – CHANGER Section – ................ 59
8-22. Printed Wiring Boards – CD DOOR Section – ............. 60
8-23. Schematic Diagram – CD DOOR Section – ................. 61
8-24. Printed Wiring Board – SW Board – ............................. 62
8-25. Schematic Diagram – SW Board –................................ 63
8-26. Printed Wiring Boards – TC DOOR Section – ............. 64
8-27. Schematic Diagram – TC DOOR Section – .................. 65
8-28. Printed Wiring Board – MC Board –............................. 66
8-29. Schematic Diagram – MC Board – ............................... 67
8-30. Printed Wiring Board
– DSP Board (Component Side) –.................................. 68
8-31. Printed Wiring Board
– DSP Board (Conductor Side) – ................................... 69
8-32. Schematic Diagram – DSP Board (1/3) – ..................... 70
8-33. Schematic Diagram – DSP Board (2/3) – ..................... 71
8-34. Schematic Diagram – DSP Board (3/3) – ..................... 72
8-35. Schematic Diagram – CENTER SWAMP Board – ..... 73
8-36. Printed Wiring Board
– CENTER SW AMP Board –
(US, CND, AEP, UK Models) ........................................ 74
8-37. Printed Wiring Board
– CENTER SW AMP Board –
(EA, MX, SP, KR Models) ............................................. 75
8-38. Printed Wiring Board
– FRONT REAR AMP Board –...................................... 76
8-39. Schematic Diagram
– FRONT REAR AMP Board –...................................... 77
8-40. Printed Wiring Boards – SPEAKER Section – ............. 78
8-41. Schematic Diagram – REGULATOR Board –.............. 79
8-42. Schematic Diagram – SPEAKER Section (1/2) –......... 80
8-43. Schematic Diagram – SPEAKER Section (2/2) –......... 81
8-44. Printed Wiring Board – GC Board – ............................. 82
8-45. Schematic Diagram – GC Board – ................................ 83
8-46. Printed Wiring Boards – PANEL Section – .................. 84
8-47. Schematic Diagram – PANEL Section – ....................... 85
8-48. Printed Wiring Board – MIC Board –
(EA, MX, SP, KR models) .............................................. 86
8-49. Schematic Diagram – MIC Board –
(EA, MX, SP, KR models) .............................................. 87
8-50. Printed Wiring Board – VIDEO Board –....................... 88
8-51. Schematic Diagram – VIDEO Board – ......................... 89
8-52. Printed Wiring Board – SUB TRANS Board –
(US, CND, AEP, UK Models) ........................................ 90
8-53. Printed Wiring Board – SUB TRANS Board –
(EA, MX, SP, KR Models) ............................................. 91
8-54. Schematic Diagram – SUB TRANS Board –................ 92
8-55. Printed Wiring Board – TRANS Board –...................... 94
8-56. Schematic Diagram – TRANS Board –......................... 95
8-57. IC Pin Function Description .......................................... 104
9. EXPLODED VIEWS
9-1. Case Section ................................................................... 124
9-2. Front Panel Section-1..................................................... 125
9-3. Front Panel Section-2..................................................... 126
9-4. Front Panel Section-3..................................................... 127
9-5. Front Panel Section-4..................................................... 128
9-6. Chassis Section-1 ........................................................... 129
9-7. Chassis Section-2 ........................................................... 130
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

6
HCD-FL7D
9-8. Chassis Section-3 ........................................................... 131
9-9. Chassis Section-4 ........................................................... 132
9-10. DVD Mechanism Deck Section-1
(CDM53N-DVBU14)..................................................... 133
9-11. DVD Mechanism Deck Section-2
(CDM53N-DVBU14)..................................................... 134
9-12. DVD Mechanism Deck Section-3
(CDM53N-DVBU14)..................................................... 135
9-13. DVD Mechanism Deck Section-4
(CDM53N-DVBU14)..................................................... 136
9-14. Base Unit Section (DVBU14)........................................ 137
9-15. Tape Mechanism Deck Section
(TCM-230AWR41CS) ................................................... 138
10. ELECTRICAL PARTS LIST .............................. 139
•Abbreviation
CND: Canadian
EA : Saudi Arabia
KR : Korean
MX : Mexican
SP : Singapore
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

7
HCD-FL7D
NOTES ON HANDLING THE OPTICAL PICK-UP
BLOCK OR BASE UNIT
The laser diode in the optical pick-up block may suffer electro-
static break-down because of the potential difference generated
by the charged electrostatic load, etc. on clothing and the human
body.
During repair, pay attention to electrostatic break-down and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused
on the disc reflective surface by the objective lens in the optical
pick-up block. Therefore, when checking the laser diode emis-
sion, observe from more than 30 cm away from the objective lens.
LASER DIODE AND FOCUS SEARCH OPERATION
CHECK
Carry out the “S curve check” in “CD section adjustment” and
check that the S curve waveforms is output three times.
SERVICE POSITION
In checking the DSP/MB/MC/VIDEO boards, prepare jig.
SECTION 1
SERVICING NOTES
•MODEL IDENTIFICATION
– Back Panel –
MODEL PART No.
US model 4-240-060-0[]
Canadian model 4-240-060-1[]
AEP and UK models 4-240-060-2[]
Saudi Arabia model 4-240-060-3[]
Singapore model 4-240-060-4[]
Mexican model 4-240-060-5[]
Korean model 4-240-060-6[]
PART No.
extension cable (J-2501-217-A)
to the MB board (CN501)
and RF board (CN002)
extension cable (J-2501-198-A)
to the MB board (CN204)
and video board (CN701)
video board (CN701)
GC board
regulator board
SP relay board
DSP board
front rear AMP board
blue LED board
panel (L) board
panel (R) board
RF board (CN002)
mechanism deck
MB board (CN204)
SUB trans board
trans board center SW AMP board
MB board (CN501)
Any board to put
MC board
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

8
HCD-FL7D
•TYPE A/B DISCRIMINATION
Specification of this set is changed in the midway of production. Therefore, the set is classified into two types according to which IC,
IC204 or IC205, is mounted.
When replacing IC205 of type A, install IC204 instead of IC205.
– MB BOARD (Conductor Side) –
IC205 (48 pin) is mounted :TYPE A
IC204 (44 pin) is mounted :TYPE B
•RELEASING THE DISC TRAY LOCK
The disc tray lock function for the antitheft of an demonstration
disc in the store is equipped.
Releasing Procedure :
Press two buttons of Z(DVD) and [DVD TOP MENU] simulta-
neously for five seconds. The message “UNLOCKED” is displayed
and the tray is unlocked.
Note: When “LOCKED” is displayed, the tray lock is not released by
turning power on/off with the [I/ ] button.
1
Ver 1.2
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

9
HCD-FL7D
SECTION 2
GENERAL This section is extracted from
instruction manual.
LOCATION OF CONTROLS
– Front Panel –
ALPHABETICAL ORDER
A – G
2.1CH/MULTI (North American
and European models only) ql
CD SYNC HI-DUB qd
DIGITAL wf
DISC SELECT 4
DISC 1 indicator wl
DISC 2 indicator wk
DISC 3 indicator wj
DISC 4 indicator wh
DISC 5 indicator wg
Display window 2
DISPLAY ws
DVD ed
DVD MENU qs
DVD TOP MENU qa
E – R
ECHO LEVEL (Asian model
only) wa
EFFECT (North American and
European models only) w;
GROOVE (North American and
European models only) wa
MD (VIDEO) (Except for North
American model) wd
MIC jack (Except for North
American and European
models) ql
MIC LEVEL (Except for North
American and European
models) w;
MULTI CHANNEL DECODING
indicator 3
PHONES jack qh
REC PAUSE/START qf
Remote sensor e;
BUTTON DESCRIPTIONS
?/1 (power) 1
Z(disc tray) 5
ZA (deck A) qk
ZB (deck B) qj
hH (play) 6
X(pause) 8
x(stop) 7
./>(go back/go forward)
9
–/m, M/+
(rewind, fast forward) q;
Z
ZZ
xX
>.
M+– m
hH
?/1
1
6
8
452 3
ed
es
ea
wf
wd
ws
w;
ql
qk
qa
qs
qd
qf
qg
qh
qj
7
9
q;
wl
wk
wj
wh
wg
wa
w;
ql
wa
e;
T – V
TAPE A/B ea
TUNER/BAND es
VIDEO (MD) (North American
model only) wd
VOLUME qg
(North American model and
European models only)
(Except for North American
model and European models)
ACOMPONENT VIDEO OUT jacks
Use video cables (not supplied) to connect an
optional component (such as a TV) to this jack.
If your TV accept progressive format file
signals, you must use this connection and set
“COMPONENT OUT” to “PROGRESSIVE”
in “SCREEN SETUP”.
BVIDEO OUT jack
Use a video cable (supplied) to connect an
optional component (such as a TV) to this jack.
You can then output the video to the
component from this unit, and enjoy the video
images of DVDs, etc.
CS VIDEO OUT jack
Use an S video cable (not supplied) to connect
an optional component (such as a TV) to this
jack. You can then output the video to the
component from this unit, and enjoy higher
quality video images.
DOPTICAL DIGITAL IN jack
Use a digital optical cable (square, not
supplied) to connect an MD deck or DVD
player to this jack. You can then record or
listen to digital audio from the MD deck or
DVD player through this system.
EOPTICAL DVD DIGITAL OUT jack
Use a digital optical cable (square, not
supplied) to connect an MD deck to this jack.
You can then output the digital audio to the
MD deck from this system.
FVIDEO (MD)IN jacks
(NorthAmericanmodelonly)
MD(VIDEO) IN jacks
(othermodels)
Use audio cords (not supplied) to connect an
MD deck or VCR to these jacks. You can then
listen to analog audio from the MD deck or
VCR through this system.
GVIDEO (MD)OUT jack
(NorthAmericanmodelonly)
MD(VIDEO) OUT jacks
(othermodels)
Use audio cords (not supplied) to connect an
MD deck or VCR to these jacks. You can then
output audio to the MD deck or VCR from this
system.
Tip
When you remove the optical cover, keep it for future
use.
– Rear Panel –
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

10
HCD-FL7D
Remote Control
ALPHABETICAL ORDER
A – E
2.1CH/MULTI* e;
ALBUM +/– ed
AMP MENU 9
ANGLE ek
AUDIO el
CLEAR ql
CLOCK/TIMER SELECT* wf
CLOCK/TIMER SET wf
D.SKIP 5
digipad 7
DISPLAY 4
DSP EDIT* ej
DVD qh
DVD DISPLAY qa
DVD MENU qg
DVD SETUP* 9
DVD TOP MENU qj
EFFECT* es
ENTER 6
BUTTON DESCRIPTIONS
?/1 (power) qk
hH (play) wk
X(pause) r;
x(stop) wl
.(go back) wj
>(go forward) wj
m(rewind) ra
M(fast forward) ra
V/v/B/b/ENTER eg
>10 wa
*To use these functions, press the
button while pressing SHIFT.
F – S
FUNCTION 0
GAME MODE eh
GROOVE* ef
KARAOKE PON* eh
MOVIE MODE es
MUSIC MODE ej
Numeric buttons wd
P FILE* el
PLAY MODE/DIRECTION w;
PRESET +/– wj
PREV/NEXT wj
REPEAT/FM MODE ws
RETURN Oe;
SCAN/SLOW t/ T ra
SELECT wk
SHIFT qd
SLEEP wg
SUBTITLE ea
T – V
TAPE A/B qs
TOOL MODE ef
TUNER MEMORY* w;
TUNER/BAND qf
TUNING +/– ra
TV/VIDEO wh
TV ?/1 1
TV CH +/– 3
TV VOL +/– 2
VOLUME +/– 8
B
v
V
1 2 3 45 6 7
890qaqsqdqfqgqhqjqk
ql
wh
wg
wf
ws
w;
wa
wd Bb
v
V
wk
wj
wl e;
ea
es
ef
ed
eg
eh
ej
ek
el
r;
ra
Setting the clock
1 Turn on the system.
2 Press CLOCK/TIMER SET on the
remote.
3
Press .or >repeatedly to set the
hour.
4 Press ENTER on the remote.
5 Press .or >repeatedly to set the
minutes.
6 Press ENTER on the remote.
To adjust the clock
1 Press CLOCK/TIMER SET on the remote.
2 Press .or >repeatedly to select
“CLOCK SET?”, then press ENTER on the
remote.
3 Do the same procedures as step 3 to 6
above.
Note
The clock settings are canceled when you disconnect
the power cord or if a power failure occurs.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

11
HCD-FL7D
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
3-4. SIDE PANEL (A)/(B)
(Page 13)
3-3. BACK COVER
(Page 12)
3-2. TOP PANEL ASSY
(Page 12)
3-5. CASE
(Page 13)
3-7. GC BOARD
(Page 14)
3-14. FITTING BASE (GUIDE)ASSY,
BRACKET (CHASSIS),
MAGNET ASSY
(Page 18)
3-17. CHASSIS (MOLD B) SECTION,
STOCKER SECTION,
SLIDER (SELECTION)
(Page 19)
3-11. DVD MECHANISM BLOCK
(Page 16)
3-16. TRAY (SUB)
(Page 19)
3-13. DVD MECHANISM DECK
(CDM53N-DVBU14)
(Page 17)
3-12. DSP BOARD
(Page 17)
3-21. TRANS BOARD
(Page 21)
3-22. SP RELAY BOARD
(Page 22)
3-18. VIDEO BOARD
(Page 20)
3-19. SUB TRANS BOARD
(Page 20)
3-20. BACK COVER SECTION
(Page 21)
3-15. BASE UNIT
(DVBU14)
(Page 18)
3-6. FRONT PANEL ASSY
(Page 14)
3-8. TAPE MECHANISM ASSY
(Page 15)
3-9. BELT
(Page 15)
3-10. SW BOARD,
HEAD (A) BOARD,
HEAD (B) BOARD
(Page 16)
SET
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

12
HCD-FL7D
Note: Follow the disassembly procedure in the numerical order given.
3-2. TOP PANEL ASSY
3-3. BACK COVER
1 four screws
(hexagon socket tapping)
2 top panel ass
y
1 five screws
(BVTP3
× 8
)
2 back cover
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

13
HCD-FL7D
3-4. SIDE PANEL (A) / (B)
3-5. CASE
4 side panel (A)
1 three screws
(top)
2 side panel (B)
3 three screws
(top)
5 two screws
(BVTP3
× 8)
2 six screws
(BVTT3 × 8 (S))
1 three screws
(BVTP3 × 8)
1 three screws
(BVTP3 × 8)
6
6
4 screw (case 3 TP2
)
7 case
3 screw (case 3 TP2)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

14
HCD-FL7D
3-6. FRONT PANEL ASSY
3-7. GC BOARD
two claws
qg Rifting up the CD mechanism block
section, and release two claws.
7 connector
(CN1)
8 connector
(CN808)
9 connector
(CN318)
1 wire (flat type) (15 core)
(CN206)
5 wire (flat type)
(17 core) (CN109)
2 connector
(CN201)
3 connector
(CN203)
4 connector
(CN207)
6 connector
(CN2)
qf two screws
(BVTP3 × 8)
0 screw
(BVTP3 × 8)
qs screw
(BVTP3 × 8)
qa harness
qd harness
qh front panel assy
Saudi Arabia,
Korean, Mexican,
Singapore
4 three screws
(BVTP3
× 8)
2 wire (flat type) (19 core)
(CN202)
1 wire (flat type) (17 core)
(CN204)
3 connector
(CN713)
5 GC board
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

15
HCD-FL7D
3-8. TAPE MECHANISM ASSY
3-9. BELT
1 two screws
(2.6
× 8)
5 tape mechanism ass
y
2 two screws
3 Push two solenoids.
4 Open cassette lid.
1 two screws
(PS 2.6 × 5)
2 motor assy (capstan
)
(M901)
3 belt (capstan C)
4 belt (capstan B)
4 belt (capstan B)
5 belt (FR)
5 belt (FR)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

16
HCD-FL7D
3-10. SW BOARD, HEAD (A) BOARD, HEAD (B) BOARD
3-11. DVD MECHANISM BLOCK
6 screw (PTT 2 × 4)
4 screw (PTT 2 × 4)
3 SW board
2 five claws
5 head (A) board
7 head (B) board
1 Remove the four solders.
8 two connectors
(CN805, 806)
9 claw
6 two connectors
(CN702, 703)
0 two claws
SP-relay
board
MC board
qa DVD mechanism block
3 connector
(CN905)
4 connector
(CN903)
1 wire (flat type)
(11 core: EXCEPT AEP, UK)/
wire (flat type)
(15 core: AEP, UK)
(CN105)
2 wire (flat type)
(17 core) (CN204)
5 connector
(CN807)
7 six screws
(BVTP3
× 8
)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

17
HCD-FL7D
3-13. DVD MECHANISM DECK (CDM53N-DVBU14)
3-12. DSP BOARD
1 wire (flat type) (9 core
)
(CN603)
4 two screws
(BVTP3
× 8)
5 DSP boar
d
2 wire (flat type) (19 core)
(CN602)
3 wire (flat type) (11 core)
(CN601)
2 two screws
(BVTP 3
× 8)
1 two screws
(BVTP 3
× 8)
3 bracket top panel
7 chassis (CDM) section
6
5
wire (flat type) (29core)
(CN501)
4 four screws
(BVTP 3
× 8)
8 DVD mechanism deck
(CDM53N-DVBU14)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

18
HCD-FL7D
3-14. FITTING BASE (GUIDE) ASSY, BRACKET (CHASSIS), MAGNET ASSY
3-15. BASE UNIT (DVBU14)
1 two connectors
(CN709, 715)
7 connecto
r
(CN710)
9 magnet assy
2 four screws
(BTTP M2.6)
8 four screws
(BTTP M2.6)
4 two screws
(BTTP M2.6)
6 Bracket
(chassis)
5 two screws
(BTTP M2.6)
3 fitting base
(guide) assy
6 base unit
(DVBU14)
5 two screws
(PTPWH M2.6
)
1 connector
(CN710)
4 magnet assy
3 two hooks
2 four screws
(BTTP M2.6)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

19
HCD-FL7D
3-16. TRAY (SUB)
3-17. CHASSIS (MOLD B) SECTION, STOCKER SECTION, SLIDER (SELECTION)
A
B
pully (LD)
stocker section
tray (sub)
slider (selection)
pully (mode)
1 Rotating the pulley (LD), shift the slider (selection) in the arrow A direction.
2 Rotating the pulley (mode) in the arrow direction, adjust the tray (sub) to be removed.
3 Rotating the pulley (LD), shift the slider (selection) in the arrow B direction.
4 Rotating the pulley (mode) in the arrow direction, remove the tray (sub) to be removed.
6 stocker
section
1 three screws
(BVTP M2.6)
2 chassis (mold B) section
3 gear (eject)
4 two step screws
5 two step
screws
7 two screws
(PTPWH M2.6)
8 slider (selection)
9 washer
0 compression
spring
Pully (LD)
Note: Rotating the pully (LD),
shift the slider (selection)
to the left.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

20
HCD-FL7D
3-18. VIDEO BOARD
3-19. SUB TRANS BOARD
1 three screws
(BVTP3 × 8)
2 video board
3 three screw
s
(BVTP3 × 8)
2 connector
(CN902)
1 connector
(CN901)
5 SUB trans board
4 harness
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
