Sony IPELA SNC-DS10 User manual

NETWORK CAMERA
SNC-DS10
SNC-DM110
SERVICE MANUAL
1st Edition (Revised 1)

SNC-DS10/DM110
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
When using a modular jack cable:
For safety, do not connect to the connector for peripheral
device wiring that might have excessive voltage.

1
SNC-DS10/DM110
Table of Contents
Manual Structure
Purpose of this manual ................................................................. 3
Related manuals ........................................................................... 3
Trademarks ................................................................................... 3
1. Service Overview
1-1. Board Location ...............................................................1-1
1-2. Replacing the Main Parts ................................................1-1
1-2-1. Upper Case N Assembly .......................................1-1
1-2-2. Chassis Assembly..................................................1-2
1-2-3. SY-358 Board........................................................1-2
1-2-4. PS-744 Board ........................................................1-3
1-2-5. Varifocal Lens/BI-222/BI-224 Board ...................1-3
1-2-6. Cable Connection ..................................................1-4
1-3. Replacing the Electrolytic Capacitor ..............................1-5
1-4. Unleaded Solder..............................................................1-5
2. Adjustments
2-1. Preparation ......................................................................2-1
2-1-1. Adjustment Tools and Required Equipment .........2-1
2-1-2. Installation of Adjustment Program ......................2-2
2-1-3. Connection Diagram .............................................2-2
2-2. Adjustment......................................................................2-3
2-2-1. Connection ............................................................2-3
2-2-2. VSUB Voltage Adjustment
(Only SNC-DM110)..............................................2-4
2-2-3. Setup Level Adjustment ........................................2-5
2-2-4. Burst Level Adjustment ........................................2-5
2-2-5. White Defect Correction .......................................2-6
2-2-6. White Defect Correction (Light funnel)
(Only SNC-DM110)..............................................2-6
2-2-7. Mechanical Iris Adjustment ..................................2-7
2-2-8. Video Level Adjustment .......................................2-7
2-2-9. White Balance Data Retrieving.............................2-8
2-2-10. White Balance Data Retrieving
(Light funnel) (Only SNC-DM110) ......................2-9
2-2-11. Color Reproduction Adjustment .........................2-10
2-2-12. Saving of Adjustment Results .............................2-11
2-3. Check after Adjustment ................................................2-11
2-3-1. Preparation of Check ...........................................2-11
2-3-2. Burst Level Check ...............................................2-11
2-3-3. Video Level Check ..............................................2-11
2-3-4. Color Reproduction Adjustment Check ..............2-11
2-3-5. VSUB Voltage Check
(only SNC-DM110).............................................2-12
2-4. Procedure for SY-358 Board Replacement ..................2-12
2-4-1. Re-sticking of MAC Address Label....................2-12
2-4-2. MAC Address and Serial Number Writing .........2-12
3. Circuit Description
3-1. SY-358 Board .................................................................3-1
3-1-1. Camera DSP, MPEG4 & JPEG Encoder,
and Main CPU Blocks...........................................3-1
3-1-2. Electrical Volume Block .......................................3-1
3-1-3. SDRAM (Video) Block.........................................3-1
3-1-4. Real Time Clock Block .........................................3-1
3-1-5. Voltage Monitor and Reset Blocks .......................3-1
3-1-6. Video Encoder Block ............................................3-1
3-1-7. Audio AD/DA Block.............................................3-2
3-1-8. Sensor Input Block ................................................3-2
3-1-9. Alarm Output Block ..............................................3-2
3-1-10. Ethernet Controller Block .....................................3-2
3-1-11. SDRAM (System) .................................................3-2
3-1-12. Flash Memory Block .............................................3-2
3-1-13. Iris Switch .............................................................3-3
3-1-14. VIDEO OUT Switch .............................................3-3
3-1-15. Factory Reset Switch.............................................3-3
3-2. PS-744 Board ..................................................................3-3
3-2-1. Power Block ..........................................................3-3
3-3. BI-222 Board (SNC-DS10) ............................................3-4
3-4. BI-224 Board (SNC-DM110) .........................................3-4

2SNC-DS10/DM110
4. Troubleshooting
4-1. Power LED is not lit .......................................................4-1
4-2. Cannot connect to the network .......................................4-2
4-3. Image is not displayed on the PC viewer........................4-3
4-4. Image on the PC viewer is abnormal ..............................4-4
4-5. Image is not displayed from the analog video output.....4-6
4-6. Abnormal SENSOR IN...................................................4-7
4-7. Abnormal ALARM OUT ...............................................4-7
4-8. Abnormal AUDIO IN .....................................................4-8
4-9. Abnormal LINE OUT .....................................................4-9
A. Spare Parts
A-1. Notes on Repair Parts ....................................................A-1
A-2. Exploded Views ............................................................. A-2
A-3. Electrical Parts List ........................................................A-5
A-4. Packing Materials & Supplied Accessories .................A-14
B. Block Diagrams
Overall (SNC-DS10) ..................................................... B-1
Overall (SNC-DM110) .................................................. B-2
C. Schematic Diagrams
BI-222 ............................................................................ C-2
BI-224 ............................................................................ C-3
PS-744............................................................................ C-4
SY-358 ........................................................................... C-6
D. Board Layouts
BI-222 ............................................................................D-2
BI-224 ............................................................................D-3
PS-744............................................................................D-4
SY-358 ...........................................................................D-5
Appendix

3
SNC-DS10/DM110
Manual Structure
Purpose of this manual This manual is the Service Manual of the Network Camera SNC-DS10/DM110.
This manual contains the service overview, adjustments, spare parts, block diagram,
schematic diagrams, and board layouts.
Related manuals In addition to this Service Manual, the following manuals are provided.
..
..
.Installation Manual (Supplied with SNC-DS10/DM110)
This manual describes the information on installing the SNC-DS10/DM110.
..
..
.“Easy Setup Guide for the Sony Network Camera ” CD-ROM
(Supplied with SNC-DS10/DM110)
This manual describes the information on setting the SNC-DS10/DM110.
..
..
.“User’s Guide” CD-ROM (Supplied with SNC-DS10/DM110)
This manual describes the information required for the proper operation and
application of this unit.
..
..
.“Semiconductor Pin Assignments” CD-ROM (Available on request)
This “Semiconductor Pin Assignments” CD-ROM allows you to search for
semiconductors used in Broadcast and Professional equipment.
Part number: 9-968-546-06
Trademarks Trademarks and registered trademarks used in this manual are follows.
.Windows is a registered trademark of Microsoft Corporation in the United States
and Other countries.
.Ethernet is a registered trademark of Xerox Corporation.
Other system names, product names, and company names appearing in this manual
are trademarks or registered trademarks of their respective holders.

1-1
SNC-DS10/DM110
Section 1
Service Overview
1-1. Board Location
n
When repairing or replacing the board of this unit, be sure
to perform the adjustment according to Section 2.
1-2. Replacing the Main Parts
1-2-1. Upper Case N Assembly
1. Remove the cover using a tool such as a flat screw-
driver.
2. Remove the stepped screw (with stopper), then remove
the upper case N assembly by rotating it in the direc-
tion of the arrow.
3. To install, reverse the removal procedure.
n
1. Align the groove of upper case N assembly with the
groove (a) of lower case.
2. Rotate the upper case N assembly in the direction of
the arrow to align its groove with the groove (b) of
lower case.
SY-358 board
BI-222 board (SNC-DS10)
BI-224 board (SNC-DM110)
PS-744 board
Cover
Upper case N
assembly
Stepped screw
(with stopper)
Flat
screwdriver
Cover
Case (upper)
Case (lower)
Groove (b) Groove (a)
Case (upper)
Case (lower)
Groove
Groove (b) Groove (a)
Groove
At the time of
the installation
Under lock
condition

1-2 SNC-DS10/DM110
1-2-2. Chassis Assembly
1. Remove the upper case N assembly.
(Refer to Section 1-2-1.)
2. Disconnect the LAN cable and power input cable from
the connectors (CN301 and CN809) on the SY-358
board.
3. Remove the two hooks in the direction of the arrow,
then remove the board cover N.
4. Remove the three screws (PSW2.6 x8), then remove
the chassis assembly.
5. Disconnect the two harnesses from the connectors
(CN807 and CN808) on the SY-358 board.
6. To install, reverse the removal procedure.
1-2-3. SY-358 Board
n
When installing the SY-358 board, be careful not to catch
the harness.
1. Remove the upper case N assembly.
(Refer to Section 1-2-1.)
2. Remove the chassis assembly.
(Refer to Section 1-2-2.)
3. Remove the LAN earth plate B.
4. Remove the screw, then remove the SY-358 board.
5. Disconnect the two harnesses from the connectors
(CN801 and CN811) on the SY-358 board.
6. Remove the radiation rubber (large) and radiation
rubber (small) from the SY-358 board.
7. To install, reverse the removal procedure.
Hooks
Board cover N
Chassis assembly
PSW2.6 x8
Harnesses
Power input
cable
LAN cable
CN808
CN807
CN809 CN301
SY-358 board
CN811
CN801
Harness
Harness
Radiation rubber
(small)
Radiation rubber
(large)
SY-358 board
LAN earth plate B
PSW2.6 x8

1-3
SNC-DS10/DM110
1-2-5. Varifocal Lens/BI-222/BI-224 Board
1. Remove the upper case N assembly.
(Refer to Section 1-2-1.)
2. Remove the chassis assembly. (Refer to Section 1-2-2.)
3. Remove the screw (R3 x10), then open the chassis in
the direction of the arrow.
4. Remove the lens block.
5. Remove the two screws (BTP2 x6), then remove the
ball (upper).
6. Remove the two screws (BTP2.6 x8), then remove
the two BI guides.
7. Remove the two screws (BTP2.6 x8), then remove
the optical block assembly.
8. Disconnect the two harnesses from the connectors
(CN101 and CN102) on the BI-222/BI-224 board.
1-2-4. PS-744 Board
1. Remove the upper case N assembly.
(Refer to Section 1-2-1.)
2. Remove the chassis assembly.
(Refer to Section 1-2-2.)
3. Remove the SY-358 board. (Refer to Section 1-2-3.)
4. Remove the three screws, then remove the PS-744
board.
5. Remove the cable tie, then remove the MG sheet and
harness.
6. Disconnect the two harnesses from the connectors
(CN1 and CN2) on the PS-744 board.
7. To install, reverse the removal procedure.
Harnesses
CN2
CN1
PSW2.6 x5.8
PS-744 board MG sheet
Cable tie
BTP2 x6
BTP2.6 x8
B3 x10
BTP2.6 x8
Lens block
Chassis
Ball (upper)
Optical block
assembly
CN101
CN102
Lower ball (P)
BI guides
Harness
Harness
BI-222/BI-224
board

1-4 SNC-DS10/DM110
Lens tube
Lens glass
Focus ring
PTPWH2 x6
P2 x5
CN103
Varifocal lens
Lens bracket
BI-222/224 board
Seal rubber
Filter
Harness
9. Place the unit with the lens side down.
n
When placing the varifocal lens facing down, if the
lens glass protrudes from the end of the lens tube,
retract the lens glass by rotating the focus ring in the
direction of the arrow.
10. Disconnect the harness from the connector (CN103)
on the BI-222/224 board.
11. Remove the two screws (PTPWH2 x6), then remove
the BI-222/224 board, seal rubber and filter.
12. Remove the three screws (P2 x5), then remove the
lens bracket.
13. To install, reverse the removal procedure.
1-2-6. Cable Connection
m
.For the indoor wiring (routing of cable from the side),
the lower case is provided with a knock-out type slit that
can be broken off using a tool such as plier.
By breaking off this slit, all cables including the supplied
I/O cable and audio cable can be routed from the side.
.Only the LAN cable and power input cable are connect-
ed to this unit at the shipment.
LAN cable
Audio cable (Supplied)
BNC cable (Supplied)
Power input cable
I/O cable
(Supplied)
Slit (knock-out type)
When performing the indoor wiring
Cable
SY-358 board
CN301
CN805
CN810
CN806
CN809

1-5
SNC-DS10/DM110
1-4. Lead-free Solder
Boards requiring use of lead-free solder are printed with a
lead free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come
printed with the lead free mark due to their particular size.)
: LEAD FREE MARK
m
.Be sure to use the lead-free solder for the printed circuit
board printed with the lead free mark.
.The lead-free solder melts at a temperature about 40 dC
higher than the ordinary solder, therefore, it is recom-
mended to use the soldering iron having a temperature
regulator.
.The ordinary soldering iron can be used but the iron tip
has to be applied to the solder joint for a slightly longer
time. The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful.
1-3. Replacing the Electrolytic Capacitor
The electrolytic capacitor used in this unit needs to be
replaced periodically.
When a service for repair or maintenance is provided, and
if the unit has been used for a long period of time, it is
recommended that the following electrolytic capacitor (or
assembled part that include it) to be replaced at once after
having consent from the customer. Refer to Section A-3
for the part number of replacing part.
The length of the operating life varies depending on the
environment and conditions of how the part has been used.
Make note that the part is not guaranteed for the number of
years described below. It is served as a guide for replace-
ment.
Board Ref. No. Average length of
name operating life
SY-358 C216 12 years
C217 8 years
PS-744 SWR1 (AC-DC converter) 14 years

2-1
SNC-DS10/DM110
Section 2
Adjustments
2-1. Preparation
2-1-1. Adjustment Tools and Required
Equipment
J-6431-850-A: Pattern box PTB-700
SNC-DM110
J-7120-480-A: Vectorscope scale (Mega)
SNC-DS10
J-7120-490-A: Vectorscope scale (SD)
J-6097-390-A: Color-bar chart (For PTB-700)
.For the color reproduction adjustment
J-7120-450-A: Gray scale chart I type (For PTB-700)
WGC Y YI M g RB
.Camera adjustment software: J-7120-470-A
.Personal computer (PC)
OS: Windows 2000/XP/Vista
CPU: Pentium series, Core series
Memory: 128 MB or more
Free space on HDD: 500 MB or more
.Waveform monitor
.Color video monitor
.Vectorscope
.Voltmeter (only SNC-DM110)
.Power supply for this unit (12 V DC/24 V AC)
.LAN cable (cross)
.Light source for test chart
n
There are no characters on the color-bar chart.
.For the color reproduction adjustment
(This scale is printed on the Appendix.)
.The following is the vectorscope scale used in SNC-
DM110.
J-6080-058-A: Color temperature correction filter C14

2-2 SNC-DS10/DM110
Pattern box PTB-700
Voltmeter
(Only SNC-DM110)
Waveform
monitor
Personal computer
SY-358 board
CN301
VIDEO
OUT 12 V DC/
24 V AC
Color video monitor
75 Ztermination
Vectorscope
LAN cable
(cross)
Camera
2-1-3. Connection Diagram
n
Only SNC-DM110
Remove the upper case and board cover of this unit, and
then connect the positive terminal to TP801 on the SY-358
board and connect the negative terminal to TP101 on the
SY-358 board.
2-1-2. Installation of Adjustment Program
1. Start the PC.
2. Copy “CameraAdjustmentTool” directory from the
CD-ROM of adjustment program to an arbitrary place.
3. Execute “vcredist_x86.exe” in the copied folder.
4. Create a shortcut of “CameraAdjustmentTool.exe” on
an arbitrary place such as desktop.

2-3
SNC-DS10/DM110
2-2. Adjustment
m
.In the adjustment using CameraAdjustmentTool.exe
(hereafter referred to as “adjustment tool”), if “OK”is
not displayed in the upper right area of the window, quit
the adjustment software and turn the power of this unit
off and on, and then perform the adjustment from the
beginning again.
When replacing the BI board and SY board, perform all
adjustments.
.In this section, the window of SNC-DM110 is used for
description unless otherwise stated.
2-2-1. Connection
1. Connect each equipment according to the connection
diagram in Section 2-1-3.
2. Turn on the power of each device.
3. Click “CameraAdjustmentTool.exe”to start the
camera adjustment software.
4. Type the IP address of camera, and then click the
[Connect] button.
n
If “Failed to connect”message is displayed on the
window, check if the network connection and IP
address are correct. After waiting for a while, click the
[Connect] button again.
n
If you want to start the adjustment over again after
clicking the [Connect] button, quit the adjustment
software once, and then turn the power of this unit off
and on again.
5. The dialog box is displayed. Then, select NTSC or
PAL radio button according to the measurement
device to be used.
6. Check that all check boxes are checked, and then click
the [OK] button.
In the case of SNC-DM110
In the case of SNC-DS10
n
The adjustment of item whose check box is checked can be
performed.
7. Check that the image is output on the video monitor.
n
If no image is output on the video monitor, press the
[VIDEO|OUT] button several times so that the image
can be output on the video monitor.

2-4 SNC-DS10/DM110
2. Operate the spin box so that the voltage value of the
voltmeter matches the value displayed in the lower
area of the adjustment software window.
3. Click the [OK] button.
4. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
Spin box
2-2-2. VSUB Voltage Adjustment
(Only SNC-DM110)
n
You can check the imprint of CCD used in this adjustment
from the side B of the BI-224 board. Before starting the
procedure, disassemble this unit so that you can check the
BI-224 board and write down the imprinted letter. Be sure
to read the letter from the direction as shown in the picture.
.Subject: None
.Measurement device: Voltmeter
.Specification: Displayed in the lower portion of
the adjustment software window.
1. Select the letter imprinted on the backside of CCD (“f”
in the above picture), then click the [OK] button.
Imprinted letter
List box
Specificaion

2-5
SNC-DS10/DM110
2-2-3. Setup Level Adjustment
.Subject: None
.Measuring equipment: Waveform monitor
.Specification: NTSC: A = 7.5 ±2 (IRE)
PAL: A = 0 ±14 (mV)
1. Operate the spin box while checking the waveform
monitor to adjust the level to the specification A.
2. Click the [OK] button.
3. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
2-2-4. Burst Level Adjustment
.Subject: None
.Measuring equipment: Waveform monitor
.Specification: NTSC: B = 40 ±2 (IRE)
PAL: B = 280 ±14 (mV)
1. Operate the spin box while checking the waveform
monitor to adjust the level to the specification B.
2. Click the [OK] button.
3. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
A
Spin box
B
Spin box

2-6 SNC-DS10/DM110
2-2-6. White Defect Correction (Light funnel)
(Only SNC-DM110)
.Subject: None
.Measuring equipment: None
.Specification: None
1. Cover the lens with the lens cap, etc.
2. Click the [Light|funnel|White|Defect|Revision]
button.
3. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
4. Remove the cover (lens cap, etc.) from the lens.
2-2-5. White Defect Correction
.Subject: None
.Measuring equipment: None
.Specification: None
1. Cover the lens with the lens cap, etc.
2. Click the [White|Defect|Revision] button.
3. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
4. Remove the cover (lens cap, etc.) from the lens.

2-7
SNC-DS10/DM110
2-2-7. Mechanical Iris Adjustment
.Subject: Gray scale chart type I
.Measuring equipment: None
.Specification: None
1. Shoot the Gray scale chart type I using this unit and
adjust the angle of view.
2. Click the [A just|DC|Servo|Lens] button.
3. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
2-2-8. Video Level Adjustment
.Subject: Clear chart
.Measuring equipment: Waveform monitor
.Specification: NTSC: C = 65 ±5 (IRE)
PAL: C = 455 ±35 (mV)
1. Shoot the clear chart and adjust the angle of view.
2. Operate the spin box while checking the waveform
monitor to adjust the level to the specification C.
3. Click the [OK] button.
4. Check that “OK”is displayed in the upper right area of
the window, and then click the [Next] button.
C
Spin box

2-8 SNC-DS10/DM110
2-2-9. White Balance Data Retrieving
.Subject: Clear chart
.Measuring equipment: Vectorscope
.Specification: None
1. Check that the luminescent spot stays near the center
of vectorscope, and then click the [3200K] button.
2. Put the color temperature correction filter C14 over the
lens.
3. Check that the luminescent spot stays near the center
of vectorscope, and then click the [5800K] button.
4. Check that “OK”is displayed in the upper right area of
the window, and then remove the color temperature
correction filter C14.
5. Click the [Next] button.
