Mini Dome 720p/30fps Camera
Powered by IPELA ENGINE EX™ Technology
nMaximum resolution of 1280 x 1024 pixels with the
Exmor™ CMOS sensor
nThree simultaneous video streams
nExtremely Wide Dynamic Range to 130dB achieved with
View-DR technology
nNew video analytics functions including face detection and
object removal/left behind
nH.264 (High/Main/Baseline Profile)/JPEG video codecs and
AAC (16 kHz/48 kHz)/G.726/G.711 audio codecs
nMinimum illumination of 0.05 lx in Color and 0.04 lx in B/W
(50 IRE @ 1/30 sec)
•IPELA ENGINE EX signal processing system developed based on
Sony’s unique signal processing and video analytics
technologies to provide unique features
such as a View-DR, XDNR™, and DEPA™
Advanced technologies
•View-DR – Sony’s innovative wide dynamic range technology
– to capture objects clearly and adaptively even under very
harsh, severe backlight or highlight conditions
•Visibility Enhancer (VE) to optimize the brightness and color
reproduction of an image dynamically on a pixel-by-pixel basis
while continuously adapting to the scene within the given
dynamic range
•DEPA Advanced Intelligent Video Analytics to
trigger an alarm based on user-defined rules
•True D/N (Day/Night) function to switch to Day or
Night mode depending on the light level
•SD memory card slot for an on-board recording capability1
•XDNR (eXcellent Dynamic Noise Reduction) technology for clear
images with virtually no motion blur under low illumination
•Built-in HTML viewer compatible with most Smartphones
•Easy Focus - allows installer/user to focus the camera remotely
using a PC or locally
•Easy Zoom - allows installer/user to change field of view locally
or remotely using a PC
•Powered by either PoE (IEEE 802.3af-compliant), AC 24 V ±20%,
or DC 12 V ±10% for easy installation
•ONVIF™ (Open Network Video Interface Forum)
Profile S conformance software that ensures
greater interoperability and more flexibility in
building multiple-vendor systems
•VBR (variable bitrate) or CBR (constant bitrate) encoding
format selectable to correspond with various network
conditions
•Easy initial network settings with supplied SNC Easy IP Setup
Guide application
•Image Stabilizer to help minimize the effect of camera shake or
vibration for less blurry images
KEY FEATURES
1 Data recorded on an SD memory card (sold separately) may be lost or damaged by data
access during power-off, mechanical shock, memory card detachment, or other operations.
Data loss or damage can also occur when a memory card reaches end of life, which varies
according to operational conditions. No guarantee is given against damage (including
passive damage). The on-board recording function, the intelligent motion detection function
and the tamper alarm function cannot be used simultaneously.
ON
OFF
Actual Images
Actual Images
OFF
ON
SNC-VM600B
Network Mini Dome HD Camera – V Series

Printed in USA (1/13)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/security
S-IP2149 (MK11005V1)
©2013 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
Weights and measurements are approximate.
Sony, IPELA, IPELA ENGINE EX, DEPA,View-DR, XDNR, Exmor, ONVIF and
the Sony make.believe logo are trademarks of Sony.
Microsoft, Windows,Windows Vista and Internet Explorer are registered trademarks of
Microsoft Corporation in the United States and/or other countries.
Google and Google Chrome are trademarks of Google Inc. Safari is a trademark of Apple Inc.
All other trademarks are the trademarks of their respective owners.
SPECIFICATIONS
DIMENSIONS
Network Recording Software
IMZ-NS100 Series
Recording Server
NSR-500
PC
SNC-VM600B
SNC-VM600B
HD monitor
SYSTEM CONFIGURATION
ø5 7/8 (148)
4 3/8 (108)
Unit: inches (mm)
SNC-VM600B
Camera
Image Sensor 1/3-type progressive scan Exmor CMOS
Image Sensor (Number of Effective Pixels) Approx.1.37 Megapixels
Signal System NTSC color system
Minimum Illumination (50 IRE) Color: 0.05 lx (F1.2,View-DR OFF,VE OFF, AGC ON,1/30 s,30 fps)
B/W:0.04 lx (F1.2, View-DR OFF,VE OFF,AGC ON,1/30 s, 30 fps)
Minimum Illumination (30 IRE) Color: 0.03 lx (F1.2,View-DR OFF,VE OFF, AGC ON 1/30 s,30 fps)
B/W:0.02 lx (F1.2, View-DR OFF,VE OFF,AGC ON,1/30 s, 30 fps)
Dynamic Range Equivalent to 130 dB with View-DR technology
S/N Ratio More than 50 dB (Gain 0 dB)
Gain Auto
Shutter Speed 1/1 s to 1/10000 s
Sync System Internal synchronization
Exposure Control Exposure compensation,AGC,Shutter speed,Iris
White Balance ATW,ATW-PRO,Fluorescent lamp, Mercury lamp, Sodium vapor lamp,Metal halide lamp, White LED, One push WB,Manual
Lens Built-in vari-focal lens
Powered Zoom Yes (Easy Zoom)
Zoom Ratio Optical zoom 3x, Digital zoom 2x
Powered Focus Yes (Easy Focus)
Horizontal Viewing Angle 93.0° to 31.6°
Vertical Viewing Angle 50.6° to 17.8°
Focal Length f = 3.0 mm to 9.0 mm
F-Number F1.2 (Wide), F2.1 (Tele)
Minimum Object Distance 300 mm
Horizontal Resolution 600 TV lines (analog video) *2
Preset Position 8
Tour 5
Camera Features
Day/Night Yes
Wide-D Yes (View-DR)
Image Enhancement Visibility Enhancer (VE)
Noise Reduction XDNR technology
Image Stabilizer Yes *4
Codec Image Size (H x V) 1280 x 1024, 1280 x 960, 1024 x 768, 1280 x 720, 800 x 600, 720 x 576, 720 x 480, 704 x 576,640 x 480,352 x 288,
320 x 240 (H.264, JPEG)
Video Compression Format H.264 (High/Main/Baseline Profile),JPEG
Codec Streaming Capability Triple Streaming *1, CBR/VBR (selectable)
Maximum Frame Rate H.264: 30 fps (1280 x 1024)
JPEG: 30 fps (1280 x 1024)
Audio
Audio Compression Format G.711/G.726/AAC (16 kHz, 48 kHz)
Scene Analytics
Intelligent Motion Detection Yes
Face Detection Yes *3
Rule-based Filter DEPA Advanced
Network
Protocols IPv4,TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, DNS, NTP, RTP/RTCP, RTSP, SMTP, IPv6 *3, HTTPS, SNMP (MIB-2)
ONVIF Conformance Yes (Profile S) *3
Number of Clients 20
Authentication IEEE 802.1X
Interface
Analog Video Output BNC x1, 1.0 Vp-p, 75 Ω, unbalance, sync negative
Analog Monitor Output Phono jack x1
Line Input Mini jack (monaural)
Line Output Mini jack (monaural),Maximum output level:1 Vrms
Network Port 10BASE-T/100BASE-TX (RJ-45)
Sensor Input x 2, make contact, break contact
Alarm Output x 2, 24 V AC/DC,1 A (mechanical relay outputs electrically isolated from the camera)
Microphone Input Mini jack (monaural)
Card Slots SD Card x 1
System Requirements
Operating System Windows®XP (32 bit) Professional Edition
Windows Vista®(32 bit) Ultimate,Business Edition
Windows 7 (32/64 bit) Ultimate,Professional Edition
Processor Intel Core i7 2.8 GHz or higher
Memory 2 GB or more
Web Browser Microsoft Internet Explorer®Ver. 7.0, Ver. 8.0,Ver. 9.0
Firefox®Ver.3.5 (Plug-in free viewer only)
Safari®Ver. 4.0 (Plug-in free viewer only)
Google Chrome™Ver. 4.0 (Plug-in free viewer only)
General
Power Requirements PoE system (IEEE 802.3af compliant), DC 12 V ± 10%, AC 24 V ± 20%
Power Consumption 6.0 W max.
Operating Temperature 14°F to 122°F (-10°C to +50°C)
Starting Temperature 32°F to 122°F (0°C to 50°C)
Storage Temperature -4°F to +140°F (-20°C to +60°C)
Operating Humidity 20% to 80%
Storage Humidity 20% to 95%
Dimensions (W x H x D) ø5 7/8 inches x 4 3/8 inches (ø148 mm x 108 mm)
Weight Approx.1 lb 11 oz (760 g)
Safety Regulations JATE Technical standard (LAN)
UL2044, IEC60950-1 (CB)
VCCI (Class A), FCC (Class A), IC (Class A)
Emission: EN55022 (Class A) + EN50130-4
Immunity: EN55022 (Class A) + EN55024
Emission:AS/NZS CISPR22 (Class A)
Supplied Accessories CD-ROM (supplied programs) (1),Installation Manual (1),Template (1), Audio cable (1), I/O cable (1), BNC cable (1),
Power input cable (1),Screw M3 (1), Bracket (1),Wire rope (1), Safety regulations (1)
*1 Triple streaming (any combination with JPEG/H.264, including multiple streams of the same format)
*2 Monitor display ratio 4:3 *3 Version 1.4 or later *4 Default setting: OFF
