Sony SNC-RS44N User manual

SNC-RS Series
Network Rapid Dome Cameras
SNC-RS44N/RS44P, SNC-RS46N/RS46P,
SNC-RS84N/84P, SNC-RS86N/RS86P
sony.com/security
click: sony.com/sonysports
New Rapid Dome Cameras from Sony - High Visibility,
Feature Rich, and a Choice of Models
Sony introduces its new rapid dome cameras, the
SNC-RS Series, supporting H.264, MPEG-4, and JPEG
compression formats.
This newly developed line of high speed 360 degree
pan/tilt/zoom cameras offers a 210 degree tilt range to
cover above the horizon viewing applications.
Additional features include excellent dual streaming
capabilities in H.264/MPEG4; H.264/JPEG and
H.264/MPEG4 @ up to 30 fps in 768 x 576 resolution, CF
slot for 802.11g wireless (optional SNCA-CFW5) or
additional on board memory. Newly developed image
processing technologies like XDNR for noise reduction,
Visibility Enhancer (VE) enables the camera to be used
in a wide variety of applications.
With new features and excellent performance, the
SNC-RS Series is the perfect choice for a variety of
applications.
SNC-RS84N/RS84P
SNC-RS86N/RS86P
SNC-RS44N/RS44P
SNC-RS46N/RS46P
Quick Release
The camera can be detached quickly and easily.
Indoor
model
Outdoor
model
Press Release Button and pull
Remove Top Sunshade, Rotate Main Unit and pull
(Need to remove Locking screws)
• 18x, 36x Zoom
• XDNR (Excellent Dynamic Noise Reduction)
• Visibility Enhancer
• DEPA™ Advanced
• 210° Tilt
• Quick Release for Easy Installation
• hPoE (Compliant With IEEE802.3at*1)
• Triple Codec: H.264/MPEG-4/JPEG
• ONVIF Compliant
*1 Tentative
FEATURES
¡UJMUVQ¡UJMUVQ
¡UJMUXJUIFnJQ
FnJQBUCPUUPN
210° Tilt
The cameras cover a wide monitoring area with
great efficiency.
Visibility Enhancer
OFF ON
To suppress the extreme whites in a scene,and boost
dark areas in a scene at the same time dynamically to
produce clear images on the monitor.(Images simulated)
Preliminary

S-IP2041 (MK10585V2)
© 2009 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without written permissions is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony, IPELA and DEPA are trademark of Sony.
Windows XP and Vista are trademarks of Microsoft Corporation.
Pentium4 and Core2 Duo are trademarks of Intel Corporation.
Printed in USA (3/09)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/security
click: sony.com/sonysports
SPECIFICATIONS SYSTEM CONFIGURATIONS
Mounting arm with screw
(not supplied)
1. Rotate and Lock Coupler
2. Base Unit with Memory
Back-up
3. Main Unit with Built-in
Sunshade
4.Top Sunshade
Install in indicated numerical order
/FUXPSL
3FDPSEJOH4PGUXBSF
*.;/44FSJFT
3FDPSEJOH4FSWFS
/434FSJFT
8JSFMFTT
"DDFTT1PJOU 1$
$'8JSFMFTT$BSE
.%47/2+3526%),,!.#%2%#/2$%2.32
0/7%2 .%47/2+
4/$$'8
*&&&H
4/$344FSJFT
4/$344FSJFT
)%NPOJUPS
Unit: inches (mm)
DIMENSIONS
SNC-RS44N/RS44P
SNC-RS46N/RS46P
SNC-RS84N/RS84P
SNC-RS86N/RS86P
9 (226)
65/8(166)
61/8
(Ø154)
13 5/8(346)
93/8(ø238)
CONFIGURATION
SNC-RS84N/RS84P
SNC-RS86N/RS86P
SNC-RS46N/RS86N
(x36)
SNC-RS46P/RS86P
(x36)
SNC-RS44N/RS84N
(X18)
SNC-RS44P/RS84P
(X18)
Camera
Image device 1/4-type CCD with Exwave HAD®technology
Day/Night *1Yes
Wide-D *2Yes
Number of effective pixels
(H x V)
380,000 (768 x 494) 440,000 (752 x 582) 380,000 (768 x 494) 440,000 (752 x 582)
Electronic shutter speed 1 to 1/10,000 s
Auto gain control Auto/Manual (-3 to +28 dB)
Exposure control Auto, Full auto, Shutter-priority, Iris-priority, Manual, EV compensation, Backlight compensation
White balance mode Auto, Indoor, Outdoor, One-push WB, ATW, Manual
Lens type Auto-focus zoom lens
Zoom ratio 36x 18x
Horizontal viewing angle 1.7 to 57.8 degrees 2.8 to 48.0 degrees
Focal length f=3.4 to 122.4 mm f=4.1 to 73.8 mm
F-number F1.6 (wide), F4.5 (tele) F1.4 (wide), F3.0 (tele)
Pan angle 360 degrees endless rotation
Pan speed 400 degrees/s (max.)
Tilt angle 210 degrees (with e-flip)
Tilt speed 400 degrees/s (max.)
Codec image size (H x V) 720 x 480, 640 x 480,
320 x 240, (H.264,MPEG-4,
JPEG) (Tentative)
720 x 576, 640 x 480,
320 x 240, (H.264,MPEG-4,
JPEG) (Tentative)
720 x 480 , 640 x 480,
320 x 240, (H.264,MPEG-4,
JPEG) (Tentative)
720 x 576 , 640 x 480,
320 x 240, (H.264,MPEG-4,
JPEG) (Tentative)
Video compression format H.264, MPEG-4, JPEG
Maximum frame rate H264/MPEG-4/JPEG:
30 fps (720 x 480)
H264/MPEG-4/JPEG:
25 fps (720 x 576)
H264/MPEG-4/JPEG:
30 fps (720 x 480)
H264/MPEG-4/JPEG:
25 fps (720 x 576)
Audio
Audio compression G.711/G.726
Scene analytics
Simple activity detection No
Intelligent motion detection Yes (with built in Post Filter)
Intelligent object detection No
Network
Protocols TCP/IP, ARP, ICMP, HTTP, FTP (client/server), SMTP, DHCP, DNS, NTP, RTP/RTCP, SNMP (MIB-2) (Tentative)
Wireless network Yes (With Optional *3)
Number of clients 10 (Tentative)
Authentication IEEE802.1X
Analog video output
Signal system NTSC PAL NTSC PAL
Horizontal resolution 530 TV lines
S/N ratio more than 50 dB
Interface
Ethernet 10BASE-T/100BASE-TX (RJ-45)
Serial interface RS-232C/RS-422 (PELCO D protocol) (Tentative)
Card slots CF card x1
Analog video output Composite video (1Vp-p)
Sensor input x 4
Alarm output x 2
External microphone input Mini-jack (Monaural),MIC IN/LINE IN: 2.2k ohm, 2.45VDC plug-in power
Audio line output Mini-jack (Monaural), Max output level:1 Vrms
General
Weight Indoor Model:Approx.4 lb 10 oz (2.1 kg) Outdoor Model:Approx.9 lb 15 oz (4.5 kg)
Dimensions (ø x H) Indoor : 6 1/8x 9 inches (154 x 226 mm) Outdoor : 9 3/8x 13 5/8inches (238 x 346 mm)
Power requirements Indoor: hPoE (Tentative), AC24V, DC12V Outdoor:AC24V
Power consumption Indoor: 25 W max. Outdoor: 80 W max. (Tentative)
Operating temperature Indoor : 32 to 122 °F (0 to 50 °C) Outdoor : -40 to 122 °F (-40 to 50 °C)
Storage temperature -4 to 140 °F (-20 to 60 °C)
System requirements
Operating system Windows®XP,Windows Vista®
Processor CPU: Pentium4®3GHz,Intel Core2 Duo™ 2GHz or higher
Memory 1GB or more (Tentative)
Web browser Microsoft Internet Explorer Ver6.0 or higher
Supplied accessories
SNC-RS44N/RS44P, SNC-RS46N/RS46P: Base unit, Mounting bracket, Screws, Cables (Power input, BNC, I/O, Serial),
Installation manual,CD-ROM (User’s guide, SNC toolbox),
Mounting template,Wire rope
SNC-RS84N/RS84P, SNC-RS86N/RS86P: Base unit,Top sunshade, Rotate-and-lock coupling,Waterproof plug, Screws,
Installation manual,CD-ROM (User’s guide, SNC toolbox), Wire rope
*1 Removable IR Cut Filter. *2 DynaView™ Technology. *3 With optional SNCA-CFW5.
