Sony IPELA SNC-CS10 User manual

2-687-966-12 (1)
Network Camera
© 2006 Sony Corporation
SNC-CS10/CS11
User’s Guide
Software Version 1.0

Table of Contents
2
Table of Contents
Overview
Features .................................................................. 4
Phenomena Specific to CCD Image Sensors ....... 5
How to Use This User’s Guide .............................. 6
System Requirements ............................................ 6
Preparation
Connecting to a Computer or a Network ............ 7
Connecting the Camera to a Computer .............. 7
Connecting the Camera to a Local Network ...... 7
Assigning the IP Address to the Camera ............ 8
Assigning an IP address using the IP Setup
Program ............................................................ 8
When using Windows XP Service Pack 2 ........ 10
When using Windows Vista ............................. 12
Accessing the Camera Using the Web Browser 14
Basic Configuration by the Administrator ....... 16
Operating the Camera
Administrator and User ..................................... 17
Logging in to Homepage — Welcome Page ...... 18
Logging in as a User ........................................ 18
Displaying the setting window for the
administrator directly ..................................... 19
About Viewers .................................................. 19
Configuration of Main Viewer ........................... 20
Main menu ....................................................... 21
Camera Control Section ................................... 21
Monitor Image .................................................. 22
Controlling the Monitor Image .......................... 22
Monitoring the camera image .......................... 22
Zooming in the monitor image ......................... 23
Capturing a Monitor Image ............................... 23
Capturing a monitor image .............................. 23
Saving the captured image ............................... 24
Sending an Image File ......................................... 24
Sending a Monitor Image via e-Mail ............... 24
Sending a Monitor Image to an FTP Server ..... 24
Recording a Still Image in the Built-in Memory of
the Camera ........................................................... 25
Controlling Alarm output ................................... 25
Switching TCP/UDP Transmission Mode ......... 26
Administrating the Camera
Basic Operations of Administrator Menu .........27
How to setup the Administrator menu ..............27
Configuration of Administrator menu ..............28
Configuring the System — System menu ..........29
System Tab ........................................................29
Date & time Tab ................................................30
Initialize Tab .....................................................31
System log Tab .................................................31
Access log tab ...................................................32
Setting the Camera Image and Audio
— Camera Menu ..................................................32
Common Tab ....................................................32
Picture Tab ........................................................34
MPEG4 Tab ......................................................36
JPEG Tab ..........................................................36
Reset Tab ..........................................................37
Configuring the Network — Network Menu .....37
Network Tab .....................................................37
PPPoE Tab - Setting of PPPoE Connection ......38
Dynamic IP address notification Tab — Notifying
the IP Address .................................................39
Setting the User — User Menu ...........................41
Setting the Security — Security Menu ...............42
Sending an Image via mail
— e-Mail (SMTP) Menu ......................................43
Common Tab — Setting the e-Mail (SMTP)
Function ..........................................................43
Alarm sending Tab — Setting the mail sending
mode when detecting the alarm ......................44
Periodical sending Tab — Setting the periodical
mail sending mode ..........................................45
Sending Images to FTP Server
— FTP client Menu ..............................................46
Common Tab — Setting the FTP Client Function
.........................................................................46
Alarm sending Tab — Setting the FTP client
action when detecting the alarm .....................46
Periodical sending Tab — Setting the Periodical
FTP Client Activity ........................................47
Recording Images in Memory
— Image memory Menu ......................................48
Common Tab — Setting the Image memory
Function ..........................................................48
Alarm recording Tab — Setting the Image
Memory Function when Detecting the Alarm 49
Periodical recording Tab — Setting the Periodical
recording mode ...............................................50
Folder structure of image memory ...................51
Downloading Images from the Camera
— FTP server Menu ............................................52
Setting the Alarm Output
— Alarm output Menu ........................................52
Setting the Operations from the Viewer Page
— Trigger Menu ...................................................53

Table of Contents 3
Setting the Schedule
— Schedule Menu ................................................ 55
Setting the Alarm Buffer
— Alarm buffer Menu ........................................ 55
Setting the Motion Detection Function
— Motion detection Menu .................................. 56
Setting the Motion Detection Area, Sensitivity and
Threshold level ............................................... 57
Others
Using the Supplied Setup Program .................... 58
Starting the Setup Program .............................. 58
Bandwidth Control Tab .................................... 58
Date time Tab ................................................... 59
PPPoE Tab ........................................................ 59
Rebooting the Camera ...................................... 60
Using the SNC audio upload tool — Transmitting
Audio to Camera (SNC-CS11 only) ................... 60
Installing the SNC audio upload tool ............... 60
Connecting the Camera to the Computer ......... 61
Using the SNC audio upload tool ..................... 61
Using the SNC video player
— Playing Video File Recorded on Camera ..... 66
Downloading the SNC video player ................. 66
Using the SNC video player ............................. 66
Using the Custom Homepage Installer .............. 67
Uploading the homepage to the camera using the
Custom Homepage Installer ........................... 67
Assigning the IP Address to the Camera Using
ARP Commands .................................................. 69
Using the SNMP ................................................... 70
1. Inquiry Commands ...................................... 70
2. Setting Commands ...................................... 70
Pin Assignment of I/O Port ................................. 72
Attaching a CS-mount Lens ............................... 73
Attachment of the auto-iris lens connector
(optional) ........................................................ 73
Detaching the Lens ........................................... 73
Attaching the Lens ........................................... 74
Glossary ................................................................ 74
Index ..................................................................... 77

Overview
Features
4
Overview Features
This product is a compact boxy network camera of lens
changing type equipped with concentrated features
necessary for a monitoring camera. The camera has the
following features:
• A boxy body which is the most appropriate for
security use.
• Providing an image of an adequate brightness both
indoors and outdoors by using with the auto-iris lens.
• Adopting 1/4-inch elementary colors filter progressive
scan CCD. Providing high quality images in color
reappearance, resolution and sensitivity.
• Corresponding to variable power inputs, and the
power cord wiring is easy in installation.
• SNC-CS10: Two power inputs of AC 24V/DC 12V
• SNC-CS11: Three power inputs of AC 24V/DC 12V/
PoE
• Equipped with a video output terminal and a flange
focus adjusting function. It is easy to adjust the angle
of view and the focus.
• Switchable video compressing formats, MPEG4 and
JPEG. Enables you to plan variable monitoring styles.
• Equipped with the function to stay the video bit rate
constant. You can accurately estimate the network
occupation band and the memory size of the recording
equipment.
• Audio can be sent and received (SNC-CS11 only).
• Supplied with the low aberration vari-focal lens
adopting aspheric lens (SNC-CS11 only).
• You should keep in mind that the images or audio
you are monitoring may be protected by privacy and
other legal rights, and the responsibility for making
sure you are complying with applicable laws is yours
alone.
• Access to the images and audio is protected only by
a user name and the password you set up. No further
authentication is provided nor should you presume
that any other protective filtering is done by the
service. Since the service is Internet-based, there is a
risk that the image or audio you are monitoring can
be viewed or used by a third-party via the network.
• SONY IS NOT RESPONSIBLE, AND ASSUMES
ABSOLUTELY NO LIABILITY TO YOU OR
ANYONE ELSE, FOR SERVICE
INTERRUPTIONS OR DISCONTINUATIONS OR
EVEN SERVICE CANCELLATION. THE
SERVICE IS PROVIDED AS-IS, AND SONY
DISCLAIMS AND EXCLUDES ALL
WARRANTIES, EXPRESS OR IMPLIED, WITH
RESPECT TO THE SERVICE INCLUDING, BUT
NOT LIMITED TO, ANY OR ALL IMPLIED
WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, OR
THAT IT WILL OPERATE ERROR-FREE OR
CONTINUOUSLY.
• Always make a test recording, and verify that it was
recorded successfully. SONY WILL NOT BE
LIABLE FOR DAMAGES OF ANY KIND
INCLUDING, BUT NOT LIMITED TO,
COMPENSATION OR REIMBURSEMENT ON
ACCOUNT OF FAILURE OF THIS UNIT OR ITS
RECORDING MEDIA, EXTERNAL STORAGE
SYSTEMS OR ANY OTHER MEDIA OR
STORAGE SYSTEMS TO RECORD CONTENT
OF ANY TYPE.
• Always verify that the unit is operating properly
before use. SONY WILL NOT BE LIABLE FOR
DAMAGES OF ANY KIND INCLUDING, BUT
NOT LIMITED TO, COMPENSATION OR
REIMBURSEMENT ON ACCOUNT OF THE
LOSS OF PRESENT OR PROSPECTIVE
PROFITS DUE TO FAILURE OF THIS UNIT,
EITHER DURING THE WARRANTY PERIOD
OR AFTER EXPIRATION OF THE WARRANTY,
OR FOR ANY OTHER REASON WHATSOEVER.
• If you lose data by using this unit, SONY accepts no
responsibility for restoration of the data.

Overview
Phenomena Specific to CCD Image Sensors 5
NOTICE TO USERS
© 2006 Sony Corporation. All rights reserved. This
manual or the software described herein, in whole or in
part, may not be reproduced, translated or reduced to
any machine readable form without prior written
approval from Sony Corporation.
SONY CORPORATION PROVIDES NO
WARRANTY WITH REGARD TO THIS MANUAL,
THE SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN AND HEREBY EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO THIS
MANUAL, THE SOFTWARE OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL SONY
CORPORATION BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING OUT OF
OR IN CONNECTION WITH THIS MANUAL, THE
SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.
Sony Corporation reserves the right to make any
modification to this manual or the information contained
herein at any time without notice.
The software described herein may also be governed by
the terms of a separate user license agreement.
• “IPELA” and are trademarks of Sony
Corporation.
• Microsoft, Windows, Internet Explorer and MS-DOS
are registered trademarks of Microsoft Corporation in
the United States and/or other countries.
• Java is a trademark of Sun Microsystems, Inc. in the
United States and other countries.
• Intel and Pentium are registered trademarks of Intel
Corporation or its subsidiaries in the United States and
other countries.
• Adobe, Acrobat and Adobe Reader are trademarks of
Adobe Systems Incorporated in the United States and/
or other countries.
All other company and product names are trademarks or
registered trademarks of the respective companies or
their respective makers.
Phenomena Specific to
CCD Image Sensors
The following phenomena that may appear in images are
specific to CCD (Charge Coupled Device) image
sensors. They do not indicate malfunctions.
White flecks
Although the CCD image sensors are produced with
high-precision technologies, fine white flecks may be
generated on the screen in rare cases, caused by cosmic
rays, etc.
This is related to the principle of CCD image sensors
and is not a malfunction.
The white flecks especially tend to be seen in the
following cases:
• when operating at a high environmental temperature
• when you have raised the gain (sensitivity)
• when using the slow shutter
Vertical smear
When an extremely bright object, such as a strong
spotlight or flashlight, is being shot, vertical tails may be
produced on the screen, or the image may be distorted.
Aliasing
When fine patterns, stripes, or lines are shot, they may
appear jagged or flicker.
Monitor screen Vertical thin tails shown on
the image
Bright object (e.g. strong
spotlight, strong reflected
light, flashlight, the sun)

Overview
How to Use This User’s Guide / System Requirements
6
How to Use This User’s
Guide
This User’s Guide explains how to operate the SNC-
CS10 or SNC-CS11 Network Camera from a computer.
The User’s Guide is written to be read on the computer
display.
As this section gives tips on using the User’s Guide, read
it before you operate the camera.
Jumping to the related page
When you read the User’s Guide on the computer
display, click on the sentence to jump to the related page.
Software display examples
Note that the displays shown in the User’s Guide are
explanatory examples. Some displays may be different
from the ones which appear as you operate the
application software.
Printing the User’s Guide
Depending on your system, certain displays or
illustrations in the User’s Guide, when printed out, may
differ from those as portrayed on your screen.
Installation Manual (printed matter)
The supplied Installation Manual describes the names
and functions of parts and controls of the Network
Camera, connecting examples and how to set up the
camera. Be sure to read the Installation Manual before
operating.
System Requirements
These are the requirements for the computer that
displays the image or controls the camera.
Processor
Intel Pentium III, 1 GHz or higher (Intel Pentium 4, 2.4
GHz or higher recommended)
RAM
256 MB or more
OS
Microsoft Windows 2000, Windows XP, Windows Vista
Web browser
Microsoft Internet Explorer Ver. 6.0 or later

Preparation
Connecting to a Computer or a Network 7
Preparation
The Preparation section explains what the administrator
has to prepare for monitoring the images after
installation and connection of the camera.
Connecting to a
Computer or a Network
To connect to the computer, use a commercially
available network cable (cross cable).
To connect to the network, use a commercially available network
cable (straight cable).
Connecting the Camera to a
Computer
Using a commercially available network cable (cross),
connect the LAN port on the camera to the network
connector of a computer.
Connecting the Camera to a Local
Network
Using a commercially available network cable, connect
the LAN port on the camera to a hub in the network.
LAN
TEST OUT
– +
DC 12V
12
AC 24V
SEE INSTRUCTION MANUAL
CLASS 2 WIRING
1
NETWORK
NTSC PAL
POWER
234
SNC-CS11 (rear)
Network cable
(cross, not supplied)
Network
connector
Computer
LAN
LAN
TEST OUT
– +
DC 12V
12
AC 24V
SEE INSTRUCTION MANUAL
CLASS 2 WIRING
1
NETWORK
NTSC PAL
POWER
234
SNC-CS11 (rear)
Network cable
(straight, not
supplied)
Hub
Network
10BASE-T/
100BASE-TX
LAN

Preparation
Assigning the IP Address to the Camera
8
Assigning the IP
Address to the Camera
To connect the camera to a network, you need to assign
a new IP address to the camera when installing the
camera for the first time.
You can assign an IP address in two ways:
• Using the setup program stored in the supplied CD-
ROM (see page 8)
• Using the ARP (Address Resolution Protocol)
commands (see page 69)
This section explains how to assign an IP address to the
camera using the supplied setup program and how to
configure the network.
Before starting, connect the camera, referring to
“Connecting to a Computer or a Network” on page 7.
Consult the administrator of the network about the
assigned IP address.
Notes
• The IP Setup Program may not operate correctly if you
use a personal firewall or antivirus software in your
computer. In that case, disable the software or assign
an IP address to the camera using another method. For
example, see “Assigning the IP Address to the Camera
Using ARP Commands” on page 69.
• If you are using Windows XP Service Pack 2 or
Windows Vista, disable the Windows Firewall
function. Otherwise the IP Setup Program will not
operate correctly. For the setting, see “Configuring
Windows Firewall” in “When using Windows XP
Service Pack 2” on page 11 or “Configuring Windows
Firewall” in “When using Windows Vista” on
page 13.
Assigning an IP address using the
IP Setup Program
1 Insert the CD-ROM in your CD-ROM drive.
A cover page appears automatically in your Web
browser.
If it does not appear automatically in the Web
browser, double-click on the index.htm file on the
CD-ROM.
When you are using Windows Vista, pop-up
“AutoPlay” may appear. For details, “Installing
software” in “When using Windows Vista” on
page 12.
2 Click the Setup icon of IP Setup Program.
The “File Download” dialog opens.
When you are using Windows XP Service Pack 2 or
Windows Vista, a message regarding the active
contents may appear. For details, see “Installing
software” in “When using Windows XP Service
Pack 2” on page 10 or “Installing software” in
“When using Windows Vista” on page 12.
3 Click Open.
Note
If you click “Save this program to disk” on the “File
Download” dialog, you will not be able to perform
set up correctly. Delete the downloaded file, and
click the Setup icon again.
4 Install the IP Setup Program on your computer
using the wizard.
If the Software License Agreement is displayed,
read it carefully and click Accept to continue with
the installation.
5 Start the IP Setup Program.
When you are using Windows Vista, message “User
Account Control – An unidentified program wants
access to your computer” may appear. In this case,
click Allow.
The program detects the network cameras
connected to the local network and lists them on the
Network tab window.

Preparation
Assigning the IP Address to the Camera 9
6 Click on the camera in the list to which you want to
assign a new IP address.
The network settings for the selected camera are
displayed.
7 Set the IP address.
To obtain the IP address automatically from a
DHCP server:
Select Obtain an IP address automatically.
The IP address, Subnet mask and Default gateway
are assigned automatically.
To specify the IP address manually:
Select Use the following IP address, and type the
IP address, Subnet mask and Default gateway in the
relevant boxes.
Note
When you select Obtain an IP address
automatically, make sure that the DHCP server is
operating on the network.
8 Set the DNS server address.
To obtain the DNS server addresses
automatically:
Select Obtain DNS server address automatically.
To specify the DNS server addresses manually:
Select Use the following DNS server address, and
type the Primary DNS server address and
Secondary DNS server address in the relevant
boxes.
Note
The Third DNS server address and Fourth DNS
server address are invalid for this camera.
9 Set the HTTP port No.
Normally, select 80 for the HTTP port No. To use
another port number, type the port number between
1024 and 65535 in the text box.
10 Type the Administrator name and Administrator
password.
The factory settings of both items are “admin.”
Note
You cannot change the Administrator name and
Administrator password in this step. To change
these items, see “Setting the User — User Menu”
on page 41.
11 Confirm that all items are correctly set, then click
OK.
If “Setting OK” is displayed, the IP address is
correctly assigned.
12 To access the camera directly, double-click the
camera name in the list.

Preparation
Assigning the IP Address to the Camera
10
Tip
The factory setting of the camera network is as
follows.
IP address: 192.168.0.100
Subnet mask: 255.0.0.0
The welcome page of the network camera is displayed in
the Web browser.
Note
If the IP address is not set correctly, the welcome page
does not appear after step 12. In this case, try to set the
IP address again.
When using Windows XP Service
Pack 2
Installing software
A warning message regarding the active contents may
appear when you install software such as IP Setup
Program from CD-ROM. In this case, operate as
follows:
Example: In case of IP Setup Program
If message “Internet Explorer” appears, click Yes .
If message “File Download – Security Warning”
appears, click Run.
Note
If you select Save in the “File Download – Security
Warning” dialog, you will not be able to perform
installation correctly. Delete the downloaded file, and
click the Setup icon again.
If message “Internet Explorer – Security Warning”
appears, click Run.
The software installation starts.
Installing ActiveX Control
During installation of ActiveX Control, the information
bar or “Security Warning” may appear. In this case,
operate as follows:
If message “Information Bar” appears, click OK.

Preparation
Assigning the IP Address to the Camera 11
If the information bar appears, click on the bar and select
Install ActiveX Control….
If “ Internet Explorer – Security Warning” appears, click
Install.
The installation of ActiveX Control starts. When
installation is completed, the main viewer or the Motion
detection menu appears.
Configuring Windows Firewall
The IP Setup Program or SNC audio upload tool may
not operate correctly depending on the configuration of
Windows Firewall. (No cameras are shown in the list
even if they are detected.) In this case, confirm the
Windows Firewall configuration as follows:
Example: In case of IP Setup Program
1 Select Control Panel from the Start menu of
Windows.
2 Select Security Center of the working field.
3 Select Windows Firewall and select Off in the
Windows Firewall dialog.
The cameras will be displayed in the list.
If you want to keep Windows Firewall On, continue
with the following steps.
4 Select the “Exceptions” tab.
5 Select Add Program….

Preparation
Assigning the IP Address to the Camera
12
6 In the Add Program dialog, select IP Setup
Program and click OK.
Then the IP Setup Program is added to the
Programs and Services list.
7 Click OK.
When the above procedure is completed, the
cameras connected in the local network are
displayed in the IP Setup Program.
When using Windows Vista
Installing software
A warning message regarding the active contents may
appear when you install software such as IP Setup
Program from CD-ROM. In this case, operate as
follows:
Example: In case of IP Setup Program
If pop-up “AutoPlay” appears when a CD-ROM is
inserted into the CD-ROM drive, click Install or run
program.
Note
If you click Open folder to view files, Web browser will
not open automatically. In this case, double-click the
“index.htm” file in the CD-ROM.
If message “Internet Explorer” appears, click Ye s.
If message “File Download – Security Warning”
appears, click Run.
Note
If you select Save in the “File Download – Security
Warning” dialog, you will not be able to perform

Preparation
Assigning the IP Address to the Camera 13
installation correctly. Delete the downloaded file, and
click the Setup icon again.
If message “Internet Explorer – Security Warning”
appears, click Run.
If message “User Account Control – An unidentified
program wants access to your computer” appear, click
Allow.
The software installation starts.
Starting the software
When you start software such as IP Setup Program,
message “User Account Control – An unidentified
program wants access to your computer” may appear. In
this case, click Allow.
Installing ActiveX Control
During installation of ActiveX Control, the information
bar or “Security Warning” may appear. In this case,
operate as follows:
If message “Information Bar” appears, click OK.
If the information bar appears, click on the bar and select
Install ActiveX Control….
If message “User Account Control – Windows needs
your permission to continue” appear, click Continue.
If “Internet Explorer – Security Warning” appears, click
Install.
The installation of ActiveX Control starts. When
installation is completed, the main viewer or the Motion
detection menu appears.
Configuring Windows Firewall
The IP Setup Program or SNC audio upload tool may
not operate correctly depending on the configuration of
Windows Firewall. (No cameras are shown in the list
even if they are detected.) In this case, confirm the
Windows Firewall configuration as follows:
Example: In case of IP Setup Program
1 Select Control Panel from the Start menu of
Windows.
2 Click Windows Firewall.
3 Select Turn Windows Firewall on or off.
“User Account Control – Windows needs your
permission to continue” may appear. In this case,
click Continue.
4 Select Off in the “General” tab.

Preparation
Accessing the Camera Using the Web Browser
14
The cameras will be displayed in the list.
If you want to keep Windows Firewall On, continue
with the following steps.
5 Select the “Exceptions” tab.
6 Select Add Program….
7 If the Add Program dialog appears, select IP Setup
Program and click OK.
Then the IP Setup Program is added to the Program
or port list.
8 Click OK.
When the above procedure is completed, the
cameras connected in the local network are
displayed in the IP Setup Program.
Accessing the Camera
Using the Web Browser
When the IP address has been assigned to the camera,
check that you can actually access the camera using the
Web browser installed in your computer.
Use Internet Explorer as the Web browser.
1 Start the Web browser on the computer and type the
IP address of the camera in the URL box.
The welcome page of the network camera is
displayed in the Web browser.
2 Click Enter.
The main viewer is displayed.
SNC-CS11

Preparation
Accessing the Camera Using the Web Browser 15
SNC-CS10
When the main viewer is correctly displayed, the IP
address assignment is completed.
When the main viewer of the camera is
displayed for the first time
When you click Enter, “Security Warning” is displayed.
When you click Ye s , ActiveX control is installed and the
main viewer is displayed.
Notes
• If Automatic configuration is enabled in the Local
Area Network (LAN) Settings of Internet Explorer,
the image may not be displayed. In that case, disable
Automatic configuration and set the Proxy server
manually. For the setting of the Proxy server, consult
your network administrator.
• When you install ActiveX Control, you should be
logged in to the computer as Administrator.
• When you are using Windows XP Service Pack 2 or
Windows Vista, the information bar or “Security
Warning” may appear as you click Enter. For details,
see “Installing ActiveX Control” in “When using
Windows XP Service Pack 2” on page 10 or
“Installing ActiveX Control” in “When using
Windows Vista” on page 13.
Tip
Every page of this software is optimized as display
character size Medium for Internet Explorer.
To display the welcome page and the
main viewer correctly
To operate the welcome page and the main viewer
correctly, set the security level of the Internet Explorer
to Medium or lower, as follows:
1 Select Tools from the menu bar for Internet
Explorer, then select Internet Options and click
the Security tab.
2 Click the Internet icon (when using the camera via
the Internet) or Local intranet icon (when using
the camera via a local network).
3 Set the slider to Medium or lower. (If the slider is
not displayed, click Default Level.)
When using antivirus software, etc. on
the computer
• When you use antivirus software, security software,
personal firewall or pop-up blocker on your computer,
the camera performance may be reduced, for example,
the frame rate for displaying the image may be lower.
• The Web page displayed when you log in to the
camera uses JavaScript. The display of the Web page
may be affected if you use antivirus software or other
software described above on your computer.

Preparation
Basic Configuration by the Administrator
16
Basic Configuration by
the Administrator
You can monitor the image of the camera by logging in
with the initial condition of this network camera. You
can also set various functions according to the install
position, network condition or purpose of the camera.
We recommend you configure the following items
before monitoring the image from the camera.
Setting contents Administrator menu
Select the white balance mode according to the installing position (under tungsten
bulb or daylight).
White balance (page 34)
Set the format of the image sent from the camera (MPEG 4 or JPEG). Video mode (page 32)
Select the equipped lens. Lens type (page 34)
Select the brightness of the image sent from the camera. Shutter mode (page 34)
Exposure compensation (page 35)
Select the quality of the image sent from the camera. MPEG4 Tab (page 36)
JPEG Tab (page 36)
Select the size of the image sent from the camera. Image size (page 33)
Select weather the audio from the camera microphone is sent or not. (SNC-CS11
only)
Microphone (page 33)
Accord date and time of the camera with those of the computer. Date & time Tab (page 30)
Make the setting for sending the monitor image attached to a mail. e-Mail (SMTP) Menu (page 43)
Set the access right of the user for the camera. User Menu (page 41)

Operating the Camera
Administrator and User 17
Operating the Camera
The Operating the Camera section explains how to
monitor the image from the camera using the Web
browser. Use Internet Explorer as the Web browser.
The functions of the camera should be set by the
Administrator. For setting the camera, see
“Administrating the Camera” on page 27.
Administrator and User
This network camera classifies the people who log in as
the Administrator and the User.
The Administrator can use all functions of this network
camera including camera setting. The functions the
User can use are monitoring the image from the camera,
and controlling the camera. The Viewer mode setting
restricts the user's access right, and the user is classified
as the one of three types.
Note
The audio can be monitored only in SNC-CS11.
Each type of the user can use the following functions.
zUsable function
– Not usable function
1) This function is usable with the Java applet viewer.
2) This function is not usable with the Java applet
viewer.
The access rights of the administrator and the user can
be set in “Setting the User — User Menu” on page 41.
Function Administrator User
Full Light View
Monitor a live
z zzz
Watch date and
time
z zzz
Control the frame
rate (Usable only
when JPEG mode
is selected)
zz––
Control the image
view size
zzz–
Zoom a image by
the digital zoom
zzz–
Save the still image
in the computer
zzz–1)
Send an image file
to the FTP server
zz––
Send an image
attached to a mail
zz––
Record an image
on the inside
memory of the
camera
zz––
Control the Alarm
out of the I/O port
on the camera main
unit
zz––
Switch the TCP/
UDP transmission
mode (Available in
MPEG4 mode
only)
z2) z2) ––
Control the audio
(SNC-CS11 only)
z zzz
Control the setting
menu
z–––
Function Administrator User
Full Light View

Operating the Camera
Logging in to Homepage — Welcome Page
18
Logging in to Homepage
— Welcome Page
Logging in as a User
1 Start the Web browser on the computer and type the
IP address of the camera you want to monitor.
The welcome page of the network camera is
displayed in the Web browser.
2 Select the viewer.
The usable viewers differ depending on the Video
mode (page 32) of the camera.
When the Video mode is set to MPEG4, you can
only select ActiveX viewer, and may not select
other viewers. (MPEG4 is default. See illustration
on Step 1 above.)
When the Video mode is set to JPEG, you can
select ActiveX viewer or Java applet viewer.
For details, see “About Viewers” on page 19.
Welcome page when the Video mode is
JPEG
3 Select the viewer language.
Click English or Japanese at the bottom of the
welcome page.
4 Click Enter.
The main viewer appears.
With the ActiveX viewer (MPEG4)
With the Java applet viewer
Control the camera from the main viewer.
Note
If the Welcome page does not activate correctly, the
security level of the Internet Explorer may be set to
Medium or higher. See “To display the welcome page
and the main viewer correctly” on page 15 and check the
security level.

Operating the Camera
Logging in to Homepage — Welcome Page 19
Displaying the setting window for
the administrator directly
When the administrator sets the camera functions, the
setting window can be displayed directly from the
welcome page.
1 Select the viewer language on the welcome page.
Click English or Japanese at the bottom of the
welcome page.
2 Click Setting on the welcome page.
The following dialog appears.
3 Enter the user name and password for
Administrator, then click OK.
The user name “admin” and the password “admin”
are set at the factory for the Administrator. You can
change them in the User menu of the Administrator
menu (see page 41).
The Administrator mode menu appears in another
window.
About Viewers
You can use the following viewer according to the Video
mode setting in the Camera menu of the Administrator
menu (page 32).
ActiveX viewer
This viewer can monitor the image in both MPEG4 and
JPEG video modes.
You must install this viewer when you access to the main
viewer at the first time.
When you display the main viewer of the
camera for the first time
When you log in the network camera using ActiveX
viewer for the first time (clicking Enter to enter the
main viewer), the Security Warning appears. Click Ye s
and install ActiveX Control. You can use all the
functions of the viewer by using ActiveX Control.
Java applet viewer
You can select this viewer when the camera Video mode
is set to JPEG. The frame rate is lower than the ActiveX
viewer.
The Java applet viewer operates only when Java is
installed and Java (Sun) is enabled. If it does not operate
correctly, check whether the effective Java version has
been installed successfully and Java (Sun) is enabled.
Effective versions: Java Plug-in Ver. 1.6.0_01
To check the Java version
Select Tools from the menu bar of Internet Explorer,
then select Internet Options and click the Advanced
mode tab. Check whether the version of Java displayed
for Java (Sun) is one of the versions specified above. If
Java (Sun) is not displayed, it means that Java is not
installed. You need to install Java.
To enable Java Plug-in
Check “Use JRE 1.6.0_01 for <applet> (requires
restart)” in “Java (Sun)”.
To install Java Plug-in
Download Java 2 Runtime Environment, Standard
Edition (JRE) from the homepage of Sun Microsystems,
Inc., and install it by following the instructions on the
installer.
Notes
• If Automatic configuration is enabled in the Local
Area Network (LAN) Settings of Internet Explorer,
the camera image may not be displayed. In that case,
disable Automatic configuration and set the Proxy
server manually. For the setting of the Proxy server,
consult your network administrator.

Operating the Camera
Configuration of Main Viewer
20
• When you install ActiveX Control, you should be
logged in to the computer as the Administrator.
Tip
Every page of this software is optimized for display
character size Medium for Internet Explorer.
Configuration of Main
Viewer
This section explains the functions of the parts and
controls of the main viewer. For a detailed explanation
on each part or control, see the specified pages.
Main viewer
MPEG4
JPEG
Camera control
section
Monitor image
section
Main menu
Camera control
section
Monitor image
section
Main menu
