SERVICE MANUAL
Sony Corporation
Published by Sony EMCS (Malaysia) PG Tec
SPEAKER SYSTEM
• SS-SHAKE33 is front speakers in SHAKE-33.
• SS-SHAKE55 is front speakers in SHAKE-55.
• SS-SHAKE77 is front speakers in SHAKE-77.
• SS-SHAKE44 is front speakers in SHAKE-44D.
• SS-SHAKE66 is front speakers in SHAKE-66D.
• SS-SHAKE88 is front speakers in SHAKE-88D.
• SS-SHAKE33P is the package speaker of front speakers in SHAKE-33.
• SS-SHAKE55P is the package speaker of front speakers in SHAKE-55.
• SS-SHAKE77P is the package speaker of front speakers in SHAKE-77.
• SS-SHAKE88P is the package speaker of front speakers in SHAKE-88.
Ver. 1.3 2014.07
9-890-649-04
2014G80-1
© 2014.07
US Model
SS-SHAKE33/SHAKE55
AEP Model
UK Model
SS-SHAKE33
Russian Model
SS-SHAKE66D
E Model
SS-SHAKE33/SHAKE44D/SHAKE55/
SHAKE66D/SHAKE77/SHAKE88D
Argentina Model
Mexican Model
SS-SHAKE33/SHAKE55/SHAKE77
Australian Model
SS-SHAKE77
Malaysia Model
SS-SHAKE44D/SHAKE66D/SHAKE88D
Saudi Arabia Model
South African Model
Thai Model
SS-SHAKE44D/SHAKE88D
SS-SHAKE33/SHAKE44 SS-SHAKE55/SHAKE66 SS-SHAKE77/SHAKE88
• JIG
When disassembling the set, use the following jig (for front panel
removal).
Part No.: J-2501-238-A JIG FOR SPEAKER REMOVAL
SPECIFICATIONS
Speakers
SS-SHAKE88 for SHAKE-88D
Speaker system
4-way, Sound Pressure Horn and Bass
Reflex
Speaker unit
Woofers: 200 mm, cone type
Tweeters: 25 mm, horn type
Mid speakers: 100 mm, cone type
Subwoofers: 380 mm, cone type
Rated impedance
Woofers/mid speakers/tweeters:
4 ohms
Subwoofers: 8 ohms
Dimensions (w/h/d) (Approx.)
510 mm × 783 mm × 450 mm
Mass (Approx.)
35.0 kg
Quantity: 2 pieces
SS-SHAKE66 for SHAKE-66D
Speaker system
3-way, Sound Pressure Horn and Bass
Reflex
Speaker unit
Woofers: 200 mm, cone type
Tweeters: 25 mm, horn type
Subwoofers: 350 mm, cone type
Rated impedance
Woofers/tweeters: 4 ohms
Subwoofers: 10 ohms
Dimensions (w/h/d) (Approx.)
490 mm × 660 mm × 363 mm
Mass (Approx.)
26.0 kg
Quantity: 2 pieces
SS-SHAKE44 for SHAKE-44D
Speaker system
3-way, Sound Pressure Horn
Speaker unit
Woofers: 300 mm, cone type
Tweeters: 25 mm, horn type
Mid speakers: 100 mm, cone type
Rated impedance
Mid speakers/tweeters: 5 ohms
Woofers: 4 ohms
Dimensions (w/h/d) (Approx.)
410 mm × 610 mm × 376 mm
Mass (Approx.)
18.5 kg
Quantity: 2 pieces
SS-SHAKE77 for SHAKE-77
Speaker system
4-way, Sound Pressure Horn and Bass
Reflex
Speaker unit
Woofers: 200 mm (7 7/8in), cone type
Tweeters: 25 mm (1 in), horn type
Mid speakers: 100 mm (4 in), cone
type
Subwoofers: 380 mm (15 in), cone
type
Rated impedance
Woofers/mid speakers/tweeters:
4 ohms
Subwoofers: 8 ohms
Dimensions (w/h/d) (Approx.)
510 mm × 783 mm × 450 mm
(20
1/8in × 30 7/8in × 17 3/4in)
Mass (Approx.)
35.0 kg (77 lb 3 oz)
Quantity: 2 pieces
SS-SHAKE55 for SHAKE-55
Speaker system
3-way, Sound Pressure Horn and Bass
Reflex
Speaker unit
Woofers: 200 mm (7 7/8in), cone type
Tweeters: 25 mm (1 in), horn type
Subwoofers: 350 mm (14 in), cone
type
Rated impedance
Woofers/tweeters: 4 ohms
Subwoofers: 10 ohms
Dimensions (w/h/d) (Approx.)
490 mm × 660 mm × 363 mm
(19
3/8in × 26 in × 14 3/8in)
Mass (Approx.)
26.0 kg (57 lb 6 oz)
Quantity: 2 pieces
SS-SHAKE33 for SHAKE-33
Speaker system
3-way, Sound Pressure Horn
Speaker unit
Woofers: 300 mm (12 in), cone type
Tweeters: 25 mm (1 in), horn type
Mid speakers: 100 mm (4 in), cone type
Rated impedance
Mid speakers/tweeters: 5 ohms
Woofers: 4 ohms
Dimensions (w/h/d) (Approx.)
410 mm × 610 mm × 376 mm
(16
1/4in × 24 1/8in × 14 7/8in)
Mass (Approx.)
18.5 kg (40 lb 13 oz)
Quantity: 2 pieces
Design and specifications are subject to
change without notice.
SS-SHAKE33/SHAKE44/SHAKE55/
SHAKE66/SHAKE77/SHAKE88
SS-SHAKE33P/SHAKE55P/SHAKE77P/SHAKE88P

2
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
SECTION 1
DIAGRAMS
For Schematic Diagrams.
Note:
• C: panel designation.
•Signal path
F: AUDIO
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
For Printed Wiring Boards.
Note:
• X: Parts extracted from the component side.
• : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
1-1. PRINTED WIRING BOARD – SPK LED Board (SHAKE33/SHAKE44/SHAKE55/SHAKE66) –
• : Uses unleaded solder.
1-2. SCHEMATIC DIAGRAM – SPK LED Board (SHAKE33/SHAKE44/SHAKE55/SHAKE66) –
1
A
B
C
D
2345678
JL2702
JL2701
JR
JR2701
JR
JR2702
JR
JR2703
14
CN2700
D2700
JL2700 JL2703
SPK LED BOARD
(SHAKE33/SHAKE44/SHAKE55/SHAKE66)
(COMPONENT SIDE)
SPK LED BOARD
(SHAKE33/SHAKE44/SHAKE55/SHAKE66)
(CONDUCTOR SIDE)
LED SPEAKER
L/R
1-888-253-
11
(11) 1-888-253-
11
(11)
GA
RA
BA
GK
RK
BK
D2700
GK
BK
RK
GA
BA
RA
1
A
B
C
D
2345678
SPK LED BOARD
SHAKE33/SHAKE44/
SHAKE55/SHAKE66
R
G
B
LED
SPEAKER
L/R
M+5V
RED_LED
BLUE_LED
GREEN_LED
1
2
3
4
JL2702
JL2700
JL2701
JL2703
4P
CN2700
SMLVN6RGB1U17QYB
D2700
Ver. 1.1

3
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
1-3. PRINTED WIRING BOARDS – SPK LED (SHAKE77/SHAKE88) AND SPLITTER Board (SHAKE77/SHAKE88) –
• : Uses unleaded solder.
1
A
B
C
D
E
F
G
H
I
J
K
2345678
D1800
JL1806
JL1807
JL1805
JL1804
R1800 R1801 R1802
14
CN1803
D1800
JL1807
16
CN1803
JL1811
JL1812JL1810
JL1808
JL1809
JL1803
JL1801
JL1800
JL1802
JL1804
JL1806
JL1805
14
CN1800
14
CN1801
16
CN1802
GA
RA
BA
GK
RK
BK
GK
BK
RK
GA
BA
D1800
RA
GA
RA
BA
GK
RK
BK
GK
BK
RK
GA
BA
D1800
RA
SPK LED BOARD
(SHAKE77/SHAKE88)
(COMPONENT SIDE)
SPK LED BOARD
(SHAKE77/SHAKE88)
(CONDUCTOR SIDE)
SPK LED BOARD
(SHAKE77/SHAKE88)
(COMPONENT SIDE)
SPK LED BOARD
(SHAKE77/SHAKE88)
(CONDUCTOR SIDE)
SPLITTER BOARD
(SHAKE77/SHAKE88)
(COMPONENT SIDE)
SPLITTER BOARD
(SHAKE77/SHAKE88)
(CONDUCTOR SIDE)
1-887-624-
21
(21)
1-889-308-
11
(11)
1-889-150-
11
(11)
1-887-624-
21
(21)
1-889-308-
11
(11)
1-889-150-
11
(11)
LED
SPEAKER
L/R
Ver. 1.1

4
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
1-4. SCHEMATIC DIAGRAM – SPK LED (SHAKE77/SHAKE88) AND SPLITTER Board (SHAKE77/SHAKE88) –
1
A
B
C
D
E
F
G
H
I
J
K
2345678
SPK LED BOARD
SPK LED BOARD
SHAKE77/SHAKE88
SPLITTER BOARD
SHAKE77/SHAKE88
SHAKE77/SHAKE88
R
G
B
R
G
B
JL1806
JL1805
JL1804
JL1803
JL1802
JL1801
JL1800
GREEN_LED
BLUE_LED
RED_LED
RGB +13V
4P
CN1800
4P
CN1801
1 RGB +13V
2RED
3
4
3
2
1
Green_LED
Blue_LED
Red_LED
+13.0V
4
3
2
1
BLUE
4 GREEN
6P
CN1802
6P
CN1803
GREEN 1
2
BLUE
3
RED
4
RED_LED
BLUE_LED 5
GREEN_LED 6
GREEN
1
2BLUE
3RED
4RED-LED
BLUE_LED
5
GREEN_LED
6
JL1805
JL1807
JL1806
JL1804
4P
CN1803
R1800
68
R1801
68
R1802
68
SMLVN6RGB1U17QYB
D1800
JL1809
JL1807
JL1808
JL1810
JL1811
JL1812
SMLVN6RGB1U17QYB
D1800
LED
SPEAKER
L/R
Ver. 1.1

5
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
SECTION 2
EXPLODED VIEWS
The components identified by mark 0
or dotted line with mark 0are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifié.
The components identified by mark 9con-
tain confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque
9contiennent des informations confiden-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est rem-
placé et / ou réparé.
1
not supplied
#1
not supplied
(SPK LED board)
1
2
2
3
3
2
2
4
5
7
7
3
3
8
9
10
11
6
Note: This diagram is for L channel speaker.
The mechanical position of R channel is reversed.
1 4-874-614-12 SCREW (1) (3.5X14), TAPPING
2 4-462-486-02 PROTECTOR, CORNER
3 4-176-619-01 FOOT, RUBBER
4 4-874-614-52 SCREW (1) (3.5X20), TAPPING
5 1-826-143-71 LOUDSPEAKER (2.5CM)
6 1-859-000-21 LOUDSPEAKER (10CM)
7 4-238-407-02 SCREW (1) (4X20), +BV TAPPING
8 1-859-009-21 LOUDSPEAKER (30CM)
9 A-1981-773-B PANEL (L) ASSY, FRONT
9 A-1981-774-B PANEL (R) ASSY, FRONT
10 A-1981-775-A CABINET (L) ASSY, SPEAKER
(SHAKE33: EXCEPT US/SHAKE44)
10 A-1981-776-A CABINET (R) ASSY, SPEAKER
(SHAKE33: EXCEPT US/SHAKE44)
10 A-1988-408-A CABINET (L) ASSY, SPEAKER (SHAKE33: US)
10 A-1988-410-A CABINET (R) ASSY, SPEAKER (SHAKE33: US)
11 1-848-136-21 CABLE WITH CONNECTOR
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Ver. 1.2
2-1. SS-SHAKE33/SHAKE44
Note:
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120 V AC area in E model
E4 : African model
E12 : 220-240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
RU : Russian model
SAF : South African model
TH : Thai model

6
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
Ver. 1.3
2-2. SS-SHAKE55/SHAKE66
51 4-874-614-12 SCREW (1) (3.5X14), TAPPING
52 4-462-486-02 PROTECTOR, CORNER
53 4-534-892-01 FOOT
54 4-874-614-02 SCREW (1) (3.5X14), TAPPING
55 1-826-143-61 LOUDSPEAKER (2.5CM)
(for dust cap of loudspeaker (20CM)/(35CM): gray)
55 1-826-143-81 LOUDSPEAKER (2.5CM)
(for dust cap of loudspeaker (20CM)/(35CM): black)
56 A-1999-109-A PANEL (L) ASSY, FRONT
56 A-1999-110-A PANEL (R) ASSY, FRONT
57 4-238-407-02 SCREW (1) (4X20), +BV TAPPING
58 1-858-902-21 LOUDSPEAKER (20CM)
(dust cap of loudspeaker: black)
58 1-859-038-11 LOUDSPEAKER (20CM)
(dust cap of loudspeaker: gray)
59 1-858-903-21 LOUDSPEAKER (35CM)
(dust cap of loudspeaker: black)
59 1-859-039-11 LOUDSPEAKER (35CM)
(dust cap of loudspeaker: gray)
60 A-1999-111-A PANEL (SW) ASSY, FRONT
61 A-1999-112-A CABINET (L) ASSY, SPEAKER
(SHAKE55: EXCEPT US/SHAKE66)
61 A-1999-113-A CABINET (R) ASSY, SPEAKER
(SHAKE55: EXCEPT US/SHAKE66)
61 A-1999-178-A CABINET (L) ASSY, SPEAKER (SHAKE55: US)
61 A-1999-179-A CABINET (R) ASSY, SPEAKER (SHAKE55: US)
62 1-848-271-11 CABLE WITH CONNECTOR
(LEFT CHANNEL SPEAKER)
62 1-848-271-21 CABLE WITH CONNECTOR
(RIGHT CHANNEL SPEAKER)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note: This diagram is for R channel speaker.
The mechanical position of L channel is reversed.
not supplied
dust cap of loudspeaker
dust cap of loudspeaker
not supplied
not supplied
not supplied
51
51
52
61
62
52
52
52
53
54
54
59
54
58
55
56
60
57
57
not supplied
not supplied
not
supplied
#1
A
A
53
not supplied
(SPK LED board)

7
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
2-3. SS-SHAKE77/SHAKE88
101 4-532-593-01 SCREW (4X13) (TR-184A)
102 4-486-400-01 PROTECTOR, CORNER (FR)
103 4-486-402-01 PROTECTOR, CORNER (REAR)
104 4-486-404-03 PROTECTOR, CORNER (BTM R)
105 4-486-403-03 PROTECTOR, CORNER (BTM L)
106 4-534-892-01 FOOT
107 4-874-614-02 SCREW (1) (3.5X14), TAPPING
108 1-826-143-61 LOUDSPEAKER (2.5CM)
(for dust cap of loudspeaker (10CM)/(20CM)/
(38CM): gray)
108 1-826-143-81 LOUDSPEAKER (2.5CM)
(for dust cap of loudspeaker (10CM)/(20CM)/
(38CM): black)
109 A-1980-950-B PANEL (L) ASSY, FRONT
109 A-1980-953-B PANEL (R) ASSY, FRONT
110 1-858-855-21 LOUDSPEAKER (10CM)-2
(dust cap of loudspeaker: black)
110 1-859-000-21 LOUDSPEAKER (10CM)
(dust cap of loudspeaker: gray)
111 1-858-853-21 LOUDSPEAKER (20CM)
(dust cap of loudspeaker: black)
111 1-858-993-21 LOUDSPEAKER (20CM)
(dust cap of loudspeaker: gray)
112 4-238-407-02 SCREW (1) (4X20), +BV TAPPING
113 1-858-854-21 LOUDSPEAKER (38CM)
(dust cap of loudspeaker: black)
113 1-858-999-21 LOUDSPEAKER (38CM)
(dust cap of loudspeaker: gray)
114 1-848-126-21 CABLE WITH CONNECTOR
115 1-848-127-21 CABLE WITH CONNECTOR
116 A-1980-951-A PANEL (SW) ASSY, FRONT
117 A-1980-952-B CABINET (L) ASSY, SPEAKER
117 A-1980-954-B CABINET (R) ASSY, SPEAKER
118 1-848-139-31 CABLE WITH CONNECTOR
(LEFT CHANNEL SPEAKER)
118 1-848-139-41 CABLE WITH CONNECTOR
(RIGHT CHANNEL SPEAKER)
119 4-536-324-01 CUSHION A
120 4-535-727-02 CUSHION
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note: This diagram is for R channel speaker.
The mechanical position of L channel is reversed.
Ver. 1.3
C
D
A
B
A
C
B
D
101
101
103
102
107
104
103
103
102
103
105
not supplied
not supplied
not supplied
not supplied
not supplied
dust cap of
loudspeaker
dust cap of
loudspeaker
dust cap of loudspeaker
not supplied
not supplied
not supplied
not supplied
#1 #1
#1
101
101
101
106
106
101
101
112
107
112
109
110
111
112
113
114
115
117
118
116
108
112
not supplied
(SPK LED board)
not supplied
(SPK LED board)
not supplied
(SPLITTER board)
119
120
112

8
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
SECTION 3
ELECTRICAL PARTS LIST
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• CAPACITORS
uF: μF
• COILS
uH: μH
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120 V AC area in E model
E4 : African model
E12 : 220-240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
MY : Malaysia model
RU : Russian model
SAF : South African model
TH : Thai model
SPK LED SPLITTER
SPK LED BOARD
*************
< CONNECTOR >
CN1803 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
(SHAKE77/SHAKE88)
CN2700 1-580-057-11 PIN, CONNECTOR (SMD) 4P
(EXCEPT SHAKE77/SHAKE88)
(LED SPEAKER L/R)
< DIODE >
D1800 6-503-944-51 DI SMLVN6RGB1U17QYB (SHAKE77/SHAKE88)
D2700 6-503-944-51 DI SMLVN6RGB1U17QYB
(EXCEPT SHAKE77/SHAKE88)
< JUMPER RESISTOR >
JR2701 1-216-864-11 SHORT CHIP 0
(EXCEPT SHAKE77/SHAKE88)
JR2702 1-216-864-11 SHORT CHIP 0
(EXCEPT SHAKE77/SHAKE88)
JR2703 1-216-805-11 METAL CHIP 47 5% 1/10W
(EXCEPT SHAKE77/SHAKE88)
************************************************************
SPLITTER BOARD (SHAKE77/SHAKE88)
**************
< CONNECTOR >
CN1800 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
(LED SPEAKER L/R)
CN1801 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1802 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
Ref. No. Part No. Description Remark
The components identified by mark 0
or dotted line with mark 0are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifié.
The components identified by mark 9con-
tain confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque
9contiennent des informations confiden-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est rem-
placé et / ou réparé.
Ver. 1.2

MEMO
9
SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
Ver. 1.1

SS-SHAKE33/SHAKE44/SHAKE55/SHAKE66/SHAKE77/SHAKE88
REVISION HISTORY
Ver. Date Description of Revision
1.0 2014.01 New
1.1 2014.04 Addition of SS-SHAKE44, SS-SHAKE55, SS-SHAKE66 and SS-SHAKE88 model.
Add illustration of ABSORBENT, ACOUSTIC and CUSHION C in page 6.
Change P/N of Ref. No. 51 in page 6.
1.2 2014.05 Addition of Argentina model (SHAKE-33/55/77).
Change P/N of Ref. No. 6, 8 and 12 in page 5.
Change P/N of Ref. No. 110, 111, 113, 114, 115 and 117 in page 7.
Delete SARANET, CUSHION in page 5.
Delete CUSHION D in page 7.
1.3 2014.07 Add P/N and description of Ref. No. 55, 58 and 59 (for loudspeaker’s dust cap: black) in page 6.
Add P/N and description of Ref. No. 108, 110, 111 and 113 (for loudspeaker’s dust cap: black) in page 7.
Change description of Ref. No. 55, 58 and 59 (for loudspeaker’s dust cap: gray) in page 6.
Change description of Ref. No. 108, 110, 111 and 113 (for loudspeaker’s dust cap: gray) in page 7.
Change P/N of Ref. No. 118 in page 7.
How to search for a contact point of signal lines or the like in DIAGRAMS SECTION
If a contact point of a BLOCK DIAGRAM, PRINTED WIRING BOARD or SCHEMATIC DIAGRAM is shown in a different page, use
the PDF file search function to find one.
e.g.) If a contact point is shown as , follow the procedure below.
Procedure:
1. Press the [F] key while pressing the [Ctrl] key.
2. Input “>001Z” in the search box and press the [Enter] key.
3. The relevant part (page), where the contact point is shown, appears.
Note: If you still see the original page, press the [Enter] key again.
