SERVICE MANUAL
US Model
STR-K5900P/K9900P
Canadian Model
STR-K5900P
STR-K5900P/K9900P
FM STEREO/FM-AM RECEIVER
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(Models of area code US only)
With 6 ohm loads, both channels driven, from
120 – 20,000 Hz; rated 90 watts (STR-K9900P)/
70 watts (STR-K5900P) per channel minimum
RMS power, with no more than 0.7 % total
harmonic distortion from 250 milliwatts to rated
output.
Amplifier section
Power Output 1)
Model of area code US
(6 ohms 1 kHz, THD 10 %)
STR-K9900P: FRONT 2) : 140 W/ch
CENTER2) : 140 W
SURR2) : 140 W/ch
SURR BACK 2) : 140 W
STR-K5900P: FRONT 2) : 110 W/ch
CENTER2) : 110 W
SURR2) : 110 W/ch
SURR BACK 2) : 110 W
SPECIFICATIONS
Model of area code Canadian
(6 ohms 1 kHz, THD 0.7 %)
STR-K5900P: FRONT 2) : 70 W/ch
CENTER2) : 70 W
SURR 2) : 70 W/ch
SURR BACK 2) : 70 W
(6 ohms 1 kHz, THD 10 %)
STR-K5900P: FRONT 2) : 110 W/ch
CENTER2) : 110 W
SURR 2) : 110 W/ch
SURR BACK 2) : 110 W
1) Measured under the following conditions:
Area code Power requirements
US, Canadian 120 V AC, 60 Hz
2) Depending on the sound field settings and the
source, there may be no sound output.
Ver. 1.0 2005. 03
9-879-562-01
2005C04-1
© 2005. 03
Sony Corporation
Audio Group
Published by Sony Engineering Corporation
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
“DTS”, “DTS-ES”, “Neo:6” and “DTS 96/24” are
trademarks of Digital Theater Systems, Inc.
– Continued on next page –
Photo: STR-K9900P
•STR-K5900P/K9900Parethe
FM/AM receiver section in
HT-5950DP/6900DP/9900M.

2
STR-K5900P/K9900P
Inputs (Analog)
MULTI CH IN*, Sensitivity: 800 mV
SA-CD/CD, MD/TAPE, Impedance: 50 k ohms
DVD, VIDEO 1, 2, 3
* STR-K9900P only.
Inputs (Digital)
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
VIDEO 2, SA-CD/CD Sensitivity: –
(Optical) Impedance: –
Outputs (Analog)
MD/TAPE (OUT), Voltage: 800 mV
VIDEO 1 (AUDIO OUT) Impedance: 10 k ohms
SUB WOOFER Voltage: 2 V
Impedance: 1 k ohm
Reproduction frequency range:
28 – 20,000 Hz
Tone
Gain levels ±6 dB, 1 dB step
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Model of area code US, Canadian
With 10-kHz tuning scale: 530 – 1,710 kHz 3)
With 9-kHz tuning scale: 531 – 1,710 kHz 3)
Antenna Loop antenna
Intermediate frequency 450 kHz
3) You can change theAM tuning scale to 9 kHz or 10 kHz.
After tuning in anyAM station, turn off the receiver. While
holding down PRESET TUNING + or TUNING +, press
?/1. All preset stations will be erased when you change
the tuning scale. To reset the scale to 10 kHz (or 9 kHz),
repeat the procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO: Y: 1 Vp-p, 75 ohms
PB/CB/B-Y: 0.7 Vp-p,
75 ohms
PR/CR/R-Y: 0.7 Vp-p,
75 ohms
80 MHz HD Pass Through
General
Power requirements
Area code Power requirements
US, Canadian 120V AC, 60 Hz
Power consumption
Area code Power consumption
US (STR-K9900P) 190 W
US (STR-K5900P) 140 W
Canadian 200 VA
Power consumption (during standby mode)
0.2 W
Dimensions (w/h/d) (Approx.)430 ×157.5 ×310 mm
(16 7/8 ×6 2/8 ×12 2/8
inches) including
projecting parts and
controls
Mass (Approx.) 8.0 kg (17 lb 11 oz)
Design and specifications are subject to change
without notice.

3
STR-K5900P/K9900P
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES
SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL
OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
1.5 k Ω 0.15 µFAC
voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
SAFETY CHECK-OUT (US MODEL)
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Checktheantennaterminals,metal trim, “metallized” knobs, screws,
and all other exposed metal parts forAC leakage.
Check leakage as described below.
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit” indica-
tion is 0.75 V, so analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa SH-63Trd are ex-
amples of a passive VOM that is suitable. Nearly all battery
operated digital multimeters that have a 2 V AC range are suit-
able. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.

4
STR-K5900P/K9900P
TABLE OF CONTENTS
1. GENERAL
Main unit ................................................................................. 5
Remote button description....................................................... 6
2. DISASSEMBLY
2-1. Case ..................................................................................... 7
2-2. Front Panel Section ............................................................. 8
2-3. Back Panel Section.............................................................. 8
2-4. Digital Board ....................................................................... 9
2-5. Standby Board ..................................................................... 9
2-6. Main Board ....................................................................... 10
3. TEST MODE ..................................................................... 11
4. DIAGRAMS
4-1. Circuit Boards Location .................................................... 12
4-2. Block Diagram – Tuner/Audio Section – .......................... 13
4-3. Block Diagram – Digital Section – ................................... 14
4-4. Block Diagram – Video Section – ..................................... 15
4-5. Block Diagram – Key/Display Section – .......................... 16
4-6. Block Diagram – Power Section – .................................... 17
4-7. Printed Wiring Boards – Main Section – .......................... 19
4-8. Schematic Diagram – Main Section (1/2) – ...................... 20
4-9. Schematic Diagram – Main Section (2/2) – ...................... 21
4-10. Printed Wiring Board – Digital Section (1/2) – ................ 22
4-11. Printed Wiring Board – Digital Section (2/2) – ................ 23
4-12. Schematic Diagram – Digital Section (1/4) – ................... 24
4-13. Schematic Diagram – Digital Section (2/4) – ................... 25
4-14. Schematic Diagram – Digital Section (3/4) – ................... 26
4-15. Schematic Diagram – Digital Section (4/4) – ................... 27
4-16. Printed Wiring Boards – Speaker Section – ...................... 28
4-17. Schematic Diagram – Speaker Section – .......................... 29
4-18. Printed Wiring Boards – Video Section – ......................... 30
4-19. Schematic Diagram – Video Section – .............................. 31
4-20. Printed Wiring Boards – Panel Section – .......................... 32
4-21. Schematic Diagram – Panel Section – .............................. 33
4-22. Printed Wiring Board – Power Section – .......................... 34
4-23. Schematic Diagram – Power Section – ............................. 35
5. EXPLODED VIEWS
5-1. Case Section ...................................................................... 42
5-2. Front Panel Section ........................................................... 43
5-3. Back Panel Section............................................................ 44
5-4. Chassis Section ................................................................. 45
6. ELECTRICAL PARTS LIST ........................................ 46
MODEL IDENTIFICATION
— BACK PANEL —
Part No.
MODEL PART No.
STR-K5900P: US 2-546-121-0s
STR-K9900P: US 2-546-121-1s
STR-K5900P: CND 2-546-121-7s
•Abbreviation
CND: Canadian model

5
STR-K5900P/K9900P
SECTION 1
GENERAL This section is extracted
from instruction manual.
59
US
Additional Information
Main unit
A.F.D. (button/indicator) qa (30,
32, 53)
AM wa (23, 24, 25, 40)
DIMMER 4(26)
DISPLAY 3(26, 54)
Display 7(27)
DVD wg (23)
ENTER qg (18, 40)
FM ws (23, 24, 25, 40)
FM MODE es (24)
Input buttons w; (23, 35, 39, 40,
54)
INPUT MODE qj (35)
IR (receptor) 5(43, 54)
MAIN MENU 8(19, 36, 37, 40)
MASTER VOLUME –/+ qh (18,
22, 23, 53)
MD/TAPE wf (23)
MEMORY ef (25)
MOVIE (button/indicator) qs
(31, 32, 53)
MULTICHANNELDECODING
(indicator) 6(24)
MULTI CH IN* 9(24)
MUSIC(button/indicator)qd (32,
53)
PHONES (jack) ed (23, 53)
PRESET TUNING –/+ wl (25,
56)
SA-CD/CD wd (23)
SLEEP** 9(40)
SPEAKERS (OFF/A/B/A+B)*
2(16, 41, 53)
SPEAKERS(ON/OFF)**2(16,
41, 53)
SURR BACK DECODING qf
(33)
TUNING –/+ e; (24, 56)
VIDEO 1 wk (23)
VIDEO 2 wj (23)
VIDEO 3 wh (23)
VIDEO 3 IN/PORTABLE AV IN
(jacks) ea (13)
2CH (button/indicator) q; (29,
32, 37)
?/1 (power) 1(18, 19, 37, 56)
</> ql (19, 36, 37, 40)
+/– qk (19, 36, 38, 40)
*HT-9900M and HT-6900DP
only.
**HT-5950DP only.
List of button locations and reference pages
How to use this page
Use this page to find the location of buttons that are
mentioned in the text.
Ill
us
t
ra
ti
on num
b
er
r
DISPLAY 3(26, 54)
RR
Name of button/part Reference page
ALPHABETICAL ORDER
A - H
I - O
P - Z
NUMBERS AND SYMBOLS
28 6534 7
1
wawswdwfwgwhwjwk
qj
ql qh
9q;qaqs qfqd qg
w
;
wle;edesef ea qk

6
STR-K5900P/K9900P
Operations Using the Remote RM-AAP001
43
US
You can use the remote RM-AAP001 to operate
the components in your system.
Inserting batteries into the
remote
Insert R6 (size-AA) batteries with the + and –
properly oriented in the battery compartment.
When using the remote, point it at the remote
sensor on the receiver.
Tip
Under normal conditions, the batteries should last for
about 6 months. When the remote no longer operates
the receiver, replace all batteries with new ones.
Notes
•Do not leave the remote in an extremely hot or humid
place.
•Donot use a new battery with an old one.
•Do not expose the remote sensor to direct sunlight or
lighting apparatuses. Doing so may cause a
malfunction.
•Ifyou don’t use the remote for an extended period of
time, remove the batteries to avoid possible damage
from battery leakage and corrosion. *TheH, TV VOL +, TV CH + and MASTER
VOL + buttons have a tactile dot. Use the tactile dot
as a reference when operating the receiver and other
audio/video components.
Operations Using the Remote RM-AAP001
Before you use your
remote
Remote button
description
HX
Mm
.>
-
VIDEO1 VIDEO2 VIDEO3 DVD
RM SET UP
SYSTEM STANDBY SLEEP
AV1 AV2
TV ?/1 AV ?/1
MD/TAPE
SA-CD/CD TUNER AUX
MULTI CH
SHIFT
TOP MENU/
GUIDE AV MENU MUTING
MASTER
VOL
DISPLAY
TV VOL TV CH TV/
VIDEO MAIN MENU
TEST
TONEWIDE
RETURN/EXIT
D.TUNING DISC ALT
ANT CLEAR SEARCH MODE
2CH A.F.D.
123
456
789
0/10 >10/11 12
MOVIE
SUBTITLE ENTER
MUSIC
AUDIO ANGLE JUMP/
TIME PRESET/ CH/D.SKIP
SB
DECODING
DUAL
MONO
x
?/1
P
O
v
V
bB
ql
wg
wh
wj
wk
e;
ea
es
ed
ef
qj
qk*
ENTER
1
2
3
4
6
5
*qs
*q;
7
8
9
qa
*qd qf
qg
qh
w;
wa
ws
wd
wf
wl
continued

7
STR-K5900P/K9900P
Note : This set can be disassemble according to the following sequence.
SECTION 2
DISASSEMBLY
2-1. CASE
Note : Follow the disassembly procedure in the numerical order given.
2-1. CASE
(Page 7)
2-2. FRONT PANEL SECTION
(Page 8) 2-3. BACK PANEL SECTION
(Page 8)
SET
2-5. STANDBY BOARD
(Page 9) 2-4. DIGITAL BOARD
(Page 9)
2-6. MAIN BOARD
(Page 10)
1 two screws
(case 3 TP2)
2 two screws
(+BVTP 3
× 8)
3 two screws
(case 3 TP2)
4 case

8
STR-K5900P/K9900P
2-2. FRONT PANEL SECTION
2-3. BACK PANEL SECTION
9 front panel section
3 CNS505 (21 core)
2 CNP791 (4P)
4 CNP202 (3P)
5 CNP503 (3P
)
1 clip
6 two screws
(+BVTP 3
× 8)
7 two screws
(+BVTP 3
× 8)
8 three screws
(+BVTP 3
× 8)
2 CNS509 (13P)
3 CNP203 (3P)
1 connector (11P)
5 CNP600 (4P)
6 CN806 (4P)
4 CNP503 (4P)
7 CNP901
9 screw
(+BVTP 3 × 8)
qa five screws
(+BVTP 3 × 8)
qd back panel section
0 three screws
(+BVTP 3 × 8)
8 four screws
(+BVTP 3 × 8)
qs two screws
(+BVTP 3 × 8)

9
STR-K5900P/K9900P
2-4. DIGITAL BOARD
7 CNP501
5
6
CNP500
1 CNP505 (9P)
2 CNP504 (5P)
3 CNP503 (6P)
9 bracket (digital)
0 DIGITAL boar
d
4 screw
(+BVTP 3
× 8)
8 screw
(+BVTP 3
× 8)
6 STANDBY board
3 CNP903 (2P)
1 CNP801 (5P)
4 CNP902 (2P)
2 CNP804 (3P)
5 three screws
(+BV3 (3-CR))
2-5. STANDBY BOARD

10
STR-K5900P/K9900P
3 two screws
(+BV3 (3-CR))
4 two screws
(+BV3 (3-CR))
5 screw (+BV3 (3-CR))
6 MAIN boar
d
1 CNP908 (5P)
2 CNP802 (5P)
2-6. MAIN BOARD

11
STR-K5900P/K9900P
SECTION 3
TEST MODE
FACTORY PRESET MODE
* All preset contents are reset to the default setting.
* Procedure:
While depressing the [FM MODE] and the [DISPLAY] buttons
simultaneously, press the ?/1 button to turn on the main power.
The message “FACTORY” appears for a moment and the present
contents are reset to the default values.
AM CHANNEL STEP 9 kHz/10 kHz SELECTION
MODE (US, Canadian model only)
* Either the 9 kHz step or 10 kHz step can be selected for the AM
channel step.
* Procedure:
Press the [AM] button to set AM and press the ?/1 button to
turn off the main power.
While depressing the [PRESET TUNING +] button or the
[TUNING +] button, press the ?/1 button to turn on the main
power.
Either the message “9k STEP” or “10k STEP” appears for a
moment and select the desired step.
SPEAKER SIZE SELECTION MODE
* Either the normal speaker or micro satellite speaker can be se-
lected.
* Procedure:
While depressing the [DIMMER] button, press the ?/1 button to
turn on the main power.
Either the message “NORM. SP.” or “MICRO SP.” appears for a
moment and select the desired speaker size.
FLUORESCENT INDICATOR TUBE TEST MODE
* All fluorescent segments are tested.
When this test is activated, all segments light on at the same
time, then each segment lights on one after another.
* Procedure:
While depressing the [TUNING --] and the [SPEAKERS $OFF/A/B/
A+B%] buttons simultaneously, press the ?/1 button to turn on
the main power.
1. ALL segments light on.
[2CH], [A.F.D.], [MOVIE], [MUSIC] and [MULTI CHANNEL DE-
CODING] LED light on.
2. Press the [VIDEO 1] button, confirm display.
[A.F.D.] and [MUSIC] LED light on.
3. Press the [VIDEO 1] button, confirm display.
[2CH], [MOVIE] and [MULTI CHANNEL DECODING] LED light
on.
4. Press the [VIDEO 1] button, all segments and all LEDs light off.
5. Every pressing the [VIDEO 1] button turns on each segment and
LED one after another in the same order.
(Not only the [VIDEO 1] button, but also the other buttons such
as [VIDEO 2], [VIDEO 3], [DVD], [MD/TAPE], [SA-CD/CD], [FM]
and [AM] can be used.)
SOUND FIELD CLEAR MODE
* The preset sound field is cleared when this mode is activated.
Use this mode before returning the product to clients upon
completion of repair.
* Procedure:
While depressing the [2CH] button, press the ?/1 button to turn
on the main power.
The message “SF. CLR.” appears for a moment and initializa-
tion is performed.
SOFTWARE VERSION DISPLAY MODE
* The software version is displayed.
* Procedure:
While depressing the [TUNING --] and the [DISPLAY] buttons
simultaneously, press the ?/1 button to turn on the main power.
The model name, destination and the software version are dis-
played for a moment.
KEY CHECK MODE
* Button check
* Procedure:
While depressing the [TUNING --] and the [MAIN MENU] buttons
simultaneously, press the ?/1 button to turn on the main power.
Either the message “REST 30” appears.
Every pressing of any button other than the ?/1 counts down
the buttons. The buttons which are already counted once are not
counted again.When all buttons are pressed “REST 00” appears.
COMMAND MODE SELECTION MODE
* The command mode (AV1 or AV2) of the remote commander
can be selected.
* Procedure:
While depressing the [ENTER] button, press the ?/1 button to
turn on the main power.
Either the message “C.MODE.AV 1” or “C.MODE.AV 2” ap-
pears for a moment and select the desired mode.
L
SW
CR
SL S SR
SBL SB SBR
LFE SP A
SP B SLEEP OPT COAX MULTI CH IN 96/24
DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS
D.RANGE EQ STEREO MONO
D
D D D
dB
kHz
mft.
MHz
MEMORY
DIRECT
L
SW
R
S
SB
LFE SP A
SP B SLEEP OPT COAX MULTI CH IN 96/24
DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS
D.RANGE EQ STEREO MONO
D
D D D
dB
kHz
mft.
MHz
MEMORY
DIRECT
C
SL SR
SBL SBR
SP A
SP B SLEEP OPT COAX MULTI CH IN 96/24
DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS
D.RANGE EQ STEREO MONO
D
D D D
kHz
mft.
MHz
MEMORY
DIRECT

12
STR-K5900P/K9900P SECTION 4
DIAGRAMS
4-1. CIRCUIT BOARDS LOCATION
DIGITAL boar
d
POWER board
STANDBY board
VIDEO board
SPEAKER C/SB board
SPEAKER B (P) board
(STR-K9900P)
MAIN board
TUNING board
VIDEO3 board
HEADPHONE board
DISPLAY board

STR-K5900P/K9900P
13 13
STR-K5900P/K9900P
4-2. BLOCK DIAGRAM — TUNER/AUDIO SECTION —
76
75
78
74
73
70
SA-CD/CD
IN
MD/TAPE
OUT
MD/TAPE
IN
DVD AUDIO
IN
L
J403J402 J298(2/2) J404
R
R-CH R-CH R-CH R-CH
LR
AM
TN1
FM/AM TUNER UNIT
SYSTEM
CONTROL
IC1101 (1/4)
LRLR L
-3 -4 -5 -6 -1 -2
RL
VIDEO 2
VIDEO 3 INPUT
AUDIO OUT AUDIO INAUDIO IN
RLR
R-CH
S LATCH
SW RY
17 TUNER DATA
16 T SERIAL CLK
VOL DATA
VOL CLK
STEREO
TUNED
MUTE
DO
L-CH
R-CH
STEREO
TUNED
MUTING
CE
DO
DATA
CLOCK
VIDEO 1
AUDIO
OUT
SUB WOOFER
AUDIO OUT
SUB
WOOFER
RELAY
DRIVER
Q560
SUB WOOFER
AMP
IC402
J309
-2
-1
-1
-2
K9900P
RY560
SBL-CH
C-CH
SR-CH
FR-CH
SL-CH
FL-CH
R-CH
L-CH
17
11
14
28
27
FM 75Ω
COAXIAL
44
45
24
25
68 66
32
28
30
34
38
60
59
46
SUB
WOOFER
LR
R-CH R-CH
LR
FRONT
K9900P
SURROUND
CENTER
J401
MULTI CH IN
ANTENNA
10
13
12
41
42
88
87
85
84
86
81
83
5 7
54 56 51 52 49
SW
SEL
C
SEL
SL
SEL
L
SEL
R-CH
R-CH
26
27
R-CH
R-CH
R-CH
R-CH
R-CH
R-CH
DIR
FUNCTION SELECT
IC401
AVCCAVEE
+7V-7V
-1 -2 -3 -4
AUDIO
R-CH
LR
-2 -3-3 -4 -1 -2
-1 -2 -3 -4 -5 -6
SEL
SW
MCU
I/F
3.3V
(STBY)
SBL OUT
SBR OUT
SW OUT
C OUT
SL OUT
L OUT
R-CH
R-CH
R-CH
TU+10V
• Signal path
: TUNER (FM/AM)
: VIDEO (AUDIO)
: CD (ANALOG)
• R-ch is omitted due to
same as L-ch.
SBL
SEL
55
DIGITAL
SECTION B
DIGITAL
SECTION
A
POWER
SECTION
C
(Page 14)
(Page 17)
(Page 14)

STR-K5900P/K9900P
1414
STR-K5900P/K9900P
4-3. BLOCK DIAGRAM — DIGITAL SECTION —
• Signal path
: TUNER (FM/AM)
: VIDEO (AUDIO)
: CD (DIGITAL)
• R-ch is omitted due to
same as L-ch.
1
+5V-2
A.5V
SDI1
SD01
DOUT 15 18
GP8
AUDIO 24
SYS CLK
16
XMCK
20
69
LRCKI1
15
BCKI1
17
KFSI0
CKOUT 13 22
BCKI2
BCK 14 29
LRCKI2
LRCK 15 28
SDI2 CS
WE
DATAO
LRCK 13
SCLK 14
23
SD02 24
SD03 25
SD04 26
SCKOUT 14
LRCKO 19
BCKO
LRCKO
SCKOUT
BCKO
20
X1502
13.9MHz
MCLK1 9
MCLK2 12
CSO 44
WEO 45
68
108,107,105 -102,99,
98,80 - 77,75 - 72
24 - 27,42 - 44,
1 - 5,18 - 21
29 - 32,35 - 38,
16-13,10 - 7
112,110,109,97 - 92,
85-82,66 - 64
6
17
211336 35 33 3432
21
37
6 74 18 19 205
EXLOCK
GP12
56
BST
ERROR
21
22
99
25
24
RST
6
95 96 97 98
38 37 36 35 33 47 17
INPUT DATA
DEMODULATOR
Pa,Pb DETECTION LOCK
DETECTION
MICROPROCESSOR
I/F
C bit DETECTION 34 59
16 30
DVD
IN
DIGITAL
(COAXIAL)
1
SA-CD/CD
IN
(OPTICAL)
OUT
IC1354
1
VIDEO 2
IN
(OPTICAL)
OUT
IC1351
IC1303
X1301
12.288MHz
DIGITAL AUDIO I/F RECEIVER
IC1301
J1301
-1 23 WAVE
SHAPER
+2.6V
VDDI
+3.3V
VDDE
5
+3.3V
VDD NC
L-IN
R-IN R-CH
LIN LPF AUDIO
I/F
A/D
CONVERTER
IC1401
DSP
IC1501
SDRAM
IC1502
SWITCH
IC1503
GP9
DIR_DATAO
8
GP12
HACN
HCS
XRST
HDIN
PM
1514131210
PCM1608RST
PCM1608ML
PCM1608MC
PCM1608MDI
PCM1608MDO
3
BST
92
BST SEL
HDOUT
HCLK
GP9 HACN HCS XRST HDIN PM HDOUT HCLK
6
DIR_CLK
DIR CE
DIR DI
DIR DO
DIR_XSTATE
CLK CE DI DO BPSYNC CKSEL1
93100
48
DIR_XMODE
94
DIR CKSEL1
XMODE XSTATE
9
PCM1800 RST
5
4
3
XOUT
DIN1
DIN2
2DOUT
DIN0
XIN
SYSTEM_MUTE
Q1103
INV.
ERROR
ANA/DIG
Q1105
INV.
Q1104
GATE
D1105
D1106
D1103
D1301
D0-15A0-15 D0-15A0-15
SYSTEM
CONTROL
IC1101 (2/4)
TUNER/
AUDIO
SECTION
B
TUNER/
AUDIO
SECTION
AADC
DATA3
L OUT
C OUT
R-CH
VOUT5
VOUT6
47
310 1
5
97
AMP
IC1403
DATA1
SL OUT
R-CH
SW OUT
VOUT1
VOUT2
45
5
14 7
3
13 1
AMP
IC1405
AMP
IC1404
DATA2
VOUT3
VOUT4
46
SCKI
38
BCK
40
LRCK
SCKOUT
BCKO
LRCKO 41
MC
35
MDI
34
RST
37
ML
36
LRCKO
3
12 1
5
11 7
DATA4
SBL OUT
SBR OUT
VOUT7
VOUT8
31
5
16 7
3
20 1
AMP
IC1406
8CH DAC
IC1452
DAC
DAC
DAC
DAC
1
2
MDO
33
(Page 13)
(Page 13)

STR-K5900P/K9900P
15 15
STR-K5900P/K9900P
4-4. BLOCK DIAGRAM — VIDEO SECTION —
3CH1 IN2
CH2 IN2
CH3 IN2
CH1 IN3
CH2 IN3
CH3 IN3
CHI OUT
CH2 OUT
CH3 OUT
5
9
11
14
12
2 4
Y
P
B/ C B/ B-Y
P
R/ C R/ R-Y
Y
SW1 SW2
COMP SW1 COMP SW2
P
B/ C B/ B-Y
P
R/ C R/ R-Y
J301 (1/2)
J201 (1/2)
22
75Ω
DRIVER
6dB AMP
20
75Ω
DRIVER
6dB AMP
18
75Ω
DRIVER
6dB AMP
10 6 14 2
13
J200 (1/2)
5
3
4
VIDEO 2
IN
DVD
IN
VIDEO
IN
VIDEO
IN
COMPONENT
VIDEO
-4
-5
-6
-1
-2
-3
Y
P
R/ C R/ R-Y
P
B/ C B/ B-Y
J301 (2/2)
MONITOR
OUT
COMPONENT
VIDEO
-7
15
75Ω
DRIVER
6dB AMP
1
1 3
75Ω
DRIVER
6dB AMP
-3
J200 (2/2)
J201 (2/2)
-8
-9
-1
VIDEO 1
J298 (1/2)
VIDEO
-1
VIDEO 3
INPUT
VIDEO 2
DVD
-2
VIDEO
IN
-1
VIDEO
OUT VIDEO 1
-2
VIDEO
OUT MONITOR
+5V
REG
IC807
+5V-3
3 2
-5V
REG
IC804
-5V-3
V SW1
V SW2
V SW3
V SW4
COMP SW1
COMP SW2
SW1
SW2
SW3
SW4
D203,204
OR
VEE -5V-3
VCC +5V-3
+15V
-15V
V1.OUT
M.OUT
V-1,-2 -5V-3
V+1,+2+5V-3
V1
V2
DVD
V3
NC
SW2 SW4 SW3 SW1
SW2 SW3 SW4 SW1 SW5
VIDEO
SELECTOR
IC203
COMPONENT VIDEO SELECTOR
IC304
7
9
KEY/DISPLAY
SECTION
D
• Signal path
: VIDEO
(Page 16)

STR-K5900P/K9900P
1616
STR-K5900P/K9900P
4-5. BLOCK DIAGRAM — KEY/DISPLAY SECTION —
29
FL DISPLAY DRIVER
IC100
14
I
29
30
29
30
5
6
45
46
54
SW NETWORK
S120-125,128-130
RV102
MASTER
VOLUME
56
51
49
28
27
77
+3.3V
(STBY)
X1
X0
SDA
SCL
POWER KEY
FLASH1
FLASH2
MD2
MD0
RSTX
SDA
SCL
EEPROM
IC1131
X1101
24MHz
89 SW4
V SW4
88 SW3
V SW3
71 COMP SW1
COMP SW1
65 COMP SW2
COMP SW2
87 SW2
V SW2
86 SW1
V SW1
SIRCS
9
4
2
60
59
57
FL LAT
FL DATA
FL CLK
9STB
7DIN
8CLK
3
6
8
2
SW2
1
SW1
GRID12
I
GRID1
SEG1
I
SEG16
4
SW4
3
SW3
VOL ENC A
VOL ENC B
A/D2
SW NETWORK
S140-143,148-153
SW NETWORK
S100-110
A/D0
A/D1
1
3
BUFFER
IC101
1
REMOTE
CONTROL
RECEIVER
IC102
OUT
SIRCS
SYSTEM
CONTROL
IC1101 (3/4)
CNS504
S131
FLASH1
FLASH2
MD2
MD0
RESET
1
2
7
6
5
FLASH
PROGRAMMING
12
I/ I
VIDEO
SECTION
D
D101-104
47
38
39
40
BLUE LED
FL101
VACUUM
FLUORESCENT
DISPLAY
IC1111
RESET
31
I
42
LED DRIVE
Q110
D105
(Page 15)

STR-K5900P/K9900P
17 17
STR-K5900P/K9900P
4-6. BLOCK DIAGRAM — POWER SECTION —
812
11
DRIVE POWER AMP
Q701-704 CURRENT
DETECT
Q705,706 RY791
RY610
RY601
RY701
PRE DRIVER
IC701
IN 2 +VOUT2
-VOUT2
SPEAKERS
IMPEDANCE
USE 8-16Ω
R
L
FRONT B
L
SURROUND
SURROUND
BACK
CENTER
R
R-CH
R-CH
R-CH
FL-CH
FR-CH
SL-CH
C-CH
R-CH
SR-CH R-CH
TUNER/
AUDIO
SECTION
C
RY901
RY801
K9900P
D804
F1
F2
-20V
+3.3V
(STBY)
+2.6V
+5V-1
-7V
+7V
TU+10V
-20V
RECT
D910-913
T902
POWER
TRANSFORMER
D914
Q921 D915
D1110
D1111
D1107
D1108
~ AC IN
OVERLOAD
DETECT
D740,Q740
1
61
12
11
DRIVE POWER AMP
Q501-504
CURRENT
DETECT
Q505,506
-32V REG
Q801
-B SWITCH
Q691,692
RELAY
DRIVER
Q901
PRE DRIVER
IC501
IN2 +VOUT2
-VOUT2
OVERLOAD
DETECT
D540,Q540
812
11
DRIVE POWER AMP
Q651-654
CURRENT
DETECT
Q655,656
PRE DRIVER
IC601
IN 2 +VOUT2
-VOUT2
OVERLOAD
DETECT
D640,Q640
RELAY
DRIVER
Q790
RELAY
DRIVER
RELAY
DRIVER
Q610
RY501
RELAY
DRIVER
Q550
69
66
62
PROTECTOR
D721,722,732
Q722,723,725,793,795
55
58
48
68
OVERLOAD
DETECT AMP 72
IC691
-B-1
-B
BACK-UP
SWITCH 4
5
+3.3V 2
IC1901
+5V-2 +5V
REG 13
IC1001
+3.3V
REG 13
IC1904
+10V
REG 13
IC1902
-15V
+15V
+7V
REG 31
IC801
-7V
REG 23
IC802
+5V
REG 13
IC1031
+B
R-CH
R-CH
R-CH R-CH
R-CH R-CH
RECT
D802
RECT
D920-923
RECT
D805-808
T901
POWER
TRANSFORMER
TM610
R
FRONT A
L
R-CH
TM601
TM501
J791
PHONES
HP-RY SB-RY FRONT RY REAR-RY C/SB RY HP DETECT
HP-RY
HP DETECT
SB-RY
FRONT-RY
REAR-RY
C/SB RY
HP_RY
FRONT RY
REAR_RY
PROTECTOR
HP DETECT
P0WER RY
67
SP_B_RY
72
BRIDGEABLE RY
STOP
C/SB RY
SYSTEM
CONTROL
IC1101 (4/4)
PRE
DRIVE
PRE
DRIVE
62
3
DRIVE POWER AMP
Q533,534,571,572
CURRENT
DETECT
Q535,536
IN1 +VOUT1
-VOUT1
OVERLOAD
DETECT
D580,Q580
PRE
DRIVE
SBL-CH
-B-1 +B
-B-1 +B
-B-1 +B
PRE
DRIVE
RELAY
DRIVER
Q710
RELAY
DRIVER
Q809
R810
R811
F901
R910
RELAY
SWITCH
Q800(DE698/DV10)
Q810(DE98)
K5900P
• Signal path
: TUNER (FM/AM)
• R-ch is omitted due to
same as L-ch.
(Page 13)

STR-K5900P/K9900P
1818
STR-K5900P/K9900P
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is
printed in each block.)
for schematic diagram:
•All capacitors are in µF unless otherwise noted. (p: pF)
50 WV or less are not indicated except for electrolytics
and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
•f: internal component.
•2: nonflammable resistor.
•5: fusible resistor.
•C: panel designation.
•A: B+ Line.
•B: B– Line.
•Voltage and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : FM
•Voltagesaretaken with aVOM(Input impedance 10MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
•Circled numbers refer to waveforms.
•Signal path.
F: TUNER (FM/AM)
L: VIDEO (AUDIO)
I: VIDEO
J: CD (ANALOG)
c: CD (DIGITAL)
for printed wiring boards:
•X: parts extracted from the component side.
•f: internal component.
•: Pattern from the side which enables seeing.
Caution:
Pattern face side: Parts onthepattern facesideseenfrom the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
C
B
These are omitted.
E
Q
B
These are omitted.
C
Q
Q
E
BCE
Note:
The components identi-
fied by mark 0or dotted
linewith mark 0arecriti-
cal for safety.
Replace only with part
number specified.
Note:
Lescomposants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
• Waveforms
— DIGITAL Board —
1 IC1301 qd (CKOUT)
3.5Vp-p
3.2Vp-p
1V/DIV, 50nsec/DIV
3 IC1301 wa (XOUT)
1V/DIV, 50nsec/DIV
4 IC1501 9(MCLK1)
1.8Vp-p
1V/DIV, 50nsec/DIV
2 IC1301 qf (BCK)
4.8Vp-p
1V/DIV, 0.2 µ s/DIV
13.9MHz
12.288MHz
3.07MHz
12.288MHz
5 IC1501 qs (MCLK2)
3.6Vp-p
2Vp-p
1V/DIV, 50nsec/DIV
7 IC1101 id (X1)
1V/DIV, 50nsec/DIV
6 IC1501 qf (SCKOUT)
3.5Vp-p
1V/DIV, 50nsec/DIV
24MHz
12.288MHz
13.9MHz

STR-K5900P/K9900P
19 19
STR-K5900P/K9900P
1
A
B
C
D
E
F
G
H
234567891011121314
S
(K9900P)
C790
JW791 TP701
CNP791
IC401
JW628
Q653
Q703 Q704
JW707
JW630
Q654 Q753 Q603 Q604
JW601
JW735
CN505
JW736
JW757
JW739
JW702
JW706
JW703
JW701
JW312
JW313
JW441
Q503 Q504
JW503
CNP503
C403
JW611
JW755
JW610
JW613
JW612
JW720
JW722
JW752
JW716
JWH108
JW717
JW754
JW751
JW455
JW456
JW442
JW322
R468
JW434
JW614
JW818
JW419
JW417
JW415
JW414
CN792
JW753
TM601
JW815
JW428
JW433
JW784
JW783
JW782
JWH122
JW820
JW771
JW770
JW780
JW781
JWH114
JWB01
JWB03
JW714
JW715
JWH111
JW801
JW568
Q754
JW602
JWH110
JW558
JW584
JW569
JW817
JW816
JW581
JW582
JW578
JW615
JW626
JWH112
JW507
JW636
JW637
JW708
JWH116
CN807
JWH113
JW767
K9900P
Q534
Q533
JW450
JW453
JW320
JW401
JWH120
JWH118
JWH119
JW411
JW412
JW436
JW409
JW410
JW439
JW440
VIO
JW416
JW435
JW423
JW430
JWH101
JW311
JW316
JW454
JW321
JW431
JW424
JW418
JW420
JWH121
JW504 JW620
JW314
JW315
CN808
JW713
JW712
JW836
JW774
JW438
JW559
JW429
JW432
JW508
JW506
JW704
JW819
JW451
JW425
JW772
JW822
JWB02
TP801
JW800
WP102
VIO WP101
WP04
JWH117
JW788
K9900P
K5900P
K9900P
K9900P
K9900P
JW786
JW749
JW785
JW813
C721
Q692
R532
IC801
C732
Q752
R454
R555
C490
C554
C471
R747
R455
R480
C621
D722
R748
R614
C791
RY560
R698
R648
R695
Q572
RED
BRN
R731
C468
L701
R766
C656
R775
R681
Q535
WP02 WP03
R407
C484
Q571
R517
Q680
R402
R434
R405
R470
C493
R676
R831
L601
C409
R404
R562
Q755
D710
R794
R736
C517
C539
Q506
R638
Q750
C751
R408
R756
R431
C744
R432
R603
R458
R300
R657
C561
R693
R757
L651
R732
R456
C810
R406
C767
R733
R621
R780
R457
R771
D750
C733
R772
R761
R763
C492
D802
R436
R667
Q691
Q722
D732
D721
C681
C710
C802
R764
R721
D791
C576
R502
Q560
C619
R503
C669
C504
R703
C531
CNP501
R620
R433
Q602
R616
R622
R617
C655
C570
R553
R625
Q605
R778
R610
R624
C752
L751
C488
C805
D680
C803
R691
R792
C701
C811
C519
R655
Q606
C553
R505
R516
R704
R671
R520
R522
R556
R521
R515
Q702
R510
C577 R511
R473
R557
C408
R680
C482
C472
R524
R540
C511
R714
R554
R573
C400
R513
D505
R575
Q701
R469
Q652
R585
R623
R666
R475
R669
R320
D665
R696
R675
C801
C485
C670
D610
R429
Q756
Q793
D540
C640
R692
C661
C760
C740
RY801
C486
R665
R750
Q740
R526
C642
D691
R660
R755
R773
Q640
R661
R640
R677
Q723
C702
C491
R737
C720
Q795
R663
C762
Q655
Q710
R561
R719
C807
R360
C761
R350
R767
R716
D740
C565
R715
C610
Q651
C510
Q601
R710
D765
R711
R723
R514
R760
CNP500
Q502
R722
R746
C464
R656
R533
Q705
R499
R673
R674
R664
R459
C653
R758
R602
C496
C822
R690
C680
CNP908
C660
C580
IC402
Q809
D705
C711
R586
C804
Q751
R535
R725
R713
Q505
Q725
C651
R310
C567
R694
CNP802
R806
C691
Q580
C506
C507
IC691
Q790
R476
D560
C809
D690
C494
C654
R525
RY601
C489
R474
R340
Q501
R572
Q540
R724
CNP911
R534
Q610
R611
C503
C483
C481
C722
C581
D585
R743
RY701
C445
R804
C716
RY791
IC802
C505
R452
WP100
Q536
R530
R631
R587
R531
C611
C459
D896
C757
C458
R824
C501
R588
C707
Q801
R740
R752
C566
R702
R751
R701
R754
C756
C705
C704
C706
R651
R652
C754
C607
C601
C605
IC701
C657
R653
R654
C750
R604
R765
C606
Q706
C703
R537
R601
C604
R580
C755
C603
C743
IC601
D580
D640
C808
R409
R523
C741
C495
R435
C620
C806
IC501
R699
C499
C469
R735
C444
R501
C666
Q656
R428
D804
R330
R745
R546
C766
C717
C541
C742
C516
D818
D605
R734
R618
R634
R668
R802
R718
R768
R803
R830
JW711
R791
JW821
JW710
JW762
JW759
JW763
R793
D801
JW760
JW761
C832
R910
D808
D805
D806
D807
C830
C831
CN915
JW787
JW791
JW790
JW750
JW789
R613
R615
JW317
JW318
JW457
JW458
JW459
JW460
R574
R576
R570
R571
R672
JW445
TP800
CNP912
CNP806
C540
R769
C770
R741
R717
C753
R744
R753
BC E
1
1
10
58
41
30
31
50
51
80
81
1100
58
14
1
123
32 1
2
2
15
14
15
14
1
13
2
15
14
BCE BCE BCE BCE BCE BCE BCEBCEBCEBCEBC E
41
1
1
4
41
1
2
5
5
1
B
C
E
1
11
14
J791
J404
J401
J309
J403J402
31
K9900P
K9900P
K9900P
4-7. PRINTED WIRING BOARDS — MAIN SECTION — • Refer to page 12 for Circuit Boards Location.
(Page 23)
(Page 23)
(Page 23)
(Page 28)
(Page
28)
(Page 28)
(Page 34)
(Page 30) (Page 28)
(Page 23)
(Page 23)
(Page 28)
(Page 34)
(Page 34)
(Page 30)
D505 F-5
D540 F-4
D560 C-8
D580 F-2
D585 F-3
D605 F-12
D610 D-8
D640 F-9
D665 F-9
D680 F-10
D690 E-9
D691 E-9
•Semiconductor Location
Ref. No. Location Ref. No. Location Ref. No. Location Ref. No. Location
D705 F-7
D710 D-9
D721 E-10
D722 E-10
D732 E-11
D740 F-5
D750 F-9
D765 F-10
D791 E-13
D801 E-13
D802 C-12
D804 E-12
D805 D-13
D806 D-13
D807 D-13
D808 D-13
D818 B-12
D896 D-6
IC401 D-4
IC402 E-4
IC501 F-3
IC601 E-7
IC691 E-8
IC701 E-6
IC801 D-6
IC802 D-6
Q501 F-4
Q502 G-5
Q503 G-4
Q504 G-5
Q505 F-5
Q506 F-5
Q533 G-3
Q534 G-4
Ref. No. Location
Q535 F-4
Q536 F-3
Q540 F-4
Q560 D-7
Q571 F-2
Q572 G-3
Q580 G-2
Q601 F-11
Q602 G-11
Q603 G-11
Q604 G-12
Q605 F-12
Q606 F-12
Q610 D-9
Q640 F-8
Q651 F-8
Q652 G-8
Q653 G-8
Q654 G-9
Q655 F-8
Q656 F-9
Q680 F-10
Q691 E-10
Q692 E-9
Q701 F-6
Q702 G-6
Q703 G-6
Q704 G-7
Q705 F-7
Q706 F-7
Q710 D-9
Q722 E-11
Q723 E-11
Q725 E-10
Q740 F-6
Q750 F-9
Ref. No. Location Ref. No. Location Q751 F-10
Q752 G-10
Q753 G-9
Q754 G-10
Q755 F-10
Q756 F-11
Q790 E-12
Q793 E-11
Q795 E-11
Q801 E-12
(Q809) D-13
Ref. No. Location
( ): STR-K9900P only

STR-K5900P/K9900P
2020
STR-K5900P/K9900P
4-8. SCHEMATIC DIAGRAM — MAIN SECTION (1/2) —
(Page 31)
(Page 27)
(Page 27)
(Page 24)
(Page 35)
(Page 35)
(Page 21)
(Page 35)
(Page 27)
(Page 26)
C472
C810
C811
D560
D896
R402
R404
R405
R406
R407
R408
R452
R454
R455
R456
R457
R458
R499
R533
R803
R474
R480
R806
R459
R409
C408
C409
C458
C459
C488
C801 C802
C807
C808
C822 C809
C464
C805
C806
R476
R475
D801
C481
C485C490
C492
C493
C495
CNP802
C468
C469
R473
IC802
C499
R802
R468
R470
R532
R824
D818
JW786
R831
CNP501
CNP503
R436
R435
R434
R433
R432
R431
CN505
CNP912
CNP500
WP103
WP102
C444
R428 R429
C484
C496
C489
C486
C494
C491
C482
R360
R340
R350
R320
R330
R300
RY560
R469
D806
D805 C831
C830
D808
D807
C832
IC801
RY801
C762C702
J403
J404
IC401
CN915
D804
R804
WP101
C483
R310
Q560
Q801
IC402
J401
C471
WP100
CNP911
R910
D802
Q809
J402
C403
C445
C400
J309
C803
C804
R830
JW790
JW791
CNP908
(Page 31)
