Sony HCD-BX6AV User manual

SERVICE MANUAL
COMPACT DISC DECK RECEIVER
US Model
Canadian Model
AEP Model
UK Model
HCD-BX6AV
E Model
Australian Model
HCD-DX6AV
SPECIFICATIONS
HCD-BX6AV/DX6AV
Photo: HCD-BX6AV
HCD-BX6AV/DX6AV is the Amplifier,
CD player, Tape player and Tuner
section in MHC-BX6AV/DX6AV.
Model Name Using Similar Mechanism HCD-BX2/DX2
CD Mechanism Type EXL-M7
Optical Pick-up Name OPTIMA-7
Model Name Using Similar Mechanism HCD-RXD6AV
Tape Transport Mechanism Type CWL-44-RR
CD
Section
Tape deck
Section
– Continued on next page –
AUDIO POWER SPECIFICATIONS:
(US model only)
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
with 6 ohm loads both cha els drive , from
120-10,000 Hz; rates 10 watts per cha el
mi imum RMS power, with o more tha
10% total harmo ic distortio from 250
milliwatts to rated output.
Amplifier section
US model
Center Speaker:
Co ti uous RMS power output (refere ce)
40 watts
(6 ohms at 1 kHz,
10% THD)
Rear Speaker:
Co ti uous RMS power output (refere ce)
40 + 40 watts
(6 ohms at 1 kHz,
10% THD)
Canadian model
Front Speaker:
Co ti uous RMS power output (refere ce)
60 + 60 watts
(6 ohms at 1 kHz,
10% THD)
Total harmo ics distortio
Less tha 0.07%
(6 ohms at 1 kHz, 30 W)
Center Speaker:
Co ti uous RMS power output (refere ce)
40 watts
(6 ohms at 1 kHz,
10% THD)
Rear Speaker:
Co ti uous RMS power output (refere ce)
40 + 40 watts
(6 ohms at 1 kHz,
10% THD)
AEP, UK models
Front Speaker:
DIN power output (rated) 40 + 40 watts
(6 ohms at 1 kHz, DIN)
Co ti uous RMS power output (refere ce)
50 + 50 watts
(6 ohms at 1 kHz,
10% THD)
Music power output (refere ce)
100 + 100 watts
(6 ohms at 1 kHz,
10% THD)
Center Speaker:
DIN power output (rated) 25 watts
(6 ohms at 1 kHz, DIN)
Co ti uous RMS power output (refere ce)
35 watts
(6 ohms at 1 kHz,
10% THD)
Music power output (refere ce)
70 watts
(6 ohms at 1 kHz,
10% THD)
Rear Speaker:
DIN power output (rated) 25 + 25 watts
(6 ohms at 1 kHz, DIN)
Co ti uous RMS power output (refere ce)
35 + 35 watts
(6 ohms at 1 kHz,
10% THD)
Music power output (refere ce)
70 + 70 watts
(6 ohms at 1 kHz,
10% THD)
Other models:
The followi g measured at AC 120/240 V,
50/60 Hz
Front Speaker:
DIN power output (rated) 45 + 45 watts
(6 ohms at 1 kHz, DIN)
Co ti uous RMS power output (refere ce)
60 + 60 watts
(6 ohms at 1 kHz,
10% THD)
Center Speaker:
DIN power output (rated) 30 watts
(6 ohms at 1 kHz, DIN)
Co ti uous RMS power output (refere ce)
40 watts
(8 ohms at 1 kHz,
10% THD)
Rear Speaker:
DIN power output (rated) 30 + 30 watts
(6 ohms at 1 kHz, DIN)
Co ti uous RMS power output (refere ce)
40 + 40 watts
(6 ohms at 1 kHz,
10% THD)
I puts
MD/VIDEO IN: voltage 250/450 mV,
(pho o jacks) impeda ce 47 kilohms
DVD INPUT:
FRONT IN: voltage 450 mV,
(pho o jacks) impeda ce 47 kilohms
REAR IN: voltage 450 mV,
(pho o jacks) impeda ce 47 kilohms
CENTER IN: voltage 450 mV,
(pho o jacks) impeda ce 47 kilohms
WOOFER IN: voltage 450 mV,
(pho o jacks) impeda ce 47 kilohms
Outputs
PHONES: accepts headpho es of
(stereo mi i jack) 8 ohms or more
FRONT SPEAKER: accepts impeda ce of 6 to
16 ohms
REAR SPEAKER: accepts impeda ce of 6 to
16 ohms
CENTER SPEAKER: accepts impeda ce of 6 to
16 ohms
WOOFER: Voltage 1 V, impeda ce
1 kilohms
CD player section
System Compact disc a d digital
audio system
Laser Semico ductor laser
(λ=780 m)
Emissio duratio :
co ti uous
Laser output Max. 44.6
µ W*
*This output is the value
measured at a dista ce of
200 mm from the
objective le s surface o
the Optical Pick-up Block
with 7 mm aperture.
Ma ufactured u der lice se from Dolby
Laboratories Lice si g Corporatio .
Additio ally lice sed u der Ca adia pate t
1,037,877. “Dolby”, the double-D symbol ; a d
“PRO LOGIC” are trademarks of Dolby
Laboratories Lice si g Corporatio .
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED
LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY. CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
Wavele gth 780 – 790 m
Freque cy respo se 20 Hz – 20 kHz (±0.5 dB)
Sig al-to- oise ratio More tha 90 dB
Dy amic ra ge More tha 90 dB
CD OPTICAL DIGITAL OUT
(Square optical co ector jack, rear pa el)
Wavele gth 660 m
Output Level –18 dBm
Tape player section
Recordi g system 4-track 2-cha el stereo
Freque cy respo se 40 – 13,000 Hz (±3 dB),
usi g So y TYPE I cassette
Tuner section
FM stereo, FM/AM superheterody e tu er
FM tuner section
Tu i g ra ge 87.5 – 108.0 MHz
A te a FM lead a te a
A te a termi als 75 ohm u bala ced
I termediate freque cy 10.7 MHz
AM tuner section
Tu i g ra ge
US, Ca adia models: 530 – 1,710 kHz
(with the i terval set at
10 kHz)
531 – 1,710 kHz
(with the i terval set at
9 kHz)
AEP, UK a d Middle Easter models:
531 – 1,602 kHz
(with the i terval set at
9 kHz)
Other models: 531 – 1,602 kHz
(with the i terval set at
9 kHz)
530 – 1,710 kHz
(with the i terval set at
10 kHz)
A te a AM loop a te a
A te a termi als Exter al a te a termi al
I termediate freque cy 450 kHz
General
Power requireme ts
US, C adia models: 120 V AC, 60 Hz
AEP, UK models: 230 V AC, 50/60 Hz
Australia model: 220 – 240 V AC, 50/60 Hz
Mexica model: 120 V AC, 60 Hz
Other models: 110 – 120 V or 220 – 240 V AC, 50/
60 Hz
Adjustable with voltage selector
Power co sumptio
US model: 160 watts
Ca adia model: 180 watts
AEP, UK models: 160 watts
Other models: 160 watts
Dime sio s (w/h/d)
Approx. 280 x 325 x 390 mm
Mass
US model: Approx. 9.2 kg
Ca adia model: Approx. 9.2 kg
AEP, UK models: Approx. 9.2 kg
Other model: Approx. 9.1 kg
Supplied accessories: AM loop a te a (1)
FM lead a te a (1)
Remote Comma der (1)
Speaker cords (2)
Ce ter speaker pads (4)
Desig a d specificatio s are subject to cha ge
without otice.
This applia ce is classified
as a CLASS 1 LASER
product. The CLASS 1
LASER PRODUCT
MARKING is located o
the rear exterior.
