Sony SRR1000 User manual

MEMORY STORAGE UNIT
SR-R1000
INSTALLATION MANUAL
1st Edition
Serial No. 10001 and Higher: SR-R1000 (SY)
Serial No. 50001 and Higher: SR-R1000 (CN)

SR-R1000
!警告
このマニュアルは，サービス専用です。
お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，
人身事故につながることがあります。
危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to the
following port(s).
: MAINTENANCE connector
: NETWORK 1 connector
: NETWORK 2 connector
Follow the instructions for the above port(s).
For kundene i Norge
Dette utstyret kan kobles til et IT-strømfordelingssystem.

SR-R1000 1 (P)
Attention-when the product is installed in Rack:
1. Prevention against overloading of branch circuit
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
make sure that the rack does not overload the supply
circuit.
2. Providing protective earth
When this product is installed in a rack and is
supplied power from an outlet on the rack, please
confirm that the outlet is provided with a suitable
protective earth connection.
3. Internal air ambient temperature of the rack
When this product is installed in a rack, please make
sure that the internal air ambient temperature of the
rack is within the specified limit of this product.
4. Prevention against achieving hazardous
condition due to uneven mechanical loading
When this product is installed in a rack, please
make sure that the rack does not achieve hazardous
condition due to uneven mechanical loading.
5. Install the equipment while taking the operating
temperature of the equipment into consideration
For the operating temperature of the equipment, refer
to the specifications of the Operation Manual.
6. When performing the installation, keep the
following space away from walls in order to
obtain proper exhaust and radiation of heat.
Right, Left: 4 cm (1.6 inches) or more
Rear: 15 cm (6 inches) or more
設置時には，通気やサービス性を考慮して設置スペース
を確保してください。
. ファンの排気部( リアパネル面，右側面後ろ側 )や通
気孔（フロントパネル面，前面下部，前面両端部）を
ふさがない。
. 通気のために，セット周辺に空間をあける。
. 作業エリアを確保するため，セットの左側面および右
側面は 4cm 以上，セット後方は 40cm 以上の空間を
あける。
机上などの平面に設置する場合は，左側面および右側面
は 4cm 以上の空間をそれぞれ確保してください。ただ
し，セット上部はサービス性を考慮し 40cm 以上の空
間を確保することを推奨します。
When installing, the installation space must be secured
in consideration of the ventilation and service operation.
.Do not block the fan exhaust areas (rear panel and
rear part of the right side panel) and vents (front panel,
front lower part, and front right and left ends) with
objects.
.Leave a space around the unit for ventilation.
.Secure working spaces (at least 4 centimeters from
the left panel and right panel and at least 40 centime-
ters from the rear panel of the unit).
When the unit is installed on the desk or the like, leave at
least 4 centimeters of space in the left and right sides.
Leaving 40 centimeters or more of space above the unit
is recommended for service operation.

1 (E)
SR-R1000
Table of Contents
Manual Structure
Purpose of this manual............................................................ 3 (E)
Related manuals...................................................................... 3 (E)
Trademarks.............................................................................. 3 (E)
1. Installation
1-1. Installation Procedure................................................ 1-1 (E)
1-2. Accessories................................................................1-1 (E)
1-3. Operating Environment............................................. 1-2 (E)
1-4. Power Supply ............................................................1-2 (E)
1-4-1. Power Supply Specifications ...........................1-2 (E)
1-4-2. Recommended Power Cord .............................1-2 (E)
1-5. Installation Space ......................................................1-4 (E)
1-6. Rack Mounting.......................................................... 1-5 (E)
1-7. Connectors and Cables............................................ 1-10 (E)
1-8. Connector Input/Output Signals.............................. 1-11 (E)
1-9. Setting Switch on the Connector Panel................... 1-14 (E)
1-10. Opening/Closing the Control Panel.........................1-14 (E)
1-11. System Setting Method ...........................................1-15 (E)
1-11-1. Setting System Frequency .............................1-15 (E)
1-11-2. Setting Port ....................................................1-16 (E)
1-11-3. Setting Metadata ............................................1-17 (E)
1-11-4. Storing and Reading System Settings in/
from the User Bank........................................1-18 (E)
1-12. Reference System....................................................1-20 (E)
1-13. Settings when Connecting the Unit to an Editing
Device......................................................................1-20 (E)
1-13-1. Setting Timecode ...........................................1-20 (E)
1-13-2. Setting Constant Values for VTR of Editing
Device ............................................................1-20 (E)
1-14. Removing/Installing Plug-in Boards.......................1-21 (E)
1-14-1. Combination of Option Boards......................1-21 (E)
1-14-2. Option Board Installing/Removing
Procedures...................................................... 1-23 (E)
1-14-3. Checking Recognition of SRK-R201/
SRK-R202 by the Unit...................................1-24 (E)
1-14-4. Settings after Installing SRK-R201/
SRK-R202......................................................1-25 (E)
1-15. Ejecting SRMemory (Memory Card) Manually .....1-27 (E)
Appendix A Setting Check Sheet

3 (E)
SR-R1000
Manual Structure
Purpose of this manual
This manual is the installation manual of Memory Storage Unit SR-R1000.
This manual is intended for use by trained system and service engineers,
and provides the information that is required to install (operating environment,
installation space, connection information, initial setting, etc.) and the setting check
sheet.
Related manuals
Besides this Installation Manual, the following manuals are prepared for SR-R1000.
.Operation Manual (PDF) (Supplied with this unit. (CD-ROM))
This manual describes the application and operation of this unit.
.Maintenance Manual (Available on request)
Volume 1: Service Instruction
Volume 2: Parts List, Block Diagrams, and Board Layouts
Volume 3: Schematic Diagrams
These manuals describe the maintenance and service information (service over-
view, error message, detailed parts list, block diagrams, board layouts, schematic
diagrams, etc.) for this unit.
.Protocol Manual of Remote (9-pin) Connector (Available on request)
This manual explains the protocol for controlling this unit via the RS-422A (9-pin
serial remote).
Trademarks
Trademarks and registered trademarks used in this manual are follows.
.Ethernet is a registered trademark of Xerox Corporation.

1-1 (E)
SR-R1000
1-1. Installation Procedure
The following flowchart shows the installation procedure
of the unit.
For details of each step, refer to the relevant section.
Items marked with an asterisk (*) also need the Operation
Manual.
Start
Determination of
installation place
1-3. Operating Environment
1-4. Power Supply
1-5. Installation Space
1-7. Connectors and Cables
1-8. Connector Input/Output Signals
1-9. Setting Switch on the Connector Panel
1-10. Opening/Closing the Control Panel
1-11. System Setting Method
1-12. Reference System
1-13. Settings when Connecting the Unit to an Editing Device
1-6. Rack Mounting
n
When the unit is transported, it is required to pack the unit into the specified new packing materials.
Do not reuse the packing materials.
n
If an error message appears on the time data display area, refer to the operation manual.
(For more details, refer to the maintenance manual volume 1.)
* Connection
* Initial setup
* Operation check
End
Unpacking
Rack mounting
Section 1
Installation
1-2. Accessories
.Operation Manual CD-ROM (PDF) (x1)
.Installation Manual (x1)
.Operation Guide (x1)
.SR VIEWER CD-ROM (x1)

1-2 (E) SR-R1000
1-3. Operating Environment
n
Do not block any air vents in the cabinet and exhaust vents
for fans to reduce temperature rise in the unit.
Furthermore, implement appropriate measures for cooling
air to adequately flow in the unit.
Operating temperature: 5 to 40 degrees-C
Operating humidity: 25 to 90 % (no condensation)
Storage temperature: _20 to 60 degrees-C
Prohibited installation places:
.Places exposed to direct sunlight or intense light
.Places near a heat source
.Dusty places or places subject to constant vibration
.Places in strong magnetic field
.Places subject to much electrical noise
.Places where electrostatic noise is likely to be generated
.Places where specified installation space cannot be
provided (Refer to Section 1-5 “Installation Space.”)
.Sealed places
Horizontal installation condition:
Allowable gradient of 30 degrees or less
Do not tilt the front or rear of the unit more than 30
degrees.
c
If the unit is used at a slant, secure it to prevent it from
slipping down.
1-4. Power Supply
1-4-1. Power Supply Specifications
A switching regulator is used in the power supply unit of
the unit.
n
Be sure to use the unit within the following power voltage
range.
Power voltage: 100 VAC ±10 %
Power frequency: 50 or 60 Hz
Power consumption: 480 W max. (including options)
Inrush current: 25 A at 100 VAC
n
The AC power supply requires capacity including inrush
current.
If the AC power capacity is insufficient, the circuit breaker
of the AC power supply on the supply side may be turned
on, which may cause malfunction of the unit.
1-4-2. Recommended Power Cord
This unit does not come with a power cord.
To get a power cord, please contact your local Sony Sales
Office/Service Center.
w
.Use the approved Power Cord (3-core mains lead)/Appli-
ance Connector/Plug with earthing-contacts that con-
forms to the safety regulations of each country if appli-
cable.
.Use the Power Cord (3-core mains lead)/Appliance
Connector/Plug conforming to the proper ratings (Volt-
age, Ampere).
If you have questions on the use of the above Power Cord/
Appliance Connector/Plug, please contact your local Sony
Sales Office/Service Center.
w
.Never use an injured power cord.
For customers in the U.S.A. and Canada:
1Power cord 125 V 10 A (2.4 m): !1-551-812-31
2Plug holder: 3-613-640-01
2
1
AC inlet
For customers in the United Kingdom
1Power cord 250 V 10 A (2.4 m): !1-777-823-12
2Plug holder: 3-613-640-01
AC inlet
21

1-3 (E)
SR-R1000
For customers in European countries except the United
1Power cord 250 V 10 A (2.0 m): !1-551-631-15
2Plug holder: 3-613-640-01
AC inlet
21
For customers in China
1Power cord 250 V 10 A (1.8 m): !1-830-860-11
2Plug holder: 3-613-640-01
AC inlet
21

1-4 (E) SR-R1000
1-5. Installation Space
When installing, the installation space must be secured in
consideration of the ventilation and service operation.
.Do not block the ventilation slots at the left side and right
side panels, and vents of the fans.
.Leave a space around the unit for ventilation.
.Leave more than 40 centimeters of space in the rear of
the unit to secure the operation area.
When the unit is installed on the desk or the like, leave at
least four centimeters of space in the left and right sides.
Leaving 40 centimeters or more of space above the unit is
recommended for service operation.
Unit : mm
Mass of this unit (not including option) : approx. 19 kg
540.7
45.5 530
481 156 45
577 (Maximum traveling distance)
454
15.9
12.7
123.8
263.5
457.5
87 87
70.6
416 (Rail-installed width)
3131 112
36.2
87
17421.5
427 (Unit width)
34
465
364
31.5
427
nRemove the feet when rack mounting.
Dimensions when Rack-Mounting
Moreover, an air flow that is effective in cooling the unit is
essential. If the ventilation is not enough, the unit may be
damaged because of an increase of the internal tempera-
ture.
n
This unit is air-cooled by the fans. The operation with the
upper lid is removed affects the air cooling by the fans.
Complete the work in a short time as possible when operat-
ing the unit for inspection with the upper lid removed.
If it takes a long time, blow to the unit by an electric fan to
cool the unit.

1-5 (E)
SR-R1000
1-6. Rack Mounting
Explains how to mount this unit into a 19-inch standard
rack.
Be sure to mount this unit into a rack accurately following
the procedure and notes mentioned below.
w
.To prevent toppling over the rack, fix it on the horizontal
and firm floor securely with bolts, etc.
.When installing the unit in an Outside Broadcasting van,
be sure to fix the unit to the rack using the screws and
ornamental washers supplied with the rack mount kit.
c
.Use the specified rack mount rail.
The use of other rail of low strength may drop the unit
and cause the risk of injury.
.Mount the unit into a rack with a steady posture.
m
.When other equipment with built-in hard disk drive is
already mounted in the same rack for mounting this unit,
turn off the power of the equipment before mounting this
unit.
.Connect long enough cables on the connector panel,
considering that the unit is pulled out from the rack.
.Do not operate this unit without the upper lid and bottom
plate except when servicing it.
.To suppress the internal temperature rise of the unit,
reserve a space of 4 cm or more on both sides and 15 cm
or more on the rear side between the rack and the unit.
(Refer to Fig. 1.)
To maintain ventilation in these spaces, open at least one
of the top, rear, right, and left faces at the rear of the unit.
(Refer to Fig. 2.)
.Adjust the temperature inside the rack within the range
of the unit’s operating temperature.
(Refer to Section 1-3.)
4 cm or more4 cm or more
4 cm or more
4 cm or more
15 cm or
more
15 cm or
more
(Fig.1)
(Fig.2)
15 cm or
more
4 cm or
more
TopTop
Left
Rear
RightRight
Left
Rear
4 cm or more
4 cm or more4 cm or more
4 cm or more
4 cm or more
15 cm or
more
15 cm or
more
(Fig.1)
(Fig.2)
15 cm or
more
4 cm or
more
TopTop
Left
Rear
RightRight
Left
Rear
4 cm or more

1-6 (E) SR-R1000
Specified Rack Mount Kit
RMM-131 (Optional accessory)
The RMM-131 Rack Mount Kit is for mounting equip-
ments in a standard EIA 19-inch rack.
Size limits on applicable equipment
.Maximum weight: 40 kg
.Maximum width: 427 mm
.Height: 4U (approximately 176 mm)
Applicable rack
Racks with a depth of 660 to 830 mm (22-inch rails).
Parts Packed in RMM-131
.Slide rail : 2 pcs
.Rack angle (handle) : 2 pcs
.Rail brackets : 4 pcs
.Plate nut (large) : 4 pcs
.Plate nut (small) : 4 pcs
.Screw (B4 x8) : 8 pcs
.Hexagon socket head cap screw : 8 pcs
.Flat washer : 8 pcs
.Screw (RK5 x14) : 2 pcs
.Decorative washer : 2 pcs
.Cap : 2 pcs
.L-shaped hexagonal wrench : 1 pc
Rack Mounting Procedure
Removing legs
1. Place the unit with its side panel down.
2. Remove the four screws to detach the legs from the
bottom plate of the unit.
3. Place the unit horizontally.
n
Keep the removed screws and legs in a safe place.
When using this unit outside the rack, be sure to reattach
the legs.
Tightening torque: 98 x10_2N .m {10 kgf .cm}
Legs
Legs
PS4 x20
PS4 x20
Legs
Legs
PS4 x20
PS4 x20

1-7 (E)
SR-R1000
Attaching inner rails
4. Pull the inner rails out of the middle rails.
5. Pull out the inner rails in the direction of arrow B
while pressing the stoppers of the inner rails in the
direction of arrow A.
6. Remove the 10 screws from the right and left side
panels of the unit as shown in the figure below.
7. Attach two inner rails to the right and left side panels
of the unit using the screws removed in step 6.
Tightening torque: 120 x10_2N .m {12.2 kgf .cm}
m
.Be sure to use B4 x6 screws to secure the inner
rails. Using other screws may cause operational
problems to the unit.
.Do not install screws other than those for inner rail
fixing screw holes that are used actually. If unneces-
sary screws are installed, the unit cannot be mounted
on the rack.
n
When replacing a Sony’s 5U-size VTR with this unit in the
rack, attach the inner rails at the lower part.
The bottom plate of this unit is at the same height of the
bottom plate of the 5U-size VTR.
A
B
Middle rail
Inner rail
Stopper
Outer rail
A
B
Middle rail
Inner rail
Stopper
Outer rail
Inner rail
Inner rail
B4 x6
B4 x6
Inner rail
Inner rail
B4 x6
B4 x6
Attaching rack angles (handles)
8. Remove the four screws from the right and left side
panels of the unit.
m
.Keep the removed screws (B4 x6) in a safe place.
.When removing the rack angles and attaching the
side panels directly with screws, be sure to use the
screws (B4 x6) removed in step 8. Using other
screws may cause operational problems to the unit.
9. Attach the two rack angles to the right and left sides of
the unit with the four rack angle fixing screws (with
stopper) supplied with the rack angles.
Tightening torque: 120 x10_2N .m {12.2 kgf .cm}
B4 x6
B4 x6
B4 x6
B4 x6
B4 x6
B4 x6
Rack angle
Rack angle
Rack angle
Rack angle

1-8 (E) SR-R1000
Attaching rail fixing brackets temporarily
10. Shift the middle rails as shown in the figure and attach
the rail fixing brackets to the outer rails temporarily
with the plate nuts (large) and four screws (two for
each side).
11. Shift the ball retainers in the arrow direction and attach
the rail fixing brackets to the outer rails temporarily
with the plate nuts (large) and four screws (two for
each side).
Plate nut (large)
Outer rail
Middle rail
B4 x8
Rail fixing bracket
Plate nut (large)
Outer rail
Middle rail
B4 x8
Rail fixing bracket
Plate nut
(large)
Outer rail
Middle rail
Rail fixing bracket
B4 x8
Ball retainer
Plate nut
(large)
Outer rail
Middle rail
Rail fixing bracket
B4 x8
Ball retainer
Attaching outer rails
12. Attach the right and left outer rails temporarily to the
rack at a height of 2U from the bottom in the 4U space
with eight hexagon socket head cap screws, eight plain
washers, and four plate nuts (small) in total.
13. Adjust the right and left rail positions so that the
distance from the rack angle installation surface of the
rack to the end of the outer rail is 50 to 55 mm as
shown in the figure below.
14. Tighten the eight screws to secure the four rail fixing
brackets that are attached temporarily to the right and
left outer rails.
Tightening torque: 120 x10_2N .m {12.2 kgf .cm}
Plate nut (small)
L-shaped hexagonal wrench
Hexagon socket head
cap screw
Rail fixing bracket
Rail
Plain washer
By 4U
2U
Plate nut (small)
L-shaped hexagonal wrench
Hexagon socket head
cap screw
Rail fixing bracket
Rail
Plain washer
By 4U
2U
50 to 55 mm
B4 x8
Rack angle
Rail fixing bracket
Rack
Outer rail
50 to 55 mm
B4 x8
Rack angle
Rail fixing bracket
Rack
Outer rail

1-9 (E)
SR-R1000
15. Check that the right and left middle rails are attached
in parallel.
16. Tighten the eight hexagon cap screws with a hexagon
wrench to secure the right and left rails that are at-
tached temporarily to the rack in step 12.
A
A’
Middle rails
Distance: A = A’ =416 mm
A
A’
Middle rails
Distance: A = A’ =416 mm
Mounting the unit on the rack
c
Be sure to perform this mounting work with two or more
persons.
17. Shift the ball retainers of the right and left middle rails
in the arrow direction.
18. Extend the right and left middle rails to the same
length.
19. Hold the handles and lift the unit and insert the inner
rails slowly into the middle rails.
20. Push the unit slowly into the rack while pressing the
right and left stoppers.
c
Be sure to perform this work with two or more per-
sons.
n
When the unit is fully pushed into the rack, the lock mech-
anism is activated and the unit can no longer be pulled out.
To pull out the unit in this state, pull it out while pressing
the unlock buttons on the rack angles.
Middle rail
Ball retainer
Middle rail
Ball retainer
Middle rail
Stopper
Stopper
Inner rail
Unlock button
Unlock button
Middle rail
Stopper
Stopper
Inner rail
Unlock button
Unlock button

1-10 (E) SR-R1000
1-7. Connectors and Cables
Use the following connectors (or cables) or equivalent for cable connection.
Panel Indication Applicable Connector (Cable) Sony Part No. Remarks
TIME CODE INPUT
TIME CODE OUTPUT
BNC 75 Z, MALE 1-569-370-12 _
AUDIO MONITOR OUTPUT L, R XLR 3P, FEMALE 1-508-083-00 _
REF. INPUT BNC 75 Z, MALE 1-569-370-12 _
DIGITAL AUDIO INPUT 1 to 16 (AES/EBU)
DIGITAL AUDIO OUTPUT 1 to 16 (AES/EBU)
BNC 75 Z, MALE (*1) 1-569-370-12 _
GPIO (25P) D-SUB 25P, MALE and
JUNCTION SHELL 25P
1-560-904-11
1-563-377-11
_
REMOTE 1 to 4 (9P) 9P remote control cable
(RCC-G series) or
D-SUB 9P, MALE and
JUNCTION SHELL 9P
_
1-560-651-00
1-561-749-00
_
VIDEO CONTROL D-SUB 9P, MALE and
JUNCTION SHELL 9P
1-560-651-00
1-561-749-00
_
HD SDI INPUT A/B
HD SDI INPUT MONITOR A/B
HD SDI MULTI MONITOR
HD SDI OUTPUT A/B
SD/HD SDI OUTPUT MONITOR A/B
BNC 75 Z, MALE 1-569-370-12 _
PHONES JM-60 stereo phone plug _Below SRMemory slot on
the control panel
NETWORK 1, 2
MAINTENANCE
Network cable (commercially available) __
*1: Maximum cable length: 300 m (Reference value of this unit)
Fujikura’s 5C-2V or equivalent is recommended for the coaxial cable.

1-11 (E)
SR-R1000
1-8. Connector Input/Output Signals
INPUT
A B A B MULTI IN OUT 1/2 3/4 5/6 7/8 9/10 11/12 13/14 15/16
HD SDI TIME CODE DIGITAL AUDIO INPUT(AES/EBU)
INPUT MONITOR
INPUT BOARD (SRK-R201)
OUT1 OUT2
A B B A B MULTI OUT 1/2 3/4 5/6 7/8 9/10 11/12 13/14 15/16A
TIME CODE DIGITAL AUDIO OUTPUT(AES/EBU)
SD/HD SDI MONITOR
OUTPUT BOARD (SRK-R202)
!-!\
15 3628
!\
4
!/
!] != ![
7968
Input Connectors
Panel Indication Remarks
1HD SDI INPUT A/B BNC x2
Impedance: 75 Z?1 %
Voltage: 0.8 V p-p
HD SDI (1.485Gbps) (SMPTE-292M/BTA-S004B compliant)
Dual Link HD SDI (SMPTE-372M compliant)
3G SDI (2.97Gbps) (SMPTE-424M)
2TIME CODE INPUT BNC x1
High impedance, unbalanced
Voltage: 0.5 to 18 V p-p
3DIGITAL AUDIO INPUT 1 to 16 (AES/EBU) BNC x8 (1 set: CH1/2, CH3/4, CH5/6, CH7/8, CH9/10, CH11/12, CH13/14, CH15/16)
Impedance: 75 Z?1 %
Voltage: 1.0 ?0.1 V p-p
AES/EBU format, unbalanced (AES3id compliant)
4REF. INPUT BNC x2 (Loop-through output x1, 75 Zwith terminating switch)
External reference video signal
.HD (Tri-level SYNC): 0.6 V p-p, 75 Z
.SD (Black burst or composite SYNC):
NTSC: 0.286 V p-p, 75 Z(terminated)
PAL: 0.3 V p-p, 75 Z(terminated)

1-12 (E) SR-R1000
Output Connectors
Panel Indication Remarks
5HD SDI INPUT MONITOR A/B BNC x2
Impedance: 75 Z?1 %
Voltage: 0.8 V p-p
HD SDI (1.485Gbps) (SMPTE-292M/BTA-S004B compliant)
Dual Link HD SDI (SMPTE-372M compliant)
3G SDI (2.97Gbps) (SMPTE-424M)
6HD SDI MULTI MONITOR BNC x1
Impedance: 75 Z?1 %
Voltage: 0.8 V p-p (with 75 Zterminating resistance)
HD SDI (1.485Gbps) (SMPTE-292M /BTA-S004B compliant)
7SD/HD SDI OUTPUT A/B BNC x6 (MONITOR: with character superimposition)
Impedance: 75 Z?1 %
Voltage: 0.8 V p-p (with 75 Zterminating resistance)
HD SDI (1.485Gbps) (SMPTE-292M/BTA-S004B compliant)
3G SDI (2.97Gbps) (SMPTE-424M)
8TIME CODE OUTPUT BNC x1
Impedance: 75 Z
Voltage: 1.2 V p-p ?3 dB
9DIGITAL AUDIO OUTPUT 1 to 16 BNC x8 (1 set: CH1/2, CH3/4, CH5/6, CH7/8, CH9/10, CH11/12, CH13/14, CH15/16)
(AES/EBU) Impedance: 75 Z?1 %
Voltage: 1.0 ?0.1 V p-p
AES/EBU format, unbalanced (AES3id compliant)
!/ AUDIO MONITOR OUTPUT L/R XLR 3-pin x2 (1 set: L, R)
Analog audio
+4 dBm (typical) (with 600 Zload), low impedance, balanced
_PHONES JM-60 stereophone jack x1
(Below SRMemory slot on the control Analog audio
panel) Up to _12 dBu (with 8 Zload), unbalanced
Remote Connectors
Panel Indication Remarks
!- REMOTE 1 to 4 D-SUB 9-pin x4
RS-422 interface, remote control
!= VIDEO CONTROL D-SUB 9-pin x1
For connection to HD digital video controller (HKDV-900)
![ NETWORK 1/2 RJ-45 8-pin x2
1000BASE-T
!] GPIO (25P) D-SUB 25-pin x1
!\ MAINTENANCE USB type x1
RJ-45 8-pin x1
