Sony SA-WEX200 User manual

1
SA-WEX200
ACTIVE SUBWOOFER
US Model
Canadian Model
SPECIFICATION
Ver 1.0 2001.09
SA-WEX200 is sub woofer in CMT-EX200.
9-873-267-01
2001I0200-1
© 2001.9
Sony Corporation
Home Audio Company
Shinagawa Tec Service Manual Production Group
Amplifier section
For the U.S.model
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 4 ohms loads,from 50 – 150 Hz;rated 30 watts
per channel minimum RMS power,with no more than
10%total harmonic distortion from 250 milli watts to
rated output.
Canadian model:
Continuous RMS power output (reference):
30 watts
(4 ohms at 55 Hz,10%
THD)
Speaker system Active sub woofer
(magnetically shielded
design)
Speaker unit 10 cm dia,cone type
woofer (x2)
Practical maximum output 30 watts
Reproduction frequency range
45 – 150 Hz
High frequency cut-off range
70 – 150 Hz
Phase selector Normal,reverse
Input SPEAKER INPUT:
Input terminal
Output SPEAKER OUTPUT:
Output terminal
Power requirements 120 V AC,60 Hz
Power consumption 40 watts
Dimensions Approx.150 x 220 x
345 mm (w/h/d,incl.
projecting parts and
controls)
Mass Approx.6.2 kg
Design and specifications are subject to change
without notice.
SERVICE MANUAL

2
SA-WEX200
TABLE OF CONTENTS
1. GENERAL .......................................................................... 3
2. DIAGRAMS
2-1. Circuit Boards Location ........................................................ 3
2-2. Printed Wiring Board ............................................................ 4
2-3. Schematic Diagram ............................................................... 5
3. EXPLODED VIEW
3-1. Front Section ......................................................................... 6
4. ELECTRICAL PARTS LIST ......................................... 6
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
After correcting the original service problem, perform the
following safety checks before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized”knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
LEAKAGE
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit”indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples of
a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2V AC range are suitable. (See
Fig. A)
SAFETY CHECK-OUT
(US model)
Fig. A. Using an AC voltmeter to check AC leakage.
0.15µF
To Exposed Metal
Parts on Set
1.5kΩ
AC
voltmeter
(0.75V)
Earth Ground

33
SA-WEX200
SECTION 1
GENERAL
SECTION 2
DIAGRAMS
For schematic diagrams.
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
•C: panel designation.
For printed wiring boards.
Note:
•X: parts extracted from the component side.
•b: Pattern from the side which enables seeing.
• : B+ Line.
• : B– Line.
• Voltages are dc with respect to ground under no-signal con-
ditions.
no mark : Power on
• Voltages are taken with a VOM (Input impedance 10MΩ).
Voltage variations may be noted due to normal preduction
tolerances.
• Signal path.
K: AUDIO
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
2-1. Circuit Boards Location
Note:
The components identi-
fied by mark 0or dotted
line with mark 0are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
This section is extracted from
instruction manual.
Sub Woofer
CUT OFF FREQ 3(15)
LEVEL 1(15)
PHASE 4(15)
Power indicator 2
• Location of controls
INPUT board
MAIN boar
d
AC board
POWER AMP board
FRONT board

44
SA-WEX200
2-2. PRINTED WIRING BOARD
• See page 3 for Circuit Boards Location.
18
CN201
1
8
IC201
18
IC202
R204
R214
R117
R115
R203
R116
R114
R206
R207
R208
R205 C209
C208
C211
C210
C205
C207
C213
C203
C212
C204
C103
C104
D201
ON/STBY
RV202
LEVEL
RV201
CUT OFF FREQ
FRONT BOARD
11
(11)
S201
PHASE
1
11
10
2
L
SPEAKER
INPUT
R
TM101
+
–
+
–
L
SPEAKER
OUTPUT
R
+
–
+
–
1
8
12
1
2
1
2
3
1
2
R401
R402
C452
C451
C404
C406
C405
C403
C401C402
1
8
CN201M
1
7
CN302W
13
CN501
1
10
CN301W
1
CN203M
1
CN502
T2
F402
–+
F401
D401
D404
D403
D451
D455
D454
D453
D452
R451
MAIN BOARD
11
(11)
R303 R304
R309
R307
R310
R311
Q303
Q304 Q302 Q301
R313
R312
R301
R308 R302
B C
E
E
C B
E
C B
E
C B
C309
C305
C311
C306
C312
C310
C303
C302
C308 C307 C320
R306
C314
D302
D304
D303
1
7
CN302
1
CN303
RY301
D301
IC851
POWR AMP BOARD
11
(11)
SP901
SP902 (PASSIVE WOOFER)
INPUT BOARD
11
(11)
R503
R513
R501
R507
R120
R121
R502
R504
R511
R506
R103
R510
R512
R515 R514
R508R509
R505
R105
R102 R101
R106
R112
R123
R122
R118R111 IC101
R107
C505
C504
C704
C703
CN301
10
1
C506
C501
C503
C507
C502
C701
C711
D102
D503
D504
D103
D101
D104
D501
D502
D505
B
C
E
E C B
E C B
E C B
B C E
B C E
B C E E
C
B
Q501
Q507
Q508
Q506
Q503
Q504
Q502
Q505
RY461
C2
C3
D461
1
CN203
CN503
CN501M
CN502M S1
POWER
AC BOARD
11
(11)
CP901
AC IN
T1
POWER
TRANSFORMER
2345678910111213
A
1
B
C
D
E
F
G
H
J
I
1-683-832- 1-683-834-
1-683-831-
1-683-833-
1-683-835-
D101 B-10
D102 B-10
D103 B-10
D104 A-10
D201 H-2
D301 I-5
D302 I-5
D303 I-4
D304 H-4
D401 B-4
D403 B-1
D404 C-1
D451 A-6
D452 A-6
D453 A-6
D454 A-6
D455 B-7
D461 F-9
D501 C-10
D502 E-10
D503 D-9
D504 C-10
IC101 A-10
IC201 G-2
IC202 H-2
IC851 H-5
Q301 G-4
Q302 G-4
Q303 H-4
Q304 G-4
Q501 C-10
Q502 E-10
Q503 D-9
Q504 D-10
Q505 E-9
Q506 D-10
Q507 D-10
Q508 C-10
• Semiconductor
Location
Ref. No. Location

55
SA-WEX200
2-3. SCHEMATIC DIAGRAM
IC202(2/2)
IC202(1/2)
R208
R207
R205
R206
C204
R214
C203
R204
C212
R203
IC201(2/2)
IC201(1/2)
C103 C104
C213
R115
R117
R114
R116
D201
CN201
CN201M
IC101(2/2)
IC101(1/2)
R107
R118
R112
D104
D103
D102
D101
R103
R105
R101
R120
R122
R123
R121
R106
R102
TM101
R513
R511
R512
R510
D504
Q505
Q504
R507
R508
R509
Q503
D505
D503
R505
R503
R504
Q502
C507
R502
D502
R501
C502
D501
D455
R451
D454
D451
D452
D453
CN203M CN203
D461
C3
JW1
CN503
JW2
D403
D404 R402
F402
C401
D401
F401
R314
D304
R313
R312
Q304
Q302
Q301
R310
R311
D303
R309
RY301
CN303
C308
C307
R307
R304
R302
R306
C302
C320 D302
D301
R111
T1
R301
IC851
C207 C210
C211
C205
C312
C305
C306
C504
C503
C506
C311
C704
C208
C209
C703
C405
C406
C451
C452
C303
C501
C505
C310
C309
R308
R401
T2
C403
C404
C402
CN502 CN502M
CN501M
CN501
CN301 CN301W
CN302
CN302W
RY461
C2
RV201
RV202
S201
R514
R515
R506
Q506
Q508
Q507
SP901
R303 Q303
Q501
C701
C711
SP902
JW3
NJM4580
NJM4580
100k
10k
10k
10k
0.068
100k
0.47
4.7k
100p
10k
NJM4580
NJM4580
0.047 0.047
100p
8.2k
1M
220k
470k
SML72423C-TP4
8P
BOARD
IN
8P
PH-L
NJM4580
NJM4580
22k
1.5k
180
1SS133
1SS133
1SS133
1SS133
180
10k
10k
4.7k
1/2W
220
1/2W
220
1/2W
4.7k
1/2W
10k
10k
SPEAKER
510
10k
220
100k
11ES2
2SC2785
2SA1175
820k
820k
10k
2SC2785
JW
1SS133
10k
1M
JW
2SC2785
0.1
100k
MTZJ-3.0A
2.2k
22000p
MTZJ-5.6A
1SS133T
4.7k
11ES2
11ES2
11ES2
11ES2
2P
PH
2P
BOARD
IN
1SS133T
0.1
275V
JW
2P
UP-S
YEW
JW
MTZJ15B
MTZJ15B 1k
2W
3.15A
125V
0.1
D3SBA20
3.15A
125V
10k
1SS133T
47k
100k
2SC2785
2SC2785
DTC124ES
100k
10k
1SS133T
22k
SPK RELAY
24V
2P
VH-L
WHT
1
1
2.2
1W
56k
22k
33k
220p
220p 1SS133T
1SS133T
10k
4.7k
LM3876-TF
4.7
50V
22
50V
22
50V
4.7
50V
10
50V
47
50V
47
50V
10
50V
4.7
50V
4.7
50V
4.7
50V
47
25V
47
25V
47
25V
47
25V
100
25V
100
25V
470
25V
470
25V
100
25V
47
25V
47
25V
100
25V
220
10V
JW
1k
2W 3300
35V
AS
3300
35V
AS
0.1
2P 2P
2P
3P
10P 10P
7P
7P
4700p
125V
20k
20k
10k
10k
10k
UN4111
10K/10K
UN4111
10K/10K
DTC114ES
10K/10K
1.5k 2SC2785
2SC2785
JW
JW
JW
IN
POWER AMP
SPK/LINE MIX
L/R MIX
HPF
+15V
-15V
GND
IN
GND
OUT
OUT
LEVEL
NUTRAL
LIVE CP901
6MA
9MA
ON/STBY
SUB TRANS
GRN-LED
RED-LED
CHASSIS
REVERSE
NORMAL
LEVEL
CUT OFF FREQ
CUT OFF FREQ
PHASE
INPUT/OUTPUT
POWER
TRANSFORMER
AC IN
5
6
8
7
3
2
4
1
1
4
3
27
6
58
1
2
3
4
5
6
8
7
RELAY
DRIVER
DETECT
DETECT
AC IN
Q301,302
DC LEVEL
LCD DRIVER
LCD DRIVER
INV.
RELAY
DRIVER
Q504,505
Q502,503
AUDIO
LEVEL DETECT
REG
WOOFER
PASSIVE

66
SA-WEX200
3-1. FRONT SECTION
SENTION 3
EXPLODED VIEWS
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Accessories and packing materials are given
in the last of the electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
SECTION 4
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
A-4727-799-A AC BOARD, COMPLETE
*****************
< CAPACITOR >
0C2 1-113-926-11 CERAMIC 0.0047uF 20% 125V
0C3 1-131-983-11 FILM 0.1uF 10% 275V
< CONNECTOR >
*CN501M 1-568-226-11 PIN, CONNECTOR 2P
*CN502M 1-568-226-11 PIN, CONNECTOR 2P
*CN503 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D461 8-719-911-19 DIODE 1SS119-25
< RELAY >
0RY461 1-755-198-11 RELAY
******************************************************
A-4727-796-A FRONT BOARD, COMPLETE
********************
< CAPACITOR >
C103 1-136-161-00 FILM 0.047uF 5% 50V
C104 1-136-161-00 FILM 0.047uF 5% 50V
C203 1-137-194-81 FILM 0.47uF 5% 50V
C204 1-136-495-11 FILM 0.068uF 5% 50V
C205 1-126-163-11 ELECT 4.7uF 20% 50V
C207 1-126-163-11 ELECT 4.7uF 20% 50V
C208 1-119-799-11 ELECT 47uF 20% 25V
C209 1-119-799-11 ELECT 47uF 20% 25V
C210 1-128-858-11 ELECT 22uF 20% 50V
C211 1-128-858-11 ELECT 22uF 20% 50V
C212 1-162-282-31 CERAMIC 100PF 10% 50V
C213 1-162-282-31 CERAMIC 100PF 10% 50V
< DIODE >
D201 8-719-056-11 DIODE SML72423C-TP15 (ON/STBY)
< IC >
IC201 8-759-261-93 IC NJM4580LD
IC202 8-759-261-93 IC NJM4580LD
< RESISTOR >
R114 1-247-887-00 CARBON 220K 5% 1/4W
R115 1-249-428-11 CARBON 8.2K 5% 1/4W F
R116 1-247-895-91 CARBON 470K 5% 1/4W
R117 1-247-903-00 CARBON 1M 5% 1/4W
R203 1-249-429-11 CARBON 10K 5% 1/4W
R204 1-249-425-11 CARBON 4.7K 5% 1/4W F
R205 1-249-429-11 CARBON 10K 5% 1/4W
R206 1-249-429-11 CARBON 10K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-249-441-11 CARBON 100K 5% 1/4W
R214 1-249-441-11 CARBON 100K 5% 1/4W
< VARIABLE RESISTOR>
RV201 1-227-435-11 RES, VAR 20K (CUT OFF FREQ)
RV202 1-227-435-11 RES, VAR 20K (LEVEL)
< SWITCH >
S201 1-554-419-00 SWITCH, PUSH (1 KEY) (PHASE)
******************************************************
A-4727-797-A INPUT BOARD, COMPLETE
*******************
< CAPACITOR >
C501 1-126-947-11 ELECT 47uF 20% 25V
C502 1-136-157-00 FILM 0.022uF 5% 50V
C503 1-126-963-11 ELECT 4.7uF 20% 50V
C504 1-126-964-11 ELECT 10uF 20% 50V
C505 1-126-947-11 ELECT 47uF 20% 25V
C506 1-126-963-11 ELECT 4.7uF 20% 50V
C507 1-136-165-00 FILM 0.1uF 5% 50V
C703 1-119-799-11 ELECT 47uF 20% 25V
C704 1-119-799-11 ELECT 47uF 20% 25V
< CONNECTOR >
*CN301 1-569-505-11 PIN, CONNECTOR 10P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-991-33 DIODE 1SS133T-77
D104 8-719-991-33 DIODE 1SS133T-77
D501 8-719-109-88 DIODE RD5.6ESB1
FRONT
AC INPUT
1 4-220-455-01 FOOT (FELT)
2 4-238-165-01 BOTTOM BOARD
3 4-238-164-01 SPEAKER BOX
4 4-238-158-01 KNOB
5 4-238-159-01 BUTTON
6 X-4954-421-1 FRONT PANEL ASSY
7 A-4727-796-A FRONT BOARD,COMPLETE
8 A-4727-795-A MAIN BOARD,COMPLETE
9 A-4727-798-A POWER AMP BOARD,COMPLETE
10 A-4727-799-A AC BOARD,COMPLETE
11 4-238-152-01 PANEL, BACK
12 A-4727-797-A INPUT BOARD,COMPLETE
013 1-783-531-31 CORD, POWER
*14 3-703-244-00 BUSHING (2104), CORD
15 4-238-157-01 COVER, BACK
16 4-238-156-01 FOOT, SMALL
17 4-238-155-01 FOOT, LARGE
18 4-874-614-31 SCREW (4) (3.5X12), TAPPING
19 2-110-606-01 SCREW (DIA. 4X3.5) (1), +BTP
SP901 1-544-909-11 SPEAKER (10CM)
SP902 1-544-910-11 SPEAKER (10CM)
0T1 1-437-503-11 TRANSFORMER, POWER
16
1
1
2
17
17
19
3
18
18
4
5
6
7
8
18
18
9
15
14
13
11
10
12
SP901
SP902
Supplied with
RV201, 202
not supplied
not supplied
not supplied
not supplied
not
supplied
T1
#
4
#4
#3
#3
#3
#3
#3
#3
#3
#3
#1
#5
#5
#5
#5
#5
#2 #2

7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-WEX200
D502 8-719-981-97 DIODE MTZJ-3.0A
D503 8-719-991-33 DIODE 1SS133T-77
D504 8-719-200-82 DIODE 11ES2
< IC >
IC101 8-759-261-93 IC NJM4580LD
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q503 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q504 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q505 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q506 8-729-422-57 TRANSISTOR UN4111
Q507 8-729-900-80 TRANSISTOR DTC114ES
Q508 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R101 1-249-429-11 CARBON 10K 5% 1/4W
R102 1-249-429-11 CARBON 10K 5% 1/4W
R103 1-249-408-11 CARBON 180 5% 1/4W F
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-429-11 CARBON 10K 5% 1/4W
R107 1-249-433-11 CARBON 22K 5% 1/4W
R111 1-249-429-11 CARBON 10K 5% 1/4W
R112 1-249-408-11 CARBON 180 5% 1/4W F
R118 1-249-419-11 CARBON 1.5K 5% 1/4W F
R120 1-260-107-11 CARBON 4.7K 5% 1/2W
R121 1-260-107-11 CARBON 4.7K 5% 1/2W
R122 1-260-320-11 CARBON 220 5% 1/2W
R123 1-260-320-11 CARBON 220 5% 1/2W
R501 1-249-421-11 CARBON 2.2K 5% 1/4W F
R502 1-249-441-11 CARBON 100K 5% 1/4W
R503 1-247-903-00 CARBON 1M 5% 1/4W
R505 1-249-429-11 CARBON 10K 5% 1/4W
R506 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-247-901-11 CARBON 820K 5% 1/4W
R508 1-247-901-11 CARBON 820K- 5% 1/4W
R509 1-249-429-11 CARBON 10K 5% 1/4W
R510 1-249-441-11 CARBON 100K 5% 1/4W
R511 1-249-429-11 CARBON 10K 5% 1/4W
R512 1-249-409-11 CARBON 220 5% 1/4W F
R513 1-249-442-11 CARBON 510 5% 1/4W
R514 1-249-429-11 CARBON 10K 5% 1/4W
R515 1-249-429-11 CARBON 10K 5% 1/4W
< TERMINAL >
TM101 1-694-844-11 TERMINAL BOARD (8P) (SPEAKER IN/OUT)
******************************************************
A-4727-795-A MAIN BOARD, COMPLETE
*******************
1-533-293-31 FUSE HOLDER
< CAPACITOR >
C401 1-136-165-00 FILM 0.1uF 5% 50V
C402 1-136-165-00 FILM 0.1uF 5% 50V
C403 1-126-860-11 ELECT 3300uF 20% 35V
C404 1-126-860-11 ELECT 3300uF 20% 35V
C405 1-104-665-11 ELECT 100uF 20% 25V
C406 1-104-665-11 ELECT 100uF 20% 25V
C451 1-126-941-11 ELECT 470uF 20% 25V
C452 1-126-941-11 ELECT 470uF 20% 25V
< CONNECTOR >
*CN201M 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P
*CN203M 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
*CN301W 1-569-496-11 SOCKET, CONNECTOR 10P
*CN302W 1-569-493-11 SOCKET, CONNECTOR 7P
CN501 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D401 8-719-028-23 DIODE D3SBA20-4101
D403 8-719-110-41 DIODE RD15ESB2
D404 8-719-110-41 DIODE RD15ESB2
D451 8-719-200-82 DIODE 11ES2
D452 8-719-200-82 DIODE 11ES2
D453 8-719-200-82 DIODE 11ES2
D454 8-719-200-82 DIODE 11ES2
D455 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0F401 1-533-451-11 FUSE, GLASS TUBE (DIA. 5) (3.15A 125V)
0F402 1-533-451-11 FUSE, GLASS TUBE (DIA. 5) (3.15A 125V)
< RESISTOR
0R401 1-215-892-11 METAL OXIDE 1K 5% 2W
0R402 1-215-892-11 METAL OXIDE 1K 5% 2W
R451 1-249-425-11 CARBON 4.7K 5% 1/4W F
< TRANSFORMER >
0T2 1-437-504-11 TRANSFORMER, POWER
******************************************************
A-4727-798-A POWER AMP BOARD, COMPLETE
************************
< CAPACITOR >
C302 1-102-110-00 CERAMIC 220PF 10% 50V
C303 1-119-827-11 ELECT MELF 100uF 20% 25V
C305 1-107-909-11 ELECT 47uF 20% 50V
C306 1-107-909-11 ELECT 47uF 20% 50V
C307 1-136-177-00 FILM 1uF 5% 50V
C308 1-136-177-00 FILM 1uF 5% 50V
C309 1-126-934-11 ELECT 220uF 20% 10V
C310 1-119-827-11 ELECT MELF 100uF 20% 25V
C311 1-126-963-11 ELECT 4.7uF 20% 50V
C312 1-107-906-11 ELECT 10uF 20% 50V
C320 1-102-110-00 CERAMIC 220PF 10% 50V
< CONNECTOR >
*CN302 1-569-502-11 PIN, CONNECTOR 7P
*CN303 1-566-693-11 PIN, CONNECTOR 2P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77
INPUT POWER AMP
MAIN
The components identified by mark 0or
dotted line with mark 0are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.

8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-WEX200
< IC >
IC851 8-759-331-41 IC LM3876TF
< TRANSISTOR >
Q301 8-729-029-86 TRANSISTOR DTC124ESA
Q302 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q303 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q304 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R301 1-249-425-11 CARBON 4.7K 5% 1/4W F
R302 1-249-433-11 CARBON 22K 5% 1/4W
R303 1-249-419-11 CARBON 1.5K 5% 1/4W F
R304 1-249-438-11 CARBON 56K 5% 1/4W
R306 1-249-435-11 CARBON 33K 5% 1/4W
R307 1-216-353-00 METAL OXIDE 2.2 5% 1W
R309 1-249-433-11 CARBON 22K 5% 1/4W
R310 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-441-11 CARBON 100K 5% 1/4W
R313 1-249-437-11 CARBON 47K 5% 1/4W
R314 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
RY301 1-515-920-11 RELAY (24V)
******************************************************
MISCELLANEOUS
*************
013 1-783-531-31 CORD, POWER
SP901 1-544-909-11 SPEAKER (10CM)
SP902 1-544-910-11 SPEAKER (10CM)
0T1 1-437-503-11 TRANSFORMER, POWER
The components identified by mark 0or
dotted line with mark 0are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une marque
0sont critiques pour la sécurité.
Ne les remplacer que par une piéce portant
le numéro spécifié.
POWER AMP
*************
HARDWARE LIST
*************
#1 7-685-887-01 SCREW +BVTT 4X25 (S)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#3 7-685-871-01 SCREW +BVTT 3X6 (S)
#4 7-685-873-01 SCREW +BVTT 3X10
#5 7-685-880-01 SCREW +BVTT 4X6 (S)
******************************************************

9
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-WEX200
MEMO

10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SA-WEX200
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page.
Ver. Date Description of Revision
1.0 2001.09 New
