SA-WP780
SECTION 2
EXPLODEDVIEWS
NOTE:
•-XX and -X mean standardized parts, so they
may have some difference from the original
one.
•Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
•The mechanical parts with no reference
numberin the exploded viewsarenot supplied.
•Abbreviation
AR : Argentine model
AUS:Australian model
CND : Canadian model
E51 : Chilean and Peruvian models
RU : Russian model
SP : Singapore model
SP6 : Singapore and Malaysia models
The components identified by mark 0or
dotted line with mark 0are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
1A-1157-214-A FRONT PANEL ASSY (BLACK)
(US, CND, AEP, UK, E51, SP, SP6, AUS, AR)
1A-1171-410-A FRONT PANEL ASSY (SILVER)
(CND, AEP, UK, RU, SP, SP6, AUS)
24-999-482-81 KNOB (VOL)
031-696-848-81 CORD, POWER (AUS)
031-777-071-23 CORD, POWER (AEP, UK, RU, E51, SP, SP6)
031-783-820-11 CORD, POWER (US, CND)
031-783-941-12 CORD, POWER (AR)
4A-1156-567-A MAIN BOARD, COMPLETE
(EXCEPT E51, SP, AR)
4A-1175-815-A MAIN BOARD, COMPLETE (E51)
4A-1237-500-A MAIN BOARD, COMPLETE (SP)
4A-1237-502-A MAIN BOARD, COMPLETE (AR)
53-905-609-32 SCREW (TRANSISTOR)
(Continued on page 10)
1
6
SP1
#2
including
RV801
F900
Q307
Q308
F901
F902
T1
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
62
7
3
8
#2
#2
#2
#2
(US, CND)
not supplied
(EXCEPT US,CND)
not
supplied
#1
#1
4
65
2-1. OVERALL SECTION-1
