Sony BRAVIA KDL-32L5000 User manual

LCD Digital
Color TV
KDL-32L5000
KDL-26L5000
FSony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: ww_,.sony.ca/support
United States Canada
1.800.222.SONY 1.877.899.SONY
Sony will work to resolve
your questions more quickly than your retailer.
Please Do Not Return
the Product to the Store J
© 2009 Sony Corporation

Owner's Record
The model and serial numhers are located at the rear of the TV.
Record these numbers in the spaces provided below. Rellzr to
them whenever you call upon your Sony dealer regarding this
TV.
Model Name
Serial No,
CAUTION
To prevent electric shock and blade exposure, do not use
this polarized AC plug with all extension cord, receptacle or
other outlet unless the blades call be fully inserted.
[] Operate the TV only on 120-240 V AC.
Licensing Information
Macintosh is a trademark of Apple Inc., registered in the U.S. and
other countries.
HDMI, the HDMI logo and High-Definition Multimedia Interlace
are trademarks or registered trademarks of HDMI Licensing, LLC.
Fergasou Patent Properties, LLC:
U.S. Patent No. 5,717,422
U.S. Patent No. 6,816,141
Manufactured under license fi'nm Dolby Laboratories. Dolby and
the dnuble-D symbol are trademarks of Dolby Laboratories.
Blu=ray Disc is a trademark.
"BRAVIA", BRAVIA, BRAVIA Sync, and [] are trademarks or
registered marks of Sony Corporation.
"PLAYSTATION" is a registered trademark and "PS3" is a
trademark of Sony Computer Entertainment Inc.
I17r¢" Frl DOLBY
DIGITAL ]
H :3 rlrl|
Your BRAVIA TV is ENERGY STAR qualified
in the "Home" mode.
It meets strict energy efficiency guidelines set by
the U.S. Environmental Protection Agency and
Department of Energy. ENERGY STAR is a joint
program of these government agencies, designed
to promote energy efficient products and
practices.
[] When the TV is initially set up, it is designed to meet
ENERGY STAR requirements.
[] Changes to certain features, settings, and t__mctionalities of
this TV (i.e. Picture/Somld, Power Savings) can slightly
change the power consumption.
Depending upou such changed settings, the power consmnptinu
may increase which possibly could exceed the limits required for the
ENERGY STAR qualificatiou.
Compatible Wall Mount Bracket Information
Use the following Sony WALL-MOUNT BRACKET with
your TV model.
SU-WL1O0 SU-WL500
Use with other WALL-MOUNT BRACKETS may cause
instability and could result in property damages or injury.
Cleaning
When cleaning, be sure to unplug the power cord to avoid
any chance of electric shock.
• Wipe the LCD screen gently with a soft cloth.
• Stubborn stains may be removed with a cloth slightly
moistened with a solution of mild soap and warm water.
• If using a chemically pretreated cloth, please follow the
instruction provided on the package.
• Never use strong solvents such as a thinner, alcohol or
benzine for cleaning.
• See the supplied Safety Booklet for additional
information.
This manual is for the 26 and 32 class BRAVIA KDL-L5000 series models with screen size measured diagonally. The 32 class has a 31.5
inch viewable image size (measured diagonally).
2

Contents
Introducing Your New BRA VIA®
Welcome to the World of BRAVIA® ........ 4
Experiencing Stunning HD with Your
BRAVIA ........................... 4
The Four Steps to a Stunning HD
Experience ......................... 5
TV Feature Highlights ................... 5
Getting Started
Setting Up Your TV ..................... 6
Locating Inputs and Outputs .............. 7
Connecting the TV ..................... 9
Connecting Other Equipment ............ 12
Bundling the Connecting Cables .......... 13
When Installing the TV Against a Wall or
Enclosed Area ..................... 13
Securing the TV ...................... 14
Running Initial Setup ................... 16
Using the Menus
Navigating through TV Menus ........... 25
Using the Picture Settings ............... 26
Using the Sound Settings ............... 27
Using the Screen Settings .............. 28
Using the Channel Settings ............. 30
Using the Parental Lock Settings ......... 31
Using the Setup Settings ............... 34
Other Information
PC Input Signal Reference Chart for PC and
HDMI IN 1/2/3 ...................... 37
Preparing the TV for Wall-Mounting ....... 38
Troubleshooting ...................... 39
Important Notices ..................... 43
Specifications ........................ 44
Index ............................... 45
Operating the TV
Using the Remote Control ............... 17
Remote Control Button Description ....... 18
TV Controls and Indicators .............. 20
Using Features
Using BRAVIA Sync with Control for
HDMI ............................ 21
Using PIP Feature ..................... 22
Favorites ............................ 22
Wide Mode .......................... 23
Wide Mode with PC ................... 23
Inputs .............................. 24
Customer Support
United States
http://www.sony.com/tvsupport
Canada
http://www.sony.ca/support
On-line Registration
United States
http://productregistration.sony.com
Canada
http://www.SonyStyle.ca/registration
3

Introducing Your New BRA VIA®
Welcome to the World of BRAVIA®
Thank you for choosing this Sony BRAVIA®high-definition television. Use the
documentations listed below to get the most out of your TV.
Safety Booklet
Contains precautionary
measures to keep you and
your TV safe. Read this
information prior to setting up
your TV.
Operating Instructions
Provides the most detailed
information to operate your
TV.
Quick Setup Guide
Provides TV setup information with sample
connection diagrams and TV features.
Experiencing Stunning HD with Your BRAVIA
The quality of the image you see on your BRAVIA TV is only as good as the quality of the
signal it receives. To experience the stunning detail of your new BRAVlA TV, you need
access to HD programming. Your BRAVlA TV can receive and display HD programming
from:
•Over-the-air broadcasting via HD-quality antenna
• HD cable subscription
• HD satellite subscription
• Blu-ray Disc TM player or other HD compatible external equipment
Contact your cable or satellite provider for information on upgrading to HD programming.
4

The Four Steps to a Stunning HD Experience
Set, Sound, Source, and Setup
Along with your BRAVIA TV set, a complete HD system requires an HD sound system, a
source of HD programming, and a proper connection setup. Refer to the Quick Setup
Guide, enclosed separately, for connecting optional equipment.
You can enjoy crisp, clear images, smooth
movement, and high-impact visuals from
1080 HD signals as shown here.
When you compare a high-definition signal
to a standard analog signal, you will notice
a big difference in picture quality. If black
bars appear as shown here, press WIDE
on the remote control to fill the screen.
¢}
3"
TV Feature Highlights
Your BRAVIA comes with many convenient features, such as:
BRAVlA Sync: Allows your BRAVlA TV to communicate with other Sony
equipment supporting the Control for HDMI function (page 21).
PIP (Picture in Picture): You can work on your PC and watch your favorite TV
program simultaneously (page 22).
Favorites: Your favorite channels and inputs are at your finger tips for easy
access (page 22).
Auto Wide Mode: Set your TV to automatically adjust the screen based on the
signal resolution (page 23).
Input Selection: Allows you to easily switch between the connected equipment
(page 24).
5

Getting Started
Setting Up Your TV
The TV is packaged with a detached Table-Top Stand so you can mount the TV to a wall right
away. If you are not mounting the TV to a wall, you will need to attach the Table-Top Stand. Use a
Philips screwdriver and the supplied screws to complete the task. Look for the attachment
instruction taped to the TV unit.
Be sure to consider the following while setting up your TV:
6
• Disconnect all cables when carrying the TV.
• Carry the TV with the adequate number of people; larger size TVs require two or more people.
• Placement of the hands carrying the TV is very important for safety and to avoid damage.
• Adequate ventilation is necessary (see page 13).
• For best picture quality, do not expose the screen to direct illumination or sunlight.
• Avoid installing the TV in a room with reflective wall and floor materials.
• Avoid moving the TV from a cold area to a warm area. Sudden room temperature changes may
cause moisture condensation. This may cause the TV to show poor picture and/or poor color.
Should this occur, allow moisture to evaporate completely before powering on the TV.

Locating Inputs and Outputs
Side Panel
J
2
Hitlrrl! i N
lIDEOv
@
'IDEO
I©
_UDIO
2
VIDEO I_
Rear Panel
®®
t_
(n
o.
[] SERVICE This port is for service only.
[] HDMI IN 1/2/3 HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-
L-AUDIO-R digital audio/video interface between this TV and any HDMI-equipped audio/video
equipment, such as a set-top box, DVD player, and A/V receiver. HDMI supports
enhanced, or high-definition video, plus digital audio. Be sure to use only an HDMI
cable that bears the HDMI logo.
Use the HDMI IN 1 port when connecting DVI equipment. Use a DVI-to-HDMI
cable or adapter (not supplied). Equipment using a DVI connection also requires an
additional audio connection using an audio cable connected to AUDIO (L/R).
[] VIDEO IN 2 Connects to the S VIDEO output jack of video equipment. If both composite video
S VIDEO and S VIDEO are connected, S VIDEO signal has priority.
VIDEO/L If you have mono equipment, connect its audio output port to the TV's L (MONO)
(MONO)- audio input port. Use VIDEO IN 2 with AUDIO L (mono) and R.
AUDIO-R
[] PC IN Connects to a personal computer's video and audio output connector. Can also be
(RGB/AUDIO) connected to other analog RGB equipment. See "PC Input Signal Reference Chart"
on page 37 for the signals that can be displayed.
For some Apple Macintosh computers, it may be necessary to use an adapter (not
supplied). If an adapter is used, connect the adapter to the computer before
connecting the HD 15-HD 15 cable.
You may need to adjust the TV settings or your PC's resolution and timing. See
page 11 for information on how to setup your PC to this TV.
[] DiGiTALAUDi6 Connecis io ihe opiicai audio inpui of a digiiai audio equipmeniihaiis............................................................................
OUT (OPTICAL) PCM/Dolby '_ Digital compatible.
_ Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
Laboratories.
(Continued) 7

[] VIDEO IN 11
COMPONENT
IN 1
(1080p/1080i/
720p/480p/480i)/
L (MONO)-
AUDIO-R
This input port can be used as a composite video input (VIDEO 1) or as a
component video input (COMPONENT 1). For composite use, connect the yellow
jack to Y/Video for video and use audio L(mono) and R for audio signal. For
component connection, use Y, PB, PRfor video signals and also connect the audio L
(mono) and R for audio signal.
This TV can auto detect and switch between the VIDEO 1 and COMPONENT 1
when VIDEO 1or COMPONENT 1 is connected.
To set to auto detection, press MENU and go to the Setup settings. Select the
Video/Component 1 Selection option then set to Auto.
[] COMPONENT Component video provides better picture quality than the S Video and composite
IN 2 video.
(1080p/1080i/ Audio connection is required for the COMPONENT IN ports, connect audio (L/R).
720p1480p1480i)l
L-AUDIO-R
[] AUDIO OUT Connects to the left and right audio input jacks of your analog audio equipment.
(FIX) L/R You can use these outputs to listen to your TV's audio through your stereo system.
[] AC power cord Plug the cord into the nearest wall outlet.
[] CABLE/ RF input that connects to your Cable or VHF/UHF antenna.
ANTENNA
8

Connecting the TV
Cable System or VHF/UHF Antenna System
You can enjoy high-definition and standard-definition digital programming (if available in your
area) along with standard-definition analog programming.
This TV is capable of receiving unscrambled digital programming for both cable (QAM and
8VSB) and external VHFAJHF antenna (ATSC).
Cable or VHF/UHF (or VHF only)
75-ohm coaxial cable _ _ Rear of TV
CABLE/ANTENNA
£b
Cable System and VHF/UHF Antenna System
Use an optional A-B RF switch (not supplied) to switch between the cable and over-the-air antenna
programming, as indicated below.
A/B RF Switch
_÷__ Rear of TV
Cable
Antenna _ _b_r- CABLE/ANTENNA
(Cotzdtzued) 9

HD Cable Box/HD Satellite Box
You can enjoy high-definition programming by subscribing to a high-definition cable service or a
high-definition satellite service. For the best possible picture, make sure you connect this equipment
to your TV via the HDMI or component video (with audio) input located on the back of your TV.
Shown with HDMI Connection
Rearof TV
HDMicabl e
HD cable box/
HD satellite box
CATV/Satellite antenna cable
Shown with DVI Connection
r-
Rearof TV DVI-to-HDMI cable
AUDIO-R (red) _ _
AUDIO-L (white)--_
HD cable box/
HD satellite box
..........!:!:/;_i_ii........_J-I _÷_
CATV/Satellite
nteia cable
Audio cable
10

Shown with Component Connection
Rearof TV CATV/Satellite antenna cable
|
HD cable box/ [_
HD satellite box
AUDIO-R (red)
AUDIO-L (white)
PR (red)
PB (blue)
Y (green)
Component video cable I _
Audio cable
PC
Use the TV as a monitor for your PC by connecting an HD 15-HD 15 cable connection as shown
below. This TV can also be connected to a PC with a DVI or HDMI output. (Refer to the separate
Quick Setup Guide.)
HD15-HD15 cable
_-- (analog RGB)
Rear of TV
Audio cable
(stereo mini plugs)
< { {
11

Connecting Other Equipment
Personal
computer
Blu-ray Digital
Disc Player/ DVD satellite Digital Audio
"PS3" player receiver cable box system
VCR/Game Digital Analog audio Digital audio equipment
system recorder equipment
(A/V Receiver/
HomeTheater)
CABLE/ANTENNA
Camcorder
12

Bundling the Connecting Cables
Untie the AC power cord from the plastic cable band and connect the AC power cord to the nearest
wall outlet when all the necessary connection is completed. Use the same plastic cable band to
bundle the connecting cables as illustrated below.
Do not bundle the AC power cord with other connecting cables.
if}
When Installing the TV Against a Wall or Enclosed Area
Make sure that your TV has adequate ventilation. Allow enough space around the TV as shown
below. Avoid operating the TV at temperatures below 41 °F (5 °C).
Installed with stand
i ]" 11 7/8 inches :
;,_ (30crn)
, I r_ 2 3/sinches
Leave at least this much space around the set,
Installed on the wall
(30 cm)
4inches ' I I I i4inches
I _ Leave at least
i I _ thismuchspace
:_4inches (10 c_) around the set.
Never install the TV set as follows:
Air circulation is blocked. Air circulation is blocked.
1all
13

Securing the TV
///_ Sony strongly recommends taking measures to prevent the TV from toppling over.Unsecured TVs may topple and result in property damage, serious bodily injury or even
death.
Preventing the TV from Toppling
[] Secure the TV to a wall and/or stand.
[] Do not allow children to play or climb on furniture and TV sets.
[] Avoid placing or hanging items on the TV.
[] Never install the TV on:
• slippery, unstable and/or uneven surfaces.
• furniture that can easily be used as steps, such as a chest of drawers.
[] Install the TV where it cannot be pulled, pushed, or knocked over.
[] Route all AC power cords and connecting cables so that they are not accessible to curious children.
Recommended Measures to Secure the TV
Consider tile following measures when securing your TV to a TV stand (not supplied).
1Secure the stand for the TV.
Make sure the TV stand can adequately support the weight of the TV. Use two angle braces
(not supplied) to secure the stand.
For each angle brace use the appropriate hardware to:
• attach one side of the angle brace to the wall stud.
• attach the other side to the TV stand.
_ Angle braces
Stand
14

2 Secure the TV to the stand.
Use the optional hardware listed below (not supplied):
• M4 x 14 mm anchor bolt and M4 nut (screwed into the TV's Table-Top Stand).
• A screw or similar (attach it to the TV stand).
• Rope or chain (strong enough to support the weight of the TV). Make sure that there is no
excess slack in the rope or chain.
An alternative way to secure the TV is with an optional Sony Support Belt Kit.
iiiiiiiiiii
3 Anchor the TV to the wall.
Use the hardware listed below (not supplied).
• Two anchor bolts, size M4 x l0-12 mm (model KDL-26L5000) or M6 x l 0-12 mm (model
KDL-32L5000). Screw the bolts into the top-most wall-mount holes located on the rear of
the TV.
• Rope or chain (attach to one anchor bolt).
• Wall-anchor (attach to the wall stud) strong enough to support the weight of the TV (pass
the rope through the wall-anchor, then attach to the other anchor bolt).
Anchor bolts
Wall-mount
holes
Rope or
chain
Wall-anchor
£b
2
15

Running Initial Setup
During initial setup, you will perform the following:
• Set the language for the On Screen Display (OSD) text
• Choose your viewing environment
• Signal source connection check
• Scan for digital and analog channels
Complete your cable connections before beginning the Initial Setup. Refer to the Quick Setup
Guide (supplied) for sample connection diagrams.
1Turn on the TV. The Initial Setup screen will
appear.
2Use the remote control buttons described below to
navigate through the Initial Setup.
tl! l.i,l,!>buttons:
Allowyou to navigate and highlightoptions where applicable.
@button:
Allows youto selectthe highlightedoption and advanceto the next screen.
3Auto Program will scan for available channels from the signal source directly connected to
the TV's CABLE/ANTENNA input. Follow the help text provided on the screen to run the
Auto Program.
16

Operating the TV
Using the Remote Control
To Insert Batteries into the Remote Control
Insert two size AA batteries (supplied) by
matching tll}and • on the batteries to the
diagram inside the battery compartment of
the remote control.
Guidelines to follow
\
• Point your remote control directly at the IR sensor
located on your TV.
• Make sure that no objects are blocking the path
between the remote control and the IR sensor on your
TV.
• Fluorescent lamps can interfere with your remote
control; try turning oft"the fluorescent lamps.
• If you are having problems with the remote control,
reinsert or replace your batteries and make sure that
they are correctly inserted.
t_
".t
17

Remote Control Button Description
@
[] DISPLAY
[] cc
[] BRAVIA
Sync
Press once to display the banner with channel/program
information you are watching. The banner will time
out in a few seconds or press again to exit.
Press to turn On, turn On when Muting or Off the
Closed Captions (CC).
These buttons are used to control the equipment
connected to the TV by using the Control for HDMI
function (not available on all Control for HDMI
equipment). Some other buttons on the remote control
may also operate BRAVIA Sync equipment,
(fast reverse): Press to play a program in fast
rewind mode.
PLAY: Press to play a program at a normal speed.
II PAUSE: Press to pause playback.
(fast forward): Press to play a program in fast
forward mode.
SYNC MENU: Press once to display the Sync'd
HDMI Devices (while a Control for HDMI device is
not selected). Select the HDMI device and then press
SYNC MENU to display the menu of connected
equipment (not available on all Control for HDMI
equipment).
• STOP: Press to stop playback.
THEATER: Press to turn on and off the Theater
Mode. The picture settings will be set for a cinema-
like experience and the audio will be switched to the
audio output of the attached speakers of your BRAVIA
Sync audio system. Your BRAVIA Sync audio system
must be connected by an HDMI connection to your TV
(see page 21 for details).
[] FAVORITES Press once to display the stored Favorites list. You
can store up to 10 channels and/or external inputs in
your Favorites list.
[] WIDE Press repeatedly to cycle through the available Wide
Mode settings. See page 23.
[] RETURN Press to go back to the previous screen or exit from the
screen when displaying menu items and settings.
[] MENU Press to display the menu with TV functions and
settings. See "Using the Menus" on page 25.
18

[] 0-9 ENT Press 0-9 to select a channel; the channel changes alter
two seconds. Press ENT to change channels
immediately.
[] O Use with 0-9 and ENT to select digital channels.
For example, to enter 2.1, press C)' C)' @ and ENT.
[] VOL +/- Press to adjust the volume.
[] MUTING Press to mute the sound. Press again or press VOL +to
restore the sound.
[] POWER Press to turn on and off the TV.
[] INPUT Press to display the list of External Inputs and TV
mode. Press repeatedly to toggle through the inputs.
See page 24.
[] 4"/,!,/<,/* Press t./!_/<,/* to move focus/highlight. Press @ to
@ select/confirm an item.
[] TOOLS Press to display a list of convenient functions and
menu shortcuts. The TOOLS menu items vary based
on current input and content.
[] CH +/- Press to scan through channels. To scan quickly
through channels, press and hold down either CH +/-.
[] JUMP Press to jump back and forth between two channels.
The TV alternates between the current channel and the
last channel that was selected.
_Q
".t
19

TV Controls and Indicators
VOLUME
PIC OFF/TIMER STANDBY
Receiver
[] Pie OFF/ Lights up in orange when the sleep timer is set
TIMER LED Lights up in green when the Power Saving is set to Picture Off.
[] STANDBY Lights up in red when your TV is in PC power saving model ........................................................................................................................................................
LED
[] POWER LED Lights up in green when the TV is turned onl .............
[] POWER .............................Press to turn on and offthe TV.
[] - CHANNEL +Press m scan through channels2 To scan quickiy through channels, press and hold down
either CH -/+. In the menu screen, these buttons serve as up/down buttons.
[] -to adjusttheGiume in the menu screenl these buttons serve as ieft/right buttonsl ...........
[] @ Press to display the iist of external inputsl Press repea{edly to toggle through the inputsl
INPUT In the menu screen, this button serves as confirming the selection or setting.
[] MENU ..............................................Press to display menu with TV _nctions and settings isee 'Using the Menus'; on page 25)i ............
[] Speaker Outputs audio signal[ .....
2O
