Sony BRAVIA KDL-32R300C User manual

KDL-32R300C
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\010COV.fm masterpage: Cover
KDL-32R300C
4-571-194-31(1)
Television
Televisor digital a
color con pantalla
de cristal líquido
Sony Customer Support
U.S.A.:
http://www.sony.com/tvsupport
Canada:
http://www.sony.ca/support
United States Canada
1.800.222.SONY 1.877.899.SONY
Please Do Not Return
the Product to the Store
Centro de Asistencia de
Sony
http://esupport.sony.com/ES/LA/
Llame al número telefónico que aparece en
su póliza de garantía.
Por favor no devuelva el producto a la tienda
donde adquirió el producto.
Operating Instructions US
(Setup Guide)
Manual de instrucciones ES
(Guía de configuración)

2US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\020REG.fm masterpage: Left
KDL-32R300C
4-571-194-31(1)
CAUTION
To prevent electric shock and blade exposure, do not use this polarized
AC plug with an extension cord, receptacle or other outlet unless the
blades can be fully inserted.
Location of the identification label
Labels for Model No. and Power Supply rating are located on the rear
of the TV.
Note:
• The illustrations of the remote control used in this manual are of the
RM-YD092 unless otherwise stated.
• The illustrations used in this manual may differ depending on your
TV model.
Cleaning
When cleaning, be sure to unplug the power cord to avoid any chance
of electric shock.
• Wipe the LCD screen gently with a soft cloth.
• Stubborn stains may be removed with a cloth slightly moistened
with a solution of mild soap and warm water.
• If using a chemically pretreated cloth, please follow the instruction
provided on the package.
• Never use strong solvents such as a thinner, alcohol or benzine for
cleaning.
• See the supplied Safety Booklet for additional information.
Owner’s Record
The model and serial numbers are located at the side and rear
of the TV. Record these numbers in the spaces provided below.
Refer to them whenever you call upon your Sony dealer
regarding this TV.
Model Name
Serial No.
The 32 class has a 31.5 inch viewable image size (measured
diagonally).

3US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\010COVTOC.fm masterpage: Right
KDL-32R300C
4-571-194-31(1)
US
Table of Contents
Introducing Your New BRAVIA®
Getting Started
Checking the Accessories. . . . . . . . . . . . . . . . 6
Inserting Batteries into the
Remote Control. . . . . . . . . . . . . . . . . . . . . . . . 6
Setting Up Your TV . . . . . . . . . . . . . . . . . . . . . 7
Attaching the Table-Top Stand . . . . . . . . . . . 7
Connecting the TV . . . . . . . . . . . . . . . . . . . . . 8
Cable System or VHF/UHF
Antenna System . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cable System and VHF/UHF
Antenna System . . . . . . . . . . . . . . . . . . . . . . . . . 8
HD Cable Box/HD Satellite Box . . . . . . . . . . . . . 8
Securing the TV. . . . . . . . . . . . . . . . . . . . . . . . 9
Preventing the TV from Toppling. . . . . . . . . . . . 9
Recommended Measures to Secure the TV . . . 9
Running Initial Setup . . . . . . . . . . . . . . . . . . .11
Parts and Controls
TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Remote Control. . . . . . . . . . . . . . . . . . . . . . . 13
Watching TV
Changing the Viewing Style. . . . . . . . . . . . . 15
Changing the Wide Mode . . . . . . . . . . . . . . . . .15
Setting Scene Select . . . . . . . . . . . . . . . . . . . . . .15
Navigating through Home Menu
Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Applications . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the TV as a Photo Frame . . . . . . . . . . . . 16
Media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Playing back Photo/Music/Video via USB . . . .17
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Customer Support. . . . . . . . . . . . . . . . . . . . . . . 25
Viewing Pictures from Connected
Equipment
Connection Diagram. . . . . . . . . . . . . . . . . . . 26
Using Audio and Video Equipment. . . . . . . 27
Additional Information
Using a Wall-Mount Bracket . . . . . . . . . . . . 28
Installing the TV Against a Wall or
Enclosed Area . . . . . . . . . . . . . . . . . . . . . . . . 28
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 29
Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 30
Safety Information . . . . . . . . . . . . . . . . . . . . 32

4US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\010COVTOC.fm masterpage: Left
KDL-32R300C
4-571-194-31(1)
Customer Support
United States
http://www.sony.com/tvsupport
Canada
http://www.sony.ca/support
On-line Registration
United States
http://productregistration.sony.com
Canada
http://www.sony.ca/registration

5US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\030INB.fm masterpage: Right
KDL-32R300C
4-571-194-31(1)
US
Welcome to the World of BRAVIA®
Thank you for choosing this Sony BRAVIA® high-
definition television. Use the documentation listed
below to get the most out of your TV.
Please take a moment to register your TV at:
U.S.A.: http://productregistration.sony.com
Canada: http://www.sony.ca/registration
Experiencing Stunning HD with Your BRAVIA
TV
To experience the stunning detail of your new
BRAVIA TV, you need access to high-definition (HD)
programming. Your BRAVIA TV can receive and
display HD programming from:
Over-the-air broadcasting via HD-quality antenna
HD cable subscription
HD satellite subscription
Blu-ray Disc™ player or other HD compatible
external equipment
Contact your cable, satellite or HD service provider
for information on upgrading to HD programming.
The Four Steps to a Full HD Experience
Set, Sound, Source, and Setup
Along with your BRAVIA TV set, a complete HD
system requires an HD sound system, a source of
HD programming and a proper connection setup.
Refer to the Quick Setup Guide, enclosed
separately, for connecting optional equipment.
Introducing Your New BRAVIA®
Safety Booklet
Contains precautionary measures to
keep you and your TV safe. Read this
information prior to setting up your TV.
Operating Instructions
Provides the most detailed information
to operate your TV.
Quick Setup Guide
Provides TV setup information with
sample connection diagrams.

6US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\040GES.fm masterpage: Left
KDL-32R300C
4-571-194-31(1)
Checking the Accessories
Remote control (1)*1
Size AAA batteries (2)
AC power cord (1)
Table-Top Stand (1)
Fixing screws for Table-Top Stand (M4 × 18) (4)
Operating Instructions (1)
Quick Setup Guide (1)
Safety and Regulatory Booklet (1)
Software License (1)
Stand Installation Guide (1)
*1 Please refer to the model name printed on the remote
control.
Inserting Batteries into the
Remote Control
1Remove the protection sheet.
2Push and slide the cover to open.
Guidelines for Remote Control
Point your remote control directly at the IR sensor
located on your TV.
Make sure that no objects are blocking the path
between the remote control and the IR sensor on
your TV.
Fluorescent lamps can interfere with your remote
control; try turning off the fluorescent lamps.
If you are having problems with the remote
control, reinsert or replace your batteries and
make sure that they are correctly inserted.
Getting Started

7US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\040GES.fm masterpage: Right
KDL-32R300C
4-571-194-31(1)
US
Setting Up Your TV
Some TV models are packaged with a detached
Table-Top Stand so you can mount your TV to a wall
right away. If you are not mounting the TV to a wall,
you will need to attach the Table-Top Stand. You will
need a Phillips screwdriver (not supplied) and the
supplied screws to complete the task. Look for the
supplied Table-Top Stand instruction leaflet.
Be sure to consider the following while setting up
your TV:
Disconnect all cables when carrying the TV.
Carry the TV with the adequate number of
people; larger size TVs require two or more
people.
Correct hand placement while carrying the TV is
very important for safety and to avoid damage.
Do not put stress on the LCD panel or the frame
around the screen.
Ensure your TV has adequate ventilation, see
page 28.
For best picture quality, do not expose the screen
to direct illumination or sunlight.
Avoid installing the TV in a room with reflective
wall and floor materials.
Avoid moving the TV from a cold area to a warm
area. Sudden room temperature changes may
cause moisture condensation. This may cause the
TV to show poor picture and/or poor color. Should
this occur, allow moisture to evaporate
completely before powering the TV on.
Ensure that there are no objects in front of the TV.
Attaching the Table-Top Stand
Note
• If using an electric screwdriver, set the tightening torque
at approximately 1.2N·m {12kgf·cm}.
• When detaching the Table-Top Stand, reverse the
attaching procedure.
• Be sure the TV is vertical before turning on. To avoid
uneven picture uniformity do not power on the TV with
the LCD panel facing down.
• When attaching the Table-Top Stand again, be sure to
fasten the screws (previously removed) to the original
holes on the rear of the TV.
KDL-32R300C
IR Sensor

8US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\040GES.fm masterpage: Left
KDL-32R300C
4-571-194-31(1)
Connecting the TV
You can enjoy high-definition and standard-
definition digital programming (if available in your
area) along with standard-definition analog
programming.
This TV is capable of receiving unscrambled digital
programming for both cable (QAM and 8VSB) and
external VHF/UHF antenna (ATSC).
Cable or VHF/UHF (or VHF only)
Note
• It is strongly recommended that you connect the CABLE/
ANTENNA input using a 75-ohm coaxial cable to receive
optimum picture quality. A 300-ohm twin lead cable can
easily be affected by radio frequency interference,
resulting in signal degradation.
Use an optional A-B RF switch (not supplied) to
switch between the cable and over-the-air antenna
programming, as indicated below.
Note
• Be sure to set the Signal Type setting to Cable or
Antenna found under the Channel settings for your input
signal (page 20).
You can enjoy high-definition programming by
subscribing to a high-definition cable service or a
high-definition satellite service. For the best
possible picture, make sure you connect this
equipment to your TV via the HDMI or component
video (with audio) input located on the back of your
TV.
Shown with HDMI Connection
Cable System or VHF/UHF Antenna System
Cable System and VHF/UHF Antenna
System
75-ohm
coaxial cable
CABLE/ANTENNA
Rear of TV
B
A
A/B RF Switch
Cable
Antenna
Rear of TV
CABLE/ANTENNA
HD Cable Box/HD Satellite Box
Rear of TV
Set Top Box

9US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\040GES.fm masterpage: Right
KDL-32R300C
4-571-194-31(1)
US
Shown with Component Connection Securing the TV
Secure the TV to a wall and/or stand.
Do not allow children to play or climb on furniture
and TV sets.
Avoid placing or hanging items on the TV.
Never install the TV on:
slippery, unstable and/or uneven surfaces.
furniture that can easily be used as steps, such
as a chest of drawers.
Install the TV where it cannot be pulled, pushed,
or knocked over.
Route all AC power cords and connecting cables
so that they are not accessible to curious children.
Consider the following measures when securing
your TV to a stand (not supplied).
1Secure the stand for the TV.
Make sure the stand can adequately support the
weight of the TV. Use two angle braces (not
supplied) to secure the stand.
For each angle brace use the appropriate
hardware to:
Attach one side of the angle brace to the wall
stud.
Attach the other side to the stand.
Rear of TV
Set Top Box
Sony strongly recommends taking
measures to prevent the TV from toppling
over. Unsecured TVs may topple and result
in property damage, serious bodily injury
or even death.
Preventing the TV from Toppling
Recommended Measures to Secure the TV
Angle braces
(not supplied)
Stand

10US
D:\SONY TV\SY150077_UC IM (SONY TAIWAN)\4571194311\01US\040GES.fm masterpage: Left
KDL-32R300C
4-571-194-31(1)
2Secure the TV to the stand.
Use the optional hardware listed below (not
supplied):
M4 machine screw (screwed into the screw
hole of the TV).
A screw or similar (attach it to the stand).
Rope or chain (strong enough to support the
weight of the TV). Make sure that there is no
excess slack in the rope or chain.
The length of the M4 machine screw differs
depending on the rope or chain diameter. Please
refer to below illustration.
3Anchor the TV to the wall by using bolts, wall
anchor and chain (or rope).
Note
• Your TV is shipped with screws attached to the rear of the
TV depending on the TV model. (They are fastened in the
screw holes for wall mounting.) Be sure to remove the
upper two screws prior to anchoring the TV to a wall.
• Securing the TV to the stand without securing the TV and
the stand to the wall provides minimum protection
against the TV toppling over. For further protection, be
sure to follow the three measures recommended.
Screw
(not supplied)
Rope or chain
(not supplied)
Screw hole of the TV M4 machine screw
(not supplied)
9-13 mm
Screw M4
Rope or chain
TV
Wall-mount
holes
Rope or chain
(not supplied)
Anchor
bolts
(not
supplied)
Wall-anchor
(not supplied)
