Sony BRAVIA KDL-32XBR4 User manual

KDL-32XBR4
32"ClassBRAVIA®XBR- seriesLCDFlatPanelHDTV(31.5inchesmeasured
diagonally)KDL -32XBR4
Key Features
10-bit16:9HDResolutionPanel(1366x768)
Motionflow™120HzHighFrameRateTechnology
BRAVIAEngine™EXfulldigitalvideoprocessing
system
LiveColorCreation™withWCG-CCFLbacklight
DMe compatible-BRAVIA ® InternetVideoLink
Ready
x
3
XrossMediaBar ® (XMB™)on-screenmenusystem
BRAVIA ® TheatreSync™technology
S -Force™FrontSurround3-Daudioeffect
AdvancedContrastEnhancer(ACE)circuit
HDMI™interfacex2(upto1080/24pinput&upto
1080/60pinput)
Key Technologies
Motionflow™120Hz High Frame Rate Technology Achieving smoother, natural motion reproduction starts
with the right performance characteristics such as the ultra fast panel response times our BRAVIA® HD LCD TVs
have. Motionflow™doubles the amount of frames from 60fps to 120fps and does it the right way by using real - time
calculation of every single frame of video to create entire new frames of information. The results are spectacular
and unlock a new level of motion reproduction. Motion performance is smooth and natural.
BRAVIA Engine™EX Video Processing System The BRAVIA Engine™EX video processing system came about as
a result of Sony’s expertise and long heritage in bringing cutting - edge picture quality to consumer televisions. It
contains intelligent picture enhancement technology that reduces unwanted digital artifacts and delivers superb
clarity and detail along with vivid colors. Sony’s own Digital Reality Creation Multi - function v1.0 (DRC - MFv1)
processor replaces the original SD signal with its HD equivalent. The result of BRAVIA Engine EX processing? Picture
quality has texture and detail, deep and vibrant colors, along with excellent depth and contrast.
Live Color Creation (featuring WCG-CCFL) Live Color Creation is a special Sony function that achieves precise,
wide color reproduction using a combination of advanced chroma signal processing algorithms. A special wide
color gamut backlight (WCG - CCFL) is coupled with Sony’s Live Color Creation circuitry. The benefit is clear blues,
natural greens and overall vibrant colors in all scenes.
DMe Compatibility DMe compatibility allows the connection and operation of a whole new category of
products that is being developed by Sony (sold separately). The first of these products is the optional BRAVIA®
Internet Video Link module.
x
x
Xross Media Bar ® (XMB™) On-Screen Menu System Xross Media Bar is Sony’s Emmy Award winning on -
screen navigation that provides quick access to various set up functions and features. For instance selecting
different types of media is made fun and easy by scrolling horizontally across icons until you find the type of
media you are looking for. After selecting the media type, a list of its content appears as vertical thumbnails. Key
set up menus and features work the same way. The main benefit of the XMB™interface is that users can navigate
through on - screen menus without taking their eyes off of their TV.
2
BRAVIA Theatre Sync™ BRAVIA ®Theatre Sync™reduces the hassle and time consuming job of powering up,
changing the signal routing, and adjusting other functions to the simple push of one button. All you need to do is to
connect BRAVIA ®Theatre Sync™capable products to each other via one HDMI cable. The rest is easy. For instance,
the One Push Play function activates by touching the play button on the remote and BRAVIA®Theatre Sync™takes
over from there. The BRAVIA ® Home Theatre System and TV turn on. The DVD input on the BRAVIA ®Theatre system
and TV activates. The TV mutes. And finally the DVD plays. There are two other BRAVIA®Theatre Sync™ functions -
One - Push Theatre Settings, which provides optimal picture and sound settings for movies and One - Push System
Shut Down for turning off the entire home entertainment system.
BRAVIA Internet Video Link The first DMe product to be introduced to the market is the DMX - NV1 BRAVIA
Internet Video Link module (sold separately). BIVL, as it is affectionately called, can stream available Internet
video from select content providers directly to your TV with a broadband connection without the need for a PC.
x
3

SonyElectronicsInc. • 16530ViaEsprillo • SanDiego,CA92127 • 1.800.222.7669 • www.sony.com
LastUpdated:05/29/2007
KDL-32XBR4
32"ClassBRAVIA®XBR- seriesLCDFlatPanelHDTV(31.5inchesmeasured
diagonally)KDL -32XBR4
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Features
General
Auto SAP: Yes
ID1 Detection: Yes
Video Label: Yes
Video
Tuner: ATSC (8VSB terrestrial) QAM on cable
Video Processing: BRAVIA Engine™EX full
digital video processing system
Noise Reduction: Yes
CineMotion®Reverse 3:2 Pulldown
Technology: Yes
Comb Filter: Yes (3D Digital)
Game Mode: Yes
Light Sensor: Yes
Picture Modes: Vivid, Standard, Cinema
Wide Mode: Wide Zoom, Normal, Full Zoom
Backlight Type: WCG-CCFL with proprietary
phosphors
Audio
Sound Mode: Dynamic, Standard, Custom
MTS Stereo Decoder: Yes
Digital Amplifier: Yes
Dolby® Digital Decoding: Yes
Steady Sound: Yes
Sound Booster: Yes
S -Force ™ Front Surround: Yes
Convenience
Channel Label: Yes
Channel Skip/Add: Yes
Favorite Channel: Yes
Sleep Timer: Yes
Timer Events: On/Off Timer
Clock: Yes
Picture Freeze: Yes
Input Skip: Yes
Channel Surf: Yes
Parental Lock: Yes
Xross Media Bar® : Yes
Specifications
General
Screen Size: 32 inch class (31.5 inches
measured diagonally)
Television Type: LCD Flat Panel
Video
Contrast Ratio: 1600:1 (On-Sceen ) / 8000:1
(Dynamic )
Resolution: 1366 x 768
4
5
Audio
Audio Power Output: 10W + 10W
Inputs and Outputs
Analog Audio Input(s): 5 (1 Side / 4 Rear)
Audio Out (Variable/Fixed): 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 3 (1 Side / 2 Rear)
HDMI ™ Connection Input(s): 3 (1 side w/o
audio input / 1 rear with audio input / 1 rear
w/o audio input) CEC capable
RF Connection Input(s): 2 (1 UHF/VHF / 1 Cable
In) Rear
S -Video Input(s): 1 (Rear)
Headphone Output(s): 1 (Side)
PC Input(s): 1 (D-sub 15)
Optical Audio Digital Output(s): 1 (Rear)
Power
Power Consumption (in Operation): 190W
Power Consumption (in Standby): less than
0.1W
AC Power: 120-240V 50/60Hz
Regulation and Standard Compliance
Energy Star ®Compliant: Yes
VESA: VESA Compatible
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year Labor
Dimensions
Weight: 37.48 lbs (17kg) with stand; 131.97 lbs
(4.5kg) without stand
Measurements: 31.1" x 22.72" x 8.43" (790 x 577 x
214mm) with stand; 31.1" x 20.87" x 3.94" (790
x 530 x 100) without stand
Supplied Accessories
Remote Control (RM-YD014)
Tabletop Stand
Instruction Manual
Quick Set Up Guide
Warranty Card
On-Line Registration Card
Type AA Batteries x2
AC Power Cord
Optional Accessories
Wall Mount Bracket (SU-WL500)
BRAVIA®Internet Video Link (DMX-NV1)
Color: Black
UPC Code: 027242710221
1.Limited toresolutions supported byboth thePCand theSony TV. See
SonyTV usersmanual and PCdocumentation forsupported resolutions
1
2.Emmy isthe copyrighted propertyof the Academyof TelevisionArts &
Sciencesand theNationalAcademy ofTelevision Arts &Sciences
(ATAS/NATAS).
3.Connection speedof at least3 Mbps recommended.Video qualityand
picturesize variesandis dependentupon broadband speedand
deliveryby contentprovider.
4.Black - whiterange seenon the screenat once
5.Black - whiterange seenover a periodof time
©2007Sony ElectronicsInc. All rightsreserved.
Sony,BRAVIA, BRAVIAEngine,BRAVIA TheatreSync, DRC, SpeedSurf,
CineMotion,S - Force,Xross MediaBar,XMB aretrademarks of Sony.Dolby
Digitalis aregisteredtrademark ofDolby Laboratories. ThisTV incorporates
High - DefinitionMultimedia Interface(HDMI™ ) technology.HDMI, the HMDI
logoand High - DefinitionMultimedia Interface aretrademarks orregistered
trademarksof HDMILicensingLLC. ATSCis a trademarkof Electronic
IndustriesAssociation. Allothertrademarks areproperty of theirrespective
owners.
Featuresand specificationsare subject tochange withoutnotice. Non -
metricweights andmeasures are approximate.
