Sony KL-37W2U User manual

CHASSIS
LE-1
37
∗Please file according to model size. ....
TRINITRON ® COLORTV
KL-37W2U
RM-838 UK
MODEL
COMMANDER DEST.
MODEL COMMANDER DEST.
MICROFILM
SERVICE MANUAL

– 2 –
Specifications
This product complies with the EU Directive 89/336/EEC.
Sound output 2 ×5 W (RMS)
Centre 1 ×20 W
Power consumption 170W
Dimensions (W ×H ×D) Approx. 920 ×825 ×390 mm
Weight Approx. 29 kg
Supplied accessories See page 6.
Other features Digital comb filter (High resolution)
PAP (Picture-and-picture)
FASTEXT
Graphic Equalizer
Design and specifications are subject to change without notice.
Receivable Channels and Channel Displays
Television system B/G/H, D/K, I, L
Colour system NTSC 3.58/4.43 (VIDEO IN)
Channel coverage See “Receivable channels and
channel displays” at the bottom.
Projected picture size 37 inches
Approx. 94 cm diagonally
Terminals
Rear 1 21-pin Euro connector
(CENELEC standard) inputs for audio
and video signals
- inputs for RGB
- outputs of TV video and audio
signals
2/
S
2 21-pin Euro connector
- inputs for audio and video signals
- inputs for S video
- outputs for audio and video signals
(selectable)
4/
S
4 21-pin Euro connector
- inputs for audio and video signals
- inputs for S video
- outputs for audio and video signals
(monitor out)
S
2,
S
4 S video inputs
- 4 pin DIN
Audio inputs (L, R) - phono jacks
S
S video output 4-pin DIN
Audio outputs - phono jacks
Audio outputs (variable)-phono
jacks
Front 3 video input - phono jack
Audio inputs - phono jacks
S
3 S video input - 4-pin DIN
2Headphone jack: stereo minijack
B/G/H
CABLE TV (1)
CABLE TV (2)
ITALY
D/K
CABLE TV (1)
CABLE TV (2)
CABLE TV
L
I
Indication on the
screen
C02 C03 C04..C12
C21..C69
S01 S02..S41
S42..S46 S01..S10
S11..S20
C11..C69
C02..C12 C21..C69
S01 S02..S41
S42 S43..S46
S02, S03..S17,
S21..S41
C01..C12 C21..C69
C21..C68
Receivable
channels
E2..12 21..69
S1..41
S01..S05 M1..M10
U1..U10
A B C D E F G H H1
H2 21..69
R01..R12 R21..R69
B..Q, S21..41
F2..F10 F21..F69
B21..B68

– 3 –
TABLE OF CONTENTS
Section Title Page Section Title Page
1. GENERAL ................................................... 4
2. DISASSEMBLY
2-1. Rear Cover Removal ........................................ 18
2-2. Chassis Assy Removal ..................................... 18
2-3. Service Position ................................................ 18
2-4. F2 Board and F2 Bracket Removal.................. 18
2-5. BB, B1 and J Boards Removal......................... 19
2-6 Power Block Removal...................................... 19
2-7. Filter Removal .................................................. 19
2-8. Lamp Removal ................................................. 20
2-9. H and F1 Boards Removal ............................... 20
2-10. Screen Frame Removal .................................... 20
2-11. C Board Removal ............................................. 21
2-12. Optical Unit Removal....................................... 21
3. CIRCUIT ADJUSTMENTS
3-1. Electrical Adjustments ..................................... 22
3-2. Test Mode ......................................................... 24
3-3. Error Monitor and Detection ............................ 26
3-4. Registration Adjustment................................... 27
3-5. C Board Adjustment ......................................... 27
3-6. A Board Adjustment......................................... 30
3-7. Sub BRT, Sub PIX Adjsutment ....................... 30
3-8. White Balance Adjustment .............................. 30
4. DIAGRAMS
4-1. Block Diagrams ................................................ 33
4-2. Frame Schematic Diagram ............................... 42
4-3. Circuit Boards Location ................................... 44
4-4. Schematic Diagrams and Printed
Wiring Boards .............................................. 44
(1) Schematic Diagrams of F1, F2,
G, H, J, TA and TB Boards ............................ 45
(2) Schematic Diagram of A (1/3) Board ................. 55
(3) Schematic Diagram of A (2/3) Board ................. 59
(4) Schematic Diagram of A (3/3) Board ................. 61
(5) Schematic Diagram of B1 (1/3) Board ............... 63
(6) Schematic Diagram of B1 (2/3) Board ............... 66
(7) Schematic Diagram of B1 (3/3) Board ............... 69
(8) Schematic Diagram of C (1/2) Board ................. 73
(9) Schematic Diagram of C (2/2) Board ................. 77
(10) Schematic Diagram of BB (1/3) Board .............. 80
(11) Schematic Diagram of BB (2/3) Board .............. 83
(12) Schematic Diagram of BB (3/3) Board .............. 86
4-5. Semiconductiors ............................................... 88
5. EXPLODED VIEWS
5-1. Chassis .............................................................. 90
5-2. Front Cover....................................................... 91
5-3. Screen Mirror Block and Optics Unit .............. 92
6. ELECTRICAL PARTS LIST .......................... 93
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK
!ON THE SCHEMATIC DIAGRAMS, EXPLODED
VIEWS AND IN THE PARTS LIST ARE CRITICAL TO
SAFE OPERATION. REPLACE THESE COMPONENTS
WITH SONY PARTS WHOSE PART NUMBERS APPEAR
AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.

– 4 –
SECTION 1
GENERAL
The operating instructions mentioned here are partial abstracts
from the Operating Instruction Manual. The page numbers of
the Operating Instruction Manual remein as in the manual.
4
Name
Main power switch
Standby indicator
Stereo A/B indicators
Programme
Volume buttons
Input select buttons
Headphones jack
Input jacks (S video/video/audio)
Symbol
f
f
A-m-B
PROGR+/–
+/–
l
S
3, 3, 3
Overview
This section briefly describes the buttons and controls on the TV
set and on the Remote Commander. For more information, refer to
the pages given next to each description.
TV set-front
Refer to page
14
14
16
14
14
15
23
24
AB
PROGR
5
Name
PAP on/off button
PAP source selector
Swap button
PAP freeze button
Name
Menu on/off button
Select buttons
OK(confirming)button
Back button
Remote commander
TV/Teletext
operation
Full-Function side
Simple side
Note
The SAT button does not
operate with this TV.
PAP (Picture-and-picture) operation
Menu operation
Refer to page
7
7
7
7
Symbol
VTR1/2/3,
MDP
;; -:: L
Jaf
PROGR +/–
Name
Video equipment selector
Video equipment operation
buttons
Refer to page
26
26
Video operation
PAP operation
Menu operation
Video operation
Name
Mute on/off button
Standby button
TV power on/TV mode selector
button
Teletext button
Input mode selector
Output mode selector
Number buttons
Double-digit entering button
Direct channel entering button
Volume control button
Programme selectors
Teletext page access buttons
Picture adjustment button
Sound adjustment button
On-screen display button
Teletext hold button
Time display button
Fastext buttons
“Freeze” button
Button to change Screen Format
Refer to page
15
14
14
15
15
24
14
14
10
14
14
20
16
16
15
20
15
20
15
15
11
$
Symbol
o
f
O
_
1,2,3,4,5,6,
7,8,9 and 0
–/--
C+/–
PROGR +/–
[
#
LLLL
TV/Teletext operation
Refer to page
18
18
18
18
Symbol
C
Symbol
MENU
>+/ ?–
OK
@
PROGR
RM-838
12
45
3
6
9
8
7
0
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET

– 5 –
6
R/D/D/D
L/G/S/I
R/D/D/D
L/G/S/I
R/D/D/D
L/G/S/I
R/D/D/D
L/G/S/I
Check the supplied accessories
When you’ve taken everything
out of the carton, check that you
have these items:
• RM-838 Remote Commander
• One IEC designation R6 battery
• Wrench (1)
• Bracket (2)
• Dust Remover (1)
Insert the battery into the Remote Commander
Step 1 Preparation
Getting Started
1
Fit an IEC aerial connector attached to 75-ohm coaxial cable (not
supplied) to the )socket at the rear of the TV.
RM-838
PROGR
VTR1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
MENU
+
_
OK
+
4
PROGR
1
1
+
_
+
_
3
PROGR
8
7
0
9
RM-838
5
3
2
46
1
1
1
2
PROGR
RM-838
8
7
0
5
3
2
46
9
1
Remove the cover. Check the correct
polarities. Refit the outside cover
making sure that the Full-
Function side is visible to use
the menu in step 2.
Note: Always remember
to dispose of used
batteries in an
enviromental friendly
way.
2
3
3
Connect the aerial
12
12
7
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_OK
+
_
RM-838
USE
MEM
RESET
Step 2 Tuning in toTV Stations
Once you have set up the TV, you can choose the language of the
menu. Then, you should preset the channels (up to 100 channels)
by choosing either the automatic or manual method. The
automatic method is easier if you want to preset all receivable
channels at once. Use the manual method if you only have a few
channels and want to preset channels one by one.
Before you begin
• Check that the Full-Function side of the Remote Commander is
visible.
• Locate Menu operation buttons on the Remote Commander.
They are shaded in the illustration at the left.
Choose a language
1Press f on the TV.
The TV will switch on. If the standby indicator on the TV is lit, press
O or a number button on the Remote Commander.
2Press the MENU button.
The LANGUAGE menu appears. (See Fig. 1.)
3Select the language you want with >+ or ?– and press OK.
Display the menu
Press MENU.
The main menu appears. (See Fig. 2.)
Using >+ or ?– select the symbol and press OK.
Now, choose one of the methods described overleaf:
“Preset Channels Automatically”
or
“Preset Channels Manually”
MENU
To go back to main
menu
Keep pressing @.
To go back to the
normal TV picture
Press MENU. Normal
TV picture will be
restored after one
minute if menu functions
are not selected.
Note on the Demo
function
If you choose Demo in
the Installation menu,
you can see a sequential
demonstration of the
menu functions.
Press MENU to stop the
function.
1
2
12
f
Fig. 2
Fig. 1
Auto 16:9
Select and press OK
Clip Board
PAP
Strobe
Screen Position
Screen Mode
[off]
[off]
[on]
[ ]
[ ]zoom
0
SCREEN MODE
LANGUAGE
English
Deutsch
Français
Italiano
Español
Nederlands
Português
Suomi
Svenska
E ŁvØxÆ
Türkçe
Select and press OK
Select
+
_
OK

– 6 –
8
Preset channels automatically
1Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears. (See Fig. 3.)
2Select “Auto Programme” with >+ or ?– and press OK.
The AUTO PROGRAMME menu appears. (See Fig. 4.)
3Press OK.
Select if necessary the TV broadcast system (B/G for Western
European or D/K for Eastern European countries) with >+ or ?–
and press OK. The first element of the “PROG” number will be
highlighted.
4Select the programme (number button) from which you want to
start presetting. Select the first element of the double-digit number
with >+ or ?– or the number buttons (e.g., For “04,” select “0”
here) and press OK.
The second element of “PROG” will be highlighted.
5Select the second element of the double-digit number with >+ or
?– or the number buttons (e.g., For “04,” select “4” here) (See Fig.
5) and press OK.
6Select “C” or “S” with >+ or ?– and press OK.
The automatic channel presetting starts.
When presetting is finished, the preset menu reappears. All
available channels are now stored on successive number buttons.
Press menu to restore normal TV picture.
To go back to the main
menu
Keep pressing @.
To stop automatic
channel presetting
Press @on the Remote
Commander.
Notes
• After presetting the
channels automatically,
you can check which
channels are stored on
which programme
positions.
For details, see
“Displaying the
Programme Table” on
page 15.
• You can sort the
programme positions to
have them appear on
screen in the order you
like. For details, see
“Sorting Programme
Positions” on page 10.
3
Fig. 3
Fig. 4
Fig. 5
Installation
Select and press OK
Programme Sorting
Manual Programme Preset
Auto Programme
PRESET
Parental Lock
B/G
Select and press OK
AUTO PROGRAMME
SYS PROG C25 CH – LABEL
––––01
B/G
SYS PROG C25 CH – LABEL
––––04
9
MANUAL PROGRAMME PRESET
PROG
1
2
3
4
5
6
7
8
9
10
Select and press OK
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
SYS
C21
C34
C33
C45
C02
C08
C10
C12
C20
C59
CH
off
off
off
off
off
off
off
off
off
off
SEARCH LABEL
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
Preset channels manually
1Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears. (See Fig. 6.)
2Select “Manual Programme Preset” with >+ or ?– and press OK.
The MANUAL PROGRAMME PRESET menu appears. (See Fig.
7.)
3Using >+ or ?–, select the programme position (number button) to
which you want to preset a channel, and press OK.
4Select, if necessary the TV broadcast system or a video input
source (EXT)) with >+ or ?–.
5Then press OK. The CH position will be highlighted. (See Fig. 8.)
6Using >+ or ?–, select C (to preset a regular channel), S (cable
channel) or F (to tune in by frequency) and press OK.
The first element of the “CH” number will be highlighted.
If you have selected EXT in step 5, select the video input source
with >+ or ?–. (See Fig. 9.)
There are two ways to preset channels, If you know the channel
number, go to step “7-Manual,”
or
If you don’t know the channel number, go to step “7-Search.”
7 Manual
-a Select the first element of the “CH” number with >+ or ?– or the
number buttons and press OK.
The second element of the “CH” number will be highlighted.
-b Select the second element of the number with >+ or ?– or the
number buttons.
The selected number appears. (See Fig. 10.)
-c Press OK
The “SEARCH” position is highlighted and the selected channel is
now stored. (See Fig. 11.)
-d Press OK until the cursor appears by the next programme position.
-e Repeat steps 3 to 7 to preset other channels.
7 Search
-a Press OK repeatedly until the colour of the SEARCH position
changes.
-b Start searching for the channel with >+ (up) or ?– (down).
The CH position changes colour. (See Fig. 12.)
The CH number starts counting up or downwards. When a
channel is found, it stops. (See Fig. 13.)
-c Press OK if you want to store this channel. If not, press >+ or ?–
to continue channel searching.
-d Press OK until the cursor appears by the next programme position.
-e Repeat steps 3 to 7 to preset other channels.
3
Use this method if there
are only a few channels
in your area to preset or if
you want to preset
channels one by one.
You may also allocate
programme numbers to
various video input
sources.
If you have made a
mistake
Press @to go back to
the previous position.
To return to the main
menu
Keep pressing @.
To go back to the
normal TV picture
Press MENU.
To tune in a channel by
frequency
After selecting F in step 6,
enter three digits using
the number buttons.
Installation
Select and press OK
Programme Sorting
Manual Programme Preset
Auto Programme
PRESET
Parental Lock
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
2C –––––21B/G off
2C –––––21B/G off
3AV1 –––––EXT
2C –––––35B/G off
2C –––––35B/G off
2C –––––50B/G 4$

– 7 –
10
PROGRAMME SORTING
PROG
1
2
3
4
5
6
7
8
Select and press OK
C15
C03
C04
C07
C09
C12
C13
C14
CH LABEL
BBC 1
BBC 2
ITV
MBC
-----
-----
-----
-----
Move PR 1 to PR - -
PROGRAMME SORTING
PROG
1
2
3
4
5
6
7
8
Select and press OK
C03
C04
C07
C09
C12
C13
C14
C15
CH LABEL
BBC 2
ITV
MBC
-----
-----
-----
-----
BBC 1
Move PR 8 to PR - -
Additional Presetting Functions
This section shows you additional presetting functions such as
sorting or skipping programme positions, captioning a station
name, manual fine-tuning, and using the parental lock.
Before you begin
• Check that the Full Function side of the Remote
Commander is visible.
• Locate the Menu operation buttons.
Sorting Programme Positions
With this function, you can sort the programme positions to a
preferable order.
1Press MENU to display the main menu.
2Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears.
3Select “Programme Sorting” with >+ or ?– and press OK.
The PROGRAMME SORTING menu appears. (See Fig. 14.)
4 Using >+ or ?–, select the programme position you want to move
to another and press OK.
The colour of the selected position changes. (See Fig. 15.)
5Using >+ or ?–, select the programme position to which you want
to move the channel of the programme position selected in step 4
and press OK. Now the programme positions have been sorted.
(See Fig. 16.)
6Repeat steps 4 and 5 to sort other programme positions.
For higher programme
positions
The display scrolls
automatically.
If you have made a
mistake
Press @to go back to
the previous position
To go back to main
menu
Keep pressing @.
To go back to the
normal TV picture
Press MENU.
PROGRAMME
SORTING
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
Fig. 14
Fig. 15
Fig. 16
8BBC1C15
12
11
FURTHER PROGRAMME PRESET
PROG
1
2
3
4
5
6
7
8
9
10
Select and press OK
ATT
0
0
- 1
- 1
0
- 1
- 1
- 1
- 1
- 1
VOL
on
on
on
on
on
on
on
on
on
on
IN-AMP AFT
on
on
- 1
- 1
on
- 1
- 1
- 1
- 1
- 1
off
off
off
off
off
off
off
off
off
off
Using“Further Programme
Preset”
Using the menu “further Programme Preset” you can
a) in case of a strong local aerial signal (striped picture) attenuate the
signal individually for each programme position (RF attenuator).
b) individually adjust and store the volume level of each channel
(Volume offset).
c) in case of a strong sound signal (distorted sound), attenuate the
sound signal for each programme position.
d) use the manual fine tuning to obtain a better picture reception, if
the picture is distorted. Normally the AFT (automatic fine tuning) is
operating.
1Press MENU to display the main menu.
2Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears.
3Select “Installation” with >+ or ?– and press OK. The
INSTALLATION menu appears.
4Select “Further Programme Preset” with >+ or ?– and press OK.
The FURTHER PROGRAMME PRESET menu appears (See Fig.
17).
5Using >+ or ?– select the desired programme position and press
OK once to select a) “ATT” (RF Attenuator), twice to select b)
“VOL” (Volume offset), three times to select c) “IN-AMP” (Input
Amplifier) or four times to select d) AFT (Automatic Fine Tuning).
The selected item changes colour.
To adjust or change:
a) RF attenuator (ATT)
Using >+ or ?– select “On” for the selected programme position.
Press OK to confirm the selection. Repeat step 5 to attenuate
other programme positions.
b) Volume offset (VOL)
Using >+ or ?– you can adjust the volume level for the selected
programme position within a range form –7 to +7.
Press OK to store the volume level.
Repeat step 5 to set the volume level for other programme
positions.
c) IN-AMP (input amplifier)
Using >+ or ?– select “Off” for the selected programme position.
Press OK to confirm the selection. Repeat step 5 to switch off the
input amplifier for other programme positions.
d) AFT
Using >+ or ?– you can fine-tune the channel within a range from
–15 to +15. Press OK to store the fine-tuned level. Repeat step 5
to fine-tune the other channels.
6Press MENU to return to the normal TV mode.
INSTALLATION
To reactivate AFT
(Automatic Fine
Tuning)
Repeat from the
beginnig and select “ON”
in step 5.
Fig. 17

– 8 –
12
MANUAL PROGRAMME PRESET
PROG
1
2
3
4
5
6
7
8
9
10
Select and press OK
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
SYS
C21
C24
C25
C27
C28
C22
C26
C25
C23
C29
CH
off
off
off
off
off
off
off
off
off
off
SEARCH LABEL
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
MANUAL PROGRAMME PRESET
PROG
1
2
3
4
5
6
7
8
9
10
Select and press OK
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
B/G
SYS
C21
C24
C25
C27
C28
C22
C26
C25
C23
C29
CH
off
off
off
off
off
off
off
off
off
off
SEARCH LABEL
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
MANUAL
PROGRAMME
PRESET
If you have made a
mistake
Press @to go back to
the previous position.
To go back to main
menu
Keep pressing @.
To go back to the
normal TV picture
Press MENU.
Skipping Programme Positions
You can skip unused programme positions when selecting
programmes with PROGR +/– buttons. However, the skipped
programmes may still be called up when you use the number
buttons.
1Press MENU to display the main menu.
2Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears.
3Select “Manual Programme Preset” with >+ or ?– and press OK.
The MANUAL PROGRAMME PRESET menu appears. (See Fig.
18.)
4Using >+ or ?–, select the programme position which you want to
skip and press OK.
The “SYS” position changes colour.
5Press >+ or ?– until “– – –” appears in the SYSTEM position.
(See Fig. 19.)
6Press OK. (See Fig. 20.)
When you select programmes using the PROGR +/– buttons, the
programme position will be skipped.
7Repeat steps 4 to 6 to skip other programme positions.
Captioning a Station Name
Programme names are usually automatically taken from Teletext if
available, You can also “name” a channel or an input video source
using up to five characters (letters or numbers) to be displayed on
the TV screen (e.g. BBC1). Using this function, you can easily
identify which channel or video source you are watching.
1Press MENU to display the main menu.
2Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears.
3Select “Manual Programme Preset” with >+ or ?– and press OK.
The MANUAL PROGRAMME PRESET menu appears. (See Fig.
21.)
4Using >+ or ?–, select the programme position you want to
caption and press OK repeatedly until the first element of the
LABEL position is highlighted.
5Select a letter or number with >+ or ?– and press OK.
The next element will be highlighted.
Select other characters in the same way. If you want to leave an
element blank, select - and press OK. (See Fig. 22.)
6After selecting all the characters, press OK repeatedly until the
cursor appears by the next programme position (at the left margin).
Now the caption you chose is stored. (See Fig. 23.)
7Repeat steps 5 and 6 to caption names for other channels.
MANUAL
PROGRAMME
PRESET
Fig. 18
Fig. 19
Fig. 20
Fig. 21
Fig. 22
Fig. 23
PROGR
+
_
3–––
4 B/G
3 –––
2 C S––––25B/G off
2CSONY25B/G off
13
C - -
3 C26 C 4
2 C42 BBC 1
PROG CH LABEL
1 C25 BBC 2
0 AV1 VHS
PARENTAL LOCK
If you try to select a
programme that has
been blocked
The message
“LOCKED” appears on
the blank TV screen.
Parental Lock
You can prevent undesirable broadcasts from appearing on the
screen. We suggest you use this function to prevent children from
watching programmes which you consider unsuitable.
1Press MENU to display the main menu.
2Select the symbol for “Preset” with >+ or ?– and press OK.
The PRESET menu appears.
3Select “Parental Lock” with >+ or ?– and press OK.
The PARENTAL LOCK menu appears. (See Fig. 24.)
4Using >+ or ?–, select the programme position you want to block
and press OK.
The symbol appears in front of the programme number
indicating that this programme is now blocked. (See Fig. 25.)
5Repeat step 4 to block other programme positions.
Cancelling blocking
1On the PARENTAL LOCK menu, select the programme position
you want to unblock with >+ or ?–.
2Press OK.
The symbol disappears indicating that the blocking has been
cancelled.
Tuning in a ChannelTemporarily
You can tune in to a channel temporarily, even when it has not
been preset. Use the buttons on the Full-Function side of the
Remote Commander.
1Press C on the Remote Commander. For cable channels, press C
twice.
The indication “C” ( “S” for cable channels) appears on the screen.
(See Fig. 26.)
2Enter the double-digit channel number using the number buttons
(e.g. for channel 4, first press 0, then 4).
The channel appears.
However, the channel will not be stored.
Fig. 24
Fig. 25
PARENTAL LOCK
PROG
0
1
2
3
4
5
6
7
Select and press OK
AV1
C25
C42
C26
C34
C35
C36
C37
CH LABEL
VHS
BBC 2
BBC 1
C 4
ITV
-----
-----
-----
Fig. 26

– 9 –
14
PROGR
RM-838
12
45
3
6
9
8
7
0
Operating Instructions
Watching theTV
If no picture appears
when you depress f
on the TV and if the
standby indicator on
the TV is lit, the TV is in
standby mode.
Press Oor one of the
number buttons to
switch it on.
This section explains the basic functions you use while watching
TV. Most of the operations can be done using the simple side of
the Remote Commander.
Switching theTV on and off
Switching on
Depress fon the TV.
Switching off temporarily
Press fon the Remote Commander.
The TV enters standby mode and the standby indicator on the front
of the TV lights up in red.
To switch on again
Press O, PROGR +/–, or one of the number buttons on the
Remote Commander.
When the power is turned on again right after the power is turned
off, the projection TV will enter standby mode with the f(standby)
indicator flashing. After the set cools down, the power will come
on.
Switching off completely
Depress fon the TV and indicator on the front of the TV lights up
in amber.
SelectingTV Programmes
Press PROGR +/– or press the number buttons.
To select a double-digit number
Press -/--, then the numbers.
For example, If you want to choose 23, press -/--, 2 and 3.
Adjusting theVolume
Press +/–.
Operating theTV Using the
Buttons on theTV
To select the programme number, press the PROGR +/– buttons.
To adjust the volume, press the +/– buttons.
To select the video input picture, press the button.
To reset picture and sound controls to the factory preset level
(RESET function), press PROGR +/– buttons simultaneously.
AB
PROGR
15
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
For details of the video
input picture, refer to
page 24.
WatchingTeletext orVideo Input
Watching teletext
1Press _to view the teletext.
2For teletext operation, enter a 3-digit page number with the number
buttons to select a page.
For fastext operation, press one of the coloured buttons.
For both operations, press V (PAGE + ) for the next page or
U(PAGE – ) for the preceding page.
3To go back to the normal TV picture, press O.
Watching a video input picture
1Press repeatedly until the desired video input appears.
2To go back to the normal TV picture, press O.
More Convenient Functions
Use the Full-Function side of the Remote Commander.
Displaying the on screen indications
• Press $once to display all the indications. They will disappear
after a few seconds.
• Press $twice to have the programme number and label stay on
screen. Press twice again to make the indications disappear.
Muting the sound
Press o.
To resume normal sound, press oagain.
Displaying the time
Press #. This function is available only when teletext is broadcast.
To make the time display disappear, press #again.
Displaying the Programme Table
Press OK. A Programme Table will be displayed on the left side of
the TV screen. (See Fig. 27.)
Selecting TV programmes
Press PROGR +/– or select the desired programme position using
>+ or ?– and press OK.
To make the Programme Table disappear, press MENU.
Freezing the Picture
When watching the TV you have the possibility to “freeze” the
picture. Press . Press the button again to return to the normal
TV picture.
Changing the Screen format
Press repeatedly to change the Screen mode as follows:
4:3 (4:3 picture)
ASmart (imitation of 16:9 for 4:3 broadcast)
AZoom (imitation of 16:9 for movies broadcast in
cinemascopic format)
or
AWide (for 16:9 broadcast).
See also page 19 for more information.
For details of the teletext
operation, refer to
page 20.
PROGR
Fig. 27
1
2
3
4
5
6
7
8
9
10
BBC
SAT
TV5
C02
C15
RTL
SKY
S34
AV1
MTV

– 10 –
16
Effect
(See page 17 for more information)
A: channel 1 B: channel 2 Stereo Mono
The selected mode of the A-m-B indicator on the TV lights up.
Less More
A: channel 1 nB: channel 2 nPAP (if PAP is switched on you
can select the PAP sound for the headphones)
Stereo nMono
Effect
Less More
Darker Brighter
Less More
Greenish Reddish
Softer Sharper
Resets picture to the factory preset levels.
Normal high: obtain a high quality picture
CONTROL
SOUND
CONTROL
Adjusting and Setting theTV Using
the Menu
SOUND CONTROL
Graphic Equalizer
Dual Sound
Headphones:
2Volume
2Dual Sound
Adjusting the Picture and Sound
Although the picture and sound are adjusted at the factory, you can
adjust them to suit your own taste. You can also select dual sound
(bilingual) programmes when available or adjust the sound for
listening with the headphones. Also you have the possibility to
adjust the sound to your individual taste using the Graphic
Equalizer and special Sound effects.
1Press (for picture) or (for sound) on the Remote Commander.
or
Press MENU and select the symbol for Picture Control or
Sound Control, then press OK.
The PICTURE CONTROL or SOUND CONTROL menu appears.
(See Fig. 28 or Fig. 29.)
2Using >+ or ?–, select the item you want to adjust and press OK.
The selected item changes colour. (See Fig. 30.)
3Adjust the setting with >+ or ?– and press OK.
The cursor appears beside the next item (at the left margin). (See
Fig. 31.)
For the effect of each control, see the table below.
4Repeat steps 2 and 3 to adjust other items.
5Press MENU to return to TV picture.
Fig. 28
Fig. 29
Fig. 30
Fig. 31
Select and press OK
2
Dual Sound
Grafic Equalizer
SOUND CONTROL
2Volume
Dual Sound (A)
[ ]mono
[ ]mono
Brightness
Colour
Brightness
If you have made a
mistake
Press @to go back to
the previous position.
To go back to the main
menu
Keep pressing @.
Notes
• HUE is only available for
NTSC colour systems.
When watching a video
input source with
stereo sound
You can select DUAL
SOUND to change the
sound.
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
Effect of each control
PICTURE CONTROL
Contrast
Brightness
Colour
Hue
Sharpness
RESET
Resolution
Select and press OK
Reset
Sharpness
Brightness
Contrast
PICTURE CONTROL
Colour
Resolution (high)
17
Graphic Equalizer
Using this function you can individually adjust the sound by cutting
and boosting selected frequencies. You can also select between
the following modes:
Flat nPop nRock nJazz nVocal nUser
1Select “Sound Control” in the main menu, then select “Graphic
Equalizer” using >+ or ?– and press OK.
The GRAPHIC EQUALIZER menu appears (See Fig. 32).
2Press OK. The colour of “Mode” changes. Select the desired
mode with >+ or ?– and press OK.
3If you want to modify a mode, select the desired bar of a frequency
band using >+ or ?– and press OK. The selected frequency
changes colour. Using >+ or ?– adjust the level of frequency and
press OK. In this way you can adjust all 5 graphic bars.
4Press MENU to return to the normal TV mode.
Using the SleepTimer
You can select a time period after which the TV automatically
switches into standby mode.
1Using >+ or ?– select the symbol tfor “Timer” and press OK.
The TIMER menu appears (see Fig. 33).
2Press OK.
The time period option changes colour.
3Select the time period with >+ or ?–.
The time period (in minutes) changes as follows:
10 n20 n30 n40 n50 n60 n70 n80 n90
4After selecting the time period, press OK.
The cursor moves back to the left margin and the timer starts
counting.
One minute before the TV switches into standby mode, a message
is displayed on the screen.
GRAPHIC EQUALIZER
Select and press OK
[User]Mode:
+
–
0
100 400 1K 4K 10K
Note: The modifications
made in “USER” mode
will be stored. All other
settings are reset to
factory-set level when
you change to another
mode.
TIMER
To switch off the timer
Select “OFF” in step 3.
To check the
remaining time
Press $.
To go back to the
normal TV picture
Press MENU.
Fig. 32
Fib. 33
TIMER
Select and press OK
Sleep Timer [ ]10 Min
Flat
Pop
Rock
Jazz
Vocal
User
↑

– 11 –
18
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_OK
+
_
RM-838
USE
MEM
RESET
PAP (Picture and Picture)
Notes
• RGB input source
cannot be displayed in
PAP.
• PAP is not available in
the Zoom mode.
• The sound of the right
screen is only available
via the headphones.
• The picture quality of
the TV screen and
PAP may differ.
With this function you can display two screens at the same time. In
this way you can watch two TV programmes at the same time. Also
you can watch or monitor the video output from any connected
equipment (for example from a VCR) while watching TV or vice
versa. For information about connection of other equipment, refer
to page 23.
Switching PAP on and off
Press to display the screens in 8:9 format.
The PAP screen will be displayed next to the main TV screen.
The PAP screen will come from the source chosen when the TV
was last used.
To switch PAP off
Press repeatedly.
Selecting PAP source
Press >.
The symbol >will be displayed at the bottom, left-hand corner of
the screen.
Press PROGR +/–, the number buttons or …to select the desired
source for the PAP screen.
Swapping screens
Press .
The main screen will switch the picture with the PAP screen.
8: 9 8: 9
Freezing the picture
You have the possibility to “freeze” the picture of the PAP screen.
Press once to freeze and twice to return to the normal screen.
PAP screen
Main
TV picture
AB BA
AA
AA
AB
A
/
/
16: 9
8: 9
Freeze
Freeze
19
Fig. 34
Fig. 35
Fig. 36
Fig. 37
Fig. 38
Fig. 39
Operating Screen Mode/PAP using
the Menu
Using the Screen Mode menu you have the possibility to change
the aspect ratio for the TV display for wide screen effects, operate
the PAP Mode or reproduce the main picture image by image
(Strobe function).
1Press MENU to display the main menu.
2Select the symbol for “Screen Mode” with >+ or ?– and press
OK. The SCREEN MODE menu appears (See Fig. 34).
You have the choice among the following modes:
4:3 for normal ratio 4:3 (See Fig. 35).
Smart: imitation of wide screen effect (16:9) for 4:3 broadcasts
(See Fig. 36).
Zoom imitation of wide screen effect (16:9) for movies broadcast
in cinemascopic format (See Fig. 37).
or
Wide: for 16:9 broadcasts (See Fig. 38).
a) Changing the Screen position (only for Zoom mode)
When using the Zoom mode part of the picture at the top and
bottom will be cut off. With the help of the function “Screen
position” you can move the screen up- or downwards in order to
see the cut-off part of the screen (e.g., to read the subtitles).
Using >+ or ?– select “Screen position” and press OK. The
selected item changes colour. Using >+ or ?– adjust the screen
position and press OK.
b) Strobe Mode
Using >+ or ?– select “Strobe” and press OK. Now the TV picture
is displayed image by image, creating a slow motion effect (See
Fig. 39). Using >+ or ?– select the speed of the motion (3
different speeds are available). Press OK to return to the normal
TV mode.
c) Switching PAP on and off
Using >+ or ?– select “PAP” and press OK. Using >+ or ?–
select “ON” to display the PAP screen in 8:9 format and “OFF” to
switch if off and press OK.
d) Freezing the PAP screen
Using >+ or ?– select “Clip Board” and press OK.
Using >+ or ?– select “On” to freeze the PAP screen and “Off” to
restore the normal picture.
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_OK
+
_
RM-838
USE
MEM
RESET
Auto 16:9
Select and press OK
Clip Board
PAP
Strobe
Screen Position
Screen Mode
[off]
[off]
[on]
[ ]
[ ]zoom
0
SCREEN MODE
When you want to
select the screen
mode
You can also select the
screen mode by
pressing the button
on the Remote
Commander.
Auto 16:9
If you preset Auto 16:9 to ON and the 16 : 9 format signal is being
transmitted, the screen mode automatically changes from any
mode to the 16 : 9 mode. When the 16 : 9 format programme is
finished, the screen mode automatically returns to the previous
mode.
1Press MENU to display the main menu.
2Select the symbol for “Screen Mode” with >+ or ?– and press
OK. The SCREEN MODE menu appears.
3Select “Auto 16:9” with >+ or ?– and press OK.
4Select ON or OFF with >+ or ?– and press OK.
off: OK
LIVELIVE
Strobe: Speed:

– 12 –
20
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
Note
Teletext errors may
occur if the broadcasting
signals are weak.
With the simple side of
the Remote
Commander
You can switch teletext
on and off, operate
Fastext, and directly
select page numbers.
Note
Fastext operation is only
possible, if the TV station
broadcasts Fastext
signals.
Teletext
TV stations broadcast an information service called Teletext via
the TV channels.Teletext service allows you to receive various
information pages such as weather reports or news at any time
you want. For advanced teletext operation, use the buttons on the
Full-Function side of the Remote Commander.
Direct Access Functions
Switching Teletext on and off
1Select the TV channel which carries the teletext broadcast you
want to watch.
2Press _to switch on teletext.
A teletext page will be displayed (usually the index page).
If there is no teletext broadcast, “No text available” is displayed on
the information line at the top of the screen.
To switch teletext off
Press O.
Selecting a teletext page
With direct page selection
Use the number buttons to input the three digits of the chosen
page number.
If you have made a mistake, type in any three digits. Then re-enter
the correct page number.
With page-catching
1Select a teletext page with a page overview (e.g. index page).
2Press OK. Using >+ or ?–, select the desired page. “Page
Catching” will be displayed on the information line. Press OK.
The requested page will appear in a few seconds.
Press _to resume normal teletext reception.
Accessing next or preceding page
Press g(PAGE+) or G(PAGE-).
The next or preceding page appears.
Superimposing the teletext display on the TV programme
• Press _once in teletext mode or twice in TV mode.
• Press _again to resume normal teletext reception.
Preventing a teletext page from being updated
• Press [(HOLD). The HOLD symbol “[” is displayed on the
information line.
• Press _to resume normal teletext reception.
Using Fastext
With Fastext you can access pages with one key stroke.
When a Fastext page is broadcast, a colour-coded menu will
appear at the bottom of the screen. The colours of this menu
correspond to the red, green, yellow and blue buttons on the
Remote Commander.
Press the corresponding coloured button on the Remote
Commander which corresponds to the colour-coded menu. The
page will be displayed after a few seconds.
21
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
Note
Some of the features
may not be available
depending on the
teletext service.
Using theTeletext Menu
This TV is provided with a menu-guided teletext system. When
teletext is switched on, you can use the menu buttons to operate
the teletext menu. Select the teletext menu functions in the
following way:
1Press MENU. The menu will be superimposed on the teletext
display. (See Fig. 40.)
2Using >+ or ?–, select the teletext function you want and press
OK. (See Fig. 41.)
USER PAGES/PRESET USER PAGES
See page 22 for information about presetting and operating the
user pages.
INDEX
The index will give you an overview of the contents of the teletext
and the page numbers.
TOP/BOTTOM/FULL
For convenient reading of a teletext page, you can enlarge the
teletext display with the ability to scroll up and down. After having
selected the function, an information line Top/Bottom/Full will be
displayed. (See Fig. 42.)
Press >+ for “Top” to enlarge the upper half. For “Bottom” keep
pressing ?–, to enlarge the lower half. Press OK for “Full” to
resume the normal size.
Press _to resume normal teletext reception.
TEXT CLEAR
After selecting the function, you can watch a TV programme while
waiting for a teletext page to be captured. (The symbol changes
colour.) (See Fig. 43.)
Press _to resume normal teletext reception.
SUBTITLES
Your teletext service will inform you if a TV programme is subtitled.
After having selected the function the subtitles will be displayed.
REVEAL
Sometimes pages contain concealed information, such as
answers to a quiz. The reveal option lets you disclose the
information. After having selected the function, an information line
“REVEAL ON/OFF” will be displayed. (See Fig.44.)
Using >+ or ?–, select ON to reveal the information or OFF to
conceal it again.
Press _to resume normal teletext reception.
TIME PAGE
Your teletext service will inform you, if a time coded page is
available. You may have a page (e.g., an alarm page) displayed at
a certain time.
1An information window will be displayed at the bottom of the page.
Using >+ or ?– select “ON” and press OK.
2To select the desired page, enter three digits for the page number
(e.g., 452) using the number buttons.
3To select the desired time, enter four digits for the desired time
(e.g., 1800) using the number buttons. Press MENU.
The selected time is displayed at the top in the left-hand corner.
At the requested time, the page will be displayed.
Press _to resume normal teletext mode.
TELETEXT MENU
Select and press OK
User Pages
Index
Top/Bottom/Full
Text Clear
Subtitles
Reveal
Time Page
Subpage
Preset User Pages
Fig. 40
Fig. 41
Fig. 42
Fig. 43
Fig. 44
TELETEXT MENU
Select and press OK
User Pages
Index
Top/Bottom/Full
Text Clear
Subtitles
Reveal
Time Page
Subpage
Preset User Pages
Top Bottom OK Full
onReveal off
Press OK to select “OFF”
for the TIME PAGE
setting to cancel the
request.

– 13 –
22
PRESET USER PAGES
Select and press OK
BANK
A
B
C
D
E
Allocate Bank
PROG LABEL BANK PROG LABEL BANK
00
01
02
P1
300
200
100
128
400
P2
255
120
220
321
238
P3
456
301
300
255
240
P4
234
303
444
118
P5
200
550
127
P6
179
345
VHS
BBC1
BBC2
–
A
C
04
05
06
MTV
SKY
ITV
D
B
C
SUBPAGE
You may want to select a particular teletext page from several
subpages which are rotated automatically. After having selected
the function, an information line will be displayed.
To select the desired subpage, enter four digits using PROGR +/–
or the number buttons (e.g., enter 0002 for the second page of a
sequence).
User Page Bank System
You can store up to 30 pages in the “Teletext page band system”.
In this way you have quick access to the pages you watch
frequently.
Storing pages
There are 5 “banks” (A to E) for 5 teletext stations. In each bank
you can store 6 preferred pages (P1 to P6).
1Press _(if Teletext is not on already) and MENU to show the
TELETEXT MENU display.
2Select PRESET USER PAGES with >+ or ?– and press OK.
3Select the desired bank with >+ or ?– and press OK. The cursor
will go to the first position (P1) of the preferred pages.
4Input the three digits of your first preferred page with the number
buttons and press OK.
The cursor will go to the second position.
5Repeat step 4 for the other 5 page numbers you want to preset. If
you do not want to preset all 6 page numbers available, press OK
without inserting any number. After having finished the presetting
press OK repeatedly until the cursor appears besides the next bank
at the left margin.
6Select Allocate Bank with >+ or ?– and press OK.
7Select the programme position for which you have preset pages
with >+ or ?– and press OK. (See Fig. 45.)
8Select the desired bank with >+ or ?– (Banks A to E are available)
and press OK.
9Repeat steps 3 to 8 for the other 4 banks available.
Displaying User Pages
1Select MENU.
2Select User Pages with >+ or ?– and press OK.
A table of the stored preferred pages will be displayed. (See Fig.
46)
3Select the desired page with >+ or ?– and press OK. The page
will be displayed after some seconds.
or
You can use the coloured buttons on the Remote Commander to
have quick access to the first four User pages. Page 1 corresponds
to the red button, P2 to the green one, P3 to the yellow one and P4
to the blue button.
To select the desired page press the respective coloured button
while you are in TV mode. Now the Page number of this teletext
page will appear in white at the top in the left-handed comer of the
TV screen. When the page number changes colour, the page is
available. Press the coloured button again to display the page.
To cancel the request
Select Subpage and
press OK.
If two broadcasting
stations use the same
Teletext
You can preset one
bank to 2 different
programme positions.
Fig. 45
Fig. 46
USER PAGES - BANK B
Select and press OK
PAGE 300
PAGE 200
PAGE 203
PAGE 500
PAGE 234
PAGE 159
23
Available output signal
Video/audio from TV tuner
Video/audio from selected source
No outputs
Video/audio displayed on TV screen (monitor out)
S/video/audio signal displayed on TV screen (monitor
out)
Audio signal
Connecting and Operating Optional
Equipment
To connect a VCR
using the )terminal
Connect the aerial output
of the VCR to the aerial
terminal )of the TV.
We recommend that you
tune in the video signal to
programme number “0.”
For details see “Preset
channels manually” on
page 9.
If the picture or the
sound is distorted
Move the VCR away from
the TV.
S/video Input
(Y/C input)
Video signals may be
separated into Y
(luminance or brightness)
and C (chrominance)
signals.
Separating the Y and C
signals prevents them
from interfering with one
another, and therefore
improves picture quality
(especially luminance).
This TV is equipped with
3 S Video input jacks
through which these
separated signals can be
input directly.
When connecting a
monaural VCR
Connect only the white
jack to both the TV
and VCR.
Note on playing video
games:
Games that involve
shooting at the screen
with an electronic gun or
similar device cannot be
played with this TV.
Connecting Optional Equipment
You can connect optional audio-video equipment to this TV such as a
VCR, video disc player, and stereo system.
Acceptable input signal
1 Normal audio/video and RGB signal
2 Normal audio/video and S video signal
3 Normal audio/video and S video signal
4 Normal audio/video and S video signal
5 No inputs
6 No inputs
R/D/D/D
L/G/S/I
R/D/D/D
L/G/S/I
R/D/D/D
L/G/S/I
PROGR
R/D/D/D
L/G/S/I
14
256
3

– 14 –
24
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
Input signal
Audio/video input through the 1 connector
Audio/RGB input through the 1 connector
Audio/video input through the 2/
S
2 connector
Audio/S video input through the 2/
S
2 or
S
2 connector (4-pin
connector)
Audio/video input through 3 and 3 connector on the front
S video input through the
S
3 connector (4-pin connector) at the front
Audio/video input through the 4/
S
4 connector
S video input through the 4 /
S
4 or
S
4 connector(4-pin connector)
Selecting input with
PROGR +/– or number
buttons
You can preset video
input sources to the
programme positions so
that you can select them
with PROGR +/– or
number buttons. For
details, see “Preset
channels manually” on
page 9.
Selecting Input and Output
This section explains how to view the video input picture (of the
video source connected to your TV), and how to select the output
signal using direct access buttons or the menu system.
Selecting input
Press repeatedly to select the input source.
The symbol of the selected input source will appear.
To go back to the normal TV picture
Press O.
Input modes
Symbol
1
2
S
2
3
S
3
4
S
4
Selecting the output
The 2 /
S
2 connector outputs the source input from the
other connectors.
Press repeatedly to select the output.
The symbol of the selected output source appears.
Output modes
2/
S
2 connector outputs
Audio/video signal from the 1 connector
Audio/video signal from the 2/
S
connector
Audio/S video signal from the 2/
S
2 or
S
2 connector (4 pin)
Audio/video signal from the 3, 3 connectors
Audio/S video signal from the
S
3, 3 connectors
Audio/video signal from the 4/
S
4 connector
Audio/S video signal from the 4/
S
4 or
S
4 connector (4 pin)
Audio/video signal from the )aerial terminal
Symbol
1
2
2
S
3
3
S
4
4
S
TV
You can also select the input mode using the button on the TV.
1
1
25
Using AV Preset
Using this function you can preset the desired input source (e.g.
1, RGB signal) to the respective AV input (AV 1 ). In this
way a connected VTR will automatically switch to the RGB signal.
1Select the symbol for “Preset” with >+ or ?– and press OK.
2Select first “Installation”, then “AV Preset” with >+ or ?– and press
OK.
The AV PRESET menu appears (See Fig. 47).
3Select the desired AV input with >+ or ?– and press OK.
4Select the desired source with >+ or ?– and press OK.
For the respective AV inputs you have the following possibilities:
AV1 RGB or AV AV3 YC3 or AV
AV2 YC2 or AV AV4 YC4 or AV
5If you want to name the AV input select “Label” using >+ or ?–
and press OK. Select a letter or a number with >+ or ?– and
press OK. The next element will be highlighted. Select other
characters in the same way. If you want to leave an element blank,
select - and press OK.
After having selected all the characters, press OK repeatedly until
the cursor appears by the next AV input at the left margin.
6Repeat steps 3 to 6 for the other AV inputs.
Checking and selecting the input and output sources
using the menu
You can display the menu to see which input sources are selected
for the TV screen and PAP screen, and which output source is
selected. You can also select them on the menu display.
1 Select the symbol for “Video Connection” with >+ or ?– and
press OK. The VIDEO CONNECTION menu appears. (See Fig.
48)
You can see which source is selected for the TV and PAP input,
and for the output. If you want to select the input and output on this
menu, go on to the next step.
2Select TV Screen (input source for the TV screen), PAP (input
source for the PAP screen), or output (output source) with >+ or
?– and press OK. One of the source items changes colour.
3Select the desired source with >+ or ?–.
For details about each source, see the table on page 24.
4Press OK.
The selected source is confirmed, and the cursor appears.
5Repeat steps 2 to 4 to select the source for other inputs or outputs.
Fig.47
Fig. 48
AV PRESET
AV-INPUT
AV1
AV2
AV3
AV4
Select and press OK
RGB
Y/C
Y/C
Y/C
SOURCE
RGB
YC2
YC2
YC2
LABEL
Select and press OK
PAP
TV screen [ ]
VIDEO CONNECTION
Output
TV -----
[ ]AV2 VHS 2
[ ]TV -----
TV
VHS 2
TV

– 15 –
26
PROGR
PROGR
1
1
VTR 1-2-3 MDP
12
45
3
6
9
8
7
0C
SAT
++
__
MENU
+
_
OK
+
_
RM-838
USE
MEM
RESET
Remote Control of Other Sony
Equipment
You can use the TV Remote Commander to control most of Sony
remote-controlled video equipment such as: beta, 8 mm and VHS
VCRs and video disc players.
Tuning the Remote Commander to the equipment
1Set the VTR 1/2/3 MDP selector according to the equipment you
want to control:
VTR1: Beta VCR
VTR2: 8 mm VCR
VTR3: VHS VCR
MDP: Video disc player
2Use the buttons indicated in the illustration to operate the
additional equipment.
If your video equipment is furnished with a COMMAND MODE
selector, set this selector to the same position as the VTR 1/2/3
MDP selector on the TV Remote Commander.
If the equipment does not have a certain function, the
corresponding button on the Remote Commander will not operate.
When recording
when you use the a
(record) button, make
sure to press this button
and the one to the right
of it simultaneously.
27
OptimumViewing Area
For the best picture quality, try to position the projection TV so that you
can view the screen from within the areas shown below.
Vertical viewing area
ForYour Information
Horizontal viewing area
1.5 m and more
1.5 m and more
35˚
35˚
75˚
75˚

– 16 –
28
Cleaning of the Air Filter
Periodic cleaning of the air filter is necessary. Clean the air
filter once a month. When the filter becomes old and dust
remains on the filter even after cleaning, replace it with a new
one.
• Clean the air filter periodically. If you don’t clean, it may
cause internal heat build-up.
• Never use an air filter which is torn or has holes. Attach the
filter firmly with six tabs. If dust enters the TV, the picture
may become dark.
1Turn off the power and disconnect the
power cord.
2Remove the front panel.
Remove the front panel without moving the TV.
Grasping the side of the front panel with your fingers, pull
it forward. Be careful not to catch your fingernails.
3Pull the filter upward and remove it.
4Clean the dust with a vacuum cleaner.
5Attach the filter.
Attach the six tabs securely.
6Attach the front panel.
Be careful not to damage the speaker.
Notes
• Attach the filter firmly. If it is not firmly attached, the power will not
turn on.
• Remove the supplied filter in the same way as the attached filter.
• Consult your nearest Sony service center to obtain a new filter.
vacuum cleaner
Supplied filter
29
3 Loosen the screw with the object such as a
coin and remove the lamp cover.
4 Loosen two screws and pull out the lamp.
The lamp is still too hot just after the power is turned off.
Be careful that you don’t touch the front glass or
surrounding area of the lamp or the glass of the lamp
compartment.
Loosen two screws with the supplied wrench.
Pull out the lamp by the handle.
5 Attach the new lamp.
Fasten two screws tightly.
6 Attach the lamp cover.
Fasten the screws tightly.
7 Attach the front panel.
Be careful not to damage the speaker.
Notes
• Do not touch or stain the front glass of the new lamp or the glass of
the lamp compartment. If the glass become dirty, the picture quality
may deteriorate or the lamp life may shorten.
• Attach the lamp cover firmly. If it is not firmly attached, the power will
not turn on.
• When the lamp burns out, a noise is audible. This does not represent
a damage.
• Consult your nearest Sony service center to obtain a new lamp.
Replacing the Lamp
When the lamp becomes dark or the picture colour is not
normal, replace with a new lamp.
• Use the lamp XL-100E for replacement. If you use another
lamp, it may cause damage to the TV.
• Do not remove the lamp except when replacing it.
• Before replacing the lamp, turn off the power and disconnect
the power cord.
• Replace the lamp after it becomes cool. The front glass of
the lamp remains 100 °C (212 °F) and more even 30 minutes
after the power is turned off.
• Do not place the removed lamp in proximity to children or
flammable material.
• Do not get the removed lamp wet, or insert objects inside the
lamp. It may cause the lamp to explode.
• Do not place near metal or easily flammable objects, as this
may cause fire. Also, do not put your hand inside the lamp
compartment, as you may be burned.
• Attach the new lamp firmly. If it is not firmly attached, the
picture may become dark.
1 Turn off the power and disconnect the
power cord.
Replace the lamp 30 minutes or more after the power is
turned off.
Prepare the new lamp.
2 Remove the front panel.
Remove the front panel without moving the TV.
Grasping the side of the front panel with your fingers, pull it
forward. Be careful not to catch your fingernails.

– 17 –
Problem
No picture (screen is dark), no sound
Poor or no picture (screen is dark), but sound is OK
Poor picture quality when watching an RGB video source
Good picture but no sound
No colour for colour programmes
Remote Commander does not function
If you continue to have problems, have your TV serviced by qualified personnel. Never open the casing yourself.
Troubleshooting
Here are some simple solutions to some problems which may affect the picture and sound.
Solution
• Plug in the TV in.
• Press fon the TV (if findicator is on, press Oor a programme number
on the Remote Commander).
• Check the aerial connection.
• Check if the selected video source is on.
• Press to enter the PICTURE CONTROL menu and adjust the
brightness, contrast and colour.
• Press repeatedly to select .
• Press +.
• If ois displayed on the screen, press o.
• Press to enter the PICTURE CONTROL menu, select RESET, then
press OK.
• The batteries are weak.
30
31
Warning Indicators
When a problem occurs, the indicator flashes as follows.
Attempt the solution recommended for the given problem.
When a problem occurs while operating the set, the f
(standby) indicator flashes first and then warning will be
indicated.
Cause
The lamp burns out or the
quality of the lamp is deficient.
The cover of the filter or the
lamp is removed.
The fan for cooling stops.
Internal heat builds up.
Indicator flashing patterns
The B indicator flashes twice then A flashes once.
Flashing continues in this manner.
The B indicator flashes three times then A flashes once.
Flashing continues in this manner.
The B indicator flashes four times then A flashes once.
Flashing continues in this manner.
The B indicator flashes five times then A flashes once.
Flashing continues in this manner.
If the lamp flashes in a way not described above, consult your nearest Sony service center.
AB
Stabilizing the ProjectionTV
After setting up, secure the projection TV to a wall, etc., with the supplied brackets, for safety
purposes.
1 Mount the two supplied brackets with the screws to the upper rear side
of the projection TV.
2 Pass a strong cord or a chain through each bracket mounted in 1, and
then secure to a wall or a pillar, etc.
Bracket (supplied)

– 18 –
2-1. REAR COVER REMOVAL
2-2. CHASSIS ASSY REMOVAL
2-3. SERVICE POSITION
2-4. F2 BOARD AND F2 BRACKET REMOVAL
SECTION 2
DISASSEMBLY
Rear cover
2
Twelve screws
(+BVTP 4 x 16)
1
Chassis assy
2
Two screws
(+BVTP 4 x 16)
1
Chassis assy
CN6504
F2 board
2
Claw
3
F2 bracket
4
Two claws
1

– 19 –
2-5. BB, B1 AND J BOARDS REMOVAL
(EXTENSION BOARD) 2-6. POWER BLOCK REMOVAL
2-7. FILTER REMOVAL
Two claws
1
Holder
2
Claw
3
BB board
4
Claw
5
B1 board
6
Screw
(+B M3 x 8)
7
RF booster
8
Three screws
(+BVTP 4 x 16)
9
Two claws
10
Terminal board
11
Claw
12
J board
13
Extension board
1-589-554-11
Common use
(BB, B1 and
J Boards)
Two printed circuit
board holders
4
Terminal
2
Two screws
(+BVTP 3 x 12)
1
Power block
5
Two screws
(+BVTP 4 x 16)
3
Filter
2
Front panel (L)
1
Filter
(Reserve)
3

– 20 –
2-8. LAMP REMOVAL
2-9. H AND F1 BOARDS REMOVAL
2-10. SCREEN FRAME REMOVAL
Lamp door
3
Screw
(Ornamental
screw B)
2
Front panel (R)
1
Lamp
5
Two screws
(Hexagon socket bolt 4 x 12)
4
Two screws
(+BVTP 3 x 12)
5
F1 board
6
Eight screws
(+BVTP 4 x 16)
1Front cover
2
H board
4
Six screws
(+BVTP 3 x 12)
3
Two screws
(+BVTP 4 x 16)
1
Screen frame
3
Eight screws
(+BVTP 4 x 16)
2
