KV-36FV300
MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
36" Wega®
Monitor/Receiver
40 1/4" x 30" x 25 1/4"
224 lbs 14 oz
120VAC
60Hz
220w
1w(stby)
