Sony XTL-750W User manual
1
SERVICE MANUAL
AEP Model
UK Model
XTL-750W/XVM-750WEX
•This set consists of the following units.
MOBILE COLOR TV
XTL-750W
EXTENSION MONITOR SYSTEM
XVM-750WEX
XTL-750W XVM-750WEX
MONITOR XVM-753W XVM-753W
HIDEAWAY UNIT XT-993V XA-602
REMOTE COMMANDER RM-X86
ANTENNA VCA-114
– Continued on next page –
SPECIFICATIONS
Monitor (XVM-753W)
System Liquid crystal color display
Display Transparent TN LCD panel
Drive system TFT active matrix system
Picture size 7 in.; 155.52 ×87.75 mm,
178.57 mm
(w ×h, diagonally)
Picture segment336,960 (w 1440 ×h 234)
Speaker type 35 ×20 mm dynamic speaker ×2
Power requirements
12 V DC car battery
(negative ground)
Current drain Approx. 1.0 A
Dimensions 215 ×126.5 ×34 mm (w ×h ×d)
Operating temperature
5˚C ~ +45˚C
Mass Approx. 650 g
Wireless remote (RM-X86: XTL-750W)
Power requirements
AA (R6) battery × 2
Operable range Approx. 3 m
Dimensions 62 ×25 ×115 mm (w ×h ×d)
Mass Approx. 100 g
(including batteries)
MICROFILM
Monitor : XVM-753W
The XTL-750W has a monitor change to the XTL-6100MK2.
The XVM-750WEX has a monitor change to the XVM-61EX.
This service manual only describes the monitor and accessories and packing materials.
Refer to the service manual for XTL-6100MK2 (9-926-587-11) for information on the hideaway unit XT-993V.
Refer to the service manual for XVM-61EX/6100 (9-925-661-11) for information on the hideaway unit XA-602.
