MODEL COMMANDER DEST. CHASSIS NO.
CHASSIS
BG-2S
SERVICE MANUAL
TRINITRON ® COLOR TV
MODEL COMMANDER DEST. CHASSIS NO.
KV-2199M5T RM-869 ME SCC-U07Q-A

– 16 –
Entering service mode
With the unit on standby
↓
DISPLAY
↓
5
↓
VOL
( + )
↓
POWER
The operation sequence puts the unit into service mode.
SECTION 5
CIRCUIT ADJUSTMENTS
5-1. ADJUSTMENTS WITH COMMANDER
Service adjustments are made with the RM-869 that comes with
this unit.
RM-869
1, 4Raise/lower the service item number
3, 6Raise/lower the data
[MUTING] Writes
-Executes the writing
7, -All data becomes the values in memory
8, -All user control goes to the standard state
5, -Service data initialization (Be sure not to use
usually.)
2, -Write 50Hz adjustment data to 60Hz, or
viceversa.
The screen display is :
1, 4Select the adjustment item.
↓
3, 6Raise/lower the data.
↓
MUTING
Writes
↓
-Executes the writing.
SERVICE Mode08
Data
HSF
50 Depends on the signals
PAL, SECAM : 50
NTSC : 60
Adjustment item
00
ModeItem #
00V3.2C052S
OEM CODE
German A2 Stereo
Software Version #
1
SERVICE00OP0
50
3D
0000000000
2
(Bit options adjustable)
¤ EG u
V…F;
B©
SELECT
PIC MODE
SOUND
MODE
.
PROGR
CI
++
123
46
789
0
+ p
– p
5
TV
A/B

– 17 –
Use the same method for Items Number 00-41. Use 1and 4to
select the adjustment item, use 3and 6to adjust, write with
MUTING
, then execute the write with -.
WRITE
WRITE
GREEN0CVSF08
SERVICE
50
50
GREEN0CVSF08
Adjusted with
3 and 6 buttons
Written with MUTING
Write executed with 0
GREEN
The WRITE display
will change back to
SERVICE.
(2nd line disappear
when written)
0CVSF08
00V3.2C052S
00V3.2C052S
Blank
5-2. ADJUSTMENT METHOD
Item Number 08
This explanation uses V-SHIFT as an example.
1. Select 08 V-SHIFT with the 1and 4buttons.
2. Raise/lower the data with the 3and 6buttons.
3. Select the optimum state. (The standard is 0F for PAL
reception.)
4. Write with the
MUTING
button.
5. Execute the writing with the -button. (The WRITE
display returns to green SERVICE.)

– 18 –
Item Adj Initial Note for Different Data Standard Data Function Device
No. Item Data
00 HSF 24 50/60Hz/RGB 50/RGB 60 2C/33/31/38 H Shift
01 HSZ 23 50/60Hz/RGB 50/RGB 60 35/35/35/35 H Size
02 PAP 21 50/60Hz 25/25 Pin Amplitude
03 CNP 29 50/60Hz 10/0C Corner Pin
04 TLT 20 50/60Hz 20/2D Tilt
05 VSL 20 50/60Hz 1F/1F V Slope
06 VAP ID 50/60Hz 1C/1B V Amplitude
07 SCR 20 50/60Hz 16/16 S Correction
08 VSF 20 50/60Hz 10/10 V Shift
09 RDR 25 28 R Drive
0A GDR 20 G Drive
0B BDR 20 B Drive
0C F0 00 TV/Video/Teletext 00/00/00 ø1 Time Constant
0D AGC 06 TV/Video/Teletext 28/28/28 AGC Take Over
0E VSW 0 TV/Video/Teletext 0/1/0 Video Mute Switch
0F FOR 00 03 Forced Field Frequency
10 DL 0 De-interlace
11 POC 0 Fixed ø1 Synchro. mode
12 COR 0 TV/Video/Teletext 01/00/00 Noise Coring
13 VPX 00 Extra Bits (see below)
14 PMX 27 TV/Video/Teletext 2B/2B/2B Picture Maximum Data
15 PMI 05 04 Picture Minimum Data
16 SBR 4B Sub Brightness
17 SHU 07 Sub Hue
18 SSH 01 TV/Video 01/03 Sub Sharpness
19 SC1 1F 50/60Hz 26/29 Sub Color Lower
1A SC2 0B 50/60Hz 0C/0D Sub Color Higher
1B AIP 40 3F Adjustment IF-PLL
1C VZM 20 19 Vertical Zoom
1D WST 15 W/G Stereo Threshold
1E WBT EA W/G Bilingual Threshold
1F WLL 05 W/G Monaural Threshold
20 ACG 1 AGC Switch auto/constant
21 CDB 28 AGC Gain at Constant Mode
22 FGP 1B FM Prescale for B/G.I.D/K
23 FMP 32 FM Prescale for M
24 FMH 36 FM Prescale for HDEV Mode
25 FMM 65 FM Prescale for HDEV Mode
26 WGP 2A W/G Prescale
27 NIP 6D NICAM Prescale
28 SCP 3B SCART Input Prescale
29 SCV 2A SCART Output Prescale
2A CRM 0 Carrier Muting on/off
2B ACO 1 Audio Clock-out on/off
2C WAC 00 W/G Agreement Count
2D NFT 50 Auto FM Switch Threshold
2E DLG 30 W/G Search Delay
2F DLN 20 NICAM Search Delay
30 DLS 10 Stereo Status Read Delay
31 SMX 73 DFP Volume Maximum
32 ING 00 M System/non-M/Video Input Gain
33 VOM 01 M System only Volume Output Gain
34 TXH 01 Teletext Horizontal Position
35 BKP 00 Picture Data at Blanking OFF
36 ODL 10 Power ON Delay
37 OFR 00 RGB Output Time (STBY OFF)
38 OFM 00 RGB Output Time (AC OFF)
AdjustmentItemTable

– 19 –
NOTE
• Note for Different Data Those are the standard data values written on the microprocessor. Therefore, the data values of
the modes are stored respectively in the memory.
In case of a device replacement, adjustment by rewriting the data value is necessary for some
items.
• 50..............50 Hz data
• 60..............60 Hz data
• Note for Different Data listed on the adjustment item table are reference values, therefore it is different for every model.
Item Adj Initial Note for Different Standard Data Function Device
No. Item Data Data
39 OSH 0A OSD H Position
3A DKS 1 0 D/K Stereo enable/disable
3B MUT 0 Muting on/off at No Sync
3C ABL 0 Bright ABL Switch
3D SCM 0 SECAM Trap active/inactive
3E FBT 1 FBT L/S C/M strict/plain
3F OP0 2F 28 (2199) 2F (J21) Optional Flags 0 (see below)
40 OP1 0F Optional Flags 1 (see below)
41 OP2 00 24 (2199) 04 (J21) Optional Flags 2 (see below)
