TRINITRON®COLOR TELEVISION
SERVICE MANUAL DX-1A CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
KV-32HS20 RM-Y183 US SCC-S47F-A
KV-36HS20 RM-Y183 US SCC-S47E-A
KV-36HS20H RM-Y183 HAWAII SCC-S54C-A
KV-32XBR450 RM-Y184 US SCC-S47D-A
KV-32XBR450 RM-Y184 CND SCC-S48D-A
KV-36XBR450 RM-Y184 US SCC-S47C-A
KV-36XBR450 RM-Y184 CND SCC-S48C-A
KV-36XBR450H RM-Y184 HAWAII SCC-S54B-A
Self Diagnosis
Supported model
9-965-898-01
KV-32XBR450 RM-Y184

—2 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
TABLE OF CONTENTS
Specifications ................................................................................. 3
Warnings and Cautions .................................................................. 4
Safety Check-out ............................................................................ 5
Self-Diagnostic Function................................................................. 6
1. Disassembly
1-1. Rear Cover Removal.............................................................. 8
1-2. Chassis Assembly Removal................................................... 8
1-3. Service Position ..................................................................... 8
1-4. Picture Tube Removal ............................................................ 9
Anode Cap Removal Procedure ..................................................... 9
2. Set-up Adjustments
2-1. Beam Landing ...................................................................... 10
2-2. V-Pin and V-Cen Adjustment ................................................ 11
2-3. Convergence ........................................................................ 11
2-3.1. Vertical and Horizontal Static Convergence............. 11
2-3.2. Operation of BMC (Hexapole) Magnet ..................... 11
2-3.3. TLH Plate Adjustment .............................................. 11
2-3.4. Screen Corner Convergence ................................... 12
2-3.5. Dynamic Convergence Adjustment .......................... 12
2-4. Focus Adjustment................................................................. 12
2-5. Screen (G2).......................................................................... 12
2-6. Picture Quality Adjustments ................................................. 13
2-6.1. Video Input - Two Picture Sub Contrast
Adjustment ............................................................... 13
2-6.2. Video Input - Sub Hue/Sub Color Adjustment.......... 13
2-6.3. RF Input - Two Picture Sub Contrast Adjustment..... 14
2-6.4. RF Input - Sub Hue/Sub Color Adjustment .............. 14
2-7. White Balance (CRT) and Sub Bright Adjustment ............... 15
2-8. Raster Center Adjustment.................................................... 15
2-9. Picture Distortion Adjustments............................................. 15
2-9.1. NTSC (DRC) Full Mode Adjustment ........................ 15
2-9.2. 1080i HD Mode Adjustment ..................................... 16
2-9.3. Vertical Compresses Mode Check and
Confirmation............................................................. 16
SECTION TITLE PAGE
3. Safety Related Adjustments
3-1. RV8001, 8002, 8003 Confirmation Method and
HV Service Adjustments ...................................................... 17
3-2. B+ Max Confirmation ........................................................... 17
3-3. HV Service Flowchart .......................................................... 17
4. Circuit Adjustments
4-1. Setting the Service Adjustment Mode.................................. 18
4-1.1 Resetting the Data ................................................... 18
4-2. Memory Write Confirmation Method .................................... 18
4-3. Remote Adjustment Buttons and Indicators......................... 18
5. Diagrams
5-1. Circuit Board Location.......................................................... 48
5-2. Printed Wiring Boards and Schematic Diagrams ................. 48
5-3. Diagrams
Block Diagram ...................................................................... 49
A Board ................................................................................ 53
B Board ................................................................................ 61
BC Board.............................................................................. 71
C Board ................................................................................ 73
D Board ................................................................................ 75
HA Board.............................................................................. 83
HB Board.............................................................................. 84
S Board ................................................................................ 85
U Board ................................................................................ 86
W Board ............................................................................... 88
5-4. Semiconductors ................................................................... 90
6. Exploded Views
6-1. Chassis ................................................................................. 92
6-2. Picture Tube (KV-32HS20/32XBR450 ONLY) ........................ 93
6-3. Picture Tube (ALL EXCEPT KV-32HS20/32XBR450) .......... 94
7. Electrical Parts List ......................................................................... 95
SECTION TITLE PAGE

—3 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
TruSurround is a trademark of
SRS Labs, Inc. SRS and the SRS
symbol are registered trademarks
of SRS Labs, Inc. in the United
States and in select foreign coun-
tries. SRS and TruSurround are
incorporated under license from SRS Labs, Inc. and are protected
under United States Patent Nos. 4,748,669 and 4,841,572 with
numerous additional issued and pending foreign patents. Pur-
chase of this product does not convey the right to sell recordings
made with the TruSurround technology.
Television system
American TV standard, NTSC
Channel coverage
VHF: 2-13/ VHF: 14-69/ CATV: 1-125
Picture tube
FD Trinitron
®
tube
Visible screen size
32-inch picture measured diagonally (KV-32HS20/32XBR450 ONLY)
36-inch picture measured diagonally (All Except KV-32HS20/32XBR450)
Actual screen size
34-inch measured diagonally (KV-32HS20/32XBR450 ONLY)
38-inch measured diagonally (All Except KV-32HS20/32XBR450)
Antenna
75 ohm external terminal for VHF/UHF
Supplied Accessories
Remote Commander RM-Y183 (KV-32HS20/36HS20/36HS20H ONLY)
Remote Commander RM-Y184 (KV-32XBR450/36XBR450/36XBR450H ONLY)
Two Size AA (R6) Batteries
Optional Assessories
Connecting cables: RK-74A, VMC-810S/820/830HGS, VMC-720M,
VMC-810S/820S, YC-15V/30V, YC-15/30HG, RKG69HG, RKC-515HG
U/V mixer: EAC-66
TV Stand: SU-32HS2 (KV-32HS20 ONLY)
SU-36HS2 (KV-36HS20/36HS20H ONLY)
SU-32XBR45 (KV-32XBR450 ONLY)
SU-36XBR45 (KV-36XBR450/36XBR450H ONLY)
SPECIFICATIONS
SRS (SOUND RETRIEVAL SYSTEM)
The SRS (SOUND RETRIEVAL SYSTEM) is manufactured by
Sony Corporation under license from SRS Labs, Inc. It is covered
by U.S. Patent No. 4,748,669. Other U.S. and foreign patents
pending.
The word ‘SRS’and the SRS symbol are registered trade-
marks of SRS Labs, Inc. BBE and BBE symbol are trademarks of
BBE Sound, Inc. and are licensed by BBE Sound, Inc. under U.S.
Patent No. 4,638,258 and 4,482,866.
Design and specifications are subject to change without notice.
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
3) Y: 1.0 Vp-p, 75 ohms, sync negative;
PB: 0.7 Vp-p, 75 ohms
PR: Vp-p, 75 ohms
4) 500 m Vrms (100% modulation), Impedance: 47 kilohms
5) More than 408 mVrms at the maximum volume setting (variable)
More than 408 mVrms (fix)
KV-36HS20
KV-36HS20H
KV-32HS20 KV-36XBR450
KV-32XBR450 KV-36XBR450H
120V, 60Hz
4
3
2
6
2
1
YES
7.5W x 4
245W
2W
898 x 678 x 579.5 mm 994 x 754.5 x 622 mm
35
3/8
x 26
3/4
x 27
7/8
in 39
9/64
x 29
45/64
x 24
1/2
in
84 kg 108 kg
185 lbs. 238 lbs.
Power Requirements
Number of Inputs/Outputs
Video
1)
S Video
2)
Y, PB, PR
3)
Audio
4)
Audio Out
5)
Monitor Out
Control-S (in/out)
Speaker Output (W)
Power Consumption (W)
In Use (Max)
In Standby
Dimensions (W x H x D)
mm
in
Mass
kg
lbs
TruSurround™
by SRS ®

—4 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
WARNINGS AND CAUTIONS
CAUTION
Short circuit the anode of the picture tube and the anode cap to the metal chassis, crt shield, or carbon painted on the crt, after
removing the anode.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of
this receiver is directly connected to the ac power line.
! SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for
safe operation. Replace these components with sony parts whose part numbers appear as shown in this manual or in supplements
published by sony. Circuit adjustments that are critical for safe operation are identified in this manual. Follow these procedures
whenever critical components are replaced or improper operation is suspected.
ATTENTION!!
Apres avoir deconnecte le cap de l’anode, court-circuiter l’anode du tube cathodique et celui de l’anode du cap au chassis metallique
de l’appareil, ou la couche de carbone peinte sur le tube cathodique ou au blindage du tube cathodique.
Afin d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisélors de tout
dépannage. Le chássis de ce récepteur est directement raccordéàl’alimentation du secteur.
! ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de
pieces sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants sony dont
le numero de piece est indique dans le present manuel ou dans des supplements publies par sony. Les reglages de circuit dont
l’importance est critique pour la securite du fonctionnement sont identifies dans le present manuel. Suivre ces procedures lors de
chaque remplacement de composants critiques, ou lorsqu’un mauvais fonctionnement suspecte.

—5 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
To Exposed Metal
Parts on Set
0.15 µF
Earth Ground
AC
Voltmeter
(0.75V)
1.5 k
Trouble Light
AC Outlet Box Ohmmeter
Cold Water Pipe
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the B+ and HV to see if they are specified values. Make sure
your instruments are accurate; be suspicious of your HV meter if sets
always have low HV.
8. Check the antenna terminals, metal trim, “metallized”knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage
as described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and from
all exposed metal parts to any exposed metal part having a return to
chassis, must not exceed 0.5 mA (500 microamperes). Leakage current
can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers’instructions to use these
instructions.
2. A battery-operated AC milliammeter. The Data Precision 245 digital
multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit”indication is 0.75 V,
so analog meters must have an accurate low voltage scale. The
Simpson’s 250 and Sanwa SH-63TRD are examples of passive
VOMs that are suitable. Nearly all battery-operated digital multimeters
that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining
screw on most AC outlet boxes is also at earth ground. If the retaining
screw is to be used as your earth ground, verify that it is at ground
by measuring the resistance between it and a cold-water pipe with an
ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble-
light (not a neon lamp) between the hot side of the receptacle and the
retaining screw. Try both slots, if necessary, to locate the hot side on the
line; the lamp should light at normal brilliance if the screw is at ground
potential (see Figure B).
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

—6 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
SELF-DIAGNOSTIC FUNCTION
Display of Standby/Timer LED Flash Count
Diagnostic items Flash count
Lamp OFF 3 sec.
Lamp ON 0.3 sec.
Lamp OFF 0.3 sec.
Standby/Timer LED
+B overcurrent 2 times
+B/Low B overvoltage 3 times
Vert. deflection stopped 4 times
White balance failure 5 times
Low B error 6 times
Horiz. deflection stopped 7 times
Stopping the Standby/Timer LED Flash
Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER LAMP from flashing.
Self-Diagnostic Screen Display
For errors with symptoms such as “power sometimes shuts off”or “screen sometimes goes out”that cannot be confirmed, it is possible to bring up
past occurrences of failure on the screen for confirmation.
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/STEREO LED will automatically begin to flash. The number
of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY/STEREO LED flash indicators is listed in the
instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review
the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
Diagnostic Test Indicators
When an error occurs, the STANDBY/STEREO LED will flash a set number of times to indicate the possible cause of the problem. If there is more
than one error, the LED will identify the first of the problem areas.
Results for all of the following diagnostic items are displayed on screen. If the screen displays a “0”, and error has occurred.
No. of times STANDBY/
Diagnostic Item STEREO lamp flashes Display Result Probable Cause Location Detected Symptoms
Power does not turn on Does not light •Power cord is not plugged in. •Power does not come on.
•Fuse is burned out (F5501) •No power is supplied to the TV.
•AC power supply is faulty.
+B overcurrent (OCP) 2 times 2:0 or 2:1 •H.OUT (Q5030) is shorted. (D Board) •Power does not come on.
(see Note 1) •+B PWM (Q5003) is shorted (D Board) •Load on power line is shorted.
•IC9001, IC9002, IC9003 is shorted (C Board)
Low B overvoltage (OVP) 3 times 3:0 or 3:1 •IC6505 is faulty. (D Board) •Has entered standby mode.
Vertical deflection stopped 4 times 4:0 or 4:1 •± 15V is not supplied. (D Board) •Has entered standby state after
•IC5004 is faulty. (D Board) horizontal raster.
•Vertical deflection pulse is stopped.
•Power line is shorted or power
supply is stopped.
White balance failure 5 times 5:0 or 5:1 •Video OUT (IC9001-IC9003) is faulty. •No raster is generated.
(not balanced) (C Board) •CRT cathode current detection
•CRT drive (IC201) is faulty. (A Board) reference pulse output is small.
•G2 is improperly adjusted. (see Note 2)
LOW B OCP/OVP 6 times 6:0 or 6:1 •+5 line is overloaded. (A, B Boards) •No picture
(overcurrent/overvoltage) •+5 line is shorted. (A, B Boards)
(see Note 3) •IC6007 is faulty. (A Board)
Horizontal Deflection stopped 7 times 7:0 or 7:1 •No picture
Note 1: If a +B overcurrent is detected, stoppage of the vertical deflection is detected simultaneously. The symptom that is diagnosed first by the microcontroller is displayed on screen.
Note 2: Refer to Screen (G2) Adjustment in Section 3-4 of this manual.
Note 3: If STANDBY/STEREO LED flashes six (6) times, unplug the unit and wait 10 seconds before performing the adjustment
Self Diagnosis
Supported model
* One flash count is not used for self-
diagnostic.

—7 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
Handling of Self-Diagnostic Screen Display
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen during repairs. When you
have completed the repairs, clear the result display to “0”.
Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after completion of the repairs.
Clearing the Result Display
To clear the result display to “0”, press buttons on the Remote Commander sequentially when the diagnostic screen is displayed, as shown below:
ENTERChannel 8
Quitting the Self-Diagnostic Screen
To quit the entire self-diagnostic screen, turn off the power switch on the Remote Commander or the main unit.
Self-Diagnostic Circuit
+B overcurrent (OCP)
Occurs when an overcurrent (more
than 6A) on the +B (135V) line is
detected by R6598/R6591. It will cause
Q6520 to turn on and force the AC
relay to turn off through Q6532 and
Q6530.
+B overvoltage (OVP)
Occurs when 1) overvoltage (more
than +140V) on the +B (135V) line
is detected by IC6505, or 2) an
overvoltage (more than 7.5 V) on the
unreg 7V line is detected by D6014.
The AC relay will turn off through
Q6532 and Q6530.
Vertical Deflection Stopped
Occurs when an absence of the vertical
deflection pulse is detected by IC201.
Power supply will shut down when
waveform interval exceeds 2 seconds.
White Balance Failure
If the RGB levels* do not balance within 2 seconds after the power is turned on, this error will be detected by IC201. TV will stay on, but there
will be no picture.
*(Refers to the RGB levels of the AKB detection Ref pulse that detects 1K).
Low B Error
Occurs when set 5V is out.
Horizontal Deflection Stopped
Occurs when either: 1) a +B overcurrent is detected (IC5007), or 2) overheating is detected (Thermistor TH5002).
Numeral “0”means that no fault
was detected.
Numeral “1”means a fault was detected
one time only.
SELF DIAGNOSIS
2: +B OCP N/A
3: +B OVP N/A
4: VSTOP 0
5: AKB 1
101: WDT 24
To Bring Up Screen Test
In standby mode, press buttons on the Remote Commander sequentially,
in rapid succession, as shown below:
DISPLAY Channel 5Sound volume -Power ON.
AKB
VPROT
HPROT
SCL
SDA
IC701
MAIN UCOM
STBY LED
HA
STR
STBY-LED
OCP
OVP
LOW B ERR AC RLY
CLKO
DATO
29
30
69
43
45
44
48
Q6532
Q6530
D6537
D6501
Q6527
RY6501
SET ON
200V OCP
+B OCP
OVP
D8027
D8003
0
0
I
UNREG 7V
D6014
D6018
SET 5V
A
A
26
25
58
35
34
CRT
VDY -
R5125
R5104 R5105
IC5007
214
Q5018
I5V
2
1
3
A
OVP
D
Q652
STBY 5V
Q6524
Q6521
IC6505
+B OVP
+B
Q6520
IC6007
IC201
Y/C JUNGLE

—8 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
1-1. REAR COVER REMOVAL
1-2. CHASSIS ASSEMBLY REMOVAL 1-3. SERVICE POSITION
SECTION 1: DISASSEMBLY
21
1
1CAUTION! - Heat sink on IC5004 is -15V. Care must be
taken not to allow heat sink to touch any other components.
2Lift lever up on the right and left sides of the chassis bracket
and gently pull the chassis assembly away from the bezel.
Remove +BVTP 4 x 16 screws from
areas indicated with a circle.
Located in:
KV-36HS20/36HS20H/
36XBR450/36XBR450H Only
1Pull up and rotate both the A and D boards in order to
service the unit.

—9 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
1Discharge the anode of the CRT and remove the
anode cap.
2Unplug all interconnecting leads from the deflection
yoke, neck assembly, degaussing coils and CRT
grounding strap.
3Remove the Speaker Assemblies.
4Remove the C Board from the CRT.
5Remove the chassis assembly.
6Loosen the neck assembly fixing screw and remove.
7Loosen the deflection yoke fixing screw and remove.
8Place the set with the CRT face down on a cushion
and remove the degaussing coil holders.
9Remove the degaussing coils.
10 Remove the CRT grounding strap and spring tension
devices.
11 Unscrew the four CRT fixing screws [located on each
CRT corner] and remove the CRT [Take care not to
handle the CRT by the neck].
1-4. PICTURE TUBE REMOVAL
WARNING: BEFORE REMOVING THE ANODE CAP
High voltage remains in the CRT even after the power is disconnected. To avoid electric shock,
discharge CRT before attempting to remove the anode cap. Short between anode and CRT
coated earth ground strap.
Coated
Earth
Ground
Strap
ANODE CAP REMOVAL PROCEDURE
WARNING: High voltage remains in the CRT even after the power is disconnected. To avoid electric shock, discharge CRT before attempting to remove
the anode cap. After removing the anode cap, short circuit to either the metal chassis, CRT shield, or carbon painted on the CRT.
REMOVAL PROCEDURES
a
b
Anode Button
c
Turn up one side of the rubber cap
inthe direction indicated by arrow a.
Use your thumb to pull the rubber
cap firmly in the direction indicated
by arrow b.
When one side of the rubber cap separates from
the anode button, the anode cap can be removed
by turning the rubber cap and pulling it in the
direction of arrow c.
HOW TO HANDLE AN ANODE CAP
1. Do not use sharp objects which may cause damage to the surface of the
anode cap.
2. To avoid damaging the anode cap, do not squeeze the rubber covering too
hard. A material fitting called a shatter-hook terminalis built into the rubber.
3. Do not force turn the foot of the rubber cover. This may cause the shatter-hook
terminal to protrude and damage the rubber.
2
13
4
5
6
7
8
9
10
11

—10 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
The following adjustments should be made when a complete
realignment is required or a new picture tube is installed.
These adjustments should be performed with rated power supply
voltage unless otherwise noted.
The controls and switch should be set as follows unless otherwise
noted:
VIDEO MODE: STANDARD (RESET)
SECTION 2: SET-UP ADJUSTMENTS
Perform the adjustments in order as follows:
1. Beam Landing
2. Convergence
3. Focus
4. Screen (G2)
5. White Balance
Test Equipment Required:
1. Color Bar Pattern Generator
2. Degausser
3. DC Power Supply
4. Digital Multimeter
2-1. BEAM LANDING
Preparation:
•Input a white pattern signal.
•Face the picture tube in an East or West direction to reduce the
influence of geomagnetism.
NOTE: Do not use the hand degausser; it magnetizes the CRT .
1. Input white pattern from pattern generator. Set the PICTURE control
to maximum, and the BRIGTNESS control to standard.
2. Perform Focus, G2 and White Balance adjustments.
3. Loosen the deflection yoke mounting screw, and set the purity control
to the center as shown below:
Purity Control
4. Input a green pattern from the pattern generator.
5. Move the deflection yoke backwards, and adjust with the purity
control so that green is in the center and red and blue are even on
both sides.
Blue Red
Green
6. Move the deflection yoke forward, and adjust so that the entire screen
becomes green.
7. Switch over the raster signal to red and blue and confirm the
condition.
8. When the position of the deflection yoke is determined, tighten it with
the deflection yoke mounting screw.
9. If landing at the corner is not right, adjust it by using the disk magnets.
Purity control
corrects this area
Deflection yoke positioning
corrects these areas
Disk magnets
or rotatable disk
magnets correct
thses areas (a-d)
b
d
a
c

—11 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
2-2. V-PIN AND V-CEN ADJUSTMENT
Preparation:
•Input a cross hatch pattern signal.
•Face the picture tube in a North/South direction and correct rotation.
•Set Video Mode to: Satndard (Reset)
1. Adjust service mode CXA2150D-1 04 VCEN so that the top pin and
and bottom pin are symmetrical from top to bottom.
2. Adjust service mode CXA2150D-1 05 VPIN so that the top pin and
and bottom pin are symmetrical from top to bottom.
3. Lines should be straight from left to right. Check landing for side
effect.
2-3. CONVERGENGE
Preparation:
•Set the CONTRAST and BRIGHTNESS control to 50%
•Input dot pattern signal.
2-3.1. VERTICAL AND HORIZONTAL STATIC
CONVERGENCE
1. Disconnect the dynamic convergence before adjusting static
convergence (CN5510), except for minor touch-up.
2. Adjust H.STAT convergence, RV9001, to converge red, green, and
blue dots in the center of the screen.
3. Adjust V. STAT magnet to converge red, green and blue dots in the
center of the screen.
R
G
B
Center dot
RV9001
H.STAT
V.STAT magnet
R G B
4. Tilt the V. STAT magnet and adjust static convergence to open or
close the V. STAT magnet.
B
G
R
B
G
R
1
2-3.2. OPERATION OF BMC (HEXAPOLE)
MAGNET
The respective dot positions resulting from moving each magnet interact.
So, perform the following adjustments while tracking.
1. Use the V.STAT tabs to adjust the red, green and blue dots so that
they line up at the center of the screen (move the dots in a horizontal
direction).
HMC Correction HMC Correction
RGB
A=B
AB
RGB
A>B
AB
RGB
A=B
AB
R
GB
A<B
AB
VMC Correction
R
G
B
C<D
C
D
R
G
B
C=D
VMC Correction
R
G
B
C<D
C
D
R
G
B
C=D
2-3.3. TLH PLATE ADJUSTMENT
Preparation:
•Input a cross hatch pattern signal.
•Adjust unbalanced horizontal convergence of red and blue dots by
adjusting the TLH plate on the deflection yoke.
TLH Plate
RV9002
RV9001
W Board
C Board
TLV
XCV
TLH+
TLH-
R B
(B)(R)
B R
(R)(B)
1. Adjust XCV core to balance X axis.
2. Adjust the vertical red and blue convergence with V.TILT (TLV VR).
Note: Perform adjustments while tracking item 1.

—12 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
2-3.4. SCREEN-CORNER CONVERGENCE
Preparation:
•Input a cross hatch pattern signal.
1. Affix a permalloy assembly corresponding to the misconverged areas:
dc
a
b
a-d: screen-corner
misconvergence
ab
cd
2-3.5. DYNAMIC CONVERGENCE
ADJUSTMENTS
Set dynamic convergence using the following service mode adjustment
data:
NO. Register Function Data Length Initial Data
1 YBWU VCA9 0-63 31
2 YBWL VCA10 0-63 31
3 RSAP DC-AMP1 0-63 31
4 RUBW VCA5 0-63 31
5 RLBW VCA6 0-63 31
6 LSAP DC-AMP2 0-63 31
7 LUBW VCA10 0-63 31
8 LLBW VCA2 0-63 31
CXA 8070 AP
1. YBWU (Upper Y-BOW)
BR BR
2. YBWL (Bottom BOW)
BR BR
3. RSAP (Right AMP)
RB
4. RUBW (Right Side Upper C-BOW)
BR
5. RLBW (Right Side Bottom C-BOW)
RB
6. LSAP (Left AMP)
BR
7. LUBW (Left Side Upper C-BOW)
BR
8. LLBW (Left Side Bottom C-BOW)
BR
2-4. FOCUS ADJUSTMENT
1. Input monoscope signal.
2. Set video mode to STANDARD.
3. Adjust focus VR counter-clockwise to confirm that the dot’s shape is
centered.
4. Confirm center focus with focus VR.
FOCUS
2-5. SCREEN (G2)
1. Input a monoscope pattern (NTSC)
2. Set to service mode and adjust as follows:
CXA 21 0P-2
NO. Disp. Item Avg.
0 ALBK ALL_BLK 0
3. Adjust RV9002 on the C Board so that the voltage on red, green and
blue cathodes is 170.0 0.5 V DC.
4. Adjust the hotizontal line at the top of the screen so it is cut off.
Note: Never set ALBK to 1 when external power supply is connected
to cathode.

—13 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
2-6. PICTURE QUALITY ADJUSTMENTS
Preparation:
•Set PRO MODE (Picture: MAX, GAMMA: 0)
•Dynamic-color: Off (=Trinitron: MID).
•Set the service mode to the following:
NO. Name Control Function Avg. Data
06 UDCL Dynami Color: OFF 0
08 UGRAM GRAMM
A
0
15 DCT
R
DC-TRAN 0
16 DPIC DYNAMIC PIC: OFF 0
C21 0P-4
1. Input signal (480i):
•Color Bar Video 75IRE (White) 75% modulation 7.5% Set-up
•Color Bar RF 75IRE (White) 75% modulation 7.5% Set-up
2-6.1. VIDEO INPUT - TWO PICTURE SUB
CONTRAST ADJUSTMENT
Preparation:
•Input a Color Bar signal to VIDEO 1 (75 IRE 75%).
•Set picture mode: P&P (PRO MODE).
1. Set to service mode and adjust as follows:
NO. Name Control Function Avg. Data
00 UPIC PICTURE 63
02 UCOL COLOR 0
NO. Name Control Function Avg. Data
01 RGBS R ON 4
21 0P-4
21 0P-2
INITIAL DATA (IMPORTANT)
NO. Name Control Function Avg. Data
23 SCON SUB-CONT 9
NO. Name Control Function Avg. Data
00 YLEV Y-OU
T
23
NO. Name Control Function Avg. Data
00 YLEV Y-OU
T
23
21 0P-4
2103-1
2103-2
2. Connect oscilloscope to Pin 1 of CN9001 (R.DRV) on the C Board
3. Adjust MAIN (left) side contrast according to service mode fro SCON.
NO. Name Control Function
02 SCON SUB-CONT
2103-1
4. Adjust SUB (right) side contrast according to service mode for SCON.
NO. Name Control Function
02 SCON SUB-CONT
2103-2
white
black
GND
VR2
VR1
32”: VR1-VR2 = VR = 1.92 ± 0.05 Vp-p
36”: VR1-VR2 = VR = 2.00 ± 0.05 Vp-p
5. Write data from steps 3 and 4 above, into memory.
2-6.2. VIDEO INPUT - SUB HUE/SUB COLOR
ADJUSTMENT
Preparation:
•Input a Color Bar signal to VIDEO 1 (75 IRE 75%).
•Set picture mode: P&P (PRO MODE).
1. Set to service mode and adjust as follows:
NO. Name Control Function Avg. Data
00 UPIC PICTURE 63
02 UCOL COLOR 31
NO. Name Control Function Avg. Data
01 RGBS R ON 7
21 0P-4
21 0P-2
2. Connect an oscilloscope to pin 5 of CN9001 (B. DRV) on the C Board.
3. Adjust MAIN (left) side color according to service mode for SCOL.
4. Adjust MAIN (left) side color according to service mode for SHUE.
NO. Name Control Function
03 SCOL SUB-COL
04 SHUE SUB-HUE
2103-1
5. Adjust SUB (right) side color according to service mode for SCOL.
6. Adjust SUB (right) side color according to service mode for SHUE.
NO. Name Control Function
03 SCOL SUB-COL
04 SHUE SUB-HUE
2103-2
VB4
VB3VB2VB1
COLOR: VB1 < VB4 (=VB1 + 0~90 MV)
HUE: VB2 < VB3 (=VB2 + 0~90 MV)
(HUE: Adjust data - 2 STEP)
7. Write data into memory.

—14 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
2-6.3. RF INPUT - TWO PICTURE SUB
CONTRAST ADJUSTMENT
Preparation:
•Input a Color Bar signal to RF (75 IRE 75%).
•Set picture mode: P&P (PRO MODE).
1. Set to service mode and adjust as follows:
NO. Name Control Function Avg. Data
00 UPIC PICTURE 63
02 UCOL COLOR 0
NO. Name Control Function Avg. Data
01 RGBS R ON 4
21 0P-4
21 0P-2
INITIAL DATA (IMPORTANT)
NO. Name Control Function Avg. Data
23 SCON SUB-CONT 9
NO. Name Control Function Avg. Data
00 YLEV Y-OU
T
23
NO. Name Control Function Avg. Data
00 YLEV Y-OU
T
23
21 0P-4
2103-1
2103-2
Note: Use the same average data as 2-6.1, items 3 and 4 after the
adjustment
2. Connect an oscilloscope to pin 1 of CN9001 (R. DRV) on the C
Board.
3. Adjust MAIN (left) side contrast according to service mode fro SCON.
NO. Name Control Function
02 SCON SUB-CONT
2103-1
4. Adjust SUB (right) side contrast according to service mode for SCON.
NO. Name Control Function
02 SCON SUB-CONT
2103-2
white
black
GND
VR2
VR1
32”: VR1-VR2 = VR = 1.92 ± 0.05 Vp-p
36”: VR1-VR2 = VR = 2.00 ± 0.05 Vp-p
5. Write data from steps 3 and 4 above, into memory.
2-6.4. RF INPUT - SUB HUE/SUB COLOR
ADJUSTMENT
Preparation:
•Input a Color Bar signal to RF (75 IRE 75%).
•Set picture mode: P&P (PRO MODE).
1. Set to service mode and adjust as follows:
NO. Name Control Function Avg. Data
00 UPIC PICTURE 63
02 UCOL COLOR 31
NO. Name Control Function Avg. Data
01 RGBS R ON 7
21 0P-4
21 0P-4
INITIAL DATA (IMPORTANT)
NO. Name Control Function Avg. Data
24 CLOF OFFSET for UCOL 8
25 HUOF OFFSET for UHUE 4
NO. Name Control Function Avg. Data
01 CLEV CB & CR-OUT 17
20 CBOF CB-OFFSET 31
21 CROF CR-OFFSET 31
NO. Name Control Function Avg. Data
01 CLEV CB & CR-OUT 17
20 CBOF CB-OFFSET 31
21 CROF CR-OFFSET 31
21 0P-4
2103-1
2103-2
Note: Use the same average data as 2-6.2, items 3-6 after the
adjustment.
2. Connect an oscilloscope to pin 5 of CN9001 (B. DRV) on the C Board.
3. Adjust MAIN (left) side color according to service mode for SCOL.
4. Adjust MAIN (left) side color according to service mode for SHUE.
NO. Name Control Function
03 SCOL SUB COLOR
04 SHUE SUB HUE
2103-1
5. Adjust SUB (right) side color according to service mode for SCOL.
6. Adjust SUB (right) side color according to service mode for SHUE.
NO. Name Control Function
03 SCOL SUB COLOR
04 SHUE SUB HUE
2103-2
VB4
VB3VB2VB1

—15 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
COLOR: VB1 < VB4 (=VB1 + 0~90 MV)
HUE: VB2 < VB3 (=VB2 + 0~90 MV)
(HUE: Adjust data - 2 STEP)
7. Write data into memory.
2-7. WHITE BALANCE (CRT) AND SUB
BRIGHT ADJUSTMENT
Preparation
•Input an all white 480I (15.734 KHz) signal into the VIDEO 1 input
terminal to perform the whit balance (highlight, cut-off) adjustments.
The parameters to adjust are in the CXA2150P in service mode.
1. Set the following:
Picture: Full Mode
Pro Mode
Color: Center
2. Adjust white balance in the service mode and set the following data:
NO. Name Control Function Avg. Data
05 RDRV R-DRIVE Fix: 41
06 GDRV G-DRIVE Adjust
07 BDRV B-DRIVE Adjust
08 RCUT R-CUT OFF Fix: 41
09 GCUT G-CUT OFF Adjust
10 BCUT B-CUT OFF Adjust
21 0P-1
3. Adjust sub brightness: Input an all black signal (to IRE 7.5% set up)
480i (15.75 KHz) signal into the VIDEO 1 input terminal and adjust the
following parameter of CXA2150P-1:
NO. Name Control Function Avg. Data
04 SBRT SUB-BRIGHT Adjust
CXA21 0P-1
INITIAL DATA (IMPORTANT)
NO. Name Control Function Avg. Data
00 SBOT SUB-BRT OFFSET 7
12 SBOF SUB-BRT OFFSE
T
63
21 0P-1
4. Repeat steps 2-3.
2-8. RASTER CENTER ADJUSTMENT
Preparation:
•Input a monoscope signal.
•Set to NTSC (DRC) mode.
1. Set to service mode and adjsut as follows:
NO. Name Control Function Avg. Data
06 AGNG AGING 1, AGING 2 2
NO. Name Control Function Avg. Data
02 HSIZ Horiz Size 31
NO. Name Control Function Avg. Data
00 HBLK Blankin
g
Enable 0
CXA21 0P-2
CXA21 0P-2
CXA21 0P-3
2. Reduce HSIZ to see sides of raster.
3. Adjust H-Center with CXA2150D-2 00.
4. Adjust to the best screen position with H-CENT and write data.
5. Resotore aging, HSIZ and HBLK to original condition.
2-9. PICTURE DISTORTION ADJUSTMENTS
2-9.1. NTSC (DRC) FULL MODE
ADJUSTMENT
1. Face the picture tube in an east-west direction.
2. Complete VPIN and VCEN adjsuments first (A2150-D1 o5 VPIN,
A2150-D1 04 VCEN)
3. Input a monoscope and crosshatch signal. Adjust the picture
distortion with the following service parameters to balance the best
condition for these two signals.
A
2150-D1 00 VPOS
A
2150-D1 01 VSIZ
A
2150-D1 02 VLIN
A
2150-D1 03 VSCO
A
2150-D1 04 SCEN
A
2150-D1 05 VPIN
A
2150-D1 06 HTPZ
A
2150-D2 01 HPOS
A
2150-D2 02 HSIZ
A
2150-D2 03 SLIN
A
2150-D2 04 PIN
A
2150-D2 05 UCP
A
2150-D2 06 LCP
A
2150-D2 07 PPH
A
A
2150-D2 08 VANG
A
2150-D2 09 LANG
A
2150-D2 10 VBOW
A
2150-D2 11 LBOW
Note: Make sure that the picture size is within specs. Vertical size is
11.8 sq. and horizontal size is 15.8 sq.
4. Write data into memory and then set the screen to 1080i mode.

—16 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
CXA2150D-1
0. VPOS (V-POSITION)
1. VSIZ (V-SIZE)
2. VLIN (V-LINE)
3. VSCO (VS-COR)
7. HTPZ (H-TRAPEZOID)
CXA2150D-2
1. HPOS (H-POSITION)
2. HSIZ (H-SIZE)
5. PIN (PIN AMP)
6. UCP (UP COR PIN COR)
7. LCP (LOW CO PIN COR)
13.PPHA (PIN PHASE)
14.VANG (AFC-ANGLE)
15.LANG (L-ANGLE)
16.VBOW (AFC-BOW)
17.LBOW (L-BOW)
2-9.2. 1080i HD MODE ADJUSTMENT
1. Input a 1080i cross-hatch signaland an HD monoscope signal that
contains overscan markers.
2. Adjust the raster position per section 3-8, only if this procedure was
not performed for full mode.
3. Adjust the geometry similar to Fill DRC mode. Vertical size is 11.8
sq. and horizontal size is 15.8 sq., if monoscope signal is available.
Otherwise, set the vertical size to 91.5% scan and horizontal size
as 90% scan.
4. Use the following register to adjust the horizontal parameter:
A
2150-D2 01 HPOS
Note: If necessary, touch up the geometry using the data register
listed above for Full mode.
5. Write the data into memory.
2-9.3. VERTICAL COMPRESSES MODE
CHECK AND CONFIRMATION
1. Input a monoscope and crosshatch signal.
2. Check vertical compressed mode.

—17 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
SECTION 3: SAFETY RELATED ADJUSTMENTS
3-2. B+ MAX CONFIRMATION
Standard............................................................................ 135.3 ± 1 VCD
Check Condition:
AC input voltage: ........... 120 (± 2) VAC at Board Adjustment Process
................................................ 130 (± 2) VAC at QC
...120 (± 2) VAC at Overall Adjustment (after aging)
Note: If using a stabilized power supply, make sure that the distortion
factor is 3% or less.
Setting mode: ............................................................................ Full mode
Signal input:.................................................. Cross-hatch of NTSC at QC
Initial setting:...........................................................Reset condition at QC
Confirm point: ........................................ Across C6544 for B+ of D Board
3-1. XRV8001, RV8002 CONFIRMATION METHOD AND HV SERVICE ADJUSTMENTS
3-3. HV SERVICE FLOWCHART
Is RHT
Changed?
Is D-Board
Replaced?
Replace RV8001, RV8002 and RV8003 (Board provided with RV8003) with the
same value:
HV project adjust and inspection
1. Turn RV8001 and RV8003 (only applicable when RV8003 is used in the circuit)
fully counter-clockwise.
2. Turn set on with black video signal then adjust RV8002 slowly to obtain
35.5kV ± 0.2kV.
3. Case 1 (Board provided with RV8003):
- Turn RV8001 (coarse adjust) clockwise slowly until hold down operation
initially activates.
- Turn the set off and turn back RV8001 approximately 1/16 of a turn, then turn
the set back on.
- Turn RV8003 (fine adjust) slowly clockwise until hold down operation initially
activates.
Case 2 (Board NOT provided with RV8003):
- Turn RV8001 clockwise slowly until hold down operation initially activates.
5. Adjust RV8002 clockwise, then turn the set on. Change video to white field then
slowly turn RV8002 counter-clockwise to get 35.0 ± 0.2kv. Confirm set does
NOT TURN OFF at this condition. If yes, then repeat from step 1 again.
6. Finally, set back RV8002 to 31.50kv + 0.2kv at video cut off (black video).
Start
No
Ye s
Change any
or
marked parts
Ye s
No
Ye s
No
Ye s
Is +B, Vd and
hold down
confirmed?
Finish for
hold-down
check
Start from
the beginning.
Confirm +B, Vd and check hold-down on the D board video with no signal (standard
reset mode) as follows:
1. Confirm +B across C6544 to make sure that it is 135.3 ± 1 Vdc.
2. Confirm Vd at pin 2 CN5506 or at TP-Vd for 4.3V <Vd <4.65 Vdc.
3. Apply 5.5 ± 0.3 Vdc at pin 2 of CN5506, then confirm that set holds down.
If all adjustments are complete, then seal and secure RV8001, RV8002 and
RV8003 (boards using RV8003) with epoxy to prevent any possible
misadjustment by non-trained technical service.

— 18 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
4-1. SETTING THE SERVICE ADJUSTMENT
MODE
1. Standby mode (Power off).
2. Press the following buttons on the remote commander within one
second of each other:
DISPLAY Channel 5Sound Volume +Power
SERVICE ADJUSTMENT MODE VIEW
2150P-1 0 +7 SERVICE
SBOT TV
Device Item Data Item
Register
Item
F/A FLAG:
CBA FLAG:
WSL: 0
READING THE MEMORY
1. Enter into service mode.
2. Press 0on the remote commander.
3. Press ENTER to read memory.
ADJUSTING THE PICTURE
1. Enter into service mode
2. Press 2or 5on the remote to select the device item.
3. Press 1or 4on the remote to select an item.
4. Press 3or 6on the remote to change the data.
5. Press MUTING then ENTER to write into memory.
4-1.1 RESETTING THE DATA
Note: Be careful when using the remote! It will clear and re-initialize
ALL NVM data including deflection adjustment data if not reset
properly as follows:
RESETTING THE DEFLECTION NVM DATA
1. Enter into service mode.
2. Press 7, then MENU , and then press ENTER on the remote.
RESETTING THE SYSTEM NVM DATA
1. Enter into service mode.
2. Press 7, then 9, and then press ENTER on the remote.
RESETTING THE SYSTEM NVM DATA
1. Enter into service mode.
2. Press 8and then press ENTER on the remote.
4-2. MEMORY WRITE CONFIRMATION
METHOD
1. After adjustment, pull out the plug from the AC outlet, then replace the
plug in the AC outlet again.
2. Turn the power switch ON and set to Service Mode.
3. Call the adjusted items again to confirm they were adjusted.
4-3. REMOTE ADJUSTMENT BUTTONS AND
INDICATORS
RM-Y183
(KV-32HS20/36HS20/36HS20H ONLY)
WRITE
INTO MEMORY
ITEM UP
ITEM DOWN
TEST
RESET
DEVICE UP
DATA UP
DATA DOWN
DEVICE DOWN
EXECUTE
READ
MEMORY
SECTION 4: CIRCUIT ADJUSTMENTS
ELECTRICAL ADJUSTMENTS BY REMOTE COMMANDER
Use the Remote Commander (RM-Y183, RM-Y184) to perform the circuit adjustments in this section.
Test Equipment Required: 1. Pattern generator 2. Frequency counter 3. Digital multimeter 4. Audio oscillator

—19 —
KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
RM-Y184
(KV-32XBR450/36XBR450/36XBR450H ONLY)
WRITE
INTO MEMORY
ITEM UP
ITEM DOWN
TEST
RESET
DEVICE UP
DATA UP
DATA DOWN
DEVICE DOWN
EXECUTE
READ
MEMOR
Y

KV-32HS20/36HS20/36HS20H/32XBR450/36XBR450/36XBR450H
—20 —
SERVICE DATA LISTS
Device Name Device Reference
Number Slave Address Comment
# 1 3D-COMB mPD64082 IC3501 / BC-board B8h (W) & B9h (R) W&R: Write & Read
# 2-1 CXA2103-1 (Main) IC3048 (Main) / B-board 9Ah # 2-2 CXA2103-2 (Sub) IC3110 (Sub) / B-board 9Eh # 3-1 CXA21 0P-1 # 3-2 CXA21 0P-2 # 3-3 CXA21 0P-3 # 3-4 CXA21 0P-4 # 4-1 CXA21 0D-1 # 4-2 CXA21 0D-2 # 4-3 CXA21 0D-3
# 5 CXA21 1 CXA2151Q IC3001 / B-board 84h # 6 D-CONV CXA8070P IC5513 / D-board DEh # 7 CXA2026 CXA2026AS IC5511 / D-board 8Eh # 8 AP BH3868AFS IC7001 / A-board 82h # 9 TRUS NJM2180M IC4101 / S-board 2Eh Controlled through CXA1315M ( IC4103 / S-board / 48h )
# 10 MID1 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Mi ro ( IC3090 / B-board / 64h ) # 11 MID2 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Mi ro ( IC3090 / B-board / 64h ) # 12 MID3 CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Mi ro ( IC3090 / B-board / 64h ) # 13 MID CXD9509AQ IC3408 / B-board 2Eh Controlled through MID-XA Mi ro ( IC3090 / B-board / 64h ) # 14 OSD M306V2ME-153FP IC701 / A-board 60h DX1A-2001 S
y
stem Mi ro
{
V1.0
}
mPD64082 IC3501 / BC-board B8h (W) & B9h (R)
CXA2103Q IC3048 (Main) / B-board 9Ah CXA2150Q IC201 / A-board 86h
# 16 ID1 CXD2085M IC3603 / B-board 40h
IC3602 (Main) / B-board 68h (Main)
IC3601 (Sub) / B-board 6Ch (Sub)
# 18 OP M306V2ME-153FP IC701 / A-board 60h DX1A-2001 S
y
stem Mi ro
{
V1.0
}
# 19 ID M306V2ME-153FP IC701 / A-board 60h DX1A-2001 S
y
stem Mi ro
{
V1.0
}
DX1A-2001 System Micro & Notes for Services DX1A-2001 MID-XA Micro
M306V2ME-153FP (MASK), Software Version 1.0, IC701/A-board (Slave Adress: 60h) The system mi ro name, software&pat h versions, and the status of NVM devi es are displayed only when in the servi e atergory
DX1A-2001 CCD&Vchip Micro
s
MB94918RPF-G-137-BND (MASK), Software Version 12/08/00, IC3090/B-board (Slave Address: 64h) CXP85840A-039Q (MASK), Software Version 2.14, IC3602/B-board (Main/Slave Address: 68h) & IC3601/B-board (Sub/Slave Address: 6
Note: * This service list is used for DX1A-2001 ONLY. Some service data is the same in DX1A-2001 & 2000, as noted in the data sheets.
# 17 CCD&VCHIP CCD&V hip Mi ro (V2.14)
DX1A-2001* Service List ------ Contents & Notes
Category Number & Name
# 15
CXA2103Q
CXA2150AQ 86h
CXP85840A-039Q
SNNR
CXA2150AQ
IC201 / A-board IC201 / A-board 86h
