TCM-200DV
Standard Cassette Voice Recorder
Step - up
Double Recording Time
Voice Operated Recording
External Microphone Jack
Playback Speed Control
25 Hour Battery Life
1
Built - In Microphone
LED Battery Level Indicator
Clear Voice ™Recording System
Large Playback Speaker for Improved Sound
Automatic Shut -Off at End of Tape
One Touch Record From Playback
Sony - Matic ® Automatic Recording Level Control
L/R Monaural Earphone Jack
Cue and Review Function
Pause Switch
Stop/Pause Release Function
DC- In Jack
Power Requirements 2 "AA" Batteries
Includes Hand Strap

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 05/20/2010
TCM-200DV
Standard Cassette Voice Recorder
Please visit the Dealer Source for current information at
www.sony.com/dealersource
Features
Double Recording Time Gives you the option of recording on a
standard cassette at either normal speed or half the normal
speed, for extended recording or dictation sessions.
Voice Operated Recording Activates the recorder only when
audible sound is present, conserving tape and eliminating
soundless passages.
External Microphone Jack Allows connection of an external
microphone for special recording applications.
Playback Speed Control Lets you adjust playing speed as
much as +30% or - 15% for easier review of recorded
information.
25 Hour Battery Life Is made possible by advanced
technology which extends battery power beyond previous
limits.
1
Built - In Microphone For extra convenience eliminates the
need for an external microphone in many situations.
LED Battery Level Indicator Provides visible indication of
battery power remaining.
Clear Voice™Recording System Sound system enhances
voice quality during recording and playback for greater clarity.
Large Playback Speaker for Improved Sound Lets you and
others hear playback without an earphone.
Automatic Shut - Off at End of Tape Helps reduce mechanical
wear, reduces battery consumption, and lets you know when
you have reached the end of the tape.
One Touch Record From Playback For simplified quick
play/record operation.
Sony - Matic ® Automatic Recording Level Control Uses
advanced circuitry to ensure correct recording level.
L/R Monaural Earphone Jack Provide sound in both ears when
using an optional stereo headset.
Cue and Review Function Provides sound during fast forward
and rewind modes to help find specific passages.
Pause Switch Temporarily halts recording or playback without
leaving that mode, and resumes at the flick of a button.
Stop/Pause Release Function Automatically turns off the
pause switch whenever the stop button is pressed, to prevent
loss of recording.
DC - In Jack Permits two - way power operation, using available
replaceable batteries or optional AC power adapter.
Power Requirements 2 "AA" Batteries
Includes Hand Strap Provides a secure, convenient band to
hold onto or carry the unit.
Specifications
General
Type of Use: Desktop Voice Recorder
RecordingMedia: Standard Audio Cassette
Recording and Playback Times: up to 180 minutes (mono)
Audio
RecordingSystem: 2 - Track, 1 - Channel Standard Cassette
Microphone: Built - in
FrequencyRange: 250 - 6300Hz
TapeSpeed: 2 Speeds (4.8cm/s, 2.4cm/sec)
Audio Features
RecordingFeatures: Voice Operated Recording (VOR), Clear
Voice ™Sound System, One - Touch Record, Sony - Matic ®
Automatic Recording Level
Convenience
Automatic Shut - off: Yes
Convenience Features
SearchFeatures: Cue and Review
Hardware
Display: N/A
Power
OutputPower: 350mW
PowerRequirements: 120V AC Adaptor (Optional)
BatteryType: "AA" x 2
Battery Life (Approx): Rec/Play: 25 Hours Continuous Recording
w/Sony Alkaline Batteries (optional)
Speaker
Type: Built - in
SpeakerDimensions: 2" (50mm) diameter
Inputs and Outputs
MicrophoneInput: 1
DC - In: 3V
HeadphoneOutput(s): 1 (Mini)
Dimensions
Weight: 6 oz (169 g)
Measurements: 3 3/8" x 4 1/2" x 1 3/8" (86.9 x 116.3 x 36.5mm)
Supplied Accessories
Hand Strap
Color: Silver
UPC Code: 027242607736
1.Actualbatterytimemayvaryuponusagepattern.
©2006SonyElectronicsInc.
Reproductioninwholeorinpart without written permission is prohibited. All rights reserved. Sony, Clear Voice,
Sony - Matic,and like.no.other are trademarks of Sony.
Features and specifications are subject to change without notice. Non - metricweightsandmeasuresare
approximate.
