Sota Bio-Tuner BT7 User manual

Instructions for SOTA Bio Tuner
Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 1 of 9 www.sota.com
CONTENTS
INTRODUCTION ....................................................................................................... 2
LEARN MORE ............................................................................................................ 2
COMPLETE UNIT INCLUDES................................................................................. 2
DO NOT USE............................................................................................................... 2
CAUTIONS .................................................................................................................. 3
SUMMARY OF LIGHTS ............................................................................................ 3
HOW TO USE THE BIO TUNER.............................................................................. 3
How it Should Feel................................................................................................. 6
Typical Use.............................................................................................................. 6
OUTPUT OF SIX MODES.......................................................................................... 7
ELECTRICAL SPECIFICATIONS ............................................................................ 7
Power Requirements.............................................................................................. 7
Optional Power Input............................................................................................ 8
Output Specications............................................................................................. 8
TROUBLESHOOTING............................................................................................... 8
COUNTRIES THAT PARTICIPATE IN MANUFACTURING............................ 8
REPLACEMENT ACCESSORIES............................................................................. 9
WARRANTY................................................................................................................ 9
REPAIRS....................................................................................................................... 9

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 2 of 9 www.sota.com
INTRODUCTION
Thank you for allowing us to be a part of your wellness team. The Bio Tuner is a
consumer product designed to complement a healthy lifestyle.
This unit outputs a broad range of harmonic frequencies in each pulse.
Please understand that results will vary. Healthy lifestyle choices are important.
Please read this manual carefully before using the Bio Tuner. The information in
this manual is subject to change. For the most up-to-date manual, please visit
www.sota.com. We encourage you to become well-informed about the use of
frequencies.
The SOTA Bio Tuner is built to give you many years of trouble-free use.
LEARN MORE
To learn more about the Bio Tuner we invite you
to visit the SOTA website:
www.sota.com
The website offers How to Videos, Frequently
Asked Questions, a Guide to Using the SOTA
Units, SOTA News ... and more.
COMPLETE UNIT INCLUDES
• One (1) Bio Tuner Unit
• One (1) Pair of Ear Clips
• One (1) Cord
• One (1) Arm Band with Clip
• One (1) 9-Volt Alkaline Battery
• One (1) Carrying Case
• One (1) Product Manual
DO NOT USE
1.Do not use in the following situations as safety has not been explored:
a. In the case of pregnancy, nursing or trying to get pregnant.
b. With an implanted device such as a pacemaker, shunt etc.
c. With seizures or psychotic conditions.

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 3 of 9 www.sota.com
d.With Neuropathy or other nerve-ending related issues.
2.Do not use if:
a. You experience headaches or pain when using the unit.
b. You are prone to tinnitus.
c. You experience a ringing in your ears when using the unit.
3.As with all electrical products do not use:
a. Near water
b. When driving a car
c. When operating heavy equipment
4.Do not:
a. Suddenly increase the intensity to the maximum level. The intensity level
should be increased gradually to a comfortable level to ensure safety.
CAUTIONS
1.If you are on psychiatric medication, please consult your health care provider
prior to using the Bio Tuner.
2. In very rare instances, individuals have reported the onset of tinnitus after using
the unit.
SUMMARY OF LIGHTS
GREEN: Indicates which Mode is selected.
RED: Indicates the battery is low and will soon need replacing.
YELLOW: Indicates the Bio Tuner is in operation and the current is owing through
the Ear Clips.
HOW TO USE THE BIO TUNER
1.Place the 9-Volt Alkaline battery in the unit.
a. On the back of the unit, slide off the
battery cover.
b. Position the 9-Volt Alkaline battery so the
positive (+) and negative (-) terminals line up as
in image 1.
Note: The smaller circle on the battery matches the smaller circle in the case …
1

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 4 of 9 www.sota.com
the larger battery circle matches the larger circle in
the case.
c. Slide the 9-Volt Alkaline battery into the case and
push down. Slide the cover back onto the unit.
2. Clean the ear lobes to eliminate skin oils. This
will allow for better conductivity.
3. Slide the clip on the back of the Bio Tuner into
the holding clip on the Arm Band as in image 2.
4. Insert the cord
into the jack on the unit as shown in image 3. The
indented square on the plug should be facing up.
When the plug is positioned correctly, it will slide in
gently. Do not force.
5.Slide the Arm Band, with the unit and cord, up the
arm to a comfortable position. Tighten the band to
secure in place as in image 4.
Option: If preferred, the unit can be placed in a pocket.
6.Wet the conductive rubber on the Ear Clips with
water.
7.Position one clip on each ear lobe as in
image 5 on page 5. Place closer to the jaw side of the
ear lobe.
8. Turn the unit ON by turning the ON/OFF switch
clockwise.
All the lights will ash once, before starting the unit
in Mode 1. If the lights do not come on, the battery
may not be placed correctly.
9. Gradually turn up the intensity to a comfortable
level. The current may or may not be felt. If felt,
the intensity should be comfortable. See ‘How It
Should Feel’ on page 6.
10.Change modes by pushing the Mode button. The green light indicates which
2
3
4

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 5 of 9 www.sota.com
Mode is selected and that the timing has started. See
Mode information on
page 7.
11.After the 20-minute timed session, the unit will
automatically cycle into Sleep Mode and the green Mode
light will ash every 2 seconds.
12.While in Sleep Mode the battery is still being used.
Either reset to continue or turn the unit OFF.
a. To reset, push the Mode button for another timed
session. Before resetting for a second timed cycle, wet
the Ear Clips again.
b. To turn the unit OFF, rotate the ON/OFF switch
counter clockwise until it clicks. Do not force the ON/
OFF switch past its natural stopping point.
13.Unplug the Cord. Do not store the unit with the
Cord plugged in as this can damage the Cord.
Notes:
Ear Clips: The Ear Clips may feel more
comfortable with the use of either a conductive
gel or aloe vera gel rather than water.
Changing Modes: When the Mode is changed
during a timed session, one of the following will
occur depending on when your unit was made:
1) the timing continues without interruption to
complete a session of approximately 20 minutes
or 2) the timing starts again for a new 20 minute
session.
Output: The yellow light is used to check the output of the unit. During normal
operation, when the unit is turned on and the Ear Clips are positioned correctly,
the light may or may not come on, even when the unit is turned up to maximum
intensity. As long as the current is felt, the unit is operating correctly, regardless
of the yellow light. It is not, however, necessary to operate the unit at a high
intensity.
5
6

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 6 of 9 www.sota.com
Low Battery Warning: The red light comes on when the battery is low. This
means the battery will soon need to be replaced.
Replacement Batteries: When purchasing replacement 9-Volt batteries, take the
Bio Tuner with you to ensure a proper t, as 9-Volt batteries vary in size.
HOW IT SHOULD FEEL
1. The sensation may be a pleasant buzzing or the current may not be felt at all.
It is not necessary to turn the control up to an uncomfortable level. If it feels
prickly or unpleasant, check the following:
a. Wet the conductive rubber of the Ear Clips again.
b. Apply conductive gel or aloe vera gel to the ear lobes.
2. With repeated use, the buzzing sensation may not be felt as much. The intensity
may be turned up if desired.
3. You may feel a sensation on one side more than the other.
TYPICAL USE
Length of session: The Bio Tuner is timed for 20-minutes (+/- 1 minute
depending on the number of Modes chosen during a session).
Research indicates that if used longer than 40 minutes at a time, the benets may
be reduced. The unit can be used for more than one 40-minute session per day by
spacing the sessions throughout the day.
Length of use: The unit should be used daily for at least 4 weeks.
Intensity Level: It is best to start the unit at a lower intensity level for the rst few
sessions. The intensity should always be set to a comfortable level.
With Extended Use: It is recommended to vary the Mode from time to time.
Sensitive skin: During the rst weeks of use, the skin may become irritated. Over
time, irritation usually decreases or disappears. Apply a healing lotion after use if
the ear lobes become red or irritated.
Drink plenty of water: It’s important to drink enough water when using the unit.
Drinking ozonated water is especially helpful.
Stop Gradually: Reduce the amount of time each day for the last week of use.
Maintenance schedule: Ongoing use may be benecial. Suggestions for a
maintenance schedule are a) once or twice weekly, b) one week per month, or c) 4
weeks every six months.

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 7 of 9 www.sota.com
OUTPUT OF SIX MODES
The Bio Tuner provides six different Modes with which to experiment and discover
what feels or works best. Try different Modes to determine which feels most
comfortable. With extended use, it is recommended to vary the Mode from time to
time, as your body can become acclimatized.
One Mode is not considered more benecial than another.
In all Modes, the base frequency of 1,000 Hz pulse-modulated by 111.11 Hz is
present. Modes 4, 5, and 6 may have a more gentle feel.
See Table of Modes below.
BIO TUNER MODES
MODE 1-3 (550US PULSE WIDTH)
Mode 1: 1,000 Hz modulated by 111.11 Hz,
Output = Continuous
Mode 2: 1,000 Hz modulated by 111.11 Hz,
Output = 1 Second ON, 1 Second OFF (0.5 Hz)
Mode 3: 1,000 Hz modulated by 111.11 Hz,
Output = Amplitude Modulated by 7.83 Hz Schumann (Earth) Sine Wave
MODE 4-6 (220US PULSE WIDTH)
Mode 4: 1,000 Hz modulated by 111.11 Hz,
Output = Continuous
Mode 5: 1,000 Hz modulated by 111.11 Hz,
Output = 1 Second ON, 1 Second OFF (0.5 Hz)
Mode 6: 1,000 Hz modulated by 111.11 Hz,
Output = Amplitude Modulated by 7.83 Hz Schumann (Earth) Sine Wave
ELECTRICAL SPECIFICATIONS
POWER REQUIREMENTS
Use a 9–Volt Alkaline battery for proper operation.

Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 8 of 9 www.sota.com
OPTIONAL POWER INPUT
The Bio Tuner can also be operated using rechargeable batteries. When
purchasing rechargeable batteries, it is suggested to take the unit with you to
ensure the batteries will t the enclosure.
OUTPUT SPECIFICATIONS
Maximum <1.5mA Peak ~40 Volts Peak-Peak into typical 4k ohm load. Minimum
<~10uA, 10 Volt Peak-Peak at lowest setting. Output impedance ~20k ohm.
1,000 Hz (+/- 1%) pulse-modulated by 111.11 Hz (+/- 1%). Waveforms are Quartz
Crystal-Controlled for precise frequency output. There are also a broad range of
harmonic frequencies delivered in each pulse as observed on a frequency domain
spectrum analyzer.
Pulses are Bi-Phasic (AC) with no direct current (DC) or offset bias. Output is
transformer coupled so that no DC can appear at electrodes.
TROUBLESHOOTING
If the yellow light does not come on when the rubber electrodes are touched
together and intensity is turned up full, check as follows:
1.Ensure the conductive rubber electrodes are clean:
a. Remove each Ear Clip from the cord.
b. Pull the rubber electrodes out of the Ear Clip and clean with a soft cloth and
toothpick or similar object.
c. Place the rubber electrodes back into Ear Clip.
d.Ensure the pin on the cord is fully inserted into the Ear Clip.
2.Turn the unit ON to maximum intensity and touch the electrodes together. The
yellow light should come on.
If the yellow light still does not come on, the Bio Tuner cord may need replacing.
For further Troubleshooting, visit www.sota.com.
COUNTRIES THAT PARTICIPATE IN MANUFACTURING
The manufacturing of the SOTA Products is a global collaboration. The following
countries have participated in the making of the Bio Tuner (listed in alphabetical
order): Canada, China, Hong Kong, Malaysia, Morocco, Taiwan and Thailand.

Made in China. Designed and Engineered in Canada.
Instructions for the SOTA Bio Tuner, Model BT7 with Ear Clips
• The SOTA units are consumer products designed for relaxation, well-being and to complement a healthy lifestyle • The SOTA units are not
medical devices nor are they intended to diagnose, treat or cure any medical or health condition • The use, safety or effectiveness of the SOTA
units, has not been approved by any government agency • Please consult a health practitioner for any medical or health condition. • Results
using the SOTA Products will vary for each person. • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC,
Canada •
© 2008 SOTA Instruments Inc. Page 9 of 9 www.sota.com
REPLACEMENT ACCESSORIES
To replace your accessories, contact your supplier.
WARRANTY
The Bio Tuner, model BT7 is covered by a three (3) year limited warranty. Please
keep proof of purchase. Warranty is void if the failure is due to abuse or negligence.
SOTA reserves the right to make changes to the Bio Tuner without notication.
REPAIRS
Please contact your supplier for return instructions. Or, for information about your
closest repair depot, contact:
Tel: 1.250.770.2023
Fax: 1.250.770.1999
Other manuals for Bio-Tuner BT7
2
Table of contents
